Used International 1586 for sale (9,043)

Condition: excellent (used), functionality: fully functional, Year of construction: 1999, machine/vehicle number: 20, Used CNC internal broaching machine Make: FORST Type: RISH 63X1000X320 Year of manufacture: 1999/ Reconditioned Mach. No.: 20 Rjdpfx Aev Htluecvsr

Condition: used, Year of construction: 2008, operating hours: 18,937 h, functionality: fully functional, machine/vehicle number: 67, STUDER S145cnc INTERNAL GRINDING MACHINE Series 65 Year of manufacture: Sep. 2008 Operating hours: 18,937 Price: €118,000 This is a service-recorded machine: it undergoes an annual maintenance check by STUDER, with all wear parts replaced as needed. The machine has been used exclusively for producing precision spindles, achieving tolerances up to max. 0.0003 mm. The machine operates with grinding oil. Initially used in single-shift operation, in the last two years it has been working two shifts. The machine is in use and available for inspection upon request. The machine is being sold due to new equipment acquisition. Extras: Spindle adapters and flanges available upon agreement. Rjdpfx Asyw Nuxecvsr Specifications: • Swing diameter ..... 448 mm • Center height ..... 225 mm • Workhead (chuck spindle head) with roller bearings, mounting taper ISO50 – spindle nose Ø110 mm, spindle bore Ø50 mm • Machine bed made from Granitan S103 • Worktable swiveling range: +/-30° • Direct measuring system for X and Z axes • Touch-trigger probe Movomatic C25 (switching) • FANUC CNC control system 21i-TB • Portable control unit Studer PCU terminal with LCD display • Machine is currently in operation • Transport arrangements to be made by the buyer The machine is equipped with 4 spindles: one external spindle, two internal spindles, and one internal spindle with longitudinal positioner. RPM – one spindle: 60,000; two spindles: 42,000; one spindle: 5,000 Type: Fischer

Condition: used, Year of construction: 2001, machine/vehicle number: IntNr231491, Manufacturer: DECKEL MAHO, Model: DMF 220 linear, Year of manufacture: 2001 Control system: Siemens 840D Powerline Travel and Axes X-axis (longitudinal): 2,200 mm Y-axis (transverse): 560 mm Z-axis (vertical): 720 mm Rapid traverse X/Y/Z: 50 m/min X-axis drive: High-dynamic linear drive Work Table Clamping surface: 2,600 x 600 mm Max. table load: 2,200 kg Main Spindle Speed range: 20 - 12,000 rpm (standard) Drive power (100% duty cycle): 35 / 25 kW (S1/S6) Max. torque: 130 / 87 Nm (at 100% duty cycle) Tool holder: SK 40 according to DIN 69871 Tool Changer Number of stations: 30-position magazine Tool change time (chip-to-chip): approx. 4-6 seconds (depending on model) Dimensions & Weight Space requirement approx.: 6,500 x 3,500 mm Machine weight approx.: 12.5 t The machine can be inspected under power by appointment. Technical data and specifications subject to change and error; prior sale reserved! Rjdpfjyvt S Eex Acvor Refurbished 5-axis CNC machining center Deckel MAHO DMF 250 linear in good condition. Year of manufacture: 2004. Control: Heidenhain iTNC 530. Technical data: X travel: 2,500 mm. Y travel: 920 mm. Z travel: 820 mm. B-axis: x/- 105° Worktable: 3,100 x 900 mm Spindle interface: HSK 63 Spindle speeds: 20 - 18,000 rpm Tool changer: 30 positions Equipped with: - Chip conveyor - Through-spindle coolant 40 bar - Operating manual Country of origin: Germany Motor power: 35 kW Machine dimensions (LxWxH): 6,000 x 3,800 x 2,950 mm Machine weight: 25,000 kg The machine can be viewed by appointment. Technical data and specifications subject to change and error, as well as prior sale!

Condition: used, Year of construction: 2004, machine/vehicle number: IntNr231486, Used, refurbished 5-axis CNC machining centre Deckel MAHO DMF 250 linear Year of manufacture: 2004 Control system: Heidenhain iTNC 530 Technical specifications: X-axis travel: 2,500 mm Y-axis travel: 920 mm Z-axis travel: 820 mm B-axis: +/- 105° Working table: 3,100 x 900 mm Spindle interface: HSK 63 Spindle speeds: 20 – 18,000 rpm Tool changer capacity: 30 positions Equipped with: - Chip conveyor - Through-spindle coolant, 40 bar - Operating manual Country of origin: Germany Rjdpfx Acsyu Ncisvjr Motor power: 35 kW Machine dimensions (LxWxH): 6,000 x 3,800 x 2,950 mm Machine weight: 25,000 kg The machine can be inspected under power by appointment. Technical data and information subject to change and error; prior sale excepted!

Condition: used, Year of construction: 2016, machine/vehicle number: IntNr231489, Keyence IM-6025 Measuring Machine – Fast and Precise Optical Measurement For sale is a Keyence IM-6025 measuring machine, ideal for rapid series inspection, incoming goods control, and precise dimensional verification in production environments. Year of manufacture: 09/2016 Main Features: Manufacturer: Keyence Model: IM-6025 Year: 09/2016 Measuring range: 300 × 200 mm (depending on model) Measuring principle: Optical 2D image processing with automatic contour recognition Measuring accuracy: High repeatability in the micron range Functions: Automatic part position detection Simultaneous multipoint measurement CAD data comparison capability SPC analysis Rodpfjyu I T Tex Acvor Intuitive user interface USB and network connectivity Lighting system: Transmitted and reflected light illumination (LED) Max. workpiece height: Up to approx. 75 mm Special features: Measurement in seconds without complex alignment Ideal for batch and spot-check inspection Operator-independent measurement results Compact design Condition: Used, tested, and fully operational. Application area: Ideal for metal and plastic processing, stamped parts, turned parts, milled parts, as well as for quality assurance and production control. The machine can be inspected under power by prior arrangement. Subject to prior sale. Changes and errors in technical specifications and information excepted.

Condition: used, Year of construction: 2003, operating hours: 86,000 h, machine/vehicle number: IntNr231169, STAR CNC Swiss-type lathe SB 16, year of manufacture 2003 CNC control FANUC 18i-TB Technical data: - Number of axes: 6 - Number of spindles: 2 MAIN SPINDLE - Max. bar diameter: 16 mm - Z-axis travel: 205 mm - Spindle speed: 10,000 rpm - Spindle drive power: 3.7 kW - Minimum C-axis resolution: 0.001 SUB SPINDLE - Max. bar diameter: 16 mm - Spindle speed: 8,000 rpm - Minimum C-axis resolution: 0.001 Bar feeder: FMB Minimag /3200/A Bar diameter: 2 – 16 mm Bar length: 3,200 mm Kraft & Bauer compact fire extinguishing system Mayfran chip conveyor High-pressure coolant system: 70 bar / 8 valves / filter bag Operating manual included Rjdpsyu I R Sofx Acvsr The machine can be inspected under power by appointment. Technical data and descriptions are subject to change and error; prior sale reserved!

Condition: used, Year of construction: 2016, machine/vehicle number: IntNr231488, Keyence IM-6025 Measuring Machine – Fast and Precise Optical Measurement For sale is a Keyence IM-6025 measuring machine, ideal for rapid series inspection, incoming goods control, and precise dimensional verification in production environments. Year of manufacture: 09/2016 Main Features: Manufacturer: Keyence Model: IM-6025 Year: 09/2016 Measuring range: Redjyu I N Uopfx Acvor 300 × 200 mm (depending on model) Measuring principle: Optical 2D image processing with automatic contour recognition Measuring accuracy: High repeatability in the micron range Functions: Automatic part position detection Simultaneous multipoint measurement CAD data comparison capability SPC analysis Intuitive user interface USB and network connectivity Lighting system: Transmitted and reflected light illumination (LED) Max. workpiece height: Up to approx. 75 mm Special features: Measurement in seconds without complex alignment Ideal for batch and spot-check inspection Operator-independent measurement results Compact design Condition: Used, tested, and fully operational. Application area: Ideal for metal and plastic processing, stamped parts, turned parts, milled parts, as well as for quality assurance and production control. The machine can be inspected under power by prior arrangement. Subject to prior sale. Changes and errors in technical specifications and information excepted.

Condition: used, Year of construction: 2007, machine/vehicle number: IntNr231168, STAR CNC Swiss-type lathe SB 16C, Year 2007 CNC control: FANUC 18i-TB Technical data: - Number of axes: 6 - Number of spindles: 2 MAIN SPINDLE - Max. bar diameter: 16 mm - Z-axis travel: 205 mm - Spindle speed: 10,000 rpm - Spindle drive power: 3.7 kW - Minimum C-axis resolution: SUB SPINDLE - Max. bar diameter: 16 mm - Spindle speed: 8,000 rpm - Minimum C-axis resolution: - Number of tool positions: 8 - Number of driven positions: 3 Bar loader: FMB Minimag 3200/A - Bar diameter: 2 – 16 mm - Bar length: 3,200 mm Redpfx Aoyu I Anecvjr HERA compact fire extinguishing system – fire protection Operating manual HD system SFB300 – 100 bar / 4V / 40μm filter Machine can be demonstrated under power by appointment. Subject to prior sale. Specifications and details subject to change and error.

Condition: used, Year of construction: 2003, machine/vehicle number: IntNr231507, 5-axis Universal Machining Centre Hermle Type: C 40 U Year of manufacture: 2003 Control: Heidenhain iTNC 530 Travel paths: X-axis: 850 mm Y-axis: 700 mm Z-axis: 500 mm NC Swivel Rotary Table: Diameter: Ø 800 mm Rodpfxsyu Ivue Acvsr Swivel range A-axis: +25° / -110° Rotary range C-axis: 360° Machine weight approx. 10.5 t Accessories: Complete documentation Coolant system Hydraulic unit NC swivel rotary table Electronic handwheel Renishaw touch probe The machine can be inspected under power by prior appointment. Technical data and specifications are subject to change and error. Sale subject to prior availability!

Condition: excellent (used), Year of construction: 1977, functionality: fully functional, Equipment: 4 in one shovel, The machine is in excellent condition and can be inspected at our warehouse. Rsdpfoyxypiox Acver

Condition: used, Out of insolvency: Rilco shaking bottle 56mm untested Redpfx Aorkzt Uocvjr

Condition: used, Out of insolvency: Converter with Rilco vibratory bottle 380 Volt Redporkzt Hofx Acver 58mm bottle function tested

Condition: not inspected (used), Out of insolvency: Converter Wacker FU 1.6 380 Volt Rsdpfx Acerkzt Aever 2x bottle connection 3-pole untested, as no suitable vibrating bottle available

Condition: used, Year of construction: 2003, internal diameter 99999 mm grinding depth 99999 mm swing diameter 99999 mm grinding diameter 99999 mm grinding length 200 mm centre height 175 mm CNC internal grinding machine Rjdpfx Ajuxft Secvor B-axis 4 x 90° Q-axis for adjusting tapers Used with minor maintenance 2 HF internal grinding spindles: -Fischer MFM 1090 90,000 rpm -Fischer MFM 1242/60 42,000-60,000 rpm 1 external grinding motor spindle Fischer MFVS1407 7,000 rpm -Pneumatic power clamping device with 20mm stroke -Dressing device with 2 swivelling arms, hydraulically foldable back -Grinding detection ring sensor Dittel on the workpiece headstock -Passive grinding detection with magnetic base -Paper belt filter 375 l

Condition: used, internal diameter 340/440 mm grinding depth 99999 mm grinding diameter 250,350,450 mm grinding length 600 mm centre height 125,175,225 mm bore 127 mm MK5 work piece spindle speed 20-400 U/min grinding head swivelling 360 ° grinding spindle head - swivable 180 + - ° grinding spindle speed 1500,1700,2200 U/min 0,001-0,030 mm/Ø 0-0,95 mm/Ø ±10 ° longitudinal feed of the table 900 mm table speeds 0,02-6 m/min 130 kg 130 inkl. Spannugkg kg 70 mm total power requirement 6,5 kW Redpfed Ih Dxjx Acvor weight of the machine ca. 2,2 t dimensions of the machine ca. 3,1 x 2,0 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your metrical overhauled and repainted with: -Neuem CE konformem Schaltschrank. -Neuem Werkstückspindelmotor und Regler in Drehstromtechnik. -Digitalanzeige in 2 Achsen. Auflösung x-Achse 0,5my Optionen: -Drehgeber mit digitaler Anzeige im Werkstückspindelstock -Drehgeber mit digitaler Anzeige im Schleifspindelstock (keine Höhenverstellung mit Spindel möglich) -Neue stabile Innenschleifvorrichtung Durchmesser 80mm oder 100mm mit Höhenjustierung. -Erhöhung der Spitzenhöhe auf max. 225mm -Drehzahlregelung für die Schleifspindel Inklusive: -Bedienwerkzeug -Spannrohr für Futter weiteres Zubehör auf Anfrage. Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, honing diameter 99999 mm Rodpfx Acjv Tqquover stroke 99999 mm throat 99999 mm Used without warranty

Condition: used, Year of construction: 2000, honing diameter 45 mm stroke 1000 mm 4 spindle honing machine for guns Honing area according to the manufacturer: Diameter 5-45mm Maximum Honing Length 750mm Accessories: Honing tools for diameter: Rjdpfx Acjxddq Ejver -10mm -12,3mm -13,3mm -21,1mm

Condition: used, Year of construction: 2010, honing diameter 54 mm Rjdpfxovk Nkue Acvjr stroke 99999 mm centre height 9999 mm Control FANUC CNC Ball and spherical honing machine

Condition: used, Year of construction: 2008, internal diameter 99999 mm grinding depth 99999 mm swing diameter 99999 mm Control FANUC 320iA 3 x internal grinding spindles 2x HV-X 100-90000/3 Housing diameter: 100 h5 mm Spindle speed max: 90000 min/1 Nominal/max. power: 2.5/3.0 kW Spindle nose: D10/18 Spindle cooling: Water 1x HS80c 120000/1.1 Housing diameter: 80 h5 mm Spindle speed max: 120000 min/1 Nominal/max. power: 0.8/1.1 kW Spindle nose D06/12 Spindle cooling: Water 1 x external grinding spindle: MMO-100 HSK-C50/4 Diameter: 100 h5 mm Maximum speed: 3770 min/1 Nominal/max. power: PS1/PS6 - 6.0/7.0 kW Clamping system: HSK-50/M12 Grinding wheels: Diameter 125-200 x 2-20 mm 1 x dressing spindle MHF-72 D40/16 Housing diameter: 72 h6 mm Maximum speed range: 16000 rpm Power S1/S6: 400/500 W Spindle nose: 40 mm/8xM5 on TK 56 mm Spindle nose: 40 mm/4xM5 on TK 32 mm 1 x measuring probe (longitudinal positioning) Etamic C25 Abrichteinheit für das automatische Abrichten mit Hydraulisch einschwenkbarem Arm. Präzisions Positionierung und Einrastung mittels Konischem Bolzen, geschliffen und gehärtet. Schwenkbewegung : Hydraulisch Schwenkgeschwindigkeit : Einstellbar 1 x Messtaster (Längspositionierung) Etamic C25 Rodpfxex Dxw Hj Acvor X-Achse Fahrweg: 400 mm Auflösung: 0.0001 mm Vorschub: 0-10'000 mm/min Messung: Glasmassstab Absolut Z-Achse Fahrweg: 400 mm Auflösung: 0.0001 mm Vorschub: 0-10'000 mm/min Messung: Glasmassstab Absolut B-Achse Fahrweg: +60°..- 91° Auflösung Winkelmessgeber: 0.0005° Auflösung Antrieb: 0.0001° Vorschub: 25°/Sek Messung: Winkelmessgeber Absolut Revolver Anzahl Position 4 Zeit beim Wechseln 5 Sek Möglicher Spindeldurchmesser: 0 100 mm Werkstück- Spindeldrehzahl max.: 1'000 min-1 Spindelstock Leistung max.: 1.8 kW 960-41 Spindelnase: A2.4/MK5 Ausrüstung Anschnitterkennung Anschnitterkennung und Prozessoptimierung zur Optimierung des Schleif- und Abrichtprozesses und zur Verkürzung des Luftschleifens. Signal über Körperschallsensor auf dem Werkstückspindelstock aufgebaut, bestehend aus: -1x AE-Auswertsystem mit Display AE4100 -1x Kabel -1x Software und Anbauaufwand inkl. Material Sensor und Empfänger für Abrichtspindel - 1x Ringsensor - 1x Ringempfänger Sensor und Empfänger für Spindelnase A2.4/MK5 Elektroschrank mit CNC-Steuerung FANUC 320i A und Bedienungskonsole mit Bildschirm 15" Color LCD TFT 1024 x 768 Bedienpanel 55 Tasten und LEDs PC Tastatur QWERTY Intel Pentium III 866 MHz Windows XP Professionnal Combitec HMI für FANUC 320i A Standard Programmiersprache nach DIN/ISO Werkstattorientierte Schleifzyklen (WOP) Mobiles Handrad mit Wahlschalter 0.001, 0.01, 0.1 mm und Achsenwahlschalter Vorschub Korrektur über Raster-Potentiometer 0-100 % Spindelgeschwindigkeits-Korrektur über Raster-Potentiometer 50-125 % RJ-45 Ethernet mit TCP/IP Software und Zubehör für das Radius und Konus schleifen mit PC Simulation und CNC-Bahnkontur schleifen Vollautomatisches Schleifen eines Radius G71 und/oder eines Konus G72 ab einem bestimmten Winkel auf einen...

Condition: used, Year of construction: 1952, 220 mm ja weight of the machine ca. 1,4 t Rjdpsyn R Nwsfx Acver

Condition: used, TECHNICAL DETAILS - Grinding diameter : 5-200 [mm] - Grinding depth : 250 [mm] - Max. part length : 250 [mm] - Centers height : 180 [mm] - Bar clearance : 50 [mm] - Internal spindle cone : 70 [mm] - Spindle speeds : 120-1000 [rpm] - Cones grinding : 0-180 [°] - Maximum stroke of the table : 600 [mm] - Table speeds : 0-10 [m/min] - Wheel speedd : 3600-40000 [rpm] - Spindle diameter : 90 [mm] Rsdpfxeu Hac Ds Acvjr - Dimensions : 3200 x 1270 x 1650 [mm] - Weight : 2700 [kg]

Condition: used, Year of construction: 2009, internal diameter max. 600 mm grinding depth max. 800 mm grinding length max. 600 mm control Siemens 840 D grinding diameter - internal max. 600 mm grinding diameter - cylindrical max. 800 mm workpiece length - max. 380 mm external grinding length max. 600 mm travel - x1 axis 150 mm travel - z1 axis 1100 mm travel - x2 axis 470 mm travel - z2 axis 800 mm workpiece spindle 8,5 kW turning speed range - stepless 1-795 U/min Equipment / Accessories: Workpiece spindle unit (U/B1/L adjustment): - Travel (U-axis): 300 mm - Swivel angle (B1 axis): -0,5°/+12° - Drive power of the workpiece spindle: 8.5 kW - Speed range (infinitely variable): 1-795 rpm - Set-up speed (jogging): 10 rpm - Spindle head size A 8 according to DIN 55026 - Through-hole 58.5 mm - Workpiece diameter max. 830 mm Redpfx Acewp S Tnsvor - Workpiece length (overhung clamping) max. 800 mm - Workpiece length (clamped between centers) max. 800 mm - Load capacity at spindle head max. 6100 N Internal grinding device (Z1/X1/B2): - Travel (Z1 axis): 1100 mm - Travel (X1 axis): 150 mm - Swivel angle (B2 axis): 270° - Manual longitudinal adjustment of internal grinding axis on table: 780 mm - Drive power of the internal grinding spindles (infinitely variable) Belt-driven grinding spindles: 7.5 kW - Grinding block mounting hole (diameter): 100 mm / 125 mm - Mounting length of sanding block: 220 mm - Sanding diameter: max. 600 mm - Sanding depth: max. 800 mm External and surface sanding device (Z2/X2): - Travel (Z2 axis): 800 mm - Travel distance (X2 axis): 470 mm - Swivel angle (B2 axis): 270° - Drive power of the external grinding spindles: 7.5 kW - Grinding block mounting hole: Ø 140 mm - Sanding diameter: max. 800 mm - Sanding length max. 600 mm - Grinding wheel dimensions: max. Ø 450 x 50 x Ø 127 mm

Condition: good (used), Year of construction: 1986, Inner diameter: 20…400 mm Grinding depth: 315 mm Internal grinding spindle speeds, stepless: 2,640…16,500 rpm Workpiece spindle speed: 40…400 rpm Table feed rate: 0.1…8 m/min Rapid traverse: 10 m/min Table travel: 630 mm Total power requirement: 16 kW Machine weight approx.: 5.8 t Additional information: Grindable diameter within workpiece guard: internal 20…400 mm; external 500 mm Max. workpiece diameter in workpiece guard: 500 mm Max. grinding depth: 315 mm Grindable taper angle: 60° Internal grinding spindle speeds: 2,640…16,500 rpm Rsdpfx Aeyx Tnlocver Drive power for face grinding attachment: 4 kW Drive power for workpiece motor: 1.5 kW Workpiece spindle speeds: 40…400 rpm Table speed: 0.1…8 m/min Rapid traverse: 10 m/min Table travel: 630 mm Max. distance from workpiece spindle flange to grinding spindle carrier: 1,250 mm

Condition: used, Year of construction: 2012, operating hours: 7,200 h, machine/vehicle number: IntNr230381, used CNC Tsugami HS2075AX with B-axis, year of manufacture 2012 Operating hours: 7,200 Control: Fanuc 31i-A Maximum machining length: 250 mm Number of controlled axes: 7 (up to 5-axis simultaneous machining) B-axis: 0°–130°, freely programmable Bar capacity: Ø 3 mm to max. Ø 20 mm Main spindle drive power: 3.7 kW Counter spindle drive power: 2.2 kW Main spindle speed: 10,000 rpm Counter spindle speed: 10,000 rpm C-axis: available on both main and counter spindle Number of linear tool carriers: 2 Total number of tools: 35 Dimensions (LxWxH): 2,110 x 1,200 x 1,885 mm Weight: 3,300 kg Convertible between long and short turning Deep-hole drilling stations NAKANISHI high-speed spindle Rear turret with Y-axis Rjdpfxjyt H D Ij Acvjr Cross-drilling on rear side Chip conveyor Fire suppression system FMB Minimag 20 bar feeder, year 2012 The machine can be inspected under power by prior arrangement. Technical data and information are subject to change and error; prior sale reserved.

Year of construction: 1999, condition: used, pulling force - max. 6,0 t Rodod Il A Nepfx Acvor max. ram stroke 1250 mm dimensions of the machine ca. 1,20 x 1,20 x 3,25 m
