Used Vtl Cnc Dorries for sale (8,563)

Condition: ready for operation (used), chuck outer diameter: 6,000 mm, controller model: Siemens/Heidenhain, empty load weight: 220,000 kg, Type: SD 600/6500 4 assen gerichte, kogelomloopspindels tussen kolommen: 6500 mm maximaal hoogte onder dwarsbalk: 4270 mm verticale beweging van de dwarsbalk: 2500 mm maximaal gewicht op tafel: 160 ton Gedpfx Ajwaiuqjfnsbh koppel van de tafel: 30.000 MKP, 200 PK Verticale beweging van Z1 Z2: 1750 mm Twee onafhankelijke schaarliften aan elke kant van de draaibank, met bedieningseenheid Max turningdia -- passage: 6500 mm Power on the spindle: 200 HP Max hight of workpiece Z-axis: 4270 mm Number of speeds: 1 > 40 rev/min Long: 20 500 mm Wide: 8500 mm Height: 6290 mm (above ground-level)

Condition: good (used), Year of construction: 2011, Ref. -No.: 10622 Manufacturer: BLANSKO Type: SKD 50 Year of construction: 2011 Type of control: CNC Control: SIEMENS SINUMERIK 840 D Storage location: Halberstadt Country of origin: Germany Z - stroke: 1950 mm Turning Height: 4130 mm Faceplate Diameter: 4770 mm Swing Diameter: 5300 mm Max. Load on the face plate: 100000 kg Traverse path of the crossbar: 3600 mm Adjustment speed of the crossbar: 500 mm / min Further information: Pickup magazine with 8 tool holder positions Automatic clamping of the tool holder in the ram 1x straight boring head 1x 90° angle head (not in the pickup magazine) 1x set of jaws The machine can be inspected under power. Gedpfxjyagiqj Afnsbh

Year of construction: 1981, condition: excellent (used), Dorries CNC Vert. boring mill single column with displaceable table - Make : Dörries - Germany - Typ : CTE 320 / 3400 - Age : 1981 – Ex. Aerospace ! - Serial.No : D 149 / 5079 - Chuck Ø : 3.200 - Max. turning Ø Pos. 2: 5.100 - Max. turning height : 2.650 - Stroke Tool holder : 1.250 - Crossrailadjustment : 1.500 - Table load : 60.000 - Tool shank size : 40 x 40 - Max. cutting power : 75000 - Max. torque on table : 60000 - Power main motor : 75 kW / 415 - Speeds 1 / 2 / 3 Range: 0,8 – 100 Gedpfjkwcpxsx Afnebh - Feeds Vario : 0,1 – 1.000 - Rapid Feed : 6.000 - Dimensions: 9,30 X 6,10 X 6,30 X 60 - CNC Siemens Sinumriek System 8 - Tool changer 16 positions - SCR Feed drives / each Axis own - Ballcrews + Slide roller guideways - Displaceable table hydraulic / manuel - Circular interpolation Please Note: The above information has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details

Condition: good (used), Year of construction: 1998, CNC Vertical lathe DS Dorries Scharmann - VCE 2000 FMC MACH-ID 9088 Godpswb Ayiofx Afnjbh Make: DS Dorries Scharmann Type: VCE 2000 FMC Control: SIEMENS 840C Year: 1998

Condition: new, Year of construction: 2026, Vertical Turning center SCR 50 2S Turning Center’s Specifications Nominal Turning Envelope Faceplate Diameter 4.500 mm Machining Diameter Godpfjhh Dnxex Afnebh Optional 4.700 mm – with the CE Enclosure - 5.300 mm ( without ) Machining Heights 2.100 mm /3500 mm Work Piece Weight 30.000 kg / 50T Nominal Turning Travels X & U - Axis Ram Carriage From -100 mm To 2.600 mm Z and W - Axis Ram 1.250 mm / 1700 mm Faceplate Diameter 4.500 mm/Normal face plate with T-slots Jaw chucks height 200 mm Work Table Speed: 0-50rpm Power Continuous S1 96 kW / 2X75kW Torque Continuous S1 130,000 Nm / 320,000Nm Turning main drive mechanism Gear box reducer ZF and belt transmission Z & W - Axis Ram Turning Ram - Left and Right side Ram Size 250 by 250 mm or bigger Tool holder type KM 63 Tool Storage (ATC) No. of Tool storage 2 Tool Storage, left and right sides Stations qty 12 stations per each tool storage Stations type Turning toolholder ATC turning capabilities: Maximum Singular Tool Weight – turning toolholder Maximum tool weight 50 kg Maximum tool size 250 x 150 mm X 700 mm Axes Drives X and U - Axes Ram Carriage Power Continuous S1 6.5 kW Thrust Continuous S1 45,000 N Z-Axis Ram Power Continuous S1 6.5 kW Thrust Continuous S1 45,000 N Axes Rates X, U And Z, W-Axes Feed Rates 0.02 to 6,000 mm/min X, U And Z, W-Axes Rapid Rates 6,000 mm/min Coolant System Coolant Tank Capacity 2,000 L Coolant Pressure / Flow Rate: -external coolant (turning) -internal Filtration unit: -type -accuracy 6 bar at 100 LPM 40 bar at 60 LPM Chips conveyor Conveyor type Hinged (Hardox material) Width The conveyors should have a width of 600 mm CNC Control -type -producer Sienumerik One Siemens / Fanuc oiF

Year of construction: 2016, operating hours: 7,000 h, condition: as good as new (ex-display), machine/vehicle number: 0012, Technical data: 1. Capacities - Maximum turning diameter with either Vertical Head 3300 mm - Maximum machining height under Cross Rail, at least 2000 mm - Maximum weight of the workpiece 20 tons 2. Table - Table diameter 3000 mm - Speed (inf. Variable) 1- 110 RPM - Main motor drive (AC) 100 KW - 4 jaw chuck with reversible jaws 3. Vertical Heads - Straight Ram vertical travel (250X250 mm cross section) 1300 mm - Horizontal and Vertical travel by means of 10 mm pitch ball screws 4. Cross Rail - Vertical Travel 2000 mm - Cross Rail elevating motor 7.5 KW AC 5. Feeds - Feed ranges 0.1 – 5 mm/rev - Rapid traverse feed 8000 mm/min 6. Overall Sizes - Dimensions (approx.) L x W x H 6600 x 5.300 x 5.400 mm - Weight (approximate) 60 tons Gbjdsdpdfzepfx Afneh GEOMETRICAL TESTS (ISO 3655, ISO 230-1; VDI 3441 and ISO 230-2) Positioning accuracy -X and Z axes mm +/-0,015/1000 Positioning repeatability -X and Z axes mm 0,010 CNC Fanuc

Condition: excellent (used), Year of construction: 2014, table diameter: 1,600 mm, workpiece diameter (max.): 2,000 mm, overall weight: 25,000 kg, CNC Vertical lathe YOUji - VTL1600ATC+C Control: FANUC 18i-TB Year: 2014 Gbjdpfeyimptsx Afnoh Driven tooling Bt-50 with 2400 Rpm 8000 Kg Table load 4 heavy duty jaws Box Slideway structure Chip conveyor Oil Chiller Coolant system Tooling package optional Automatic lubrication Max. turning Ø: 2000mm Table Ø: 1600mm Horizontal movement support: 1015mm Stroke ram left: 800mm ATC / revolver: 16 Single column or double column:single Speeds / ranges: 250Rpm Power: 45kW Maximum turning height: 1200mm C-Axis: 360000° Power live tools: 11kW Chip conveyor: Yes Length: 4500mm Width: 5500mm Height: 5800mm Weight: 25000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Technical details: faceplate diameter: 5000 mm swing diameter: 6100 mm Godpfsw Rz U Ajx Afnjbh turning height: 2400 mm ram stroke each side: 1490 mm ram head dimension: 340 x 340 mm max. workpiece weight: 100.000 kg total power requirement: 100 kW weight of the machine ca.: 155 t faceplate turning speed range: 0,4 - 50 U/min with 2 x 2 axes CNC SIEMENS 840 D *

Condition: used, Technical details: faceplate diameter: 1000 mm swing diameter: 1600 mm turning height: 1200 mm main drive: 75 kW faceplate speeds from - to: 7 - 800 U/min milling motor: 25 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 cross rail adjustment - vertical: 800 mm ram head dimension: 240 x 240 mm weight of the machine ca.: 40 to dimensions of the machine ca.: 9 x 7,8 x 6,0 m Machine general overhould in 2004 and equiped with Siemens 840 D control - tool changer rack magazine - C-axis, live tooling, - Transmit function electronical Y-axis - angular milling head - complete splash housing - coolant device, chip conveyor Gbedpfx Aevb Dcasfneh *

Condition: used, Technical details: Godsvb Dcmspfx Afnobh faceplate diameter: 1400 mm swing diameter: 2000 mm turning height: 1270 mm main drive: 80 kW faceplate speeds from - to: 1 - 355 U/min max. workpiece weight: 6.000 kg milling motor: 37 kW milling head speed: 7 - 3000 U/min milling spindle - taper: ISO 50 cross rail adjustment - vertical: 800 (8 x 100 mm) mm ram head dimension: 240 x 240 mm max. ram stroke: 1250 mm weight of the machine ca.: 50 to total power requirement: 133 kVA dimensions of the machine ca.: 11 x 5 x 6,4 m Machine general overhould in 2008 and equiped with CNC SIEMENS 840 D control - tool changer for 72 tools - C-axis, live tooling - angular- and straight tool holder head with CAPTO taper - Transmit function - complete splash housing - coolant device, chip conveyor - diverse accessories *

Condition: excellent (used), Dorries CTE 140 Retrofit CNC Siemens 840C Table Diameter: 1420 mm Swing: 2000 mm Height Under Rail: 2450 mm X – Horizontal Travel: 1041 mm Gjdpfxoyilbze Afnjbh Z – Vertical Slide Travel: 1600 mm With jaws, turret, and grinding support Weight: 20 tons Excellent condition!

Condition: used, Year of construction: 1990, turning diameter 2400 mm faceplate diameter 2200 mm turning height 2100 mm control SIEMENS Sinumerik 850T workpiece weight 17 t Tol measurements 32 Werkzeuge Crossbeam travel: 700mm Crossbeam support Travel from centre of rotation to the right: 700mm Crossbeam support Travel from centre of rotation to the left: 700mm Machine table drive Main drive power: 80kW Number of gearboxes: 2 Step change: 3.84 Speed range of the 1st gear stage: 2-32-139 rpm Speed range of the 2nd gear stage: 9-125-500 rpm Max. Machine table load: 6 tonnes Feed drive Gbodpfx Afsygx D Hsnsh Cross beam support Horizontal feed speed: 0.1 - 8 m/min Cross beam support Vertical feed speed: 0.1 - 8 m/min Cross beam support Rapid traverse speed horizontal/vertical: 8 m/min Cross beam adjustment speed: 425 mm/min Tool system Tool system: 180.1 Cutting force on the turning tool: 30 kN

Condition: good (used), Year of construction: 1982, functionality: fully functional, Single-column vertical turning lathe | Dörries VCE 1400 The machine was overhauled in 2010 by Hering, has recently been cleaned, and is in good condition. - Table diameter: 1,000 mm - Swing diameter: 1,400 mm - Turning height: 1,100 mm - Siemens CNC control type 840 D Shop Turn - Tool changer - X-axis travel: 2,000 mm - Z-axis travel: 700 mm - Slide adjustment: 1,000 mm Gbsdpfx Afsyft Nnonjh - Rapid traverse: 6,000 mm/min - Spindle speed: 500 rpm - Handwheel - Total power requirement: 62 kW Inspection possible at any time by appointment. #Tags: Doerries | VCE1400 | Dörries VCE

Condition: used, Year of construction: 1981, faceplate diameter 3200 mm swing diameter 5100 mm turning height 2505 mm cross rail - adjustment 1500 mm max. ram stroke 1250 mm slide adjustment 2000 mm control Siemens 8 T tool changer 16 STK table load 60 t faceplate turning speed range -stepless- 0,8-100 U/min feed 0,0 mm/min rapid traverse 6000 mm/min drive of main spindle 75 kW weight of the machine ca. 70 t dimensions of the machine ca. 9,3 x 6,1 x 6,0 m machine is in an excellent condition!! with div. acessories (photos available) machine can be equipped with latest electrics and Siemens CNC control SINUMERIK 840D sl for additional costs. Gbjdpfxju Sbdgo Afnsh

Condition: reconditioned (used), Year of construction: 2019, functionality: fully functional, type of input current: three-phase, total width: 2,450 mm, total length: 4,000 mm, input voltage: 400 V, input current: 32 A, feed length X-axis: 2,000 mm, feed length Y-axis: 1,800 mm, feed length Z-axis: 50 mm, working width: 1,700 mm, CUTTEC CNC Cutter Variocut with oscillating cutting tool, tool head with tangential axis. Cutting is performed on a cutting mat; material is fixed in place using a 7.5 kW vacuum system. Item location: 32105 Bad Salzuflen. Gbodoyi T Swspfx Afnjh

Condition: new, Discover the ultimate power and precision of our vertical lathe series. With its robust construction and proven technology, it delivers groundbreaking results for your machining projects. Experience the limitless possibilities of our CNC variant and take your production to the next level. Gbjdpfjd I I Ilex Afnsh TECHNICAL MAIN DATA (CNC MODEL): - Max. swing diameter: 1500/1800/2750/4000/5000 mm - Max. turning diameter: 1250/1600/2500/4000/5000 mm - Max. workpiece height: 1000/1600/2000/2000/2000 mm - Spindle motor power: 30/37/55/75 kW - Table diameter: 1000/1250/2250/3600/3600/4500 mm - Max. table speed: 500/400/120/63/63/50 rpm ACCESSORIES: Fanuc or Siemens control, ZF gearbox, chip conveyor, lubrication system, hydraulic system, machine guard, air gun, tricolor lamp, work light, chip cart, foot pedal, standard tool holder. SPECIAL ACCESSORIES: C-axis, tool magazine, linear scale, tool presetter, workpiece probe, electrical cabinet air conditioner, special tool holder, and more. For further details, please refer to the attached PDF file. TECHNICAL MAIN DATA (CONVENTIONAL MACHINE): - Faceplate diameter: 1000|1400|1800|2000|2300 mm - Swing diameter: 1200|1600|2000|2300|2600 mm - Turning height: 1000|1250|1400|1600|1500 mm - Table speed: 6.3-200|5-160|3.2-100|5-160|2.5-80 m/min - Gear stages: 16 - Max. workpiece weight: 3.2|5|8|8|8 t - Main motor power: 22|30|37|37 kW - Approx. machine weight: 9|14|18|23|21 t ACCESSORIES: Tool holder: 5-fold; Faceplate: with 4 jaw clamps; Servo motors: for axis adjustment, and more. For further details, please refer to the attached PDF file. Conventional vertical lathe with solid and proven technology, power, and precision for the machining of heavy workpieces. - Optimal loading - easily accessible with crane and forklift - Vertical support with 5-fold tool holder and side support (optional) with separate feed for internal and external machining - Heavy-duty column construction with wide, hardened guides - Hydraulic clamping of the crossbeam - Stable guide construction provides excellent stability and accuracy to the vertical arm - The spindle runs in a highly precise double-row roller bearing and is adjustable - The drive is through a reduction gear for high torque and a speed range of 2.5 - 80 min- Warranty: 12 months on the machine Now get a 15% energy subsidy from BAFA when replacing an old machine! Also benefit from the favorable leasing and hire purchase conditions of our leasing partners. Ask us about it. Of course, you also receive free delivery, assembly/commissioning, and ready-to-use handover as well as control training from us. The special net price displayed refers to the smallest model of the conventional series. The images show the CNC variants as well as a conventional version.

Condition: excellent (used), DOERRIS SCHARMANN Manual Pendant Machine Hand Pendant Gbodpfx Afow Iqz Tonoh Machine Control System

Year of construction: 2017, condition: excellent (used), 4 CNC lathes including automation and tooling. Gedpfxeyaa Nws Afnjbh Year of manufacture: 2017, 2012, 2010, and 2008

Year of construction: 1978, condition: ready for operation (used), A Dörries CNC vertical turning lathe is available. Faceplate diameter: 1600mm, turning diameter: 1800mm, turning height: 1500mm, max. travel: 1200mm, faceplate speed: 200rpm. Machine dimensions X/Y/Z: approx. 8400mm/4500mm/5300mm, weight: approx. 25000kg, control system: R&D. The machine’s electrical system and control were completely overhauled in 2010 by R&D Steuerungstechnik. Documentation available. An on-site inspection is possible. Gbodpfxjxq Ex Ds Afnjh

Condition: ready for operation (used), Year of construction: 1993, swing diameter 1400 mm faceplate diameter 1500 mm Control Sinumerik 850T work height max. 1400 mm Gsdpfx Afsvxa Tpjnebh Tool changer 12 stck. workpiece weight 5 t YEAR OF CONSTRUCTION: 1993 Mechanical overhaul: 2010

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, 1 FPT SIRIO 8 milling machine from 1998 – CNC HEIDENHAIN TNC 430 X 8000 Z 2000 Y 1200 Rotary table 1500 x 1500 – travel 2000 Admissible weight 10 t Automatic head with 144 positions – speed 3000 rpm – 37 kW ATC with 60 positions – ISO 50 Chip conveyor Good working condition Gedpfox Nh Ubjx Afnjbh

Condition: good (used), Year of construction: 2014, center height: 180 mm, center width: 600 mm, grinding diameter: 260 mm, Sinumerik 840D sl cnc control tail stock measuring device diamant roll portal loading device Technische Daten / technical details: Spitzenweite / center to center 600 mm Gjdpsvygwwefx Afnobh Spitzenhöhe / center height 180 mm max. Schleifdurchmesser / max. grinding diameter 260 mm Schleifscheibenmaß / grinding wheel dimension 600x80x304,8 mm Reitstock / tail stock MK4 Antriebsleistung Schleifspindel / drive capacity grinding wheel 12 kW Gewicht der Maschine / weight 7500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 2010, Ref. -No.: 10530 Manufacturer: DöRRIES - SCHARMANN Type: Alpha 1000 Year of construction: 2010 Type of control: CNC Control: Siemens SINUMERIK 840 D Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 2000 mm Z-Travel: 2000 mm A-Axis: 0 - 90 x 0,001 ° B-Axis: 360 x 0,001 ° Number of T-slots: 1 + 8 Max. Workpiece Weight: 5000 kg T - groove width: 22 mm T - slot spacing: 100 mm T-Slots: DIN 650 mm Tool Taper: HSK - A 100 Tool Piece Magazine With: 207 + 10 Pcs./pcs. Max. Torque: 1250 Nm Feed Speeds X/Y/Z Axis: 1 - 30000 mm / min Rapid Travel X/Y/Z: 30,00 mm / min Drive Capacity - Spindle Motor: 45 kW Total Power Requirement: 100 kW Dimensions Of The Machine Ca.: 13 x 8 x 4,5 m Size Of Pallet: 2 x 1000 x 1000 mm Spindle speed gear stage 1: 1 - 1096 1 / min Spindle speed gear stage 2: 1096 - 6000 1 / min Further information: - Measuring probe Gbsdpfxjycpxto Afnsh - Chip conveyor - Coolant system - Coolant through the spindle - Pallets with 5-way media connection and clamping hydraulics - Extraction system - Swivel spindle A-axis 0 - 90 - NC rotary table B-axis

Year of construction: 1993, condition: ready for operation (used), Vertical lathe machiningcenter Dörries Scharmann Type: VCE 2000/160 Pallet size: 1.600 mm Pallet load: max. 8.000 kg Number of pallets 13 pcs Gbjdpfx Afegulkionjh Table indexing C-Axis 0.001° Table cross travel (X) 2.300 mm Column longitudinal travel (Z) 1.500 mm Crossbeam positions: 9 steps off 100 mm Feed X/Y/Z 1 – 6.000 mm/min. Rapid X/Y/Z 8 m/min. Max rotary diameter 2.000 mm Max workpiece height 1.500 mm Main Spindle Spindle drive motor: 69KW Spindle speed: 2.8 – 315 rpm ATC 70 pots - system 240.2 Live spindle – SK50 Spindle drive motor: 30KW Spindle speed: 10 – 1500 rpm CNC controller Siemens Sinumerik 880M Accessories FMS 13 pallets Rotary loading stations 2 pcs Coolant unit with filtration system Coolant through spindle Machine weight Approx 40T. Build year 1993 (2/2)

Year of construction: 1993, condition: ready for operation (used), Vertical lathe machining centre Dörries Scharmann type: VCE 2000/160 Gsdsguk S Sspfx Afnjbh Pallet size: 1.600 mm Pallet load: max. 8.000 kg Number of pallets 13 pcs Table indexing C-Axis 0.001° Table cross travel (X) 2.300 mm Column longitudinal travel (Z) 1.500 mm Crossbeam positions: 9 steps off 100 mm Feed X/Y/Z 1 – 6.000 mm/min. Rapid X/Y/Z 8 m/min. Max rotary diameter 2.000 mm Max workpiece height 1.500 mm Main Spindle Spindle drive motor: 69KW Spindle speed: 2.8 – 315 rpm ATC for turning 59 pots - system 240.2 Live spindle – SK50 Spindle drive motor: 30KW Spindle speed: 10 – 1500 rpm ATC for SK50 61 pots CNC controller Siemens Sinumerik 880M Accessories FMS 13 pallets Rotary loading stations 2 pcs Coolant unit with filtration system Coolant through spindle Machine weight Approx 40T. Build year 1993
