VOORTMAN V304

VOORTMAN V304

Year of construction: 2013, condition: good (used),  Plasma cutting and extraction table, dimensions 2.500 x 6.000 mm. Nedpfxetp Dhpj Ad Nowb  Gantry bridge.  Carriage with servo-drives (to position the gantry bridge in X-direction).  Machine track, length 8 m.  HEB450 profiles for the foundation of the machine track, 8 m.  Plasma cutting unit Hypertherm HPR 400XD, 1 pcs.  Plasma bevel cutting unit, including automatic height control system.  Fume extraction unit Filtercube 4H for plasma cutting unit.  Oxy-fuel cutting torch, 3 pcs.  Automatic height control system IHT M4000 CAP for oxy-fuel cutting unit, 3 pcs.  Torch suspension for oxy-fuel torch (motor driven).  Torch suspension Single Drive for oxy-fuel torch, 2 pcs (automatic torch positioning).  Laser pointer (to align and position the torch).  Computer control system (consisting of an industrial PC and a control panel).  Control software 'VACAM Machine Edition' (including VaCad and VaNest software and online support).  Automatic nesting software Sigmanest "Powerpack" (including 3 days of training for max. 3 persons at Voortman Holland (excluding travel costs and board and lodging) and 1 day online-support).  Emergency stop with stop cord.  Year of build: 2013.

Condition: good (used), Year of construction: 2007, DRILLING MACHINE Operating range V630/1000M Min. / max. height 10 – 450 mm Min. / max. width 60 – 1.050 mm Max. positioning weight 9.000 kg Number of drilling units 3x Automatic tool changer 3x (3x 5 positions) Height measuring Included Width measuring Included Machine weight 12.000 kg Roller feed measuring system Max. speed 42 m/min Min. infeed length 1.500 mm Drilling unit VD40 Feed and positioning servo-motors with servo-invertors Spindle rpm Stepless 100 – 2.500 rpm (servo-motors) Lubrication Internal by mist of air / oil Holder SK 40 Drill diameter oil-tube-drills 8 – 40 mm Drill diameter carbide drills 13 – 32 mm Thread tapping M8 – M24 Centre point marking possibility Yes, 3 sides SAWING MACHINE Sawing machine VB1050 Capacity (h x w) 0° 500 x 1.130 mm Capacity (h x w) +/- 15° 500 x 1.060 mm Capacity (h x w) +/- 30° 500 x 925 mm Capacity (h x w) +/- 45° 500 x 725 mm Capacity (h x w) +/- 60° 500 x 470 mm Saw band speed stepless 40 – 120 m / min Saw drive motor 7,5 kW Njdpfx Ajvpafyed Nswb Saw band dimensions 9.550 x 54 x 1,6 mm Hydraulic band tension 48.000 N Machine weight +/- 8.500 kg

Condition: good (used), Year of construction: 2017, V304 plate processing machine (including 1 gantry beam(s) of 6.500mm and side trucks) ◼ This V304 plate processing machine is capable of processing plates up to 3.050mm x 18.000mm for bevel plasma cutting and marking (needle marker, if attached) and 4.100 x 18.000 mm for oxy-fuel cutting and marking (needle marker, if attached) ◼ X-rail (21.000mm on both sides of the machine, including double linear guides, helical rack and pinion system and rubber covering band) ◼ Plasma cutting and extraction table (4.300mm x 18.720mm, 2 channel(s), 1 pcs, suitable for ≥ 350A cutting) ◼ Position 1: Plasma cutting unit Kjellberg SmartFocus400 (1 pcs, automatic gas console, complete with cutting parameter database) ◼ Plasma 3D bevel unit (1 pcs, including 5 NC-axis, Voortman height control, intelligent torch positioning system and 3D collision sensor, for x- ,y- , k- and v-weld preparations) ◼ Driven suspension (1 pcs, servo motor driven, including laser pointer) ◼ Dross inhibitor (1 pcs, including 1,2L reservoir) ◼ Arc Glare protection (1 pcs) ◼ Position 2: Plasma cutting unit Kjellberg SmartFocus400 (1 pcs, automatic gas console, complete with cutting parameter database) ◼ Plasma 3D bevel unit (1 pcs, including 5 NC-axis, Voortman height control, intelligent torch positioning system and 3D collision sensor, for x- ,y- , k- and v-weld preparations) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Dross inhibitor (1 pcs, including 1,2L reservoir) ◼ Arc Glare protection (1 pcs) ◼ Position 3: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) Njdpfxevpalas Ad Newb ◼ Position 4: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Position 5: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Cables high instead of low ◼ Donaldson fume extraction unit DFO 4-48 - 200L (incl. frequency controller) ◼ Air conditioning for switch panel (up to an ambient air temperature of 55°C) ◼ Hardware and software (includes VACAM ‘Machine Edition’, VACAM ‘Office Edition’, VACAD editor software module, VANEST nesting software, Layout marking software module, online support) ◼ Post processor for SigmaNEST (SigmaNEST is provided by the customer) ◼ Safety devices (safety bumpers, emergency stop cord)

Condition: excellent (used), Year of construction: 2012, Voortman V613 / VB1050 Split System CNC Drilling / Sawing Line – Year 2012. Rotating Spindle. Automatic Tool changer. 24 metres In-Feed to VB1050. 24 metres Out-Feed to V613 CNC Drilling line. 24 metres Out-Feed. Roller Feed. Nwjdpfxsv U Ea Hj Ad Nob VACAM CNC Control. Short piece removal.

Condition: used, Year of construction: 2019, CNC portal plasma cutting machine Manufacturer: Microstep Model: MasterCut Compact 4001.20Ptk Year of manufacture: 2019 CNC control Working area: 2 x 4 m Nodpsxnmbnsfx Ad Newb '”MasterCut” plasma rotator with fully automatic support for weld seam preparation 1 plasma torch with Kjellberg HiFocus 280i power source TEKA filtration system ä21126

Condition: used, Year of construction: 2017, CNC gantry plasma cutting machine (bevel unit) with oxy-fuel torch Manufacturer: Zinser Model: 2425-I/3600 Year of manufacture: 2017 Nwjdpfx Asw Rpvbod Neb CNC control: 5010 Rail length: 11 m Burning table with oscillating conveyor system, including extraction system Dimensions: 2,000 x 8,000 mm 1 plasma torch with Hypertherm XPR300 power source automatic gas console incl. automatic rotating plasma bevel unit Bevel System 2015/350 1 oxy-fuel torch Filtration system Downflow 3DFP9-SP Power: 9 kW Laser diode 21126ä

Condition: good (used), Year of construction: 2018, 1 used welding fume extraction unit Manufacturer: Kemper System: 8000 Year of manufacture: 2018 Technical specifications Filter Number of filter stages: 1 Filtration method: self-cleaning filter Filter cleaning process: rotary nozzle Filter area: approx. 10 m² Number of filter elements: 4 Total filter area: 40 m² Filter type: cartridge filter Nodpfx Aewxpxysd Nswb Filter material: ePTFE membrane Separation efficiency: > 99.99% Dust class: M Basic data Extraction capacity: 3,500 m³/h Dimensions (W x D x H): 962 x 1,413 x 2,110 mm Weight: 590 kg Motor power: 3 kW Rated voltage: 3 x 400 V / 50 Hz Rated current: 6.5 A Sound pressure level: 65 dB(A) Compression force F: 6 N Additional information Fan type: radial fan, belt-driven Compressed air supply: 5–6 bar Air outlet: 355 mm Air inlet: 355 mm Dust collection container capacity: 34 L Technical data subject to change/errors excepted.

Condition: used, Year of construction: 2023, CNC Gantry Plasma Cutting Machine with Rotator Manufacturer: Microstep Model: MasterCut 6001.30PtkG Year of manufacture: 2023 CNC control system Working area: 3,000 x 6,000 mm 1 plasma torch with Kjellberg Q3000 power source 1 oxy-fuel torch GCE FIT+ three (cutting gas: acetylene) Burning/cutting table with sectional extraction, 6,000 x 3,000 mm Plasma rotator "MasterCut" with fully automatic support ACTG automatic calibration unit for the bevel cutting assembly Kemper extraction system 8000 (year 10/2015) Asper Basic 2D programming software + Asper BevelCut for bevel cutting programming Other technical data: MicroStep machine control with MMI console and 24" touchscreen iMSNC Expert System module iMSNC module for automatic calibration of mechanical probing iMSNC module assistant for loading CNC programs LCD operating unit on the gantry Njdpfexu U Ddex Ad Njwb Laser pointer with automatic offset transfer USB 3.0 ports for storage media MicroStep RemoteDiagnostics remote maintenance module Grate cover in the cutting table Reinforced version of the cutting table Connection of high-precision plasma source to CNC control Control of automatic gas console Electrical and mechanical torch sensing LED signal tower on the gantry bridge (2 colors) Tactile shutdown device for guide rails Light barrier safety system (collision protection) for the gantry bridge with emergency stop Smart Z Movement ACTG Calibration Report Fully automatic oxy-fuel torch support Automatic gas console for oxy-fuel torch (cutting gas acetylene) Active collision protection

Condition: good (used), Year of construction: 2011, CNC Gantry Flame Cutting Machine Manufacturer: Microstep Model: MasterCut-AM 9001.20 Year of manufacture: 2011 CNC Control: iMSNC with integrated network card Working area: 2,000 x 9,000 mm Extraction table 1 oxy-fuel torch Cutting thickness up to 150 mm 1 Kjellberg plasma marking unit Laser pointer Technical details: 1x oxy-fuel torch (fully automatic) 1x plasma marking unit (fully automatic) Kjellberg Finsterwalde Nodpfxsudn Rzj Ad Nswb MicroStep® CNC machine control iMSNC with integrated network card LCD operator units on the gantry Laser pointer with automatic offset transmission iMSNC control parameter database / Windows® Programming system "AsperWin-Basic" for direct programming on the machine control Module macro library "AsperWin Select" NC Simulator module "AsperWin NC-Sim" "Plasma Marking" module (for scribing) via plasma source "THC" module / Automatic height control via arc voltage USB 2.0 connection for storage device Remote diagnostics module MicroStep® "iFDS Win" Remote maintenance access via TeamViewer Central gas control via proportional valves Parameter database for 1 torch Energy supply cables Gas hoses for heating oxygen, cutting oxygen Acetylene machine cutting torch RHÖNA-Acetylene FIT+ 1 capacitive height control IHT / for oxy-fuel 1 RHÖNA-Acetylene electric ignition unit Double-sided cable protection (collision safety) for the gantry bridge via emergency stop Kjellberg® plasma marking unit FineMarker Fully automatic support for FineMarker Kjellberg® plasma labeling system FineMarker CNC interface for FineMarker / integration into the CNC control Module for automatic actuation of the marking device

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, type of input current: three-phase, input voltage: 400 V, total width: 4,780 mm, total length: 8,200 mm, table length: 6,400 mm, table width: 2,167 mm, travel distance X-axis: 2,000 mm, travel distance Y-axis: 6,000 mm, space requirement width: 6,380 mm, Number of cutting heads: 1 Number of drilling heads: 1 Table length: L [m] 6 Nsdpfx Aswhk E Hod Nowb Table width: WT [m] 2 Channel width: WCH [m] 0.8 Cutting machine with cutting table and sectional extraction: 1 USB flash drive (USB 2.0): 1 Basic tool station type R (A, B-axis for MG): 1 Remote diagnostics: 1 AsperWin – Basic module: 1 AsperWin – Nesting module: 1 AsperWin – Bevel cutting module: 1 AsperWin – Pipe cutting module: 1 AsperWin – Bevel cutting module (SolidSel): 1 Remote control for filter unit: 1 Connection of the filter unit to the power distribution unit: 1 Power distribution unit for the system: 1 Integration of the plasma source into the CNC system HPR, HD, HT, HF FF: 1 MG-22 drilling head, max. drill bit 22 mm, max. tap bit 16 mm, 5.5 kW, Y- and Z-axis 1 Cooling system – ecological cooling system for the drill bit 1 ISO 40 6-tool clamping magazine for automatic tool change linear PMB6 1 RSV 100-500 HHP pipe cutting device 1 880 mm grating for duct cover, 1 m long 6 RSV 100-500 HHP support rollers on rails 2 1 m rails for support rollers with 2 rails 7 Chuck for square pipes up to 500 mm in diameter, 4 jaws 1 Signal light 1 DFPRO 8; ART501/9 kW; 6000 m3/h [15-3x3.5-2 m - 1x] [15x1.5 m - 2x] 1 HPR260 Automatic 1
