Used Trumpf 3D Printer for sale (412)

Condition: excellent (used), functionality: fully functional, We offer a highly productive 3D printer for industrial series production. The system was finally used with AISi10MG aluminum powder. The 3D printer has already been disassembled by the manufacturer. Disassembly and functional reports are available, proving that the machine was in operation prior to disassembly. All axes are properly secured. The machine can be transported on a standard truck. TruPrint 5000 G4 Serial number S0731C0008 Year of manufacture 08/2018 Laser runtime Laser 1 beam on: 5165 hours Laser 2 beam on: 5096 hours Laser 3 beam on: 5023 hours Trumpf TruPrint 5000 with the Powder Bed Monitoring and Melt Poll Monitoring options, including a filter system. Accessories: 2x build cylinders 3x Dosing cylinder 1 used overflow tank 1 new overflow tank Manuals 4 new heat exchangers 2 new Easy Filters 3 new NTRON SIL02 Oxygen Analyzers + Sensors 1 new oxygen sensor and much more, such as seals, etc. The Armanni CAR.Elev. pallet truck for changing the tanks is also in stock and can be offered as an option. Get high-quality 3D components faster The highly productive, semi-automated TruPrint 5000 3D printing system prepares you for industrial series production. With features such as an optional 500°C preheater and full-field multi-laser configuration with three 500-watt TRUMPF fiber lasers, you are ideally equipped for the most demanding industrial applications. The machine produces high-quality components from a variety of metallic materials quickly and reliably, meeting the high quality standards in tool and mold making, including 3D printing on preform blanks, in the aerospace and medical technology industries. Optionally, the entire process chain can take place in a protective gas atmosphere: screening, printing, cooling, and depowdering. Combined with external parts and powder management and monitoring solutions from TRUMPF, it is ideal for industrial additive series production. Thanks to the Preform option, the TruPrint 5000 supports hybrid component production. The component structures to be additively manufactured are applied to a blank. This innovative option is particularly well-suited for easy handling in tool and mold making. TruPrint 5000 Build volume (cylinder) mm x mm Ø 300 x H 400 Ø 290 x H 390 Nodpfx Adjvu Syys Ejcn (Reduction if preheating >200 °C) Processable materials[1] Weldable metals in powder form, such as: stainless steels, tool steels, aluminum, nickel-based, or titanium alloys Build-up rate[2] cm³/h 5 - 180 Layer thickness[3] μm 30 - 150 Max. laser power at the workpiece (TRUMPF fiber laser) W 3 x 500 Beam diameter[3] μm 100 - 500 Min. measurable oxygen content ppm Up to

Condition: excellent (used), functionality: fully functional, We offer a highly productive 3D printer for industrial series production. Trumpf TruPrint 3000 G02 with the options Zirox Sensor, Single Laser, and Powder Bed Monitoring. Trumpf TruPrint 3000 including filter system. Serial number: S0721Q0022 Laser performance: Laser beam on 17,508 hours. The system was finally used with aluminum AlSi10MG. The 3D printer has already been disassembled by the manufacturer. Disassembly and functional reports are available, proving that the machine was in operation before disassembly. All axes are properly secured. The machine can be transported on a standard truck. Accessories: 4 dosing containers 1 construction cylinder 1 overflow container Various spare parts such as protective glass, etc. Manuals The Armanni CAR.Elev pallet truck. A container changer is also in stock and can be offered as an option. Fast to high-quality 3D components D1. Machine concept The TruPrint 3000 is a universal medium-format machine with external parts and powder management for the industrial production of complex metal components using 3D printing. Its large build volume offers high flexibility in terms of the size, quantity, and geometry of the respective application. Technical specifications TruPrint 3000 Build volume (cylinder) mm x mm Ø 300 x H 400 Processable materials5 - Weldable metals in powder form, such as: stainless steels, tool steels, aluminum, nickel-based, cobalt-chromium, copper, titanium, or precious metal alloys. Build rate 6 cm3/h 5 - 60 Layer thickness 7 μm 20 - 150 Laser source (TRUMPF fiber laser) W 500 Nodpfevu Ticex Ad Escn Beam diameter μm 100 - 500 O2 concentration ppm 100 Exposure speed (powder bed) m/s 3 Monitoring - Condition monitoring, performance monitoring. Option: Powder bed monitoring. Preheating (substrate plate) °C 200 Shielding gas - Nitrogen, argon Power supply V / A / Hz 400 - 32 - 50/60 Dimensions (incl. filter) mm 3385 x 1435 x 2225 Weight (incl. filter) kg 4300 Subject to change. The information in our offer and order confirmation is authoritative. Technical data TruPrint 3000 Table 3

Condition: new, Year of construction: 2022, PFO 3D-2 HAL Highest productivity - Highly dynamic and highly accurate 3D scanner with lightweight mirrors, with which applications up to 8000 W can be realized - Incl. documentation, transport packaging and spare parts catalog Numerous interfaces - For robot communication in "on-the-fly" operation Sensor recording for quality monitoring - Process monitoring (e.g. connection of photodiodes, camera or pyrometer) is possible on the PFO TruControl 1000 control system incl. PFO software - Optimum synchronization between laser and processing optics - For simple control and operation of the laser device and the PFO either via a control panel or an external PC - 24x digital I/O interface, expandable with fieldbus interfaces such as ProfiBus, DeviceNet and many more - Storage option for 199 laser programs Maximum process reliability Nedpfx Ajtt Eb Djd Escn - Integrated crossjet for maximum protective glass service life - Highest repeatability of process results thanks to minimization of the metal vapour effect (MDE) by special nozzle Vision Line Basic - Digital camera image with crosshairs in the laser focus for observation of the workpiece and teaching - With scanner optics, the effect of chromatic aberration is minimized aberration is corrected for all positions in the processing field - Integrated algorithm for simple calibration - Convenient touchscreen operation - Still image / live image - Saving of images TruTops PFO - Offline software for 3D programming - Network connection to TruControl - Enables the programming of different wobble methods wobble methods

Condition: ready for operation (used), Trumpf 19-01-11-11 Laser Module for Trumpf Laser HL1003D 11 with 11 and 11, used, in good condition, 100% functional, delivery contents as per photos. Ncsdpfx Aex Eu Utsd Esn

Condition: ready for operation (used), Trumpf 19-01-11-11 Laser Module for Trumpf Laser HL1003D 11 with 11 and 11, used, in good condition, 100% functional, delivery contents as per photos. Njdpex Dxqyefx Ad Eocn

Condition: ready for operation (used), Trumpf 19-01-11-11 laser module from Trumpf Laser HL1003D 11 with 11 and 11, used, in good condition, 100% functional, delivery as per photos. Ncodpfx Adex Dxqte Eon

Condition: used, functionality: fully functional, Year of construction: 2004, degree of automation: manual, actuation type: electric, Equipment: fume extraction, Trumpf HL 1003D laser unit Ncedswxq H Eepfx Ad Een Beam quality of 12 mm mrad and a laser power of 1000W at the workpiece. 2 optics with cameras.

Condition: excellent (used), functionality: fully functional, Year of construction: 2000, control type: CNC control, controller manufacturer: Delem, bending force (max.): 50 t, working width: 1,280 mm, stroke length: 215 mm, number of axes: 4, Equipment: CE marking, foot remote control, Used Trumpf Trumabend V 50 Hydraulic cnc 50ton x 1.2metre Press Brake For Sale Brand: Trumpf Njdpfx Adox Nip He Ejcn Type/Model: Trumabend V50 Year:2000 Trumabend V 50 Technical details Capacity: 50ton x 1.2metre: Full bed length: 1280 mm CNC Brand: Delem Total axis: 4 Y1, Y2, X and R Axis

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, control type: CNC control, laser type: fiber laser, laser power: 10,000 W, table length: 4,000 mm, table width: 2,000 mm, working length: 4,000 mm, working width: 2,000 mm, Equipment: CE marking, dust extraction, emergency stop, fume extraction, safety light barrier, Used Trumpf10kw 5040 4metre x 2metre Trumpf fiber laser for sale Year 2019 Complete with active cut control option Ncjdpfxjylax No Ad Esn Selling without automation 10kw / 10,000 w 4metre x 2metre cutting bed

Condition: like new (used), Year of construction: 2022, functionality: fully functional, punching force: 18 t, working range: 2,500 mm, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, Used Trumpf TruPunch 3000 S20 with Sheet Master Compact sheet load and unload for sale Technical data TruPunch 3000 medium format (S20) Dimensions, weights Width 6282 mm Depth 6548 mm Height 2195 mm Weight with all units 10700 kg Control, hardware, electrics Hard disk type SSD Number and size of the hard disc 2 GB x 120 GB Hard disk memory for customer programmes 10 GB Screen Touch screen Screen size 21.5 in Interface USB Network connection RJ45 Control type Bosch CML75 Operating system Windows 10 IoT Axis data X/Y/C axis drive NC-controlled, maintenance-free three-phase current servo motors Punching head drive Electric drive Maximum axis speeds - X axis 90 m/min Maximum axis speeds - Y axis 60 m/min Maximum axis speeds - Simultaneous 108 m/min Maximum axis speeds - C axis (punching) 350 rpm Maximum axis speeds - C axis (tapping) 350 rpm Maximum punching stroke rate (E = 1 mm) 800 1/min Maximum marking stroke rate 1000 1/min Precision - Positioning deviation Pa +/- 0.1 mm Precision - Position range Ps +/- 0.03 mm Precision - Smallest programmable increment 0.001 mm Working range and workpiece size Maximum sheet thickness 6.4 mm Maximum workpiece weight 150 kg Working range - X axis 2500 mm Working range - Y axis 1250 mm Punch-specific data Maximum punching force 180 kN Maximum presser foot force 20 kN Maximum tool size, punching (outer circle) 76.2 mm Maximum tool size, forming (outer circle) 101.6 mm Single tool changing time 2.8 s MultiTool changing time 0.5 s Number of linear magazine stations 20 pieces Number of tools when using MultiTool / clamps 18 pieces - 180 pieces Loading / part removal Maximum part size, part removal flap, punching 400 mm x 600 mm Flap size (X x Y) 400 mm x 1250 mm Maximum part size, fixed chute, punching 180 mm x 180 mm Connected loads, ambient temperature Pressure range, compressed air connection minimum (same direction) / maximum (static) 7 bar / 14 bar Painting Main colour white, NCS S 0505-R80B Secondary colour blue, RAL DESIGN 250 20 20 Switch cabinet/periphery grey, RAL 7040 SheetMaster Compact 2500 x 1250 mm (AK05) General Maximum Y1 axis traverse speed (suction frame) 27 m/min Maximum Y2 axis traverse speed (unloading cart) 18 m/min Maximum Z axis traverse speed 20 m/min Nodpfx Ajykt N Sed Eecn Y/Z axis drive Asynchronous motors controlled by frequency converter Loading Maximum sheet size 2500 mm x 1250 mm Minimum sheet size 1000 mm x 1000 mm Minimum sheet thickness 1 mm Maximum sheet thickness 6.4 mm Maximum sheet weight 160 kg Unloading Minimum sheet thickness 1 mm Maximum sheet thickness 6.4 mm Maximum sheet weight 160 kg Maximum stack height 190 mm Painting Main colour white, NCS S 0505-R80B Secondary colour blue, RAL DESIGN 250 20 20

Condition: good (used), Year of construction: 2003, Trumpf Trumatic L3020 Co2 Laser Fully working condition - removed from working factory Working Range X axis - 3000mm Y axis - 1500mm Z axis - 115mm Overshoot range X axis - -16- +88 Y axis - 19 - +61 Z axis - - 2 - +16 Max Travel range X axis - 3104mm Y axis 1580mm Z axis - 117m Control - Trumpf CNC Control based on siemens sinumerik 840D Electrical Connections with TLF 3200 - 73 kVa Fuses (at 400v) - 125A Speed - Max. positioning speed, Parallel to axis - 60m/min Ncjdpfxet H Iv Ro Ad Een Simultaneous - 85m/min Accuracy - smallest programmable increment. Positioning accuracy - +0.1mm Repeatability - +0.03mm Max laser power in cw mode with TLF3200 - 3200W Max material thickness - 20mm

Condition: ready for operation (used), Year of construction: 2004, laser power: 6,000 W, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 115 mm, number of axes: 3, This 3-axis TRUMPF Trumatic L3050 was manufactured in 2004. It features a working range of 3,000 x 1,500 x 115 mm and a maximum workpiece weight of 900 kg. The machine is equipped with a powerful 6 kW CO2 laser, capable of cutting through materials up to 25 mm thick for iron and stainless steel, and 15 mm for aluminum. If you are looking to get high-quality laser cutting capabilities, consider the TRUMPF Trumatic L3050 machine we have for sale. Contact us for further details. • Max. workpiece weight: 900 kg • Positioning speed (X/Y): 200 m/min • Simultaneous positioning speed (X+Y): 300 m/min • Maximum iron thickness: 25 mm • Maximum stainless steel thickness: 25 mm • Maximum aluminum thickness: 15 mm Additional equipment Nodpfoym A Hrox Ad Eecn • TRUMPF LiftMaster loading and unloading unit (currently not installed)

Condition: ready for operation (used), Year of construction: 1991, punching force: 15 t, overall weight: 4,300 kg, product length (max.): 3,800 mm, CNC punching machine manufactured in 1991. This TRUMPF TRUMATIC 120R features a punching force of 15 tons and a maximum punching diameter of 38 mm. It offers a working area of 1000 x 2000 mm with repositioning and includes a complete set of tools. If you are looking to get high-quality punching capabilities, consider the TRUMPF TRUMATIC 120R machine we have for sale. Contact us for further details regarding this machine. • Maximum sheet thickness: 4 mm Ncodpsymz Rcjfx Ad Esn • Maximum punching diameter: 38 mm • Working area without repositioning: 1000 x 1000 mm • Working area with one repositioning: 1000 x 2000 mm • X/Y axis speed: not specified • Rotation speed: 360 degrees per second (full rotation) • Maximum stroke rate: 340 strokes per minute • Control system: TRUMAGRAPH CC 200 • Automatic tool change: 9 tool stations • Power requirement: 15 kVA / 50 Hz • Documentation: Complete documentation included, together with machine history Additional equipment • Large set of tools • Two additional tables to extend the working area

Condition: used, Year of construction: 2009, sheet width 3050 mm plate thickness 6 mm rear stop 10-1000 mm cutting angle 0,5 - 2,5 ° down holder 20 Stk no. of strokes 14 - 23 Hub/min work height max. 900 mm oil volume 140 l total power requirement 11 kW dimensions of the machine ca. 4000 x 2150 x 1900 mm weight 7800 kg Equipment: - ELGO control unit type P50 - Automatic cutting angle adjustment Ncodsyk Dhxjpfx Ad Ejn - Automatic cutting gap adjustment - electric back gauge - Pneumatic sheet holding device - Light barrier behind the machine - 4 support arms - front finger guard - foot switch - Angle stop Operating instructions

Condition: ready for operation (used), controller manufacturer: Siemens Sinumerik 840D, laser power: 2,400 W, travel distance X-axis: 3,050 mm, travel distance Y-axis: 1,750 mm, total length: 8,400 mm, total width: 7,800 mm, empty load weight: 22,500 kg, De machine is nog steeds functioneel en in gebruik. Uitgerust met: - 3 plaatklemmen - Sheetmaster-lossysteem - GripMaster Workpiece dimensions: 3085 x 1650 mm Type of Laser: Trumpf TLF Njdpfx Adoygyvqe Eocn Max cuttingthickness in steel: 8 mm Loading System: yes, SheetMaster

Condition: good (used), functionality: fully functional, Year of construction: 2000, CNC press brake, 6 axes - Pressing force: 1,300 kN - Bending length: 3,060 mm - Number of axes: 6 programmable (X1, X2, R1, R2, Z1, Z2) - Y-axis rapid traverse: 200 mm/s - Y-axis working speed: 11 mm/s - Y-axis return: 135 mm/s - Travel speeds: X - 500 mm/s, R - 300 mm/s, Z - 1,000 mm/s - X-axis travel: 600 mm - Max. back gauge range X: 860 mm - R-axis travel: 250 mm - Y-axis stroke: 365 mm - Installation height: 535 mm - Y-axis tilt: ±10 mm - Bending length: 3,060 mm - Clear distance between uprights: 2,690 mm - Throat depth: 410 mm - Table width: 120 mm Nsdpfxsx S H Uxe Ad Eecn - Working height: 1,050 mm - Oil capacity: 250 l Dimensions: Width: 3,640 mm, Depth: 2,210 mm, Height: 2,885 mm Weight: 12,950 kg The machine can be inspected under power!

Condition: excellent (used), Year of construction: 2010, Tekol / Trumpf Laser Welding System Tekol LAP S4 with TRUMPF TruPulse 44 and TBH GL230 Extraction Unit Description: For sale is a professional laser welding system Tekol LAP S4 equipped with an integrated TRUMPF TruPulse 44 pulsed Nd:YAG laser and TBH GL 230 extraction and filter unit. This system is an enclosed precision laser welding station designed for fine, pinpoint, and low-distortion welding of metal components. The pulsed laser enables highly controlled heat input, clean weld spots, and reproducible results. Ideal for precision engineering, toolmaking, repair welding, prototyping, and small series production. Enclosed safety housing with protection system, control panel, rotary indexing table, and extraction/filter system. Technical Data – Tekol LAP S4 Operating voltage: 400 V ~ N / PE Mains type: 3~ 400 V, 50 Hz Nominal current: 32 A (approx. 22.5 kVA) Control voltage: 24 V DC Dimensions: Length: approx. 1330 mm, Depth: approx. 1300 mm, Height: approx. 2030 mm Weight: Machine: approx. 800 kg Travel: X-axis: approx. 160 mm Y-axis: approx. 100 mm Z-axis: approx. 100 mm Rotary indexing table: 2-station Technical Data – Laser TRUMPF TruPulse 44 Laser type: Nd:YAG pulsed laser Wavelength: 1064 nm Max. average power: 42 W Min. pulse power: 201 W Max. pulse power: up to 3 kW Pulse duration: 0.2 – 50 ms Max. pulse energy: 30 J Nodpfoyi Sgaex Ad Escn Max. pulse frequency: up to 900 Hz Beam parameter product: 16 mm·mrad Technical Data – Extraction Unit TBH GL 230 Voltage: 230 V / 50–60 Hz Power: 0.36 kW Free-blowing air volume: approx. 390 m³/h Effective air volume: approx. 330 m³/h Max. negative pressure: 4000 Pa Sound level: approx. 51 dB(A) Weight: approx. 40 kg Multi-stage filter system: - Pre-filter - Particle filter - Activated carbon filter Total weight approx. 900 kg Condition: used Scope of supply: (see photos) - Tekol LAP S4 laser welding system - TRUMPF TruPulse 44 laser unit - TBH GL 230 extraction unit - Documentation / folders / data carriers - Keys and accessories as shown (Specifications and technical details are subject to change and errors!) If you have further questions, please feel free to contact us by phone.

Condition: used, Year of construction: 2000, CNC press brake Manufacturer: Trumpf Model: Truma Bend V170 Year of manufacture: 2000 CNC control: Delem Ncedpfxex Di Hxe Ad Esn Pressing force: 170 t Working width: 4 m Crowning system Backgauge 6 axes Hydraulic tool clamping Height: 2.9 m Without tooling Ref: ä25226

Condition: used, Year of construction: 2000, Press Brake Ncjdpjyma Rbofx Ad Een Manufacturer: Trumpf Model: TRUMABEND V230 Year of manufacture: 2000 Refurbished: 2010 CNC Control: Delem DA 65 Graphic Year of manufacture: 2000 Max. press force: 230 tons Max. working length: 3,060 mm C-frame throat depth: 410 mm Max. installation height: 535 mm Max. stroke of bending beam: 365 mm Max. sheet thickness approx.: 12 mm Backgauge travel: 600 mm Clearance between uprights: 2,690 mm Weight: 18,210 kg Required space: 3,660 x 2,120 x 3,095 mm Standard features: Upper drive concept with two-cylinder design Y1/Y2 Y1/Y2 configuration Electro-hydraulic ram drive with proportional valve technology Ram position measuring system with spring compensation via glass scales Modern block hydraulics Spherical suspension and tilting of the press beam 2-axis (R, X - CNC) backgauge system Innovative and safe finger adjustment from the front 2 self-centering backgauge fingers Program-controlled lower tool shift (I-axis) for 2 positions Safety guard Oil cooler CE marking Including accessories and options: CNC crowning 4 support arms Hydraulic upper tool clamping Modufix Hydraulic lower tool clamping for single V dies Preparation for ACB angle measurement system 6-axis backgauge system Safety device with light curtain Additional operator console Network card Robot interface Operating manuals

Condition: used, Welding edge shaper, edge shaper, edge chamfering machine TRUMPF Chamfering of steel plates for weld seam preparation Type TKF 103 Sheet thickness: 4 - 25 mm Bevel length max: 10 mm Bevel angle: 30° Power: 2000 watts Mains connection: 220 Volt, 50 Hz - equipped with guide bracket for 30° bevel angle - resharpenable steel for high tool utilization - Set up for 20 mm sheet metal For chamfering straight and curved edges with a radius of at least 40 mm. Njdodz Sq Eepfx Ad Ejcn For chamfering edges on flat and curved workpieces as well as pipes with an internal diameter of at least 80 mm. Weight: 14 kg

Condition: good (used), Year of construction: 2018, functionality: fully functional, total width: 700 mm, total height: 1,500 mm, total length: 800 mm, overall weight: 700 kg, TRUMPF LASERSIGN PL 2 Laser Engraving Machine - Operating voltage: 100 - 240 V Nsdpfsym Rx Nox Ad Escn - Frequency: 50/60 Hz - Rated current: 7 A - Power connection: 600 W - Internal dimensions: 400 x 300 mm - Table dimensions: 330 x 270 mm - with 6 T-slots - incl. laser source from manufacturer TBH Attention: The item must be collected bindingly between 21.04. and 30.04.2026 on a date to be agreed. FCA D-96257 Marktgraitz – loaded onto truck

Condition: good (used), functionality: fully functional, Year of construction: 2009, operating hours: 14,367 h, control type: CNC control, degree of automation: automatic, actuation type: hydraulic, controller model: TASC 6000, bending force (max.): 320 t, working width: 4,420 mm, stroke length: 445 mm, throat depth: 420 mm, distance between stands: 3,680 mm, installation height: 615 mm, number of axes: 6, type of crowning: CNC-controlled, travel distance X-axis: 860 mm, back gauge adjustment: CNC-controlled, Equipment: CE marking, angle measuring system, documentation/manual, foot remote control, safety light barrier, TruBend Cell 5000 – Robotic Bending Cell 320t Complete Service History - 6-axis backgauge system with control cabinet air conditioning - Sensors for 6-axis backgauge - Hydraulic upper tool clamping - CNC crowning - Preparation for ACB - MobileControl - Rear work area lighting - Front work area lighting - Operator comfort package with screen, mouse, and keyboard - BendGuard - BendMaster 150 - Track extension 16,000 mm - NC grip re-orientation station - Double sheet detection - Right-hand side door for safety fence - Vacuum gripper - 3x pneumatic gripper couplings - Robust machine frame in full-steel construction, ram stress-relieved annealed - 4-cylinder upper drive - Block hydraulic system with low-noise double pump - Backgauge with CNC-controlled X and R axes - Hydraulic upper tool clamping - Hydraulic lower tool clamping - Control cabinet cooling via air-to-air heat exchanger - Machine control network connection Control - TRUMPF TASC 6000 Safety - Standard safety equipment Nedpfoylankex Ad Escn

Condition: excellent (used), functionality: fully functional, Year of construction: 2018, operating hours: 21,346 h, laser power: 3,200 W, X working area max.: 3000 mm Y working area max.: 1600 mm Control: Rexroth IndraMotion MTX Laser power: 3000 watts Machine - Enclosed machine frame - Hybrid axis system - Linear magazine with 20 slots for clamps and tools - Hydraulic clamps (3 pieces) - Maintenance-free three-phase motors for drives - Repositioning device with programmable hold-down - Foot pedal for clamp closing - Beam protection with direct access - Parts chute on the right - Parts flap on the left - Sensor for parts flap - Work area illumination - FocusLine - Retrofittable for SortMaster Compact - Protective tool - Transport and installation device TRUMPF Laser - Laser light cable (LLK) according to standard layout (10m) - Laser power control - Laser logbook function - Closed beam guidance via laser light cable (LLK) - Separate power supply for TruDisk Compact Cutting Unit - Solid-state laser compact cutting unit - Protective glass - Collision protection - ControlLine Punching Head - Delta Drive - Rotatable mono-tool adapter - Programmable hold-down position - Tool length compensation - Punch spray lubrication - Punch slug extraction - Forming function - Stroke counter for punch Control - TRUMPF control based on Rexroth IndraMotion MTX - Touch panel with 19'' TFT color screen - Integrated technology data - Programmable cutting gas pressure - Remote support interface - Auto shut-off with wake-up function - Program management - Production plan Data Transmission - USB interface - RJ-45 network interface - Central Link - Online Update Manager Safety - CE marking - Two-beam safety light curtain Extended Standard Equipment - TruDisk 3001 solid-state laser with 1 LLK output - Chiller (water-air) - Compact dust extraction system - 1st locating pin (right inside) - Ball tables - Good parts container for parts chute - Chip container for rear removal Extended Laser Equipment - Copper cutting package - Brass cutting package Extended Punching Equipment - MultiShear function - Multitool function - MultiBend function - Thread forming with thread counter Thread former breakage monitoring Lubricant level monitoring - Marking/fast embossing function - Engraving function - Deburring and roller technology function - Ejecting small parts function Parts Ejection - Integrated sorting function for parts chute • Sensor for parts chute • Tray line for 4 standard trays 300 x 400 mm • Customer-supplied trays Extended Machine Equipment - 1x additional clamp - Machine rated for ambient temperatures up to 43°C Ncedpfx Aoylk S Tsd Esn Special Sheet Metal Processing - Brush tables - Warping detection Options for Compact Dust Collector - CO2 extinguishing system for the compact dust collector Data Transmission - Wireless Operation Point Machine Accessories - 1 set RTC cassettes incl. die plate SheetMaster Compact - SheetMaster Compact 3000 x 1500 mm (AK05) • Loading station with spreader magnet for sheet separation • Suction frame • Vacuum sensor system • Double sheet detection • Unloading cart for scrap grid and microjoint sheets • 2nd operator's station for loading and unloading.

Condition: excellent (used), functionality: fully functional, Year of construction: 2010, laser power: 4,000 W, X working area max.: 3050 mm Y working area max.: 1550 mm Control: Rexroth IndraMotion MTX Laser power: 4,000 watts Standard equipment: Machine - Sturdy, easily accessible C-frame - Coordinate guidance for high-precision machining - Linear tool changer with 21 tool stations and 4 clamps - Maintenance-free three-phase drive motors - Repositioning device with programmable hold-down - Foot switch for closing clamps - 2 good parts containers - Automatic shutoff Laser station - TruFlow laser - High-frequency excitation - Cooling unit - TASC 3 laser controller - Enclosed beam guidance - Beam tube ventilation with compressed air - Programmable cutting gas pressure - Laser cutting head with 170 mm focal length - Universal quick-change cutting head device UTI with bus connection - LensLine - FocusLine - ControlLine - NitroLine - SprintLine - ContourLine - FlyLine - PlasmaLine - High-speed cutting - Additional Xp and Yp axes - Ejector cylinder for laser parts - Fast flap for laser parts 500 x 500 mm - Liftable laser cutting support - Slag cone detection - Laser logbook function Punching station - Electro-hydraulic punching head - Rotatable mono-tool holder - Tool length compensation - Programmable hold-down with adjustable force - Stroke counter for punches - Spray lubrication for punches - Punch slug extraction - Warp detection - Flap for punched parts 500 x 500 mm - Fill level monitoring in the punching console Control - Open control system based on Bosch Rexroth IntraMotion MTX - Operating panel with 15" TFT touchscreen - Program management and 80 GB storage capacity - Diagnostic function with laser logbook - Integrated technology data - Teleservice Data transfer - Network connection RJ45 and USB interface Safety - CE marking - Multi-beam light barriers - Monitoring system for, among others, gas pressure, temperature, cooling water - Hydraulic quick shut-off - Protection against stray radiation - Compact extraction unit - TruFlow 4000 - Vibration-dampened installation - Thread forming function - MultiTool function - Chip conveyor with tilting container Ncjdsylk Nxjpfx Ad Esn - Active die - Ejector for small parts - Brush tables with loading aid - Marking function - Repositioning cylinder - Warp detection

Condition: good (used), functionality: fully functional, Year of construction: 2014, control type: CNC control, Machine Details Manufacturer: Trumpf Type / Model: TruLaser 5030 fiber Machine Type: Laser Cutting System Cabin Protection: Safety Enclosure Color: grey / blue Spindle Arrangement: – Year of Manufacture: 2014 Laser Operating Hours (h): (not specified) Operating Hours (h): (not specified) Number of Owners: 1 Next Safety Inspection (UVV): (not specified) Control / Electrical System / Weights / Dimensions Control System: Siemens 840 D SL Operating Voltage: 400 V / 50 Hz Power Consumption (kVA): (not specified) Max. Punching Force (kN): – Hydraulic Tank (L): (not specified) Machine Weight: 12,000 kg Max. Workpiece Weight: 900 kg Max. Sheet Size: 3,050 × 1,550 mm Installation Dimensions (L×W×H): 9,500 × 6,300 × 2,500 mm Max. Sheet Thickness (mm): 10 – 25 Tool Magazine (Stations): – Nsdpfoykxq Ijx Ad Eecn Technical Specifications X-Axis Travel: 3,000 mm Y-Axis Travel: 1,500 mm Z-Axis Travel: 116 mm Rapid Traverse: 280 m/min Laser Output Power: 5,000 W Value-Adding Features Solid-State Laser TruDisk 5001 Laser Chiller Unit Cooling Unit for the System Universal Cutting Head Multi-chamber Extraction System Light Barriers Electric Roller Roof Hydraulically Adjustable Pallet Changer
