Used Vertical Broaching Machine for sale (84,128)

Condition: used, Year of construction: 2009, Technical details: turning diameter: 1000 mm swing diameter: 1000 mm Machine type: Vertical lathe Manufacturer: Hessapp Type: DV 62 Serial no.: 14.2308 Working range of the spindle Largest diameter 1000 mm Gtodpjt Rmdzefx Admjt Largest swing diameter 1000 mm Cross slide travel Stroke of the vertical slide 900 mm Stroke of the horizontal slide 1810 mm Total travel 2315 mm Turning spindle Spindle head with centering cone according to DIN 55021 A15 Spindle diameter in the front bearing 203 mm Main drive Via a controlled asynchronous motor and gear transmission with range switching. Spindle speeds Speed ??range I: 5 - 350 rpm. Speed ??range II: 30 - 1000 rpm. Travel speed X/Z axis: 10 m/min. W1 axis: 8 rpm No C-Axis *

Condition: excellent (used), Year of construction: 2009, max. wheel diameter 315 mm gear width 280 mm max. module 8 min. module 1 Control Siemens 840 D Gedex N Ndkopfx Admjtt distance cutter centre - clamping area 20 - 245 mm distance spindle /table 190 - 470 mm diameter of hob 160 mm tangential adjustment 110 mm ical angle 45 ° min. number of teeth 4 / 8 cutter length max. 200 mm table surface area 295 mm milling spindle speeds (infinitely variable) 50 - 400 U/min total power requirement 58 kW weight of the machine ca. 8,5 t dimensions of the machine ca. 4,1 x 3,5 x 2,6 m The machine was completely overhauled by SerWeMa in 2009 equipped with a Siemens Sinumerik 840D control. Possible uses: Straight and helical gears, crowned or tapered spur gears, Worm wheels for single or multi-start worms, Worms, sprockets, ratchet wheels, splines

Condition: used, max. wheel diameter 1800 mm gear width 725 mm max. module 5 Control Siemens 840D sl axial travel 725 mm turning speed range - stepless 44 - 440 U/min cutter diameter max. 240 mm cutter width - max. 300 mm table diameter 1500 mm boring diameter 350 mm weight of the machine ca. 27 t dimensions of the machine ca. 8,8 x 6,1 x 3,25 m Equipment / Accessories: - max. distance from clamping table to counterholder/to center of milling spindle: 1045 mm - milling spindle: Gjdevyliropfx Admstt - max. axis distance between milling spindle and clamping spindle with/without counterholder: 1200 mm - min. axis distance between milling spindle and clamping spindle with/without counterholder: 525 mm - quick cutter change device - chip extraction device - milling arbors - documentation

Condition: good (used), Year of construction: 2013, operating hours: 36,163 h, functionality: fully functional, clamping force: 500 kN, screw diameter: 25 mm, warehouse no.: 503615 manufacturer: ARBURG type: Allrounder 375 V 500-170 controller: Selogica-direkt year of construction: 2013 operation hours: 36163 h clamping force: 500 kN min. mould height: 200 mm max. mould height: 550 mm max. open daylight: 302 mm opening stroke: 225 mm round table diameter: 900 mm Gsdpfx Adsx Ic Dhomstt screw diameter: 25 mm swept volume: 59 ccm injection pressure: 2500 bar equipment included: screen text german rotary table Anti vibration mounts measures of machine l x w x h: 2.524m x 1.48m x 3.53m total weight: 3111KG

Condition: ready for operation (used), Year of construction: 2004, operating hours: 20,581 h, General Data Machine weight 8000 kg Gsdpfx Ajx D In Iodmott Main Drive Number of axis 3 Spindle Speed 5000 RPM Spindle motor power 20 kW Tool taper VDI 40 Control Unit Brand SIEMENS Model 840D Power Line Movement X-Axis Movement 650 mm Z-Axis Movement 300 mm Y-Axis Movement 50 mm Technical Specification Driven Tools yes This 4-axis Gildemeister CTV 250 vertical turning machine was manufactured in 2004. It features a Siemens 840D Power Line control, a spindle speed up to 5,000 rpm, and a spindle motor power of 20 kW. The machine includes a turret with 12 tool positions, driven tools, a C-axis, and a high-pressure pump. Consider the opportunity to buy this Gildemeister CTV 250 vertical turning machine. Contact us for more information about this machine. Application Types Turning

Condition: used, Technical details: x-travel: 762 mm y-travel: 382 mm z-travel: 419 mm tool taper: Sk 40 table surface area: 1070 x 230 mm range of revolution per miute: 60 - 4.200 U/min feed continuous: 0,038/0,073/0,120 in 3 steps mm/min spindle stroke: 120 mm spindle taper: Iso 40 spindle head swivable left - right: 90 ° weight of the machine ca.: 1600 kg machine dimensions LxWxH: 1,8 x 1,5 x 2,15 m This machine is currently in the technical department. Gtjdpfx Adeva Evfomjt *

Condition: used, Year of construction: 2005, Technical details: weight of the machine ca.: 8 t dimensions of the machine ca.: 2,95 x 1,6 x 2,36 m chucking diameter: 250 mm swing diameter: 265 mm x-travel: 170 mm z-travel: 200 mm spindle turning speed range: 1.500 U/min spindle bearing diameter: 100 mm Gtsdpfeizlh Hox Admjt Pick-up machine *

Condition: used, Year of construction: 1984, max. wheel diameter 1500 mm gear width 700 mm max. module 5 Control Liebherr LH90 smallest number of teeth to be hobbed 6 milling head: Motorfräskopf milling spindle speeds (infinitely variable) 44 - 440 U/min milling head -swivable +/- 45 ° table diameter 1100 mm max. table load 8000 kg total power requirement 66 kVA Equipment / Accessories: - chip extraction device - milling arbors Gtsdpfxsvvcgtj Admot - documentation

Condition: used, Year of construction: 1954, Technical details: Gtodpfjv Ty R Dex Admet max. ram stroke: 220 mm workpiece diameter - max.: 400-450 mm total power requirement: 1,5 kW work table:: 650x250 mm ram adjustment: 100 Manuell mm no. of ram strokes: 45/78/125 table adjustment: 400 längs mm table adjustment: 150-170 quer mm table adjustment: ca. 360 vertikal mm tool - head swivelling: +/- 10 Grad total power requirement: 1,5 kW weight of the machine ca.: 0,9 t dimension machine xH: 1,2 x 0,9 x 1,8 m

Condition: used, Year of construction: 2006, Technical details: turning diameter: 250 mm swing diameter: 260 mm Available from October 10, 2025 The system consists of two individual systems that are linked together. No driven tools! * Gtodpjxc Idgofx Admjt

Condition: used, Year of construction: 2007, workpiece diameter nominal 2400 mm Gjdpsw Rf S Sofx Admett max. workpiece diameter 2800 mm max. module 30 mm control Siemens Sinumerik 840 D dividing plate diameter 2200 mm table diameter 2500 mm Table hole Diameter / depth 800 / 875 mm max. table load 40000 kg Table rpm 4,5 min-1 clamping length max. 375 mm clamping diameter max. 350 mm cutter diameter max. 2800 mm Cutter arbor cone HSK-B160 swivelling range milling head + 30/-45° Distance Cutter - Workpiece 615 / 1600 mm weight of the machine ca. 57 t Slide drives: - Feed & rapid traverse speed: - axial 4000 mm/min - radial 3000 mm/min - tangential 3000 mm/min Equitment/Accessories: - IFK2 internal milling head - Milling arbor with spacers - chip conveyor - Oil mist extraction - technical Documentation

Condition: used, Technical details: center height over bed: 260 mm workpiece dia. over bed: 500 mm workpiece dia. over support: 250 mm hobbing length: 2000 mm number of teeth: 2 - 50 feed:: 0,023 - 5,17 / mm/min module max. : 8 / 12 spindle bore diameter: 102 mm workpiece rpm : 18 - 224 U/min tailstock quill adjustment: 100 mm Gtjdpfx Adov U T Dysmjt total power requirement: 9,5 kW weight of the machine ca.: 5,2 t dimension machine xH: 3,6 x 2,1 x 2,0 m

Condition: used, Year of construction: 2013, Technical details: turning diameter: 250 mm swing diameter: 250 mm turning height: 200 mm total power requirement: 37,7 kW chuck diameter: 315 mm spindle speed max.: 5500 1/min travel -x axis: 625 mm travel -y axis: +100/-80 mm travel -z axis: 250 mm worktool system: VDI 30+40 weight of the machine ca.: 8 t The synchronous spindle is powered with 37.7 kW of power, a torque of 300 Nm Gtsdpfsvxuc Eox Admot and a maximum speed of 5,500 rpm. Typical components are ball cages, ball hubs, gear wheels, sliding sleeves, pump wheels, flanges, synchronizer rings, bearing rings and pivot pins. The machine bed is made of Hydropol, a mixture of special concrete and steel, which ensures the greatest smoothness and precision even with larger components and powerful machining. *

Condition: used, Year of construction: 2001, grinding length 4200 mm Gtodpfx Aethumujdmet grinding width 1300 mm workpiece height 550 mm Control Siemens 840D passage width 1300 mm electro-magnetic table 4200 x 1300 mm grinding height 550 mm grinding motor 306 kW grinding motor turning speeds up to 370 U/min grinding motor feed, infinitely variable 0,5-35 m/min coolant flow rate 2000 l/min weight of the machine ca. 50 t dimensions of the machine ca. 11,21 x 5,25 x 3,85 m Equipment / Accessories: - segment head - diameter 1400 mm - for segment dimensions 120/106 x 41 x 250 mm - number of segments: 1 set = 26 pieces - grinding motor adjustment - in steps: 0,002 - 1 mm - continuous: up to 5 mm/min stepless

Condition: used, Year of construction: 1976, Technical details: table surface area: 1300 x 190 mm range of revolution per miute: 60 - 4000 Stufenlos U/min feed continuous: Pinole: 0,06 / 0,12 / 0,24 mm/U quill stroke vertical: 140 mm spindle taper: SK 40 spindle head swivable left - right: 90° und 45° ° Gsdpju Sq Emjfx Admett total power requirement: 3,0 kW weight of the machine ca.: 1620 kg machine dimensions LxWxH: 2,7 x 2,3 x 2,4 m Milling machine with universal milling head Spindle run right/left Table specifications: X/Y/Z travel: 860/380/460mm. feed X/Y/Z: 40 - 400mm/min. continuous rapid traverse 400mm/min. max. workpiece weight 30kg Equipment 3-way measuring display Mitutoyo with beam machine lighting Coolant tank with pump X- and Y-axis feed adjustable incl. accessories comparable to the picture *

Condition: used, Year of construction: 2002, Technical details: max. wheel diameter: 130 mm gear width: 170 mm max. module: 3 min. module: 0,5 total power requirement: 48 kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 7,64 x 3,14 x 3,25 m Godpfswdyx Ujx Admstt For technical data, see PDF-File enclosed *

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm max. module 20 mm tip circle diameter 350 mm Gtedpfxjw Rrb Hs Admet Milling arbour diameter 375 mm Total closing value 80 kVa weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation

Condition: used, Technical details: x-travel: 880 mm y-travel: 300 mm z-travel: 900 mm w-axis: 60 mm spindle head swivable left - right: 60 ° table surface area: 880 x 300 mm machine weight approx.: 1200 kg dimension machine xH: 1,3 x 1,4 x 1,9 m Gsdpfeu Ndfhex Admjtt incl. accessories *

Condition: used, Year of construction: 2002, Technical details: max. wheel diameter: 200 mm gear width: 250 mm max. module: 3 min. module: 0,5 total power requirement: 45 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 4,4 x 2,4 x 2,7 m Gedpsx Iumnefx Admstt Machine out of prototype production Without automation *

Condition: used, Year of construction: 2007, turning diameter 1400 mm swing diameter 1600 mm turning height 500 mm Workpiece length - Bore grinding 300 mm Workpiece length - Turning 500 mm control Siemens Sinumerik 840 D work piece spindle speed range 0-400 U/min boring diameter 100 - 500 mm total power requirement ca. 185 kW weight of the machine ca. 35 t With grinding spindle Table strokes: - Z1/Z2 axis 1000 mm - X1/X2 axis approx. 1400 mm Table speed infinitely variable: - Z 0 to 30 m/min Gtodpew Rf Slofx Admjt - X 0 to 60 m/min - Workpiece spindle flange diameter 520 mm - Infeed speed 0.01 - 15 mm/min Equipment/ Accessories - Grinding spindle - Kaiser dresser - Tool measuring probe - Filter system - With flushing nozzle connections - 2 Capto holders - 1 set of jaws for chuck - documentation

Condition: used, Year of construction: 2015, Technical details: turning diameter: 200 mm swing diameter: 260 mm turning height: 60 mm Gjdpeq Sc Husfx Admjtt

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 130 mm max. module: 3 total power requirement: 15 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2,3 x 2,5 x 2,17 m A well-preserved CNC hobbing machine Vertical for shafts and wheels With tailstock Also suitable for hard milling (good for steering pinion) Rapid traverse radial, axial: 10.000 mm/min Rapid traverse tangential: 7.500 mm/min Max. wheel diameter 130 mm Max. module 3 mm Tangential slide travel 200 mm Radial slide travel 10 / 100 mm Axial slide travel 300 / 200 mm Milling head speed 250-3500 U/min Milling head -swivable +/- 40 ° Tool diameter 80 mm Tool length - max. 240 mm Table turning speeds 5 - 1000 U/min Gjdpfxewv Uhbs Admjtt Milling spindle drive 15 kW Feed range mm/min Table diameter 132 mm Control Sinumerik 840 C Connected load 40 kVA Motor output 15 kW Weight : 6 T Dimensions 2300 mm * 2500 mm * 2170mm Accessories : Hydraulical workpiece clamping Automatic loading system Magnetic chip conveyor *

Condition: used, Technical details: Gtedpfx Adswx Shkemot honing diameter: 4-31 mm stroke: 350 mm throat: 250 mm

Condition: used, Year of construction: 2016, Technical details: total power requirement: 55 kW weight of the machine ca.: 13 t Godpfxsxy I Exe Admott We offer you 21 x EMAG complete € 50.000 free loaded new EMAG is around € 500.000 *

Condition: used, Year of construction: 2002, Technical details: turning diameter: 200 mm turning height: 120 mm weight of the machine ca.: 18 t Available from 01.08.2024 Gtedpjr Dwpmsfx Admot *
