Used Traub Td 36 for sale (99)

Condition: good (used), Machining diameter max: 36 mm Maximum spindle speed: 6300 rpm No. of Spindles: 2 Controller: Traub TX8i Toolchanger 1: No. of tools: 12 positions X-axis travel: 50 mm Z-axis travel: 50 mm Toolchanger fronside: No. of tools: 7 positions Speeds: 150 - 3000 Rpm 300 - 6000 Rpm Max. diameter: 40 mm X-axis travel: 370 mm Hedpfx Aotrvzxsh Honw Z-axis travel: 250 mm Toolchanger backside: No. of tools: 5 Speeds: 150 - 3000 Rpm 300 - 6000 Rpm Max. diameter: 40 mm X-axis travel: 73 mm Barfeeder: FMB Turbo 5-42 Barlength: 3200 mm Bardiameter: 5 - 42 mm Country of origin: Germany Machine LxWxH: 3400 x 1300 x 1700 mm Machine weight: 4000 kg

Condition: good (used), Year of construction: 2001, TNK 36, year of manufacture 2001 including chip conveyor, Resy filtration system Hnodpfexv Sr Ijx Ah Hjw In good condition, operated without loader, not under power

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, machine/vehicle number: 5318, spindle bore: 26 mm, spindle speed (max.): 4,750 rpm, TECHNICAL DETAILS Max round diameter: 26 mm Max square size: 18 mm Max hexagon size: 22 mm Spindle power: 2.2 kW Number of spindles: 4 Spindle bore: 26 mm Speeds: 1,180 – 4,750 rpm Tool holder: 6 slots MACHINE DETAILS Length L -- R: 1,800 mm Width F -- B: 1,000 mm Height: 1,400 mm Weight: 800 kg Hnjdpfswtq Urex Ah Hew Total power: 3.2 kW Operating voltage: 380 V 50 Hz

Condition: good (used), Year of construction: 1989, 1 x automatic lathe Traub TD 16 year of manufacture: 1989 with hydraulic single-bar feed LNS Hydrobar 3.16 -HS 4.4 Year of construction: 1989 Equipment: 6-fold star turret Material quick clamping. Long turning device Central lubrication Vogel Accessories: see photos The machine can be inspected under power. Hnedpfxevga A To Ah Hjw

Condition: excellent (used), Year of construction: 1991, Multi-spindle & bar turning machines TRAUB TD 26 1991 * Spindle power 2.2 kW * Number of spindles 4 * Spindle bore 26 mm * Speeds 1.18 > 4750 mm * Total power 3.2 kW * Length L - R 1800 mm * Width V - H 1000 mm * Height 1400 mm * Weight 800 kg * Tool changer 6 tools Additional information * Max. round: 26 mm, max. square: 18 mm, max. hexagon: 22 mm * Hodpfx Ahowc Aqwj Henw * Bar loader available

Year of construction: 1986, condition: ready for operation (used), Turning diameter over bed/face slide: 360mm/160mm, center distance: 800mm, travel X/Z: 205mm/810mm, speed: 3150rpm, spindle bore: 60mm, tool positions: 8, rapid traverse X/Z: 10m/min. Machine dimensions X/Y/Z: approx. 3300mm/1800mm/1800mm, weight: approx. 3300kg, control: Traub System TX-8. An on-site inspection is possible. Hnsdpfx Ahswmqx Ds Hjw

Condition: used, Year of construction: 1983, functionality: limited functionality, turning diameter over cross slide: 160 mm, turning length: 800 mm, spindle bore: 60 mm, travel distance X-axis: 205 mm, travel distance Z-axis: 810 mm, rapid traverse Z-axis: 10,000 m/min, rotational speed (max.): 3,150 rpm, total height: 1,800 mm, total length: 1,800 mm, total width: 3,300 mm, swing diameter over cross slide: 160 mm, turning diameter over bed slide: 360 mm, overall weight: 3,100 kg, Technical details: TRAUB TND 360 (1983) Rotation diameter over bed: 360 mm Rotation diameter over cross slide: 160 mm Turning length: 800 mm Longitudinal stroke (z axis): 810 mm Axial stroke (x axis): 205 mm Control: TX-8 Spindle clearance: 60 mm Speed: 63 - 3150 / 2 steps rev. Feed:: 10,000 mm/min. Turret head - number of stations: 8 Tailstock holder ISO: SK30 DIN 2080 Tailstock quill stroke: 105 mm Working pressure: 40 bar Total power requirement: 38 kW Machine weight approx.: 3.1 tons Hnjdpfswm Dhxex Ah Hsw Machine dimensions approx. L x W x H: 1.8 x 3.3 x 1.8 m Hydraulic system dimensions: 580 x 400 x 750 mm Equipment Lathe chuck Ø 200 mm (without jaws), hydraulic

Condition: used, Year of construction: 1988, Technical details: turning diameter over bed: 360 mm turning dia. over face-slide: 160 mm turning length: 800 mm longitudinal traverse (z-axis): 810 mm facing movement (x-axis): 205 mm control: TX-8 spindle passage: 60 mm revolution per minute: 63 - 3150 / 2 step U/min feed:: 10.000 mm/min. tool turret - number of stations: 8 operating hours - idle run: 8834 h tailstock taper ISO: SK30 DIN 2080 tailstock quill stroke: 105 mm operating pressure: 40 bar total power requirement: 38 kW Weight approx.: 3,1 t dimension machine xH: 1,8 x 3,3 x 1,8 m dimensions of hydaulic: 580 x 400 x 750 mm Equipment: Hnedju Rqabjpfx Ah Hsw Lathe chuck Ø 200 mm, hydraulic Feed force Z-axis = 8 kN and X-axis = 5 kN Coolant system control panel Accessories Fine adjustment device for tool set-up *

Condition: excellent (used), manufacturer: GRÜN SYSTEMTECHNIK WETZLER including case We offer an original ATC measuring microscope, originally taken from a TRAUB TNA turning center. The unit is designed for installation in the automatic tool changer and can be used on various CNC machines with a suitable toolholder interface (size comparable to TRAUB TNA400 Key Features & Benefits: • Universal application: Suitable for any CNC machine with compatible toolholder interface. Hodpfjxwx N Aex Ah Hsnw • Fast tool setup: Enables direct measurement of cutting edges, tool lengths, and radii inside the machine. • Process reliability: Tool wear can be identified immediately and corrected without removing the tool. • Precise referencing: Useful for checking zero points, bores, and fixtures directly in the setup. • Time savings: Eliminates the need for external presetting devices and reduces downtime. • Compact & robust design: Easy to integrate and operate within the tool changer system. This ATC measuring microscope turns your CNC machine into a precise measuring station, helping you achieve higher accuracy, shorter setup times, and improved process reliability.

Condition: like new (used), Year of construction: 2022, operating hours: 13,116 h, Max. bar capacity mm: 20 Max. Z-axis travel (sliding headstock/fixed headstock) mm: 205 / 80 Max. spindle speed rpm: 10,000 Drive power 100%/40% duty cycle kW: 3.0 / 5.5 Torque 100%/40% duty cycle Nm: 5.73 / 10.5 / max. 17.2 C-axis resolution degrees: 0.001 Max. rapid traverse Z m/min: 20 Tool stations: 8 Driven tools: 8 Max. tool speed rpm: 12,000 / 8,000 Tool holder diameter mm: 45 Drive power 100%/40% duty cycle kW: 1.0 / 2.0 Turning tool cross-section mm: 16x16 / 20x20 Slide travel X mm: 120 / 165 Slide travel Y mm: ±25.4 Slide travel Z mm: 254 / 567.5 Rapid traverse X/Y/Z m/min: 20 / 20 / 40 B-axis swivel angle degrees: 105 Lower turret: Tool stations: 8 Driven tools: 8 Max. tool speed rpm: 12,000 Tool holder diameter mm: 45 Drive power 100%/40% duty cycle kW: 1.0 / 2.0 Turning tool cross-section mm: 16x16 / 20x20 Slide travel X mm: 120 Slide travel Y mm: ±25.4 Slide travel Z mm: 155 Rapid traverse X/Y/Z m/min: 20 / 20 / 40 Back working device: Tool stations: 4 Slide travel X/Y/Z mm: 120 / ±25.4 / 155 Tool holder diameter mm: 25 Sub spindle: Max. spindle bore mm: 20 Max. spindle speed rpm: 10,000 Drive power 100%/40% duty cycle kW: 3.0 / 5.5 Torque 100%/40% duty cycle Nm: 5.73 / 10.5 / max. 17.2 Slide travel X mm: 235.5 Slide travel Z mm: 258 C-axis resolution degrees: 0.001 Rapid traverse X/Z m/min: 20 / 40 Coolant system basic unit: Pump pressure bar: 3 / 8 Tank capacity l: 250 Hodpfx Ahewuddvj Hsnw Flow rate at 3 / 8 bar l/min: 80 / 120 Filtration degree µm: 200 Machine dimensions Length x width x height mm: see installation plan* Weight kg: 5,000* Connected load kW: 40 (47 kVA)

Condition: used, Year of construction: 2001, turning diameter 340 mm turning length 750 mm control SYSTEM TX 8H spindle passage 80 mm swing over plan sled 530 mm greates pass round over bed 665 mm turning speed range - main spindle 3.150 min/-1 drive capacity - main spindle 22 kW number of tool places 12 Pos. In our assessment, the machine is in good used condition and can be inspected under power by appointment. Two machines are available. Price per unit. Machine 1: - Images 1-5 - Operating hours approx. 55,790 h Machine 2: - Images 6-10 - Operating hours approx. 54,347 h Technical Features & Accessories: - Y-axis - Accessory package with rigid and driven tool holders - Chip conveyor Hsdpfx Ahjxwdw Ee Honw Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in the technical data and specifications, as well as prior sale!

Condition: excellent (used), Year of construction: 1996, operating hours: 46,282 h, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, total height: 2,600 mm, total length: 11,000 mm, total width: 2,000 mm, overall weight: 6,000 kg, controller manufacturer: TRAUB, controller model: TX 8F, counter spindle speed (max.): 4,000 rpm, number of slots in tool magazine: 10, - Includes two 10-position tool turrets with driven tool stations - Includes HAINBUCH chuck system - Includes sub-spindle, bar feeder (manufacturer: STAMAG) - Includes chip conveyor TECHNICAL DATA: - Operating voltage: 400 V - Frequency: 50 Hz - Control voltage: 230 V - Rated current: 85 A - Connection: 54 kW - Connected load: 39 kW - Noise emission value at operator position: 71 dB(A) Ambient conditions: - Temperature: 5 – 40°C - Air humidity: max. 70% - Workpiece removal via sub-spindle - Max. sub-spindle speed: 4000 min-1 - Max. workpiece diameter: 56 mm - Programming: EIA and ISO code Input and output resolution: - X/Z: 0.001 mm - C axis: 0.001° - Rapid traverse: max. 15 m/min - Fine interpolation cycle: 0.34 ms - Largest thread pitch: 999.999 mm - Largest radius: 99,999.999 mm - Feed override: 0…200% - Rapid traverse override: 0…100% - Speed override: 50…120% - Speed input: 5 digits - Cutting speed input: 4 digits - Tool input: 4 digits - Program number: 8 digits - Subprogram number: 8 digits - Block number: 4 digits - M-functions: 3 digits - B-functions: 6 digits - Memory capacity: 32,000 characters - Tool correction pairs: 40 NUMERICALLY CONTROLLED TURNING AND POSITIONING UNIT (C AXIS): Main spindle: Hnjdpfxewpa Ruj Ah Hjw - Max. speed: 80 min-1 - Torque at 100% duty cycle: 100 Nm - Accuracy: +/- 3 min Sub-spindle: - Max. speed: 80 min-1 - Torque at 100% duty cycle: 30 Nm - Accuracy: +/- 3 min TOOL CARRIER 1 & 2: - Driven tools per tool carrier: 10 (14) - Max. speed: 4000 (8000) - Power at 100% duty cycle: 1.5 kW - Power at 15% duty cycle: 4 kW - Torque at 15% duty cycle: 12.4 (4) Nm - Tool holder/tool carrier quantity: 10 (14) - Cylindrical shank as per DIN 69880: Ø 30 x 55 (25 x 48) mm - Chisel cross-section: 20 x 20 (16 x 16) mm - Chip-to-chip time (per VDI 2852): 1.2 s - Switching time one station: 0.6 s - Over 5 stations: 1.5 s SUB-SPINDLE (NUMERICALLY CONTROLLED IN Z DIRECTION): - Max. speed: 4000 min-1 - Max. clamping diameter: 65 mm - Three-phase motor steplessly programmable: 11 kW - Torque: 210 Nm - Feed force at 100% duty cycle: 6000 N - Feed travel: 520 mm - Ball screw operation: Ø 32 x 10 mm HYDRAULICS: - System pressure: 60 bar - Tank capacity: 150 l COOLANT LUBRICATION: - Per tool carrier: 1-stage centrifugal pump - Pump pressure: 5/12 bar - Tank capacity: - without chip conveyor: 300 l - with chip conveyor: 280 l NOTICE: Due to sporadic work, the operating hours may still change slightly.

Condition: excellent (used), Year of construction: 1990, Control: CNC contouring control including color screen TRAUB TX 8 D TECHNICAL DATA Swing diameter over longitudinal slide: 560 mm Swing diameter over cross slide: 445 mm Turning diameter: 360 mm Turning length: 1000 mm Chuck diameter: 250/315 mm Spindle bore: 80 mm Hsdpfx Aswfrhwsh Hjnw Drive power: 40 kW Speed range: up to 40 - 3150 rpm Tool carrier: Number of turrets: 1 Number of tool holders: 14 Z-axis: 1070 mm X-axis: 285 mm Tailstock: -Quill diameter: 100 mm -Quill stroke: 100 mm EQUIPMENT/ACCESSORIES Hollow clamping cylinder -Tailstock including live center -Coolant system: 300 l, 2-stage pump 1.5/5 bar  Chip conveyor  Central lubrication (with VOGEL piston distributor)  Measuring arm for measuring tools in the work area  Machine light  Three-jaw power chuck ø 250 mm FORKARDT 1512577 including clamping jaws  Mounting elements  Documentation

Condition: good (used), Year of construction: 2004, control TRAUB SYSTEM TX8H weight 3500 kg range L-W-H 3960 x 1640 x 1800 mm output 11 kW number of spindle speeds 5600 / 4000 min-1 Torque 200 / 280 Nm The TRAUB turning machine TNA 300 was designed for the following machining of workpieces with a turning length of 450 mm. --> for machining metal and plastics with a defined cutting edge using suitable tools. --> for mounting in jaw chucks of sizes 160 to approx. 250 --> for machining material bars up to a Ø of 42 or 65 mm --> with EHS special version Workpiece removal device --> chip conveyor 800 mm long -> Technical data Working range Spindle diameter: 42 mm --> Spindle head DIN 55026, size: A5 --> Clamping fixture diameter: 160-175 mm / 200-250 mm --> turning diameter max: 275 mm --> Distance over turning centre: 35 mm --> max. turning length: 450 mm --> Swing diameter over cross slide: 395 mm --> Swing diameter over bed: 520 mm --> Tool carrier Tool holders for cylindrical shank DIN 60880: 12 pcs. --> Shank diameter: 30 mm --> Chisel cross-section: 20x20 mm --> Switching time 1 station: 0.5 sec. Hnjdpfxjwwl Ius Ah Hjw --> Switching time each additional station: 0.15 sec. --> Feed drives X-axis: --> Slide travel: 210 mm --> Feed force: 5000 N --> rapid traverse/path speed: 15 m/min --> Z-axis: --> Slide travel: 450 mm --> Feed force: 6000 N --> rapid traverse/path speed: 18 m/min --> Y-axis: --> slide path: +- 35 mm --> Feed force: 6000 N --> rapid traverse/path speed: 10 m/min --> C-axis: --> Speed: 100 min-1 --> Torque: 140 / 196 Nm --> electrical resolution: 0.001 degree --> tailstock quill diameter: 70 mm --> quill stroke: 60 mm --> Stroke of the quick retraction: 280 mm --> quill setting force at 55 bar: 8600 N --> Mounting according to DIN 228: Mk 4 --> Steady rest Clamping range: 8 - 95 mm --> Workpiece removal device Max. part length: 250 mm --> Max. part weight: 3 kg

Condition: excellent (used), Year of construction: 2012, ONLY 8,300 spindle hours! Control: TX 8 i-p MAIN SPINDLE Max. bar capacity: 32 mm Max. workpiece length - Swiss-type operation: 245 mm - Short turning operation: 125 mm Max. spindle speed: 6,400 rpm C-axis Hjdoxrf Etjpfx Ah Honw SUB SPINDLE Max. bar capacity: 32 mm Max. clamping depth of workpiece: 250 mm Max. spindle speed: 6,000 rpm C-axis UPPER TOOL TURRET Number of stations: 10 All driven Max. speed: 12,000 rpm LOWER TOOL TURRET Number of stations: 9 All driven Max. speed: 12,000 rpm BACK WORKING UNIT Number of stations: 8 Driven stations: 3 (T12, 13 and 14) Speed T12 & T14: 12,000 rpm Speed T13: 4,000 rpm Parts conveyor Chip conveyor Coolant pump 20 bar IFS oil mist filter Bar loader FMB turbo 3-36

Condition: good (used), Year of construction: 2004, functionality: fully functional, Dear Sir or Madam, We are pleased to offer you a Traub TNL 26 CNC Swiss-type automatic lathe from the year 2004. The machine is in well-maintained, fully functional condition. Important Note: This particular model is equipped with only one turret. The TNL 26 was also manufactured in versions with two turrets – this offer explicitly refers to the version with a single turret. Technical Data (excerpt): Manufacturer: Traub Model: TNL 26 Year of manufacture: 2004 Control: Traub TX8i-S Turret: 1 unit, lower position, 12 tool stations, driven tools (all-head drive) Bar capacity: 26 / 32 mm Max. main spindle speed: up to 8,000 rpm Drive power: approx. 6.7 kW (100% duty cycle) / 10.7 kW (40% duty cycle) Torque: 21 Nm (100% duty cycle) / 32 Nm (40% duty cycle) Axes: X1 / Y1 / Z1, C-axis integrated in main spindle Chip conveyor: hinge belt, discharge height approx. 950 mm Machine weight: approx. 4,000 – 4,200 kg Dimensions (L × W × H): approx. 4.4 × 1.4 × 1.7 m Hnjdpfx Ahoxgg Rmo Hew Condition & Application The machine is immediately available and ideally suited for the precise production of small and medium batches in the automotive, medical and precision engineering industries. Price & Terms Price: on request / negotiable Delivery: ex site, ex works Inspection: possible at any time by prior appointment. Should you require further information or wish to arrange an inspection, I am at your disposal at any time. Best regards, Arnd Sauter GmbH Björn Sauter

Condition: good (used), Internal item no.: 25090 Driven tool holder Index / Traub No.: W 7045003 B Very well-maintained condition! Hnodjxu Uz Nepfx Ah Hsw The holder was used on a Traub TNL18.

Year of construction: 1989, condition: not inspected (used), Traub KNC50 lathe currently disconnected and drained, ready for transport. Hnodpoxvx Trofx Ah Hew

Condition: used, Ser. No. A60/6094, Ser. No. A56/3985, Ser. No. 2303 (only one shared control unit available) Hnjdpfx Ahsxt Nnhj Hew +++ Attention: These 3 machines are part of an online auction! +++

Year of construction: 1989, condition: ready for operation (used), Spindle bore: 42mm, max. workpiece diameter: 115mm, speed: 3150rpm, power: 9kW, bar length: 5200mm. Machine dimensions X/Y: approx. 2100mm/1000mm, weight: approx. 1500kg. Including bar feeder Stamag D 5000 and various accessories such as collets and feed collets. Documentation available. An on site inspection is possible. Hnjdjxwn Ihjpfx Ah Hsw

Condition: good (used), - Cam-controlled automatic lathe including bar magazine - Max. bar diameter 25 mm - Tailstock Hnodpfxoxpu A Ae Ah Hew - Weight approx. 650 kg - Dimensions (LxWxH) approx. 1000 x 600 x 1500 mm - 2 vertical tool holders - 2 horizontal tool holders - FMB bar feeder for bar length 4200 mm

Condition: good (used), Internal item no.: 25091 Driven tool holder Adjustable angle head Index / Traub No.: W 7045011A Very well-maintained condition! Hnedpfx Ajxvaqleh Hew The holder was used on a Traub TNL18.

Condition: good (used), Internal item no.: 25093 Driven tool holder Hnjdpfx Ahjxvat Tj Hjw Adjustable angle head Index / Traub No.: W 7045011A Very well-maintained condition! The holder was used on a Traub TNL18.

Condition: good (used), Internal item no.: 25088 Tool holder Thread whirling holder incl. cutting inserts Hsdoxu Dcvepfx Ah Hsnw Index / Traub No.: 12068219 The tool was used on a Traub TNL18 Very well-maintained condition!

Condition: good (used), Internal item number: 25092 Driven toolholder Adjustable angle head Manufacturer: Index / Traub No.: W 7045011A Very well-maintained condition! Hnodpsxvazkofx Ah Hsw The holder was used on a Traub TNL18 lathe.
