Used Traub for sale (93)

Condition: ready for operation (used), Traub 700 734 VEMEM/I interface board, used, in good condition, 100% functional, scope of delivery as per photos. Giedpfox Eu Tvjx Abkju

Condition: ready for operation (used), Year of construction: 2012, operating hours: 19,295 h, spindle motor power: 10,700 W, spindle speed (max.): 8,000 rpm, overall weight: 6,000 kg, total width: 2,500 mm, total height: 2,600 mm, bar diameter (max.): 32 mm, travel distance X-axis: 140 mm, controller manufacturer: TRAUB, controller model: TX 8i-p, product length (max.): 4,500 mm, number of axes: 7, This 7-axis TRAUB TNL 32 P was manufactured in 2012. It features a maximum bar diameter of 32 mm and a maximum Z-axis travel of 305 mm. The machine includes two turrets with live tooling capabilities, offering 10 and 9 tool stations respectively. If you are looking to get high-quality turning capabilities, consider the TRAUB TNL 32 P swiss type turning machine we have for sale. Contact us for further details. • Number of Turrets: 2 • Maximum Z-Axis Travel: 305 mm • Main Spindle Torque: 21 / 32 Nm • Main Spindle C-Axis Resolution: 0.001° • Turret 1 Tool Stations: 10 • Turret 1 Live Tool Stations: 10 • Turret 1 Live Tool Speed: 12,000 rpm • Turret 1 Live Tool Power: 1.5 / 2.5 kW • Turret 1 Tool Holder Diameter: 45 mm • Turret 1 Turning Tool Shank: 16 x 16 mm • Turret 1 X-Axis Travel: 140 mm • Turret 1 Z-Axis Travel: 305 mm • Turret 1 H-Axis Resolution: 0.001° • Turret 1 Chip-to-Chip Time: 0.3 sec • Turret 2 Tool Stations: 9 • Turret 2 Live Tool Stations: 9 • Turret 2 Live Tool Speed: 12,000 rpm • Turret 2 Live Tool Power: 1.5 / 2.5 kW • Turret 2 Tool Holder Diameter: 45 mm • Turret 2 Turning Tool Shank: 16 x 16 mm Gijdpfxszcyhxe Abkju • Turret 2 X-Axis Travel: 140 mm • Turret 2 Y-Axis Travel: -25 / +40 mm • Turret 2 Z-Axis Travel: 320 mm • Turret 2 Chip-to-Chip Time: 0.3 sec • Counter Spindle Speed: 8,000 rpm • Counter Spindle Power: 1.5 / 2.5 kW • Counter Spindle Torque: 4.5 / 7.7 Nm • Counter Spindle C-Axis Resolution: 0.001° • Maximum Clamping Length: 250 mm • Maximum Bar Diameter (Counter Spindle): 32 mm • Back Working Tool Stations: 8 • Back Working Live Tool Stations: 3 • Back Working Live Tool Speed: 12,000 rpm • Back Working Live Tool Power: 1.5 / 2.5 kW • Back Working Tool Holder Diameter: 36 mm • Rapid Traverse (X / Y / Z): 20 / 20 / 20 m/min • Maximum Feed Rate: 20,000 mm/min • Total Power Requirement: 46 kW • Space Requirement incl. Bar Feeder: 8,000 x 2,500 x 2,600 mm • Chip Conveyor: Optional, not included • Coolant System: Yes • Tool Turrets: 2 • Back Working Unit: Yes • Bar Feeder Interface: Yes • Bar Feeder: LNS Hydrobar Express 332 S2 / 3 m • Electronic Handwheel: Yes • Hydraulic Unit: YesMachine defects: The counter spindle is currently unusable due to prolonged inactivity. Either the sensor or the motor is defective. Technical Specification Counter Spindle Yes Driven Tools Yes Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2017, operating hours: 19,295 h, spindle speed (max.): 8,000 rpm, bar diameter (max.): 32 mm, controller manufacturer: TRAUB, controller model: TX8i-s, number of axes: 9, This 9-axis TRAUB TNL32-9 was manufactured in 2017. It features a main spindle speed of 8,000 rpm and a counter spindle speed of 6,400 rpm. The machine includes dual drive systems and a maximum bar capacity of 32 mm, making it suitable for various turning applications. If you are looking to get high-quality turning capabilities, consider the TRAUB TNL32-9 swiss type turning machine we have for sale. Contact us for further details. • Main Spindle: Motor Spindle • Main Spindle Bore: 32 mm • Main Spindle C-Axis: Yes • Counter Spindle Bore: 30 mm • Counter Spindle Speed: 6,400 rpm • Upper Tool Carrier: X / Y / Z / H Axis • Lower Tool Carrier: X / Y / Z / H Axis • Tool Positions Upper Carrier: 10 • Tool Positions Lower Carrier: 10 • Dual Drive System: Yes • Long Turning Mode: Yes Giedpfx Abjzcyabskju • Short Turning Mode: Yes • Changeover Turning Mode (W-T): Yes • Internal Coolant Pressure: 20 / 80 / 120 bar • Coolant System: Bürener ECO Fluid • Coolant Tank Capacity: 600 l • Oil Mist Extraction System: Yes • Air Flow Capacity: approx. 1,500 m³/h • Automatic CO₂ Fire Extinguishing System: Yes • Hydraulic Workpiece Gripper: Yes • Counter Spindle Parts Ejector: Yes • Parts Conveyor: Yes • Tool Monitoring System: Yes • Network Interface RJ45: Yes • Voltage: 400 V • Frequency: 50 Hz • Rated Power: 36 kW • Connected Load: 44 kVA • Rated Current: 63 A • Maximum Fuse Protection: 63 A • CE Marked: Yes • Bar Feeder: FMB LSK38 / 3200 C • Bar Diameter Range: 5 - 38 mm • Maximum Bar Length: 3,200 mm • Remnant Length Disposal: up to 600 mm • Feed Direction: Right Side • Material Support Position: Front • Chip Conveyor: Optional, not included Technical Specification Through-spindle Coolant Yes Counter Spindle Yes Driven Tools Yes

Condition: used, Year of construction: 2005, Technical details: turning diameter: 275 mm turning length: 900 mm spindle passage: 65 mm power capacity at 100 % load: 25/20 kW spindle turning speed range: 1 - 5000 U/min spindle diameter in front bearing: 110 mm c-axis: 1 - 500 U/min. number of workpiece supports: 4 tool turret: 1 x-axis: 290 mm y-axis: 165 mm z-axis: 360 mm b-axis: 360 ° rapid speed: 18/30 m/min number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8000 / 2000 U/min power capacity: 25% ED 5,8 kW Giedpfx Abewp D Nbskju tool taper: TRAUB 60 tool turret: 2/3/4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid speed: 18/15/30 m/min number of driven tools: 10 mm toolpiece turning speed range: 1 - 6000 U/min power capacity: 25% ED 5,8 kW tool taper: DIN 69880 40 x 63 total power requirement: 95 kW weight of the machine ca.: 16 t dimensions of the machine ca.: 10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and Sub spindle with C-axis 1 support with B-axis 3 turret supports dust exhauster, coolant attachment with coalescence-seperator and chip conveyor 2 pc. 3-jaw chuck SMW KNCS-N 170-43 2 pc. HAINBUCH Spanntop chuck 40 pc. various tool holder non-driven 6 pc various tool holder driven Spare parts package *

Condition: used, Year of construction: 1990, Technical details: turning diameter: 445 mm turning length: 2000 mm turning diameter over bed slide: 660 Godpfjw I R Ndjx Abkeiu spindle bore: 65 mm spindle speeds:: 16 - 3150 U/min. rapid motion - x-axis: 10 mm/min rapid traverse Z-axis: 15 m/min total power requirement: 34 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: 6 x 2,5 x 2,2 m with CNC Control TX 8 D C-axis driven tooling 14 station turret head 3 jaw chuck dia. 315 mm tailstock, steady as NC-axis diverse driven toolholders diverse turning toolholders chip conveyor and coolant attachment *

Condition: ready for operation (used), Year of construction: 2003, operating hours: 124,706 h, spindle speed (max.): 6,300 rpm, travel distance X-axis: 370 mm, travel distance Z-axis: 250 mm, spindle motor power: 10,700 W, controller manufacturer: TRAUB, controller model: TX8i (64-bit), number of axes: 6, This 6-axis TRAUB TNK 36 was manufactured in 2003. It features a maximum spindle speed of 6,300 rpm and a main spindle bore of 36 mm. The machine is equipped with advanced capabilities such as tool monitoring, rigid tapping, and a high-pressure coolant system. If you are looking to get high-quality turning capabilities, consider the TRAUB TNK 36 horizontal turning machine we have for sale. Contact us for further details. TECHNICAL DATA • MDE Interface: Yes • Tool Monitoring: Yes • Rigid Tapping: Yes (without compensation chuck) • Main Spindle Bore: 36 mm • Main Spindle Drive Power: AC 6.7 / 10.7 kW • Top Turret Stroke X/Z: 50 / 100 mm Godpfxsza Ucxj Abkjiu • Rear Attachment Stroke X: 73 mm • Rear Attachment Stroke Y: ±50 mm • Main Spindle C-Axis: Yes • Hainbuch Change Parts: Yes • Hainbuch Setup Aid Base Body: Yes • Hainbuch Manual Change Device: Yes • Counter Spindle: Motor Spindle • Counter Spindle C-Axis: Yes • Counter Clamping Pressure Device: Yes • Workpiece Ejection Device: Yes • Hainbuch Axfix Chuck: Yes • Upper Tool Carrier: Yes • Electronic Gearbox: Yes • X3 Cross Axis for Front Unit: Yes • Front Unit: 5-position • Driven Tools on Front Unit: Yes • Cut-Off Side Machining Station: Yes • Driven Tools on Cut-Off Side Station: Yes • Workpiece Unloading Device: Gripper • Coolant Tank Capacity: 230 l • Coolant Pressure: 7 bar • Coolant Flow Rate: 50 l/min • Internal Coolant Supply: 30 bar • High Pressure Coolant: 120 bar (front and rear machining station) • Coolant Filter: Knoll VRF 150/750 Vacuum Rotary Filter • Suitable Materials for Filter: Aluminum, Plastic, Brass, Steel • Wash Gun: Yes • Connected Load: 22 kW • Maximum Bar Length: 3 m • Maximum Bar Diameter: 36 mm • Operating Voltage: 400 V, 3~, 50 Hz • Control Voltage: 24 V AC • Valve Voltage: 24 V DC • Clutch Voltage: 24 V DC • Total Installed Power: 33 kW • Total Rated Current: 60 A ADDITIONAL EQUIPMENT OPTIONAL • FMB turbo 5-42 XT / 3200"C" Bar Feeder • Bar Feeder Year: 2003 • Hinged Belt Chip Conveyor • Chip Conveyor Discharge Height: 950 mm • Guide Tubes D25, D36 • Running Workpiece Stop, Shank 16 × 16 mm • Brankamp CMS 100 Collision Monitoring Technical Specification Through-spindle Coolant Yes Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 1996, CNC turning center TRAUB Type:TNC65 DG Year 1996 Control TRAUB TX8F With lots of accessories. Gisdpeu Eug Ijfx Abkju

Condition: used, CNC turning machine TRAUB, Type TND 400 Serial No. 708, Year of manufacture 1996 CNC control TRAUB TX 8 F Nominal turning diameter: 400 mm Swinging diameter over bed: max. 470 mm Spindle bore in draw tube: 65 mm Motor power, spindle drive: 22 kW Total power consumption: 35 kW Mains connection: 380 volts, 50 Hz - Electronic handwheel - RS 232 data interface - Turret with 12 tool positions, VDI 40 - Includes 8 tool holders, VDI 40 - 3-jaw chuck, Ø 225 mm, SMW Autoblok, Type KNCS-N-Ø 225-65 Includes a large quantity of chuck jaws - Hydraulic internal expanding cylinder, SMW, Type ZHDAS-130-67 - Chip conveyor, KNOLL, Type 200 S-1/600 - Coolant system - Hydraulic unit (L x W x H 650 x 500 x 1000 mm) Space requirement L x W x H: 4800 x 2000 x 2100 mm Space requirement, base machine L x W x H: 3500 x 2000 x 2100 mm Space requirement, chip conveyor L x W x H: 4500 x 700 x 1550 mm Weight: approx. 5 tons Good condition Godpjzacwdjfx Abkoiu Machine is ready for demonstration. The internal expanding cylinder for workpiece clamping needs to be repaired.

Condition: ready for operation (used), Year of construction: 2017, operating hours: 1,749,535 h, functionality: fully functional, machine/vehicle number: 6060449, turning length: 305 mm, spindle speed (max.): 8,000 rpm, turning diameter: 32 mm, spindle bore: 32 mm, overall weight: 8,000 kg, rotational speed (max.): 8,000 rpm, type of input current: three-phase, bar passage: 32 mm, total length: 3,671 mm, total height: 2,650 mm, feed rate X-axis: 5 m/min, feed rate Y-axis: 5 m/min, feed rate Z-axis: 5 m/min, bar diameter (max.): 32 mm, collet bore: 32 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, input voltage: 400 V, power: 36 kW (48.95 HP), travel distance X-axis: 140 mm, travel distance Y-axis: 40 mm, travel distance Z-axis: 305 mm, clamping diameter: 32 mm, controller manufacturer: Traub System TX 8i - s V7, Equipment: documentation/manual, The machine is operational and currently in production. All information can be found in the attachment. The machine is available for immediate delivery. The order confirmation with all information about the machine and the loading magazine is included in the attachment. Gsdpfxszc Hmuo Abkoiu New price: €444,857.70 (gross) The machine was originally used as a demonstration model from 2016 to 2020. Please note the operating hours. The machine will be sold including the FMB LSK38 loading magazine. FMB LSK38 / 3200 "C"

Condition: good (used), Internal item no.: 25088 Gsdpfx Ajxu Dcvsbkjiu Tool holder Thread whirling holder incl. cutting inserts Index / Traub No.: 12068219 The tool was used on a Traub TNL18 Very well-maintained condition!

Condition: good (used), Internal item no.: 25089 Tool holder Thread whirling holder Index / Traub No.: W7045012B Very well maintained condition! Giodpfjxu Uu Aox Abkju The holder was used on a Traub TNL18.

Condition: good (used), functionality: fully functional, 1 x Multi-spindle lathe Traub A 25 Equipment: Boring tool holder Longitudinal turning attachment Weight-controlled feed Beautiful, complete machine in technically flawless condition. The machine can be inspected while powered on. Gsdpfx Abezcdp Hekjiu

Condition: good (used), Year of construction: 1982, functionality: fully functional, Traub CNC turning machine TND360, TX8, year of manufacture 1982, serial number >600. Gisdozcdnvepfx Abkju Includes 1 turret, tailstock, chip conveyor, draw tube, and 3-jaw chuck KNCS250. The images show the machine in its production environment. The machine can be inspected while powered on.

Condition: good (used), Year of construction: 1990, functionality: fully functional, Traub CNC turning center TNA480, TX8D, year of manufacture 1990, serial number >550. C-axis, rotary tool drive, 1 turret VDI40, tailstock, chip conveyor, hollow cylinder chuck, 3-jaw chuck KNCS315. Giedpfezcdgfox Abksu Good condition, ready for operation. Machine geometry has been checked and corrected/adjusted. Scrapers and belts have been inspected, replaced, maintenance performed after 4000 operating hours. The photos were taken in the production environment; the machine will be cleaned and inspected further. The machine can be inspected while powered on.

Condition: good (used), Year of construction: 2003, CNC turning center TRAUB TNK 36 Year of manufacture: 2003 Control: TX8i (64 bit) Flat screen monitor, 10.4 inches Additional V24 RS232 interface in the control cabinet MDE interface in the control cabinet (machine is running, piece counter) Tool monitoring for thread cutting without compensation chuck Main spindle: Spindle bore 36 mm, maximum speed 6,300 rpm Drive power AC 6.7 / 10.7 kW C-axis Quick-change parts Hainbuch, mounting aid, base body Quick-change device Hainbuch, manual Counter spindle: Counter spindle as a motor spindle with C-axis Device for counter pressure, workpiece ejection device, Axfix chuck Hainbuch Tool holder, top, driven tools, electronic gearbox X3 cross axis for front tool holder, front tool holder, 5-position, driven tools Cut-off station, driven tools Workpiece removal device: Workpiece gripper Gijdpfx Abezaud Aekeu Gripper jaws D5-8, D8-20, D20-36 Coolant system: Tank 230 l / 7 bar / 50 l/min. Internal coolant supply 30 bar High pressure 120 bar at the front and rear machining stations, vacuum rotary filter Knoll VRF 150/750 (suitable for aluminum, plastic, brass, and steel) Coolant gun Hinged belt chip conveyor, discharge height 950 mm Preparation for installation of bar feeder magazine (guide tube D25, D36) Workpiece stop, rotating (shank 16x16) Collision monitoring Brankamp CMS 100 on main and counter spindle Machine without known defects.

Condition: good (used), Year of construction: 2008, functionality: fully functional, cam-controlled automatic lathe including bar magazine - Manufacturer: PMT (Traub India) - max. bar diameter: 25 mm - tailstock - 2 vertical tool holders - 2 horizontal tool holders Gisdpfsy R Tqqjx Abkju - Weight approx. 650 kg - Dimensions (LxWxH) approx. 1000 x 600 x 1500 mm - Bar loader IEMCA AS 325/62 (max. bar length 6,200 mm)

Condition: good (used), Year of construction: 2015, functionality: fully functional, cam-controlled automatic lathe including bar magazine - Manufacturer: PMT (Traub India) - max. bar diameter: 25 mm - tailstock - 2 vertical tool holders - 2 horizontal tool holders - Weight approx. 650 kg - Dimensions (LxWxH) approx. 1000 x 600 x 1500 mm - Bar loader IEMCA AS 325/62 Gisdpfx Abey R Tm Soksu (max. bar length 6,200 mm)

Condition: good (used), functionality: fully functional, cam-controlled automatic lathe including bar loader magazine Gedpfx Abjy R Tg Sjkeiu - max. bar diameter 25 mm - tailstock - 2 vertical tool holders - 2 horizontal tool holders - weight approx. 650 kg - dimensions (LxWxH) approx. 1000 x 600 x 1500 mm - bar feeder IEMCA AS 325/62 (max. bar length 6,200 mm)

Condition: used, Year of construction: 1988, Technical details: turning diameter over bed: 360 mm turning dia. over face-slide: 160 mm turning length: 800 mm longitudinal traverse (z-axis): 810 mm facing movement (x-axis): 205 mm control: TX-8 spindle passage: 60 mm revolution per minute: 63 - 3150 / 2 step U/min feed:: 10.000 mm/min. tool turret - number of stations: 8 operating hours - idle run: 8834 h tailstock taper ISO: SK30 DIN 2080 tailstock quill stroke: 105 mm operating pressure: 40 bar Godpsu Rqabjfx Abkjiu total power requirement: 38 kW Weight approx.: 3,1 t dimension machine xH: 1,8 x 3,3 x 1,8 m dimensions of hydaulic: 580 x 400 x 750 mm Equipment: Lathe chuck Ø 200 mm, hydraulic Feed force Z-axis = 8 kN and X-axis = 5 kN Coolant system control panel Accessories Fine adjustment device for tool set-up *

Condition: used, Year of construction: 1993, Technical details: x-travel: 400 mm y-travel: 300 mm z-travel: 400 mm spindle revolutions per minute : 8000 U/min Gsdpfxou Idn Ho Abkeiu control: Fanuc OM clamping table: 500x300 mm magazine slots: 16 Stück tool taper: SK40 distance work spindle /surface of the table max.: 50-450 mm numbers of pallets: 2 Stück/part total power requirement: 10 kW weight of the machine ca.: 2,5 t dimension machine xH: 2,4x1,8x2,5 m transport measurements machine: 2,45x1,8x2,5 m - E-cabinet - cooling device - chip conveyor manufacturer META (conveying height 1500mm; width 200mm) *

Condition: used, Year of construction: 1987, Technical details: turning diameter over bed: 180 mm turning length: 490 mm swing diameter: 450 mm cross travel: Z-Weg: 168 mm control: Traub TX8D revolution per minute: 20 - 4000 U/min spindle passage: Ø 60 mm operating hours - idle run: 23.495 h tool turret: 12 tools Gjdpfju Ix N Sex Abkeiu total power requirement: 38 kW Weight approx.: 4,2 t dimension machine xH: 3,6 x 2,5 x 2,2 m Tool holder straight shank DIN 69880 (VDI 3425) Ø 40x63 Röhm lathe chuck Ø 200mm hydraulic clamping Operation via double foot switch and control panel/operating panel. Coolant device The Traub carries an integrated chip conveyor with an ejection height of 1,100mm (currently without function). Accessories: multiple small parts 8 x machine feet without tailstock i.D. *

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 18 [mm] - Spindle speeds : 12.000 [rpm] - Spindle power : 3.0 / 5.5 [kW] - C axis indexing precision : 0,001 [°] - Z stroke : 205 [mm] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 12.000 [rpm] - Spindle power : 1,5 / 2,5 [kW] - C axis indexing precision : 0,001 [°] - Number of turrets : 2 UPPER TURRET - Number of positions : 8 - Number of motorized positions : 8 - Live tools speed : 12.000 [rpm] - Live tools power : 1 / 2 [kW] - X/Z stroke : 165 / 550 [mm] - Y stroke : -40 / +25 [mm] - Rapid traverses rates (X/Y/Z) : 21 / 21 / 42 [m/min] - B Axis stroke : 100 [°] LOWER TURRET - Number of positions : 7 - Number of motorized positions : 7 - Live tools speed : 12.000 [rpm] - Live tools power : 1.5 / 2.5 [kW] - X/Z stroke : 120 / 250 [mm] - Y stroke : -20 / +40 [mm] - Rapid traverses rates (X/Y/Z) : 21 / 21 / 50 [mm/min] SECONDARY OPERATION - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 10.000 [rpm] - Live tools power : 1 / 2 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 24 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.060 x 1.480 [mm] - Machine height : 2.420 [mm] - Machine weight : 4300 [kg] MACHINE HOURS - Number of working hours : 14998 [h] - Number of spindle hours : 11177 [h] EQUIPMENT - CNC : Traub TX 8i-s - Rotating guide bush Giodpfozbvnlex Abkeu - Parts catcher - Parts conveying strip - Chips conveyor - Coolant tank * with high-pressure pump * with paper filtering unit - Bar loader : IEMCA ELITE 220 / 32 XL - Oil mist extractor : ELBARON RON/A 1500 DH - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: ready for operation (used), Year of construction: 2009, operating hours: 87,094 h, spindle speed (max.): 4,000 rpm, travel distance X-axis: 140 mm, travel distance Z-axis: 450 mm, spindle motor power: 18,500 W, total height: 1,917 mm, total width: 2,076 mm, overall weight: 5,200 kg, controller manufacturer: TRAUB, controller model: TX8i, product length (max.): 4,354 mm, number of slots in tool magazine: 10, number of axes: 7, This 7-axis TRAUB TNC 65 DGY was manufactured in 2009. It features a powerful tool drive turret with a speed of 4000 rpm and a high-pressure coolant system with programmable pressure stages. The machine is designed for machining metals and plastics, equipped with a C-axis for numerically controlled turning and positioning. If you are looking to get high-quality turning capabilities, consider the TRAUB TNC 65 DGY horizontal turning machine we have for sale. Contact us for further details. • Control system: TX8i with 64-bit RISC high-performance processor and additional PLC high-performance processor, integrated PC• TX8i control with TFT color flat screen and electronic handwheel• Multi-range transformer for 460V / 400V / 380V / 220V / 200V, 50 Hz• Machine operating voltage: 400V 50 Hz• Accessories operating voltage: 230V 50 Hz• Control voltage: 24V DC• Designed for machining metals and plastics with defined cutting edge• Maximum turning length: 450 mm• Main spindle bore: 65 mm• Spindle through-hole: 65 mm• Maximum clamping diameter depending on collet system: 60 mm• Front bearing diameter: 66 mm• Standard collet: DIN 6343• Maximum clamping diameter: 65 mm• Main spindle torque: 230 Nm• Main spindle C-axis numerically controlled• X-axis rapid traverse/feed speed: 7.5 m/min• X-axis feed force at 100% duty cycle: 5000 N• X-axis ball screw: 32×5 mm• Z-axis rapid traverse/feed speed: 10 m/min• Z-axis feed force at 100% duty cycle: 8000 N• Z-axis ball screw: 32×10 mm• Y-axis rapid traverse/feed speed: 3 m/min• Y-axis travel: ±35 mm• Y-axis feed force at 100% duty cycle: 8000 N• Y-axis ball screw: 25×5 mm• Tool stations: 10 (14 optional)• Tool holder size: Ø30×55 mm• Alternative tool holder size: Ø25×48 mm• Tool shank size: 20×20 mm• Alternative tool shank size: 16×16 mm• Counter spindle maximum speed: 4000 rpm• Counter spindle maximum clamping diameter: 65 mm• Counter spindle power: 11 kW• Counter spindle constant power range: 1:8• Counter spindle torque: 210 Nm• Counter spindle rapid traverse/feed speed: 10 m/min• Counter spindle travel: 520 mm• Counter spindle feed force at 100% duty cycle: 6000 N• Counter spindle ball screw: 32×20 mm• Counter spindle C-axis with speed-synchronous control• Tool drive turret 1: 3.1 kW, 4000 rpm• Tool drive turret 2: 3.1 kW, 4000 rpm• Tool monitoring TX8i with wear and breakage control via axis motor monitoring• Thread cutting without compensating chuck• TRAUB Polyform software for milling programming with C-axis (front, longitudinal, cylindrical surface)• Ethernet network connection preparation with RJ45 interface• Z/V-axis counter spindle software with defined end position (face transfer)• Hydraulic system pressure: 70 bar• Hydraulic tank capacity: 70 l• Coolant pump pressure: 12 bar• Coolant tank capacity with chip conveyor: 435 l• Electrical connected load: 39 kW• Machine weight with counter spindle and electrical cabinet: 5200 kg• Noise level: 73 dB(A)• Permissible ambient temperature: 5–40 °C• Maximum relative humidity at 40 °C: 50 %• Work area turret section: 450 mm• Work area to counter spindle: 520 mm• Total work area: 728 mm• Minimum distance F to counter spindle contour: 127 mm• The machine has a Y-axis on turret 1, but not on turret 2 Godoy Sg Nispfx Abkjiu Additional equipment

Condition: ready for operation (used), Year of construction: 2000, operating hours: 116,688 h, spindle speed (max.): 5,600 rpm, travel distance X-axis: 375 mm, travel distance Z-axis: 450 mm, spindle motor power: 11,000 W, total height: 1,800 mm, overall weight: 3,500 kg, controller manufacturer: TRAUB, controller model: TX8H, product length (max.): 2,700 mm, number of axes: 3, This 3-axis TRAUB TNA 300 horizontal turning machine was manufactured in 2000. It features a spindle diameter of 65 mm and includes a high-pressure coolant system, driven tools with 4 kW power, and an automatic bar change system. The machine is equipped with a chip conveyor and tool monitoring systems for enhanced efficiency. If you are looking to get high-quality turning capabilities, consider the TRAUB TNA 300 machine we have for sale. Contact us for further details. • Spindle bore / machine capacity: 65 mm • Installed 185E collet system capacity: max. 60 mm clamping diameter • Machine version: without tailstock • Basic configuration: included • Hydraulic hollow clamping cylinder: included • High-pressure coolant system: 12 bar / 3 bar • Control system: TX8H, 32-bit technology; processor latest generation (at time of build); parameter data on diskette • Axes/functions: • C-axis: included (numerically controlled spindle positioning and turning axis) • Y-axis: not included • Driven tools: included; power 4 kW • Monitoring and safety: • Tool breakage monitoring: included • Tool wear monitoring: included • Automatic drive shutdown after material end: selectable via parameter • Error message via parameter: selectable • Guideway cover: included • Workholding: • Collet clamping system: ROHM • Collet system compatibility: • DIN 6343 size 48, max diameter 42 mm • Rubberflex series 52 compatible • Rubberflex series 36 compatible • Fahrion collet FM 1149 MB compatible • Fahrion collet FM 1148 MB compatible • Electrical: • Electrical system according to: VDE / EN 60204 • Operating voltage: 400 V / 50 Hz • Accessory voltage: 230 V / 50 Hz • Control voltage: 24 V DC • Multi-voltage transformer: 460 / 400 / 380 / 220 / 200 V • EMC: • Compliance: industrial class A • Standards: EN 50081 / EN 50082 / EN 55011 / EN 55022 • Machine standards: DIN EN 292; DIN EN 294; DIN EN 418; DIN EN 60204-1 • Pneumatic system: Mannesmann Rexroth ISO Additional equipment • Chip conveyor: included • Workpiece removal device: included; via conveyor, left side discharge • Bar feeder preparation: included • Bar feeder: TRAUB DNH 61-3000 (automatic) • Feeding: telescopic pusher system • Bar shapes: round / hexagonal / square • Maximum bar length: 3200 mm • Maximum bar diameter (long bars): 63 mm • Maximum bar diameter (short pieces): 65 mm • Automatic bar change: included • Residual piece removal: forward • Central adjustment of bar diameter: included • Stepless feed force adjustment: included • Central magazine adjustment: included • No guide channel change required • No clamping sleeve change required • Short remnant pieces possible • Transverse loading system • Transport weight: approx. 2100 kg Giedjy Sg Dgjpfx Abkou Technical Specification Counter Spindle No Driven Tools Yes

Condition: ready for operation (used), Year of construction: 1999, operating hours: 124,009 h, number of axes: 5, This 5-axis TRAUB TNC65 DG was manufactured in 1999. It features a robust control system with TRAUB TX8H technology, dual tool carriers with 10 stations each, and a maximum clamping diameter of 60 mm. The machine is equipped with a coolant cleaning system and a hinged belt conveyor for efficient chip removal. If you are looking to get high-quality turning capabilities, consider the TRAUB TNC65 DG horizontal turning machine we have for sale. Contact us for further details. • Control system: TRAUB TX8H (32-bit technology) • Main spindle: Yes • Counter spindle: Yes • Spindle synchronization: Yes • C-axis main spindle: Yes • C-axis counter spindle: Yes • V-axis: Yes (programmable position) • Tool carriers: 2 (tool carrier I and II) • Driven tools on tool carrier I: Yes • Driven tools on tool carrier II: Yes • Number of tool stations: 10 per tool carrier • Thread cutting: Without compensating chuck • Drilling and milling units: X-direction (i=1 and i=3) and Z-direction (i=1 and i=3) • Coolant system: Cleaning system with cyclone filter • Coolant tank capacity: approx. 470 liters • Coolant pump: Supply for both turrets integrated • Hydraulic system: Yes • Operating voltage: 400 V / 50 Hz • Control voltage: 24 V DC • Accessory voltage: 230 V / 50 Hz • Multi-range transformer: 460 V / 400 V / 380 V / 220 V / 200 V • Standards: EC Machinery Directive, EMC Directive, Low Voltage Directive, DIN EN 292, DIN EN 294, DIN EN 418, DIN EN 60204 • Tool monitoring: Tool breakage and wear monitoring • Programming software: TRAUB Polyform • Coolant type: Water-based coolant compatible Additional equipment Giedpfx Absy R Uvuokou • Chip conveyor: Hinged belt conveyor • Bar feeder: TRAUB DNH 61-3000 (preparation included) • Workpiece ejection device: Yes • Workpiece removal device: Yes, with gripper • Collet system: Röhm, max clamping diameter 60 mm Technical Specification Counter Spindle Yes Driven Tools Yes
