Used cNC lathes 250-299mm turning diameter for sale (93)

Condition: used, Year of construction: 2005, functionality: fully functional, USED Takisawa Taiwan model EX-308 3-Axis slant bed universal CNC lathe with Fanuc 21i-T control. Year 2005 CF03E30096 Heavy Cast Iron Construction High Performance 4 Track Linear Guideways Bljdpeuwn Dksfx Abbsr Fanuc 21iT CNC Control 12 Station Heavy Duty, High Speed Servo Turret with Driven Tools Built in Oil Cooled Spindle Motor with Full C-Axis Programmable Tailstock Quill 8” 3-Jaw Hollow Spindle Hydraulic Chuck Tooling Package including two driven tool holders Swing Over Bed - 450 mm Distance Between Centres - 645 mm Max. Turning Diameter - 260 mm Max. Turning Length - 530 mm Bar Capacity - 52 mm X Axis Stroke - 180 mm Z Axis Stroke - 530 mm Spindle Speeds - 30 To 4000 RPM Number Of Turret Stations - 12 Number Of Driven Stations - 12 Driven Tool Speeds - 40 To 4000 Rpm Driven Tool Motor - 1.1/3.7 kW Tailstock Travel - 435 mm Tailstock Quill Travel - 100 mm Rapid Traverse Rates (X/Z) - 20/24 M/Min Main Spindle Motor - 11/18 kW Floor Space - 2360 X 1745 mm Machine Weight - 4300 Kgs Electrics - 415 V, 3 Ph, 50 Hz

Condition: used, Year of construction: 2000, turning length: 600 mm, turning diameter: 400 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 31 rpm, travel distance X-axis: 250 mm, travel distance Z-axis: 620 mm, total height: 1,960 mm, total length: 5,000 mm, total width: 2,650 mm, overall weight: 7,000 kg, Equipment: documentation/manual, CNC Lathe with driven tools CNC Control Siemens 840 D Turning diameter 400 mm Turning Length 600 mm Spindle bore diameter 65 mm Spindle speed 31 - 4.000 R/min Spindle motor 30-20.5 kW Movement X-axis 250 mm Movement Z-axis 620 mm Driven tool stations 12 Number of driven tools 12 Tool taper VDI 40 Bedpfsx Ahxwox Abbelr If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: excellent (used), Hardinge HXL-S CNC Lathe Bedpfx Absxrvdgsbelr Fagor Control Year 1998 Manuals Great Condition - Fully Working with no faults. We welcome any inspections

Condition: used, Year of construction: 2006, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Hardinge Lathe Model Talent 10/78 Siemens CNC Year 2006 With Tooling With Documentation Bjdoxzp R Sspfx Abbolr With Chip Conveyor Video Available

Condition: excellent (used), Ecoca SJ-30HT, 3 Jaw Chuck, Tailstock, Toolarm, Year 2007 Control Fanuc 18-T Swing over bed 580 mm Swing over cross slide 434mm Max turning diameter 280mm Max turning length 460mm (centers) Chuck size 254mm (10") Bar passage (bore) 90mm or 75mm (SJ 30G) Bodpfxjwx Hnfs Abbjlr Spindle 3500–4200RPM; 25–30Hp / 11–15kW Spindle nose A2 8 Spindle bore 90mm (through hole) X-axis travel 190mm Z-axis travel 520mm Rapid traverse X/Z 15m/min (X), 20m/min (Z) Tool turret 12 station hydraulic Curvic coupling Quill (tailstock) 90mm dia, taper MT 5, 120mm travel Spindle motor power 25/30Hp (18–22kW) Electrical power 40kVA supply Coolant tank147L Footprint 4460×1920mm Net weight 5000kg

Condition: excellent (used), Year of construction: 1999, very nice teach-in lathe in good condition built in 1999 0-2800 rpm Bodpfotrx Azjx Abbjlr max. turning length 1000 mm t.d.c. max. turning diameter above slide 290 mm max. turning diameter above bed 500 mm spindle motor 15 kw spindle bore 70 mm incl. accessories and documentation machine is connected for inspection.

Condition: used, Year of construction: 2005, functionality: fully functional, USED Takisawa Taiwan model EX-308 3-Axis slant bed universal CNC lathe with Fanuc 21i-T control. Serial number CF02E30091 Year 2005 Bledpst Dzz Ijfx Abbor Heavy Cast Iron Construction High Performance 4 Track Linear Guideways Fanuc 21iT CNC Control 12 Station Heavy Duty, High Speed Servo Turret with Driven Tools Built in Oil Cooled Spindle Motor with Full C-Axis Programmable Tailstock Quill 8” 3-Jaw Hollow Spindle Hydraulic Chuck Tooling Package including two driven tool holders Swing Over Bed - 450 MM Distance Between Centres - 645 MM Max. Turning Diameter - 260 MM Max. Turning Length - 530 MM Bar Capacity - 52 MM X Axis Stroke - 180 MM Z Axis Stroke - 530 MM Spindle Speeds - 30 To 4000 RPM Number Of Turret Stations - 12 Number Of Driven Stations - 12 Driven Tool Speeds - 40 To 4000 RPM Driven Tool Motor - 1.1/3.7 KW Tailstock Travel - 435 MM Tailstock Quill Travel - 100 MM Rapid Traverse Rates (X/Z) - 20/24 M/Min Main Spindle Motor - 11/18 KW Floor Space - 2360 X 1745 MM Machine Weight - 4300 KGS

Condition: used, turning diameter max. 360 mm turning length 505 mm control Mazatrol SmoothC max. swing diameter over bed 660 mm swing diameter over slide guides max 255 mm bar material dia. max. 80 mm turning speed range - spindle 35 - 4000 U/min max. torque on the spindle 358 Nm x-axis 225 mm rapid traverse X-axis 30 m/min z-axis 605 mm rapid traverse Z-axis 33 m/min Bjdpov Dxw Rjfx Abbslr spindle nose A2-8'' spindle bore 91 mm spindle hollow 80 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40%ED) kW tailstock quill taper MT 5 Travel- tailstock 565 mm Axial pressure max 5,0 Nm Tool turret 1 Numbers of tools 12 (angetrieben) turning tool - shaft cross cut 25 x 25 mm tool taper BMT Required air-pressure 5 / 160 bar / l/min voltage 400 V coolant tank 180 l engine output 18,5 (30min Betrieb) kW Rated power (100% continuous operation) 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 3,6 x 2 x 1,8 m Machine incl. the following special accessories: Chip conveyor on the right side Productivity package C - special according to storage machine This package includes: High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min Preparation for chip conveyor (lateral) Automatic tool eye STANDARD ACCESSORIES Transformer for the European market Use of linear systems with guide carriage SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB memory interface (1 slot) Spindle bore 91 mm Set of manuals in electronic form on CD Mazak standard colour CE marking, metric, 50 Hz C-axis input accuracy 0.0001° NC controlled tailstock Tailstock pressure adjustment Tailstock with fixed quill MK5 SAFETY DEVICES Operator door with interlock switch Double foot switch Hydraulic pressure lock Fully enclosed work area Work area lighting Safety precautions according to global standard COOLANT SUPPLY Grundfos coolant pump type MTA (0.25kW / 7.6L/min) Complete coolant system Automatic switch-off via circuit breaker triggering MESSSYSTEM Absolute positioning system NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothC 10.4’ colour screen User macro (600 variables) EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN Various tool holders - All dimensions, weights and performance data are non-binding - Used machine without warranty -

Condition: good (used), Year of construction: 1999, Machine is in very good working condition. Bodpfx Abox Awnusbslr

Condition: like new (used), Year of construction: 2018, operating hours: 598 h, functionality: fully functional, The HARDINGE GS42 is a CNC lathe designed for precision turning of hardened surfaces. Reason for sale: Order was lost before full production commenced. ONLY 598 operating hours Control: FANUC Oi-TF Max. turning diameter: 284 mm Max. swing diameter: 457 mm Max. spindle speed: 6,000 rpm Spindle bore: 42 mm Bljdpfxoxx Rgis Abber Turret with 12 stations (VDI 30) (non-driven) PERFORMANCE PLUS package - Linear glass scales for X and Z axes - Spindle chiller - Heat exchanger for motor and spindle. High-pressure coolant system, cooling through turret (20 bar) Live high-performance tailstock VOP40P complete system (precision measuring probe)

Condition: used, functionality: fully functional, Swing diameter over bed: Ø 450 mm Swing diameter over carriage: Ø 280 mm Max. swing diameter: Ø 280 mm Turning length: 450 mm Distance between centers: 450 mm Speed range: stepless variable, approx. 50 – 5000 rpm Bodpfx Aoxg Itvjbbolr Turret: 1x 8 tool positions 1x 12 tool positions Tool system: VDI-30 Travels: X-axis travel: 120 + 25 mm Z-axis travel: 450 mm Rapid traverse: 12 m/min Motors & Electrical: Spindle motor: approx. 5.5 / 7.5 kW (continuous / 30 min) Total connected load: 29 kVA Power supply: 380V, 3-phase, 50 Hz Full load current: 44 A Weight & Dimensions: Machine weight: approx. 4,800 kg Dimensions (L×W×H): 2,985 × 1,720 × 1,850 mm

Condition: used, Year of construction: 2018, Lathes Travel distance X: 221 mm Travel distance Y :100 mm Travel distance Z: 400 mm Bledpfsw Ekimex Abbor turning length: 380 mm max. circulation diameter: 280 mm spindle boring: 65 mm input Power: 11 kW max. turning moment: 80 NM range of revolution from: 100 rpm range of revolutions till: 4500 rpm Control: Fanuc 0i-TF Powered tools: 12 working hours approx: 813 h control Fanuc Scrapper chip conveyor

Condition: used, Year of construction: 2005, functionality: fully functional, USED Takisawa Taiwan model EX-308 3-Axis slant bed universal CNC lathe with Fanuc 21i-T control. Serial number CF02E30091 Year 2005 Heavy Cast Iron Construction High Performance 4 Track Linear Guideways Fanuc 21iT CNC Control 12 Station Heavy Duty, High Speed Servo Turret with Driven Tools Built in Oil Cooled Spindle Motor with Full C-Axis Programmable Tailstock Quill 8” 3-Jaw Hollow Spindle Hydraulic Chuck Tooling Package including two driven tool holders Swing Over Bed - 450 MM Distance Between Centres - 645 MM Bjdsuwdg Uepfx Abbjlr Max. Turning Diameter - 260 MM Max. Turning Length - 530 MM Bar Capacity - 52 MM X Axis Stroke - 180 MM Z Axis Stroke - 530 MM Spindle Speeds - 30 To 4000 RPM Number Of Turret Stations - 12 Number Of Driven Stations - 12 Driven Tool Speeds - 40 To 4000 RPM Driven Tool Motor - 1.1/3.7 KW Tailstock Travel - 435 MM Tailstock Quill Travel - 100 MM Rapid Traverse Rates (X/Z) - 20/24 M/Min Main Spindle Motor - 11/18 KW Floor Space - 2360 X 1745 MM Machine Weight - 4300 KGS

Condition: excellent (used), Year of construction: 1997, Control Fanuc Series 20-T Turning diameter 330 mm Bar diameter 42 mm Turning length 650 mm Speed 5,000 min-1 8-position turret Minimum quantity lubrication Bjdpfx Aowh U Dtebbelr

Condition: used, Year of construction: 2006, total height: 1,750 mm, total length: 2,790 mm, total width: 1,570 mm, Empty weight: 4.300 kg Price: On request Bedpfx Abswfpaqobolr - Year: 2006 - Documentation available: Yes - CE certificate present: No - Serial number: GN08201038G - Drive system: CNC - Power [kW]: 15.0 - Swing over bed [mm]: 250 - Distance between centres [mm]: 460 - Spindle bore [mm]: 62 - Max. spindle speed [rpm]: 4500 - Options: Removable bed - Swing over removable bed [mm]: 460 - Transport dimensions: 2790mm x 1570mm x 1750mm (l x w x h) - Transport weight [kg]: 4300kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Year of construction: 1999, turning diameter 270 mm turning length 630 mm control SIN840D longitudinal slide -travel 745 mm cross slide - travel 200 mm spindle head DIN 55026 - Size 6 spindle bore 62 mm chucking diameter max. 315 mm rapid traverse X-axis 12 m/min rapid traverse Z-axis 20 m/min tailstock travel 112 mm tool turret - number of stations 12 workpiece weight max. 30 kg turning speed range 10 - 4000 U/min weight of the machine ca. 3 t dimensions of the machine ca. 2,75 x 2,75 x 2,10 m With SIEMENS SINUMERIK 840D control system, turret with driven tools, tailstock, chip conveyor, various tool holders. Bljdpfx Aex Avp Rsbbjr

Condition: new, Year of construction: 2026, functionality: fully functional, turning diameter over cross slide: 380 mm, turning length: 5,000 mm, turning diameter: 590 mm, spindle bore: 72 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 25 rpm, spindle motor power: 11 W, rapid traverse X-axis: 8 m/min, CNC lathe TUS 580 C New CNC-controlled machine with flat bed and Siemens Sinumerik 828D BASIC ShopTurn . Delivery date: approx. 4 months after technical and commercial agreement. Center height [mm]: 290 Swing diameter over bed [mm]: 590 Swing diameter over bed slide [mm]: 380 Center width [mm]: 1000/1500/2000/3000/4000/5000 Max. Machining length [mm]: 1250/1750/2750/3750/4750/5750 Spindle bore [mm]: 72 Spindle mount [DIN]: 55027/8 Taper in the main spindle [MK]: 8 Max. Workpiece weight: - Clamping between centers [kg]: 400 - In chuck and live center in tailstock [kg]: 600 - In chuck and steady rest [kg]: 800 - In chuck, steady rest and live center [kg]: 1300 - Flying (Lmax = 250 mm) [kg]: 150 Bed width [mm]: 400 Turning tool cross-section (HxW) [mm]: 32 x 32 Multifix system steel holder [size]: C Speeds: Total speed range [rpm]: 25 to 2000 Number of stages: 3 Gear stage I [rpm]: 25 - 100 Gear stage II [rpm]: 100 - 400 Gear stage III [rpm]: 500 - 2000 Max. Torque (spindle) [Nm]: 1200 - Gear stage I [Nm]: 1200 - Gear stage II [Nm]: 300 - Gear stage III [Nm]: 60 Travel range: Longitudinal adjustment - X axis [mm]: 290 Longitudinal adjustment - Z axis [mm]: 1000/1500/2000/3000/4000/5000 Feed range: Feed range in X/Z-axis [mm/min]: 1 - 3000 Rapid traverse speed X-axis [mm/min]: 8000 Rapid traverse speed Z-axis [mm/min]: 8000 Torque of the axis drives: X-axis [Nm]: 11 Z-axis [Nm]: 16 Feed influence [%]: 0 - 120 Tailstock: Quill diameter [mm]: 90 Quill stroke [mm]: 230 Quill taper [MK]: 5 Drives: Main motor power [kW]: 11 Bledpjufgg Djfx Abbsr Cooling pump motor output [kW]: 0.09 Total output [kVA]: 15 Space requirement/weight: Length of the machine with 1000 mm center distance [mm]: 3150 Length of the machine with 1500 mm center distance [mm]: 3650 Length of the machine with 2000 mm center distance [mm]: 4150 Length of the machine with 3000 mm center distance [mm]: 4650 Length of the machine with 4000 mm center distance [mm]: 5250 Length of the machine with 5000 mm center distance [mm]: 5750 Width of the machine, depending on the equipment [mm]: 2000 Height of the machine, depending on the equipment [mm]: 2000 Machine weight at 2000 mm center distance [kg]: 3800 Additional weight for a further 1000 mm center distance [kg]: approx. 500 Standard accessories: - Electrical equipment for three-phase current 400 V / 50Hz according to VDE 0113 - Siemens SINUMERIK 828D BASIC ShopTurn - Frequency controller for main drive - SIEMENS - Illumination lamp - Quick-change steel holder head size C - Coolant system with electric pump - Locked chuck protection hood - Rear chip guard - Chip guard at the front of the top support - Operating instructions, test report - CE and declaration of conformity - Machine color (similar to RAL 7035 RAL 7011) Options: - Fixed setting vice - Three- and four-jaw chuck - Face plate - Chuck flange - Hydraulic tailstock quill - Power chuck - Turret head with turret disk - Drill stand with boring bar - And much more

Condition: good (used), Year of construction: 2014, operating hours: 9,554 h, functionality: fully functional, machine/vehicle number: SL8-1620455DJAAH, turning diameter over cross slide: 300 mm, turning diameter: 256 mm, spindle speed (max.): 4,800 rpm, travel distance X-axis: 198 mm, travel distance Z-axis: 508 mm, rotational speed (max.): 5,000 rpm, total height: 1,900 mm, total length: 6,000 mm, total width: 2,200 mm, feed rate X-axis: 19 m/min, feed rate Z-axis: 24 m/min, overall weight: 5,500 kg, bar passage: 50 mm, bar diameter (max.): 32 mm, controller manufacturer: HURCO, controller model: MAX, positioning accuracy: 0.01 mm, repeat accuracy: 0.005 mm, operating hours of spindle: 2,027 h, HURCO TMM8i CNC Lathe - Operating voltage: 400 V - Frequency: 50 Hz - Rated current: 40 A - Connection: 28 kW - Max. swing diameter: 525 mm - Max. diameter over cross slide: 300 mm - Chuck diameter: 200 mm - Acceleration: 0 - 3000 rpm - Turret type: VDI 30 - With a total of 12 stations - Max. spindle speed: 5000 rpm - Indexing time: 0.23 sec - Max. boring bar diameter: 32 mm - Tool shank cross-section: 19 mm - Including powered tool stations The machine is equipped with a bar feeder from BREUNING, type: ILS MUK 7012-III, year of manufacture: 2017. Also included are a chip conveyor, tailstock, and a three-jaw chuck with a diameter of 200 mm. Bedpfx Aboxw Sr Debolr Attention: The item must be collected firmly and bindingly between 19.01.2026 and 23.01.2026 on a date to be agreed. FCA D-76571 Gaggenau – loaded on truck.

Condition: used, Year of construction: 2005, functionality: fully functional, USED Takisawa Taiwan model EX-308 3-Axis slant bed universal CNC lathe with Fanuc 21i-T control. Bljdjt N Sitopfx Abber Year 2005 CF03E30096 Heavy Cast Iron Construction High Performance 4 Track Linear Guideways Fanuc 21iT CNC Control 12 Station Heavy Duty, High Speed Servo Turret with Driven Tools Built in Oil Cooled Spindle Motor with Full C-Axis Programmable Tailstock Quill 8” 3-Jaw Hollow Spindle Hydraulic Chuck Tooling Package including two driven tool holders Swing Over Bed - 450 mm Distance Between Centres - 645 mm Max. Turning Diameter - 260 mm Max. Turning Length - 530 mm Bar Capacity - 52 mm X Axis Stroke - 180 mm Z Axis Stroke - 530 mm Spindle Speeds - 30 To 4000 RPM Number Of Turret Stations - 12 Number Of Driven Stations - 12 Driven Tool Speeds - 40 To 4000 Rpm Driven Tool Motor - 1.1/3.7 kW Tailstock Travel - 435 mm Tailstock Quill Travel - 100 mm Rapid Traverse Rates (X/Z) - 20/24 M/Min Main Spindle Motor - 11/18 kW Floor Space - 2360 X 1745 mm Machine Weight - 4300 Kgs Electrics - 415 V, 3 Ph, 50 Hz

Condition: excellent (used), Year of construction: 2003, Siemens 840D control system Bedpfx Abswv Hq Isbjlr Turning diameter 254 mm Turning length 500 mm Chuck diameter 210 mm Turning length 410 mm Spindle speed 4,500 rpm 8-position turret Chip conveyor

Condition: used, Year of construction: 2011, controller manufacturer: Fanuc, controller model: 31i-Model A, _____ Description: Year of manuf. : 2011 Control : Fanuc 31i-Model A Turning diam. : 255 mm Turning length : 640 mm In General: Year of manufacture:2011 Control system:Fanuc 31i Model A Turning diameter:255 mm Turning length:approx. 640 mm Bar capacity:52 mm Main spindle: Technology:Belt spindle Speed:5,000 rpm Power:15 kW Torque:115 Nm C-axis:0.001° Bar capacity:52 mm Chuck:Hainbuch Spanntop Sub spindle: Technology:Belt spindle Speed:5,000 rpm Bodpfxexy Ubyo Abbslr Power:7.5 kW Torque:86 Nm C-axis:0.001° Bar capacity:52 mm Chuck:Hainbuch Spanntop Tool carrier I (X/Y/Z): Technology:Tool turret Number of stations:12 Tool holder:BMT Tool drive:6,000 rpm, 52 Nm X-axis:190 mm Y-axis:80 (+/- 40) mm Z-axis:300 mm Tool carrier II (X/Y/Z): Technology:Tool turret Number of stations:12 Tool holder:BMT Tool drive:6,000 rpm, 52 Nm X-axis:190 mm Y-axis:80 (+/- 40) mm Z-axis:635 mm Tool carrier III (X/Y/Z): Technology:Tool turret Number of stations:12 Tool holder:BMT Tool drive:6,000 rpm, 52 Nm X-axis:190 mm Y-axis:80 (+/- 40) mm Z-axis:500 mm Equipment: Chip disposal:Chip conveyor Coolant supply:Internal coolant unit Bar feeder:Irco Breuning SiMag 70.1 - 3000 Parts removal:Parts gripper + cycle belt Set-up operation:Electronic handwheel Chuck:2x Hainbuch Spanntop Tool holders:Various driven + static holders

Condition: used, Year of construction: 2014, Very good condition! Available immediately! Bledpjxca U Defx Abber Control: Fanuc Oi - TD Travel: X-195 mm, Z-660 mm programmable tailstock: via M function turning diameter: 254 mm tool turret: 12x coolant tank : 180L, 6 bar pump pressure electric handwheel: ,

Condition: used, Year of construction: 2005, Technical details: turning diameter: 275 mm turning length: 900 mm spindle passage: 65 mm power capacity at 100 % load: 25/20 kW spindle turning speed range: 1 - 5000 U/min spindle diameter in front bearing: 110 mm c-axis: 1 - 500 U/min. number of workpiece supports: 4 tool turret: 1 x-axis: 290 mm y-axis: 165 mm z-axis: 360 mm b-axis: 360 ° rapid speed: 18/30 m/min number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8000 / 2000 U/min power capacity: 25% ED 5,8 kW tool taper: TRAUB 60 tool turret: 2/3/4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid speed: 18/15/30 m/min number of driven tools: 10 mm Blodpfx Abjwp D Nbebsr toolpiece turning speed range: 1 - 6000 U/min power capacity: 25% ED 5,8 kW tool taper: DIN 69880 40 x 63 total power requirement: 95 kW weight of the machine ca.: 16 t dimensions of the machine ca.: 10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and Sub spindle with C-axis 1 support with B-axis 3 turret supports dust exhauster, coolant attachment with coalescence-seperator and chip conveyor 2 pc. 3-jaw chuck SMW KNCS-N 170-43 2 pc. HAINBUCH Spanntop chuck 40 pc. various tool holder non-driven 6 pc various tool holder driven Spare parts package *

Condition: new, Year of construction: 2025, Horizontal CNC Lathe HTC200 II x 560 C2023030141 Working Area: Max. swing diameter over bed: Ø620 mm Max. swing diameter over carriage: Ø410 mm Max. turning diameter: Ø400 mm Max. turning length: 560 mm Spindle center height: 1035 mm X-axis travel: 215 mm Z-axis travel: 615 mm Bodpfxew Rpche Abbjlr Motorized High-Speed Spindle Max. spindle speed: 4,500 rpm Spindle power (continuous/30 min overload): 11/15 kW Spindle torque: 158/211 Nm Spindle nose taper: DIN55026 A2 6 Spindle bore: Ø66 mm Spindle bearing diameter: Ø100 mm Chuck size: 8 inches Turret Turret type: Servo V12 OD tool size: 25x25 mm ID tool size: Ø40 mm Indexing time (tool to tool): 0.2 s Tailstock: Tailstock type: Hydraulic Quill diameter: Ø100 mm Quill taper: MT No.5 Quill stroke: 122 mm Tailstock travel: 550 mm Feed Shaft X/Z-axis travel: 215/615 mm Rapid traverse X/Z-axis: 24/30 m/min Type of guideway: Linear guideway X/Z-axis drive power: 1.8/1.8 kW Control System: FANUC 0i-TF Power supply: 35 kVA Coolant capacity: 240 l Machine weight: 4.8 t Machine dimensions (LxWxH, without chip conveyor): 3097x1855x1755 mm Components Control: FANUC X/Z-axis ball screw: PMI (TW) Spindle bearings: NTN/NSK (JP) Spindle ball bearings: FAG (GE) Chuck and cylinder: STRONG (TW) Servo turret: HISION (CN) Main components of pump and valves: NACHI (JP) Main lubrication system components: LIUBIAN (CN) Main electronic components: Schneider

Condition: new, Year of construction: 2025, Horizontal CNC Turning Machine HTC200 II x 560 C2023030332 Working Area: Max. swing over bed: Ø620 mm Max. swing over carriage: Ø410 mm Blodpfx Abjw Rpa Tober Max. turning diameter: Ø400 mm Max. turning length: 560 mm Spindle center height: 1035 mm X-axis travel: 215 mm Z-axis travel: 615 mm Motorized High-Speed Spindle Max. spindle speed: 4,500 rpm Spindle power (continuous/30 min. overload): 11/15 kW Spindle torque: 157/211 Nm Spindle nose taper: DIN55026 A2 6 Spindle bore: Ø66 mm Spindle bearing diameter: Ø100 mm Chuck size: 8 inch Turret Turret type: Servo V12 OD tool size: 25x25 mm ID tool size: Ø40 mm Indexing time (tool-to-tool): 0.2 s Tailstock Tailstock type: Hydraulic Quill diameter: Ø100 mm Center type: MT 04 Quill stroke: 122 mm Tailstock travel: 550 mm Feed Shaft X/Z axis travel: 215/615 mm Rapid traverse X/Z axis: 24/30 m/min Guideway type: Linear guideways X/Z axis drive power: 1.8/1.8 kW Control System: FANUC 0i-TF Power supply: 35 kVA Coolant tank capacity: 240 l Machine weight: 4.8 t Machine dimensions (LxWxH, without chip conveyor): 3,097 x 1,855 x 1,755 mm Components Control system: FANUC X/Z-axis ball screws: PMI (TW) Spindle bearings: NTN/NSK (JP) Spindle angular contact bearings: FAG (GE) Chuck and cylinder: STRONG (TW) Servo turret: HISION (CN) Main hydraulic pump and valves: NACHI (JP) Primary lubrication system components: LIUBIAN (CN) Main electronic components: Schneider
