bore capacity in steel (diameter) 22,0 mm
x-travel 336 mm
y-travel 190 mm
table: 580 x 250 mm
turning speeds 40 - 3600 U/min
spindle taper MT 3 MK
throat 300 mm
quill stroke 120 mm
threading M18
spindle feeds: 0,02 - 0,6 mm/U
spindle diameter 65,0 mm
total power requirement 0,75 / 1,1 kW
weight of the machine ca. 830 kg
range L-W-H 1000 x 1300 x 1850 mm
O0kv2
Furnishing:
- Drilling & milling machine
- with electrical height adjustment
- stable sliding cross table
- Aciera quick change system...
Ref. -No.: 10209
Brand: SCHIESS
Btwpcopp2p
Type of control: CNC
Control: Philips CNC3460/500
Storage location: Halberstadt
Country of origin: Deutschland
X-Travel: 21600 mm
Y-Travel: 4900 mm
Z-Travel: 1510 mm
Spindle stroke: 1625 mm
Tool Taper: Steilkegel 60
Spindle Speed: 520 RPM
Feed Speeds X/Y/Z Axis: 2,3-2200 mm / min
Rapid Travel X/Y/Z: 2200 mm / min
Rotary table diameter: 4500 mm
Rotary table travel V: 2500 mm
Rotary table max. Load: 120.000 kg
Control Unit
Brand HEIDENHAIN
Model TNC 355
Main Drive
Spindle speed range 1250
Movement
X-Axis Movement 1980 mm
Y-Axis Movement 1750 mm
Z-Axis Movement 2000 mm
W-Axis Movement 800 mm
Workpiece
Workpiece weight 8000 kg
Table
Outer length 1600mm
Outer width 1400mm
Bmezr337od
This Union BFT 110 Milling Drill was manufactured in the year 1989. This reliable machine is capable of working with a spindle speed up to 1250rpm.
Application Types
Drilling
throat:580 mm
bore stroke:650 mm
X-axis :3000 mm
Drill head RPM:140-2000 U/min
Drive x + y + z axis:Servomotor
Rapid traverse x axis:20 m/min
Rapid traverse y axis:15 m/min
Rapid traverse z axis:15 m/min
Distance table top - bottom Chuck:700 mm
Bobqqoya
Table width:560 mm
T-slots:14
Threaded drill up to:M4-M20
Tolerance x axis::0,1 mm
Tolerance of y and z axis::0,06 mm
total power requirement:4 kW
weight of the machine ca.:ca. 4 t
description of the Company Bauer:
Drilling rig driving stand ...
Drill stand with cross table
-Transfer in current condition as seen
-One: threaded spindle is missing
-Clamping table: 340 x 200 mm
-Admission
-Dimensions: 430/320/H560 mm
R8jjzihaa
-Weight: 8 kg
Technical data :
Engine power 1 kW
6 speeds 200-270-410-700-940-1450 rpm
Recording MK 3
quill stroke 100 mm
Bty3mk97c3
Column diameter 120 mm
Table size , W x D approx. 640 x 260 mm incl. border
Y-path approx. 220 mm
X-path approx. 360 mm
max. distance MK-reception - table 310 mm
max. distance collet chuck - table 335 mm
height adjustment from head approx. 330 mm
Dimensions, W x D x H approx. 0.9 x 1 x 2.18 m
Weight estimated approx. 0.6 to
.
.....
bore capacity in steel (diameter) 45 mm
throat 230 mm
bore stroke 125 mm
spindle taper ISO 30
spindle turning speed range 75 - 1600 U/min
max. milling cutter diameter 80 mm
560 mm
230 mm
table surface area 800 x 240 mm
Drybkdmv8
max. distance between table and spindle-nose 460 mm
connected load frequency 230 V
total power requirement 1,1 kW
weight of the machine ca. 320 Kg
dimensions of the machine ca. 1,0 x 0,8 x 1,45 m
Drilling and milling machine
- Cross Support
- Cabinet
- Swivel spind...
spindle diameter 105 mm
x-travel 1200 mm
y-travel 1000 mm
Buai9zwq
z-travel 325 mm
adjustment of cross-rail 785 mm
distance between columns 1600 mm
distance spindle - column min./max. 215 / 1100 mm
spindle feeds - stepless 1 - 6000 mm/min
spindle taper ISO 40
spindle turning speed - stepless 40 - 1800 U/min
table surface area 900 x 1500 mm
workpiece weight 2000 kg
spindle drive 5 kW
total power requirement KVA
weight of the machine ca. 6 t
dimensions of the machine ca. 3,3 x 3,0 x 2,8 m
dime...
bore capacity in steel (diameter):130 mm
Ozhhp
x-travel:3.100 mm
y-travel:1.800 mm
Z-axis (longitudinal movement column):2.000 mm
W-axis (movment quill):800 mm
spindle taper ISO:50
spindle power:37 kW
transmission ratio:2
torque gear step 1/2:2360/590
speed range :4-2.500 min-1
clamping table::
max. workpiece weight:10.000 kg
number of T-slots:9 28H8
Resolution of measuring system:0,001 °
drum magazine:40-fold
feed range X,Y,Z - axis:0-10.000 mm/min
feed range W-axis:0-8.000 mm/min
rapid t...
bore capacity in steel (diameter) 13,0 mm
x-travel 300 mm
B3zatnl8
y-travel 130 mm
turning speeds 100 - 2500 U/min
throat 165 mm
spindle taper MT 3 MK
table-size 490 x 120 mm
diameter of hob 30,0 mm
motor 230 Volt
total power requirement 0,75 kW
weight of the machine ca. 50 kg.
dimensions of the machine ca. 520x500x740 mm
Sofort ab Standort frei :
Btxnibreax
Universal Bohr - Fräsmaschine Bohner & Köhle
Type F 30
Baujahr 1974
Tisch 1600 x 800 mm
Verfahrwege X / Y / Z 1800 / 700 / 1150 mm
Verstellung der Pinole 300 mm
Spindeldrehzahlen 45 - 2250 U / min stufenlos
Fräskopf 360 Grad schwenkbar
Antrieb 12,5 kw
Spindelaufnahme SK 50
Heidenhain Digitalanzeige 3 Achsen
Div. SK 50 Aufnahmen
Zum Preis von Euro 4.000.-- zzgl. Mwst. ab Standort
Spindle quill: Ø 130mm optional Ø 150 mm
Spindle speed: 3.500 rpm optional 4.000 rpm
Main drive power S1: 40 / 46 kW
Spindle torque S1: 1.650 / 2.050 Nm
Hydrostatic machining table: 1.600 x 1.600 / 1.600 x 2.000 / 2.000 x 2.000 / 2.000 x 2.500
Table load, max.: 20.000 kg
X axis: 2.000 / 3.000 / 4.000 / 5.000 mm
Y-axis: 2.000 / 2.500 / 3.000mm
Z axis: 1.500 / 2.000 / 2.500 / 3.000 mm
W-axis (Spindle quill): 800 mm
Control: SIEMENS Sinumerik 840D sl / HEIDENHAIN TNC 64...
bore capacity in steel (diameter) 16 mm
throat 170 mm
bore stroke 50 mm
16 mm
spindle taper MK2
spindle turning speed range 50 - 2250 U/min
Bpij3syc
320 mm
145 mm
table surface area 500 x 140 mm
connected load frequency 230 V
total power requirement 0,5 kW
weight of the machine ca. 90 Kg
dimensions of the machine ca. 0,5 x 0,45 x 0,84 m
Drilling and milling machine with
- variable spindle speed
- Digital depth display
- Left / right switch
- Cross support
- swiveling spindle head
- Feeds ...
Control Unit
Brand Fagor
Model 8025
Main Drive
Spindle speed range 1000
Movement
X-Axis Movement 2900 mm
Y-Axis Movement 1900 mm
Z-Axis Movement 1000 mm
Table
Outer length 1400 mm
Outer width 1620 mm
Additional Equipment
2 extra heads
Control Unit
Brand Fagor
Model 8025
Main Drive
Spindle speed range 1000
Movement
X-Axis Movement 2900 mm
Y-Axis Movement 1900 mm
Z-Axis Movement 1000 mm
Table
Outer length 1400 mm
Outer width 1620 mm
Bsbhenke0a
Additional Equipment
2 extra heads
This Sace...
bore capacity in steel (diameter) 20 mm
x-travel 510 mm
y-travel 240 mm
table-size 240x800 mm
spindle taper MT 3
mx. distance t. milling head and table 450 mm
turning speeds 0 - 2500 U/min
400 V
total power requirement 0,75 kW
weight of the machine ca. 420 kg
dimensions of the machine ca. 870 x 890 x 1920 mm
?solid column to avoid vibration
?gear wheels in oil bath
?left and right turning
Suuwo8
?precision setting for milling depth
?with drawbar (M12)
Universal drilling machine OERLIKON
Mod: UB 2
Machine-No. 277892
cone holder - MK 3 with tightening thread
Brojdeyrup
8 x speeds from - 25 - 2560 rpm
3 x autom. drill feeds
spindle stroke - 150 mm
Base plate surface - 880 x 700 mm
pole-changing motor - 1,2 / 1,5 PS
with original cross table from OERLIKON
accessories: collet holder with 33 x collets from Schaublin
from 4 - 20 mm
Digital display Elesta.
Accessories available.
Working range
Travel lengthwise X-axis 450 mm
traverse path cross Y-axis 260 mm
quill stroke Z-axis 120 mm
traverse path machine head W-axis 450 mm
feeds/rapid traverse
X- and Y-axis manual
X- and Y-axis (option motor table) 10 - 1'000 mm/min
Z-axis: feed gear with 6 steps 0.02 - 0.30 mm/rev
W-axis 1'800 mm/min
Feed forces:
X- and Y-axis manual
Z-axis with feed gear 5'000 N
Rapid traverse:
X and Y axis (motorized option) manual
X- and Y-axis 1'500 m...
Drilling milling machine in modular design for the drilling of profiles up to 6 meters and light milling.
Designed for metal fabricators and fitters
X 800 mm up to 6000 mm on request
Y-100 mm to 500 mm on request
Z 100 mm to 600 mm on request
Spindle drive according to customer requirements
Tool holder as needed
Control: Siemens
Drives: Siemens
Zuooz8l9
Our proprietary system for CNC machines allows to make flexible machines according to your needs. This applies to the workable dimensions of...
bore capacity in steel (diameter) 40 mm
throat 290 mm
bore stroke 115 mm
spindle taper SK 40
spindle turning speed range 70 - 3200 U/min
350 mm
130 mm
table surface area 590 x 190 mm
connected load frequency 400 V
diameter of hob max. 80 mm
feed 0,1 - 0,18 - 0,26 mm/U
total power requirement 1,1 kW
Bogxfrdomz
weight of the machine ca. 0,4 t
dimensions of the machine ca. 0,7 x 0,95 x 1,75 m
Drilling and milling machine
- Cross Support
- Cabinet
- Swivel spindle head left / right 90 °
- Feed...
bore capacity in steel (diameter):150 mm
Bm77jtou2a
x-travel:4000 mm
y-travel:3000 mm
l gth in through put process:2500 mm
W-Axis, movement quill:900 mm
B-Axis, rotary movement table:360 Grad/degrees
b-axis, positioning accuracy :360.000 x 0,001 °
fixed spindle nosing, length:280 mm
Smallest distance, front edge of spindle to table centre (2.000/2.500):-162/+88 mm
lowest position above table surface:0 mm
Tool taper DIN 69871:ISO 50, BIG PLUS, Form AD
Motor power:55 kw
max. torque on the spindle...
Boring power:35 mm
turning speed range - drilling:125 - 1500 U/min
motor speeds::1420 - 2760 U/min
number of feeds:3
table diameter:450 mm
throat:330 mm
spindle taper:MK3
quill stroke:150 mm
connected load:2,2 kW
power capacity:1,5 / 2,2 kW
Psqx2a
column diameter:180 mm
distance spindle nose and table:0 - 700 mm
distance spindle/base plate:830 - 1200 mm
machined bearing plate::580 x 540 mm
total power requirement:2,2 kW
weight of the machine ca.:ca. 0,6 t
dimensions of the machine ca.:600 x 10...
Drill milling machine Aciera
Mod: 23 TNC
with Heidenhain control - TNC 121
year: 1980
clamping surface - 590 x 320 mm
Jcevcgv
travels - x 500 mm, y 300 mm, z - 580 mm
pole-changing motor - 0,95 / 1,5 kW
infinitely variable speeds from - 45 - 4000 rpm
Drilling spindle with motor brake.
6 x autom. drill feeds
drilling capacity - 23 mm
tapping capacity - M 18
quill thrust - 120 mm
Accessories: 22 pcs. Automatic central lubrication.
Coolant sys...
Technical data:
Spindle diameter: 130 mm
spindle mounting: ISO 50
travel (X/Y/Z): 2200 / 1700 / 1250 mm
spindle adjustment (W): 800 mm
table size: 1800 x 1600 mm
table load: 12000 kg
Table rotation 90° via M-function: HEIDENHAIN VRZ 183A
spindle rotation: 1,25 - 900 rpm
linear control: HEIDENHAIN TNC 1355
controlled axes: X, Y, Z, W
motor power: 37 KW
machine weight: approx. 40 to
accessories:
1 position indicator:
HEIDENHAIN VRZ 183 A for B-axis table rotation
1 vertical milling head: type F...
- precise Drilling and milling machine in cast design
- X/Y/Z digital display
- spindle pivotable +/- 90°
- spindle mount MK 4 and SK 40
- motor feed X and Z axis with fine adjustment
- max. Drilling diameter 40 mm
- max. milling diameter 32 mm
- table size 800 x 240 mm
- travel range X= 560, Y= 230, Z= 300 mm
- max. distance table-spindle 470 mm
- spindle speed 75-3200 rpm
- tool cooling
- keyless drill chuck up to 16 mm
- lamp
- safety shield with kill switch
dimensions LxWxH: 1300 x 960 x 19...
bore capacity in steel (diameter) 40 mm
throat 290 mm
bore stroke 130 mm
spindle taper SK 40
spindle turning speed range 70 - 3200 U/min
520 mm
230 mm
table surface area 730 x 210 mm
connected load frequency 400 V
total power requirement 1,1/1,5 kW
weight of the machine ca. 0,32 t
Hgqov7n
dimensions of the machine ca. 1,1 x 0,9 x 1,15 m
domestic equipments
Digital depth gauge
Adjustable guides with wedges
Large 12-speed range from 75 to 3200 rpm
Smooth running due to hardened and g...
spindle diameter 0 mm
x-travel 805 mm
y-travel 505 mm
Bjx0gfalmn
total power requirement 2 kW
weight of the machine ca. 600 kg
dimensions of the machine ca. m
bore capacity in steel (diameter) 32 mm
x-travel 510 mm
y-travel 240 mm
table-size 820 x 240 mm
spindle taper MT 3
mx. distance t. milling head and table 445 mm
bore depth 130 mm
max. distance between table and spindle-nose 455 mm
turning speeds 75-3200 U/min
transmission ratio 12R/12L
head swivability 45 °
quill stroke 130 mm
400 V
total power requirement 0,75 kW
weight of the machine ca. 360 kg
dimensions of the machine ca. 920 x 740 x 1000 mm
Bjj2izot
solid column to avoid vibration
gea...
ser. no. 24600, speed max. 4.500 rpm, tool holder SK40, 20 tool holders SK 40 - pos. 5
F8ywhaxv8
Combined heavy drilling and milling machine make KNUTH type VBF 40
machine # 108898, year of construction 1996
technical data:
Cikaugte
Drilling capacity in steel 38 mm
tapping 25 mm
end milling up to 25 mm
cutter heads up to 75 mm
spindle mounting MK 4
throat 300 mm
16 spindle speeds 120 - 1600 rpm.
quill stroke 120 mm
3 automatic feeds 0,15 / 0,23 / 0,3 mm/rev.
table size 850 x 250 mm
max. distance spindle/table 450 mm
X x Y x Z 470 x 270 x 460 mm
drive power 2,2 kW
weight approx. 750 kg
outer...
bore capacity in steel (diameter): 30 mm
x-travel: 470 mm
y-travel: 150 mm
Distance Spindlecenter - clamping surface area, min:: 150 mm
Distance Spindle center - surface area, max:: 460 mm
distance between spindle/column: 220 mm
clamping surface area: 630x250 mm
S8wrhqxim
table-size: 800x250 mm
tool taper: MK3
quill stroke: 130 mm
spindle head swivable left - right: 2x90 °
revolution per minute: 75-3200/12Stufen-step U/min
feed - manual: Feinjustierung / precision adjustment mm
total power requi...
bore capacity in steel (diameter) 30 mm
throat 198 mm
bore stroke 75 mm
16 mm
spindle taper MK3
spindle turning speed range 95 - 2840 U/min
320 mm
190 mm
table surface area 700 x 190 mm
connected load frequency 400 V
max. distance between table and spindle-nose 55 - 405 mm
Bn0ywtumno
total power requirement 1,1 kW
weight of the machine ca. 180 Kg
dimensions of the machine ca. 0,75 x 1,05 x 1,3 m
Drilling and milling machine with
- variable spindle speed
- Digital depth display
- Left / ri...
bore capacity in steel (diameter) 30 mm
x-travel 850 mm
y-travel 435 mm
Control HEIDENHAIN TNC 150
total power requirement 16 kW
weight of the machine ca. 3500 kg
dimensions of the machine ca. m
F E H L M A N N (Switzerland)
CNC-Controlled High Precision Drilling and Milling Machine with
HEIDENHAIN CNC-Control Model TNC 150
Model PICOMAX 100 CNC 2 + A * Year 1985 Serial No. 16 085 109
_____
Table travel: Longitudinal ( X-Axis) 850 mm
Cross (Y-Axis) 435 mm
Milling/Boring head travel ver...
bore capacity in steel (diameter) 32 mm
x-travel 510 mm
y-travel 240 mm
table-size 820 x 240 mm
spindle taper MT 3
mx. distance t. milling head and table 445 mm
bore depth 130 mm
max. distance between table and spindle-nose 445 mm
turning speeds 75-3200 U/min
transmission ratio 12R/12L
head swivability 45 °
quill stroke 130 mm
230 V
total power requirement 1,1 kW
weight of the machine ca. 360 kg
dimensions of the machine ca. 920 x 740 x 1000 mm
Bjkez9cu
?solid column to avoid vibration
?ge...
ser. no. 7933, digital display FAGOR, travel X/Y/Z 410x 400 x 300 mm, speed max. 2.000 rpm, tool holder SK40, coolant system, swivelling control panel, 20 tool holders SK 40 - pos. 4
Btn8yrt77y
prec.-jig-boring & milling machine
3auljd9t
1 used, ready for use pillar drilling machine make
GILLARDON,Gemmingen, type GSB 25 with spindle adaptor MK 3,
RANGE of rotation from approx. 120 -- 2250 rpm, table size 410 x 300
mm , UNLOADING 320 mm, spindle stroke approx. 150 mm, hand feed
with scaling, lighting ! Dimensions approx. 1900 x 605 x 450 mm, installation dimension approx. around 700 mm, weight around 340 kg !
Bnvxg3pz9s
GGF: REQUEST further PHOTOS !!!
bore capacity in steel (diameter) 25 mm
throat 185 mm
bore stroke 50 mm
spindle taper MK 3
spindle turning speed range 50 - 2500 U/min
178 mm
480 mm
table surface area 700 x 180 mm
connected load frequency 230 V
total power requirement 0,75 kW
Bfitigekgu
weight of the machine ca. 160 t
dimensions of the machine ca. 0,75 x 0,8 x 0,9 m
domestic equipments
Digital depth gauge
Adjustable guides with wedges
Large 12-speed range from 75 to 3200 rpm
Smooth running due to hardened and grou...
Drilling & milling machine for metal and steel construction, prototype construction, plastics, etc.
-Machining up to 3000mm in length, longer parts in multiple voltage possible with removable side panels
-SK 40 spindle retainer
-7.5 kW driving power
-easy to use software without programming skills
-Speed continuously variable 140-2000 RPM
-10-tool changer
-Tapping up to M24
-Tool length measurement
-Handwheel
88xyvom
-Milling, drilling, Fließlochbohren, sinks, etc.
-MADE IN GERMANY
Marking ...
bore capacity in steel (diameter) 30 mm
x-travel 250 mm
y-travel 350 mm
z-axis 350 mm
table-size 240 x 800 mm
spindle turning speed - stepless 115 - 1750 U/min
spindle taper ISO 40
upper slide-adjustment 500 mm
200 -700 mm
head swivability 2 x 45 °
distance spindle /table 60 - 390 mm
feed - longitudinal/cross
total power requirement 1,5 kW
weight of the machine ca. 1050 kg
dimensions of the machine ca. 1,28 x 1,10 x 1,92 m
Coolant System
Digital Read Out
Ju90sq
distance between shaft and table: 470total power requirements: 2,2 kwweight approx.: 1,2messurements (LxWxH): Länge2400 mm Breite/Tiefe2160 mm Höhe2300 mm Gewicht 1200 kgspindle rotation speed: 60 4200 min¯¹
Nk80v
Drilling and milling machine Kudu with CNC control and tool changer (3-axis) Drilling and milling machine with movable machining unit - the table remains stationary, the drilling head moves. The automatic drilling machine can be operated manually and fully automatically. After each drilling operation, the machining unit moves fully automatically in the X and Y axes to the next drilling position. The operation is kept very simple. The data transfer to the machine control can be carried out by mea...
Milling/boring machine STANKO 2620 B
Build year: 1973
Type: 2620 B
Production No: 32428633
Table: 400 x 1600 mm
Travels XYZ : 1090 x 1000 x 1000 mm
Table load: 3000 kg
Max boring dia: 600 mm
Spindle : 12,5 rpm - 1600 rpm ( 8,3 kW )
Machine dimensions (height length width.) 3100 x 5700 x 3600 mm
Weight ~12500 kg.
Bjk2yw9cv2
Intended for sale together with other assets due to the termination of the company's business.
The price does not include transport
bore capacity in steel (diameter) 45 mm
throat 260 mm
bore stroke 120 mm
spindle taper MK4
spindle turning speed range 95 - 1600 U/min
max. milling cutter diameter 80 mm
560 mm
230 mm
table surface area 820 x 240 mm
max. distance between table and spindle-nose 475 mm
connected load frequency 400 V
total power requirement 1,1 kW
weight of the machine ca. 0,27 t
dimensions of the machine ca. 1,14 x 0,8 x 1,04 m
Domestic equipments:
automatic feed and handwheel.
Bh738z0x8a
Drill chuck with ...
Description:
Vibration absorbing cast iron construction
User friendly control panel
LED lamp
Milling head swivels 45° to the left and to the right
Automatic feed of the X and Y axis with speed adjustment
Automatic and adjustable limit stop of the X-axis
Mechanical spindle sleeve adjustment for drilling via spindle sleeve lever
Oil bath gear with ground, hardened gear wheels
Right-/left-hand rotation
Clutch for switching from manual coarse feed to manual fine feed
Large overhang of the Y-axis spi...
Bore performance 22 mm / M18
with cross table 600 x 250 mm
Adjustment boring head & table each 300 mm
Speed (stepless) 37-3600 RPM
Spindle diameter 65 mm
Overhang 300 mm
Bff7yulrlz
Table surface 320x650 mm
Spindle feed 0.02-0.04-0.1-0.12-0.25-0.6 mm/U
Taper in spindle: ACIERA attachment bracket system
Stroke quill 120 mm
Dimension (WxDxH) 90x110x185 cm
Weight 900 kg
Accessories:
1 pc. drill chuck 1-13 mm
1 pc. adapter sleeve SK30/MT1
1 pc. adaper sleeve SK30/MT2
1 pc. manual in German
Drilling and milling machines
table clamping surface 730x210 mm
Tapping capacity, steel (ST 37) M16
Drilling and milling - real added value at a favourable price
large cross table with automatic, infinitely variable feed in the X-axis for coordinate drilling and light milling operations
smooth running gear in closed oil bath - durable and robust
the high-quality milling machine spindle bearing is permanently able to withstand higher loads
the manual drilling feed can be switched to a fine feed b...
