Used Hob Sharpening Machine for sale (63,882)

Condition: used, Year of construction: 2008, grinding diameter 160 mm dist. between centers 645 mm centre height 320 mm control SIN 840D turning speeds 27.000 U/min x-axis 550 mm y-axis 235 mm z-axis 300 mm A - axis 360 ° C-axis 270 ° Ffsdoxxbzdopfx Afnju total power requirement 20 kW

Condition: good (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 4059, Specifications Manufacturer KLINGELNBERG Model SNC 30 Year 1989 Fodevu Digjpfx Afnsfu Condition Used Serial Number 4059 Stock Number AF1534 Min-max diameter 0 - 300mm Sharpening depth 90 mm Min-max helix angle 45° Max wheel slide stroke 550 mm Min-max wheel diameter 150 - 300 mm Wheel revolutions 2700 giri/min Description Equipment Arbors Wheels other accessory Manual instructions

Condition: ready for operation (used), Year of construction: 1986, operating hours: 1,200 h, functionality: fully functional, total height: 1,520 mm, total length: 2,580 mm, total width: 1,440 mm, workpiece weight (max.): 200 kg, spindle speed (max.): 2,600 rpm, spindle speed (min.): 1,500 rpm, feed length X-axis: 2,120 mm, feed length Y-axis: 250 mm, feed length Z-axis: 150 mm, type of input current: AC, grinding wheel diameter: 250 mm, overall weight: 3,730 kg, grinding length: 280 mm, rotational speed (min.): 1,500 rpm, rotational speed (max.): 2,600 rpm, center height in crank: 115 mm, center height: 115 mm, collet bore: 55 mm, grinding spindle speed: 2,600 rpm, feed rate X-axis: 12 m/min, pivoting range: 45 °, travel distance X-axis: 2,120 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 150 mm, center width: 280 mm, grinding spindle motor power: 3,000 W, table length: 2,800 mm, table width: 250 mm, power: 6.5 kW (8.84 HP), height adjustment type: mechanical, workpiece diameter (max.): 235 mm, grinding diameter: 250 mm, input frequency: 50 Hz, disc diameter: 250 mm, input voltage: 380 V, space requirement width: 1,440 mm, space requirement length: 2,580 mm, space requirement height: 1,520 mm, grinding wheel speed: 2,100 rpm, distance table to spindle center: 362 mm, tool diameter: 235 mm, workpiece length between centers: 280 mm, distance between centers: 280 mm, Hob Sharpening Machine 33C (ZZS) 3A662 (Gear hobbing cutter grinding machine) The 33C (ZZS) model 3A662 is a specialized hob sharpening machine designed for precise sharpening and regrinding of gear hobs and gear cutting tools. Manufactured by 33C (Soviet Union), this machine is intended for industrial tool rooms and gear manufacturing facilities requiring reliable accuracy and repeatable grinding quality. Fodpfex Nprbjx Afnefu The machine is suitable for sharpening hobs with a maximum diameter of 235 mm and a maximum length of 280 mm. It supports hobs with 4 to 30 flutes and allows grinding of straight and helical flutes with a helix angle range from 0° to 45°, covering a wide range of gear cutting applications. The grinding spindle is designed for grinding wheels with diameters from 200 to 250 mm. Spindle speed is adjusted via step pulleys and offers four speed stages: 1500 / 1900 / 2100 / 2600 rpm, ensuring flexibility for different tool sizes and materials. The machine is equipped with a dividing mechanism and supplied with a complete set of change gears, allowing accurate indexing during the sharpening process. A hydraulically driven table provides smooth longitudinal movement and stable grinding conditions. With overall dimensions of approximately 2580 × 1440 × 1520 mm and a machine weight of about 3730 kg, the 3A662 features a rigid and robust construction, providing excellent vibration damping and long-term operational stability. The machine operates on three-phase AC power (380 V / 50 Hz) and is supplied with original factory documentation. Key Features: *Specialized hob sharpening machine *Max. hob diameter: 235 mm *Max. hob length: 280 mm *Number of flutes: 4 – 30 *Helix angle range: 0° – 45° *Grinding wheel diameter: 200 – 250 mm *Grinding spindle speeds: 1500 / 1900 / 2100 / 2600 rpm *Hydraulically driven table *Dividing mechanism with full set of change gears *Rigid industrial construction (approx. 3730 kg) *Original technical passport and manual (Russian) Typical Applications: *Sharpening and regrinding of gear hobs *Maintenance of gear cutting tools *Tool room operations in gear manufacturing *Repair and refurbishment of worn hobs *Small- and medium-series gear production support

Condition: used, Sharpening machine for circular saws/rip saws IDL000829 - manufacturer: IMW Fedpfjvlczvjx Afnsfu

Condition: new, Year of construction: 2025, The ZM101 is a pioneering product in our lineup, designed to sharpen sawblades with widths of up to 100 mm at a remarkable rate of 65 teeth per minute. This efficiency enables it to simultaneously service 3-4 bandsaw/sawmill machines. Equipped with an abrasive ceramic disk, the ZM101 can expertly sharpen all teeth with profiles. Its robust construction allows it to perform reliably under the most demanding conditions, making it a favorite among our customers. Additionally, its straightforward design ensures ease of use and low maintenance costs, further enhancing its appeal. Technical characteristics: Maximum length of the blade: 6000 (8000) mm Minimum width of the blade: 20 mm Maximum width of the blade: 100 mm Maximum height of the tooth: 12 mm Front angle of the tooth: 0÷25° Tooth pitch: Profile N: 10, 12.5, 15, 20, 25 mm Profile WM: 22, 25 mm Working capacity: 65 teeth/min Size of the abrasive disc: Cut-in sharpening, profile N: ø200 x 10 x ø32, ø200 x 13 x ø32 mm Ffsdpfexliguex Afneu Profile sharpening, profile WM: ø200 x 8 x ø32, ø200 x 10 x ø32 mm Voltage: 380 V Power of the electric motors: 0.09 and 0.37 kW Size: Without band saw holder (L x W x H): 750 x 550 x 1100 mm With band saw holder (L x W x H): 2000 (3000) x 1000 x 1100 mm

Condition: new, Year of construction: 2025, The ZM101 is a pioneering product in our lineup, designed to sharpen sawblades with widths of up to 100 mm at a remarkable rate of 65 teeth per minute. This efficiency enables it to simultaneously service 3-4 bandsaw/sawmill machines. Equipped with an abrasive ceramic disk, the ZM101 can expertly sharpen all teeth with profiles. Its robust construction allows it to perform reliably under the most demanding conditions, making it a favorite among our customers. Additionally, its straightforward design ensures ease of use and low maintenance costs, further enhancing its appeal. Technical characteristics: Maximum length of the blade: 6000 (8000) mm Fsdexlfwpopfx Afnofu Minimum width of the blade: 20 mm Maximum width of the blade: 100 mm Maximum height of the tooth: 12 mm Front angle of the tooth: 0÷25° Tooth pitch: Profile N: 10, 12.5, 15, 20, 25 mm Profile WM: 22, 25 mm Working capacity: 65 teeth/min Size of the abrasive disc: Cut-in sharpening, profile N: ø200 x 10 x ø32, ø200 x 13 x ø32 mm Profile sharpening, profile WM: ø200 x 8 x ø32, ø200 x 10 x ø32 mm Voltage: 380 V Power of the electric motors: 0.09 and 0.37 kW Size: Without band saw holder (L x W x H): 750 x 550 x 1100 mm With band saw holder (L x W x H): 2000 (3000) x 1000 x 1100 mm

Condition: new, Year of construction: 2024, functionality: fully functional, This powerful machine to meet the requirements of larger woodworking companies, ensuring exceptional sharpening results. Equipped with an electronic tooth counter and an autonomous cooling system. The ZM150 offers precise sharpening while maintainingoptimal operating conditions. With two electric motors, including a 150mm CBNdisk for sharpening and a motor reduction group for precise blade movement,this sharpener delivers outstanding performance. Power supply voltage - 380-400V Frequency - 50Hz Power - 0.20kVa Ffodpfx Afoxiv Ugsneu Capacity - 65 teeth per min Blade width - 20 to 100 mm Tooth pitch - 6 -25mm Sharpening disc - Profiled 150mm CBN disc Weight - 115kg

Condition: good (used), Year of construction: 1989, overall weight: 1,050 kg, tooth pitch: 120 mm, total width: 1,850 mm, total length: 1,550 mm, total height: 1,800 mm, saw blade diameter: 800 mm, grinding wheel diameter: 175 mm, input voltage: 380 V, type of input current: three-phase, saw blade bore: 10 mm, saw blade width: 16 mm, input frequency: 50 Hz, We offer this good Vollmer Finimat beta sharpening machine, year of construction 1989. Use of one grinding head in combination with two diamond wheels for face and top. Triple chip tooth configuration can be ground in one revolution of sawblade. Saw blade diameter: 100-800 mm Bore size minimum: 10 mm Tooth pitch: 8-120 mm Blade thickness maximum: 16 mm Rake angle range: -20 to +30 degrees Top clearance angle range: +5 to +25 degrees Ffsdpfxox Saw Tj Afneu Bevel angle (face) range: 0 to +15 degrees Bevel angle (top) range: 0 to +45 degrees Tooth height differential range: 0 to 1 mm Grinding wheel outer diameter options: 175 or 125 mm Grinding wheel bore diameter: 50.8 mm Maximum circumferential speed: 34 m/s Minimum circumferential speed: 25 m/s Voltage: 380 V Phase: 3 Frequency: 50 Hz Total connected load: 4.6 kW Machine width: 1850 mm Machine depth: 1550 mm Machine height: 1800 mm Net weight: 1050 kg Available April 2026 If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: CHD 251R2, grinding wheel diameter: 200 mm, input current: 380 A, We offer this excellent condition Vollmer CHD 251R2 ND300 saw-blade sharpening machine. The CHD 251 R2 automatic grinding machine with ND 230 Robot system as a service for fully automatic machining with 5 bay loading. Year of construction 2002. Manufacturer: Vollmer Werke Maschinenfabrik GmbH Fodpfx Aex R Eydsfnsfu Model: CHD 251R2 ND300 Year of manufacture: 2002 Serial number: 575 Available Now If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2009, Machine-Details: Stock-No. 1022-2352 Type of machine Gear Hobbing Machine - Horizontal Make MONNIER & ZAHNER Type KOEPFER MZ 120 Year of manufacture 2009 Type of control CNC Storage location Monheim (Germany) Country of origin Switzerland Delivery time Immediately Freight basis Ex warehouse, loaded on truck Technical details: max. wheel diameter 2-45 mm gear width 250 mm max. module 1,5 mm min. module 0,5 mm Control Fanuc 18i-MB weight of the machine ca. 2,2 t dimensions of the machine ca. 2100 x 1440 x 1700 m Additional information: The combined CNC gear hobbing and worm milling machine KOEPFER MZ 120 is characterized by its flexible usability and is used in the small module area. Just by swiveling the milling spindle from the horizontal to the vertical position and selecting the corresponding operating mode of the CNC control, the worm milling machine becomes a gear hobbing machine and vice versa. CNC control Fanuc 18i-MB (Dialog/ISO) CNC axes = X-axis plunge axis Z-axis longitudinal axis C-axis workpiece spindle B-axis tool spindle V-axis loader axis longitudinal A-axis swivel axis tool spindle head (included as an option) Y-axis shift axis (included as an option) With the following production programs: Worm milling Hobbing Worm hobbing Bevel gear and spur gear milling Bevel gear hobbing Milling cycles = straight, oblique, crowned toothing, radial, radial-axial, co- and counter-rotating milling, roughing, finishing, worm gears, straight-toothed bevel gears, face gearing (option only in the partial process) Worms [Equipment] Coolant tank 300 liters KF with LNS Turbo MS 250 Chip conveyor, built in 2021!!! Kraft and Bauer fire extinguishing system Spiral conveyor Machine documentation [Technical data] Workpieces: Fodpfx Afeyhc Daensfu Workpiece diameter 2-45 mm Max. workpiece length 250 mm Tooth length 150 mm Max. module in steel= 1 mm (gear hobbing) 1.5 mm (worm milling) 0.5 mm (bevel gear hobbing) Tools: Cutter diameter= 16-32 mm (gear hobbing) 40-63 mm (worm milling) Machine: Max. setting angle of milling head= +/- 45° (gear hobbing) +/- 30° (worm milling) Shift travel= 34 mm (manual adjustment) 34 mm (CNC axis) Collet/retraction mandrel W 20 Max. speed of workpiece spindle 770 rpm. Milling spindle drive 0.55 kW Max. milling spindle speed 8000 rpm Axis drives = X-axis (plunging) / travel 80 mm via CNC Z-axis (longitudinal feed) / travel 190 mm via CNC C-axis (workpiece axis) via CNC Rapid traverse = X-axis 6000 mm/min. Z-axis 6000 mm/min. Hydraulic unit 0.37 kW

Condition: ready for operation (used), max. wheel diameter 150 mm gear width 1 - 200 mm max. module 4 min. module 1 control Sinumerik 840 D Ffedsvzhg Nspfx Afnsu table diameter 140 mm maximum axial offset 200 mm milling tool taper ISO 40 diameter of hob max. 130 mm cutter length max. 220 mm milling spindle speeds (infinitely variable) 300 - 1200 U/min shifting max. 170 mm milling head -swivable +/- 45 ° feed speeds 1 - 1500 mm/min rapid travel speed 3000 m/min max. workpiece diameter im Magazin: 150 mm total power requirement 50 kW weight of the machine ca. 8,5 t dimensions of the machine ca. 4,7 x 3,6 x 2,6 m Used gear hobbing machine, Pfauter, new in 1992 completely overhauled in 2023 by the specialist company SerWeMa, with Siemens Sinumerik 840 D control system and workpiece magazine.

Condition: used, max. wheel diameter 40 mm gear width 45 mm Fjdpfx Ajyh Rmgsfnofu max. module 1 clamping length max. 75 mm number of teeth 5 - 399 hob turning speeds 320 - 3200 U/min weight of the machine ca. 0,6 t Fully Automatic Gear Hobber with Loader for small gears

Condition: used, max. wheel diameter 40 mm gear width 45 mm max. module 1 clamping length max. 75 mm number of teeth 5 - 399 hob turning speeds 320 - 3200 U/min weight of the machine ca. 0,6 t Ffsdpfx Afeyh Rmaensu Fully Automatic Gear Hobber with Loader for small gears

Condition: used, max. wheel diameter 35 mm gear width 22 mm max. module 1 Buntmetall min. module 0,01 Fjdeyh Rl Aopfx Afnofu total power requirement 5 kW weight of the machine ca. 0,6 t dimensions of the machine ca. 0,9x0,8x1,7 m

Condition: used, max. wheel diameter 35 mm gear width 22 mm max. module 1 Buntmetall min. module 0,01 total power requirement 5 kW Fodpfx Aeyh Rlvefnsfu weight of the machine ca. 0,6 t dimensions of the machine ca. 0,9x0,8x1,7 m

Condition: ready for operation (used), thread length: 3,000 mm, Thread milling and hobbing machine Maximum spindle bore: Ø 80 mm Depending on the travel, max. Ø 250 mm and min. Ø 20 mm are possible. Fsdpfxjv Huihj Afnefu Machining length: 3000 mm With accessories: change gears, steady rest For further technical data, see the PDF file.

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 200 mm gear width: 60 mm max. module: 7 weight of the machine ca.: 15 t table diameter: 180 mm Ffjdpfx Afexc E H Senju table turning speeds: 100 U/min hob turning speeds: 750 U/min Machine in good condition, without feed, without automation Available 24.08.2024 *

Condition: good (used), Year of construction: 1975, max. wheel diameter 630 mm gear width 425 mm table hole 125 mm clamping table 550 mm max. module 10 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm main drive motor 7,5 kW total power requirement 22,5 kVa weight of the machine ca. 8,2 t Ffodpsw A Am Sofx Afnsu Machine equipment: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder - Magnetic chip transport --> Working range Largest module to be milled (in steel 600 N/mm²): 10 mm --> Straight gear teeth: --> Largest workpiece diameter: 630 mm --> Largest axial slide travel (Z-axis): 425 mm --> Smallest number of teeth to be milled: 8 --> Dimensions Diameter of workpiece table: 550 mm --> Diameter of table bore: 125 mm --> Diameter of workpiece mandrel: 36 mm --> Largest milling cutter that can be clamped: --> Diameter: 192 mm --> Width: 220 mm --> Diameter of milling cutter mandrels: 32 mm --> Centre distance between milling cutter and workpiece: --> Maximum distance: 425 mm --> Minimum distance: 50 mm --> Drive taper for cutter mandrels: Morse taper 5 --> Maximum cutter displacement: 200 mm --> Speeds and feeds Cutter speeds: 45 - 280 rpm --> Axial feed (Z axis): 0.40 - 6.30 mm/rev --> Radial feed (X axis): 0.10 - 1.60 mm/rev --> Tangential feed (Y axis): 0.14 - 2.24 mm/rev Translated with (free version)

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 27506, Complete overhaul in 2009 CNC gear hobbing machine Pfauter PE 150 Serial number: 27 506 Year of manufacture: 1991 – complete overhaul in 2009 CNC control: SINUMERIK 840 D Fodpfextpg Rox Afnofu

Condition: excellent (used), max. workpiece diameter 600 mm threading length 7000 mm max. module 8 / 12 min. module 1 swival range ° diameter of hob 63 - 140 mm spindle turning speed - stepless 45 - 450 U/min Fedswgizdjpfx Afnofu weight of the machine ca. 12,5 t dimensions of the machine ca. 9,0 x 2,0 x 2,2 m Condition: In good condition, checked and partially overhauled by a specialist. The existing milling head was replaced by an overhauled universal milling head. Furnishing: Differential for inclined machining Automatic indexing device (indexing discs changeable!) For multi-wedge, multi-thread parts, then extensive bushings, support rollers and around 70 Change gears. Conversion of the milling head speed to a frequency converter with corresponding powerful motor is a great thing and saves a lot of set-up time. Equipment: Around 70 change gears, 3 bushing sticks of different sizes, around 20 Bushings, 2 roller mountings, 2 tips for direct mounting on the Clamping spindle, 350 mm chuck, 2 spare part disks.

Condition: used, Technical data: available upon request Fedolf H Tyspfx Afnsfu

Condition: used, Clamping length: 65 mm Tool arbor: 35 mm Fedpfx Afsw Nv Aronsfu Tool grinding machine with coolant pump. After setting the correct grinding angle, the tool is ground using manual/linear feed.

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 130 mm max. module: 3 total power requirement: 15 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 2,3 x 2,5 x 2,17 m A well-preserved CNC hobbing machine Vertical for shafts and wheels With tailstock Also suitable for hard milling (good for steering pinion) Rapid traverse radial, axial: 10.000 mm/min Rapid traverse tangential: 7.500 mm/min Max. wheel diameter 130 mm Max. module 3 mm Fedpewv Uhbsfx Afnofu Tangential slide travel 200 mm Radial slide travel 10 / 100 mm Axial slide travel 300 / 200 mm Milling head speed 250-3500 U/min Milling head -swivable +/- 40 ° Tool diameter 80 mm Tool length - max. 240 mm Table turning speeds 5 - 1000 U/min Milling spindle drive 15 kW Feed range mm/min Table diameter 132 mm Control Sinumerik 840 C Connected load 40 kVA Motor output 15 kW Weight : 6 T Dimensions 2300 mm * 2500 mm * 2170mm Accessories : Hydraulical workpiece clamping Automatic loading system Magnetic chip conveyor *

Condition: used, Year of construction: 2002, Technical details: Ffodpfx Afox Ea Ipsnou max. wheel diameter: mm gear width: mm weight of the machine ca.: 7000 kg dimensions of the machine ca.: 9130 x 3895 x 3450 mm max. top circle diameter: 80 mm max. length of teeth cutting: 170 mm Total length: 240 mm taper diameter: 32 mm slide travel radial ( X-axis ): 100 mm slide travel tangential ( Y-axis ): 160 mm axial movement Z-axis: 300 mm/min workpiece spindle - bore: 45 mm electr. connected load: 44 kVA

Condition: used, Technical details: Ffedpfx Asx H Swbofnju max. wheel diameter: 46 mm max. module: 1 weight of the machine ca.: 0,5 t
