Used Tapping Center for sale (13,188)

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 5,500 mm, travel distance Y-axis: 525 mm, travel distance Z-axis: 380 mm, Model: COMET ISOLA ES381 V06 Year: 2004 Control: ISAC ‘X’ axis Stroke: 5500mm ‘Y’ axis Stroke: 525mm ‘Z’ axis Stroke: 380mm Spindle Taper: ISO 40 Hsdjyx Hn Sspfx Acvok Spindle Speeds: 24,000 RPM

Condition: excellent (used), Year of construction: 2008, operating hours: 9,626 h, functionality: fully functional, spindle bore: 55 mm, turning diameter: 410 mm, turning diameter over bed slide: 246 mm, turning length: 1,250 mm, Colchester MultiTurn 2000 CNC Lathe Model: MultiTurn 2000 Control: FANUC Oi-TC Year: 2008 Swing over Bed: 410mm Swing in Gap: 600mm Swing over cross slide: 246mm Distance Between Centres: 1250mm Spindle Speeds: 15 – 2700 RPM Spindle Bore: 55mm dia. Motor: 7.5 kw Machine with: 250mm 3-jaw chuck Hodpfeyxq Dqox Acvok 8 station auto indexing turret VDI30 Tool Holders Auto Lubrication Sliding Guards Coolant Work Light Dimensions: 2900 x 1700 x 1500mm high Weight: 2200 kgs

Condition: excellent (used), Year of construction: 2016, Traverses XYZ: 1020 x 540 x 510mm, Hsdpfeyylzajx Acvok table size 1200 x 540mm, ISO40 spindle taper, spindle speed 12000 rpm, Heidenhain Control, spindle motor power 15kW, 30 station ATC with side arm, Through Spindle Coolant, Low Volt Light, Swarf conveyor

Condition: excellent (used), Year of construction: 2017, Traverses X Y Z; 1300 x 670 x 625mm, Table size 1500 x 670mm, maximum table load 1300 kgs. min-max height spindle to table 150-775mm, spindle speed 12,000rpm, Hsdpfjyyldhjx Acvek spindle taper BT40, 30 station ATC spindle power 18.5 Kw, Fanuc OI series control, spindle probe, Through spindle coolant

Condition: good (used), Year of construction: 2011, Turning diameter 376mm, turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees, 12 station turret, 22KW Motor, Hsdjyyakvopfx Acvek Main spindle 4000rpm. milling -spindle 5000rpm, Fanuc I series, 3 jaw chucks, swarf conveyor, tool setter

Condition: new, Year of construction: 2025, functionality: fully functional, NEWAY VM1050H FANUC 0IMF1 VERTICAL MACHINING CENTRE YEAR OF MANUFACTURE - NEW - BUILT 2025 Hedpfx Acjxtfxcovok STANDARD INCLUDED FACTORY FITTED MACHINE OPTIONS AIR GUN SPINDLE AIR BLAST SPINDLE PROTECTION AIR CURTAIN 24 STATION ATC TOOL MAGAZINE CHAIN TYPE CHIP CONVEYOR WITH CHIP BOX FANUC 0IMF 1 WITH 10.4 INCH COLOUR LCD DISPLAY & 8MB MEMORY MANUAL PULSE GENERATOR (MPG) COOLANT FLUSHING SYSTEM COOLANT GUN FRONT DOOR INTERLOCK FULLY ENCLOSED SPLASH GUARDING SYSTEM TELESCOPIC SLIDEWAY COVERS LED WORKING AREA LIGHTING SYSTEM PATROL LIGHT (3 COLOUR) AIR CONDITIONING IN ELECTRICAL CABINET BASIC MACHINE INSTALLATION PARTS CE STANDARDS MACHINE CONFIGURATION CENTRALIZED AUTOMATIC LUBRICATION SYSTEM MACHINE MANUALS & OPERATOR HANDBOOKS STANDARD ACCESSORIES TRANSFORMER (415V, 3PH, 50HZ) BELT DRIVE SPINDLE - 8,000 RPM #40 TAPER WITH OIL COOLER SPINDLE MOTOR FANUC 11.0 / 15.0 KW MACHINE TYPE, CONSTRUCTION & FEATURES  HEAVY DUTY CAST IRON CONSTRUCTION  COMPACT DESIGN  PRE-LOADED BALLSCREWS  HIGH PERFORMANCE LINEAR GUIDEWAYS – X / Y / Z MACHINE SPECIFICATION Worktable Travel (X Axis) 850 MM Saddle Travel (Y Axis) 520 MM Spindle Travel (Z Axis) 560 MM Distance from Spindle Nose to Worktable 150 ~ 710 MM Distance from Spindle Centre to Column 580 MM FEEDRATES X Axis Rapid Traverse Rate 36 M / MIN 3 | Page Y Axis Rapid Traverse Rate 36 M / MIN Z Axis Rapid Traverse Rate 36 M / MIN Cutting Feed Rate 10 / 10 / 10 M / MIN ACCURACY Positioning accuracy (X / Y / Z) 0.008 / 0.008 / 0.008 MM Repeatability (X / Y / Z) 0.005 / 0.005 / 0.005 MM WORK TABLE Table Size 1,000 x 520 MM Max. Table Load 650 KGS T-Slots - Width 18 MM SPINDLE HEADSTOCK Tool Shank BT40 [BBT40] [CAT40] Pull Stud P40T-1 (MAS403) Spindle Speeds 8,000 RPM Max. Output Torque 70.0 / 96.0 NM Spindle Motor Power 11.0 / 15.0 KW AUTOMATIC TOOL CHANGER Number of Tools 24 Tool Shank BT40 Max. Tool Dimensions Ø 80 x 300 MM x 8.0 KGS Tool Exchange Time 1.5 SEC MISCELLANEOUS Power Requirement 25 KVA Power Supply 415V / 3PH / 50HZ Compressed Air Consumption / Pressure 280 L / MIN / 6 ~ 8 BARS Machine Dimensions (L / W / H) 3,680 x 2,480 x 2,850 Machine Weight 5,500 KGS

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD3100YA FANUC 0IT PLUS CNC LATHE WITH Y AXIS MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 3,500 RPM MAIN SPINDLE. ▪ 5,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. Hedpfx Aox Thu Njcvsk ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET – BMT55P ▪ HARDENED & GROUND BOX GUIDE WAYS MACHINE CAPACITIES Swing Over the Bed Ø 800 MM Swing Over the Carriage Ø 670 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 760 MM Bar Capacity – Main Spindle Ø 81 MM MAIN SPINDLE Chuck Size Ø 10” - 254 MM Spindle Bore Ø 91 MM Spindle Speed (Rpm) 3,500 RPM Motor (Max / Cont.) 26.0 / 18.5 KW Torque (Max / Cont.) 734 / 522 NM Spindle Type BELT Spindle NoseA2-8 FEED Travel X265 MM Travel Y120 (± 60) MM Travel Z830 MM Rapid Speed X24 M / MIN Rapid Speed Y10 M / MIN Rapid Speed Z30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools12 Tool Size - OD25 MM² Tool Size - IDØ 20 MM Indexing Time0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max / Cont.) 70/0 / 35.4 NM Collet Size Ø 16 – ER25 Type BMT-65P TAIL STOCK Taper MT 5 Quill Diameter Ø 100 MM Quill Travelb120 MM Travel b830 MM Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,630 X 1,910 MM Height 1,960 MM Weight 6,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CONVEYOR & CHIP BOX HELICAL INTERPOLATION FUNCTION HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO MAIN SPINDLE - 3,500 RPM, 26.0 / 18.5 KW, 734 NM BELT DRIVEN PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL FORWARD / REVERSE CONFIRMATION DEVICE QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 10 INCH 3 JAW HYDRAULIC CHUCK CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE HYDRAULIC CHUCK PRESSURE INTERLOCK - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 180 LITRES FULL SPLASH GUARDING SYSTEM CALL LIGHT TOOLBOX TOOLING PACKAGE QUILL TYPE TAILSTOCK 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, TAKISAWA TM-3000Y2 FANUC 0iTF PLUS. TOTALLY AS NEW. BUILT 2023 CNC MULTITASKING LATHE WITH UPPER & LOWER Y-AXES. 8 INCH + 6 INCH STANDARD CHUCK SIZE Hjdpfxjxrpnrj Acvsk WITH:- Y-AXIS TRAVEL +45 -45 MM - LOWER TURRET (Y2 AXIS) Y-AXIS TRAVEL +45 -45 MM - UPPER TURRET (Y1 AXIS) CHIP CONVEYOR RIGHT SIDE DISCHARGE HINGE TYPE (MORETECH JAPAN) AIR BLOW SYSTEM - RH SPINDLE WORK PHASE POSITIONING FUNCTION (C-AXIS TORQUE SKIP FUNCTION) COOLANT DELIVERY PIPE ABOVE THE SPINDLE - LH & RH SPINDLE COOLANT PUMP - 400W - 3 OFF OIL SKIMMER (OIL / WATER SEPARATOR) OIL SEPERATOR BOX HYDRAULIC PRESSURE SWITCH LED LIGHTING AUTO LUBRICATION SYSTEM AND COLLECTOR MACHINE MANUALS & OPERATOR HANDBOOKS TURRET MOUNTED MACHINE LEVELLING PLATE AUTO POWER OFF SYSTEM TRANSFORMER - 415V / 3PH / 50HZ STANDARD TOOLING PACKAGE TURRET COVER (6 EA) X 2 SERVO TURRET (LOWER) Y2 AXIS - 12 STATION WITH DRIVEN TOOLS SERVO TURRET (UPPER) Y1 AXIS - 12 STATION WITH DRIVEN TOOLS 6" 3-JAW THRU-BORE HYDRAULIC CHUCK ~ KITAGAWA B-206 RH SPINDLE 8" 3-JAW THRU BORE HYDRAULIC CHUCK (KITAGAWA BR-08) - LH SPINDLE DIRECT DRAWING DIMENSION INPUT HELICAL INTERPOLATION FUNCTION RAKU-RAKU TOOL MONITORING SYSTEM 9 BAR HI PRESS COOLANT PUMP (NIHON) 2 OFF CALL LAMP (3 COLOUR) BAR FEEDER INTERFACE - MULTI BAR MAGAZINE TYPE REMAINING BAR DISCHARGE DEVICE UNLOADER WITH PARTS DISCHARGE CONVEYOR QUICK TOOL SETTING DEVICE - MANUAL TYPE BOTH TURRETS AXIAL DRIVEN TH, ER25 OUTPUT, 6000 RPM, 1:1 RATIO, EXT COOLANT - 4 OFF RADIAL DRIVEN TH, ER25 OUTPUT, 6000 RPM, 1:1 RATIO, EXT COOLANT - 1 OFF MACHINE FEATURES TWIN SPINDLE, TWIN TURRET Y-AXIS CNC TURNING CENTRE. 2 OFF 12 STATION HIGH ACCURACY SERVO TURRETS LEFT HAND SPINDLE - 4,500 RPM RIGHT HAND SPINDLE - 6,000 RPM UPPER & LOWER TURRETS - 6,000 RPM LIVE TOOLING SPEED UPPER TURRET Y1-AXIS (+ - 45 MM) LOWER TURRET Y2-AXIS (+ - 45 MM) 8” + 6” STANDARD CHUCK SIZE MACHINE CAPACITIES Standard Turning Dia. 215 MM Maximum Turning Dia. 215 MM Maximum Turning Length 620 MM Bar Capacity Left Spindle Ø 65 MM Bar Capacity Right Spindle Ø 42 MM AXIS TRAVELS Upper Turret Travel X1 190 / 90 MM Upper Turret Travel Y1 90 (± 45) MM Upper Turret Travel Z1 660 MM Lower Turret Travel X2 190 / 90 MM Lower Turret Travel Y2 90 (± 45) MM Lower Turret Travel Z2 660 MM Travel A (RH Spindle) 660 MM LEFT SPINDLE Chuck Size Ø (8”) 203 MM Spindle Speed (RPM) 4,500 RPM Min. Indexing Angle (C-Axis) 0.001 DEG Spindle Nose A2-6 Spindle Bore Ø 77 MM RIGHT SPINDLE Chuck Size Ø (6”) 152 MM Spindle Speed 6,000 RPM Min. Indexing Angle (C-Axis) 0.001 DEG Spindle Nose A2-5 Spindle Bore Ø 53 MM TURRETS - UPPER & LOWER Number of Tools (Upper & Lower) 12 Turning Tool Shank 25 MM Boring Bar Shank Diameter 32 MM Milling Shank Diameter 16 MM Driven Tool Speed 6,000 RPM Number of Driven Tools (Upper & Lower) 12 FEEDRATES Upper Turret Rapids X1 / Y1 / Z1 20 / 12 / 40 M / MIN Lower Turret Rapids X2 / Y2 / Z2 20 / 12 / 40 M / MIN Rapid Traverse Speed - A (Right Spindle) 40 M / MIN MOTORS Spindle Motor - LH 15.0 / 11.0 KW Spindle Motor - RH 11.0 / 7.5 KW Turret Driven Tool Spindle Motor 5.5 / 3.7 KW Axis Feed Motors - X1 / Y1 / Z1 2.5 / 2.5 / 3.0 KW Axis Feed Motors - X2 / Y2 / Z2 2.5 / 1.2 / 3.0 KW Axis Feed Motor - (A) 2.5 KW SUPPLY 35 KVA MACHINE L 4,254 MM W 2,460 MM H 2,230 MM 8,300 KGS

Condition: like new (used), Year of construction: 2007, HYUNDAI WIA KH63G - YOM 2008/ FIRST INSTALLED 2010 - SERIAL NUMBER G3641-071 MACHINE CONSTRUCTION & FEATURES • Twin Pallet Horizontal Machining Centre. • One Piece Heavy Duty Cast Iron Bed Construction for High Accuracy & Rigidity. • Heavy Duty Oil Cooled 2 Stepped Geared High Torque Spindle. • Shuttle Type Pallet Changer. • Pre-Tensioned Double Anchored Ballscrews. TABLE Table Size 630 X 630 MM Maximum Load Capacity 1,000 KGS Maximum Working Size Ø 1,120 X H 875 MM Minimum Index Angle 1° FEED X-Axis 950 MM Y-Axis 825 MM Z-Axis 760 MM Distance from Table Surface to Spindle Centre 175 ~ 935 MM Distance from Table Centre to Spindle Nose 0 ~825 MM Guide Type HARDENED & GROUND BOX GUIDEWAYS SPINDLE Spindle Taper #50,DIN 69871 Spindle rpm 4,500 RPM Spindle Motor Output (Max/Cont.) 26.0 / 22.0 KW Spindle Torque (Max/Cont.) 1,267 / 1,071 NM Type 2 STEPPED GEAR FEED RATE Cutting Feed Rate X, Y and Z-Axis 5 M / MIN Rapid Feed Rate X, Y and Z-Axis 20 M / MIN ATC Number of Tools 60 Tool Type ISO 50, DIN69871 Maximum Tool Diameter Ø 110 MM Max. Tool Diameter without Adjacent Tools Ø 245 MM Maximum Tool Length 600 MM Maximum Tool Weight 20 KGS Tool Selection Method FIXED ADDRESS Tool Change Time – Tool to Tool 6 SEC Tool Change Time – Chip to Chip 11 SEC APC Number of Pallets 2 APC Type SHUTTLE TANK CAPACITY Coolant Tank 400 L POWER SUPPLY Electric Power Supply 36 KVA Voltage 415 V / 50 HZ / 3PH Hodpfx Aceu A Td Tevok MACHINE Floor Space (L x W) 3,530 X 5,320 MM Height 3,106 MM Weight 14,000 KGS STANDARD SUPPLIED MACHINE FEATURES • Total Splash Guard • Door Interlock • APC (2 Pallets) • Remote MPG • Coolant Tank • Internal Chip Conveyor (2 Sets) • Work Light • Tapped Holes in Pallets • Levelling Pads and Bolts • Operation/Programming Manuals • Call Light • Selection of Spindle Tooling

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, machine/vehicle number: TJGP2065, TAKISAWA TM-4000Y2 FANUC 31i B2 - TOTALLY AS NEW BUILT 2023 CNC MULTITASKING LATHE WITH UPPER & LOWER Y-AXES 10 INCH + 8 INCH STANDARD CHUCK SIZE. WITH:- Y-AXIS TRAVEL -50 +70 MM - UPPER TURRET (Y1 AXIS) Y-AXIS TRAVEL -50 +30 MM - LOWER TURRET (Y2 AXIS) CHIP CONVEYOR - RIGHT SIDE DISCHARGE HINGE TYPE (MORETECH JAPAN) AIR BLOW SYSTEM - RH SPINDLE ABNORMAL LOAD DETECTION FUNCTION WORK PHASE POSITIONING FUNCTION (C-AXIS TORQUE SKIP FUNCTION) COOLANT DELIVERY PIPE ABOVE THE SPINDLE - LH & RH SPINDLE COOLANT PUMP - 400W - 3 OFF OIL SKIMMER (OIL / WATER SEPARATOR) OIL SEPERATOR BOX HYDRAULIC PRESSURE SWITCH LED LIGHTING AUTO LUBRICATION SYSTEM AND COLLECTOR MACHINE MANUALS & OPERATOR HANDBOOKS TURRET MOUNTED MACHINE LEVELLING PLATE AUTO POWER OFF TRANSFORMER - 415V / 3PH / 50HZ STANDARD TOOLING PACKAGE TURRET COVER (6 EA) X 2 SERVO TURRET (LOWER) Y2 AXIS - 12 STATION WITH DRIVEN TOOLS SERVO TURRET (UPPER) Y1 AXIS - 12 STATION WITH DRIVEN TOOLS 8" 3-JAW THRU-BORE HYDRAULIC CHUCK ~ KITAGAWA BR-08 RH SPINDLE 10" 3-JAW THRU BORE HYDRAULIC CHUCK (KITAGAWA BR-10) - LH SPINDLE DIRECT DRAWING DIMENSION INPUT HELICAL INTERPOLATION FUNCTION RAKU-RAKU MONITORING SYSTEM BAR HI PRESS COOLANT PUMP (NIHON) 2 OFF CALL LAMP (3 COLOUR) BAR FEEDER INTERFACE FOR MULTI BAR MAGAZINE UNLOADER WITH PARTS DISCHARGE CONVEYOR QUICK TOOL SETTING DEVICE - MANUAL TYPE BOTH TURRETS AI CONTOUR CONTROL II Hodpoxrnwljfx Acvok CHIP CONVEYOR UPGRADE (MORETECH JAPAN) AXIAL DRIVEN TH, ER32 OUTPUT, 6000 RPM, 1:1 RATIO, EXT COOLANT - 4 OFF RADIAL DRIVEN TH, ER32 OUTPUT, 6000 RPM, 1:1 RATIO, EXT COOLANT - 4 OFF MACHINE FEATURES TWIN SPINDLE, TWIN TURRET Y-AXIS CNC TURNING CENTRE. 2 OFF 12 STATION HIGH ACCURACY SERVO TURRETS LEFT HAND SPINDLE – 4,200 RPM RIGHT HAND SPINDLE - 5,000 RPM UPPER & LOWER TURRETS - 6,000 RPM LIVE TOOLING SPEED UPPER TURRET Y1-AXIS (- 50 + 70 MM) LOWER TURRET Y2-AXIS (- 50 + 30 MM) 10” + 8” STANDARD CHUCK SIZE MACHINE CAPACITIES Standard Turning Diameter Ø 215 MM Maximum Turning Diameter Ø 215 MM Maximum Turning Length 800 MM Bar Capacity Left Spindle Ø 82 MM Bar Capacity Right Spindle Ø 65 MM AXIS TRAVELS Upper Turret Travel X1 230 / 120 MM Upper Turret Travel Y1 120 (- 50 + 70) MM Upper Turret Travel Z1 800 MM Lower Turret Travel X2 210 / 80 MM Lower Turret Travel Y2 80 (- 50 + 30) MM Lower Turret Travel Z2 800 MM Travel A (RH Spindle) 900 MM LEFT SPINDLE Chuck Size Ø (10”) 254 MM Spindle Speed (RPM) 4,200 RPM Min. Indexing Angle (C-Axis) 0.001 DEG Spindle Nose A2-8 Spindle Bore Ø 94 MM RIGHT SPINDLE Chuck Size Ø (8”) 203 MM Spindle Speed 5,000 RPM Min. Indexing Angle (C-Axis) 0.001 DEG Spindle Nose A2-6 Spindle Bore Ø 77 MM Inner Bearing Dia.120 TURRETS Number of Tools (Upper/Lower) 12 Turning Tool Shank 25 MM Boring Bar Shank Dia. 40 MM Milling Shank Diameter 20 MM Driven Tool Speed 6,000 RPM Number of Driven Tools (Upper & Lower) 12 FEEDRATES Upper Turret Rapids- X1 / Y1 / Z1 20 / 12 / 30 M / MIN Lower Turret Rapids - X2 / Y2 / Z2 20 / 12 / 30 M / MIN Rapids on A (Right Spindle) 30 M / MIN MOTORS Spindle Motor - LH 18.5 / 15.0 KW Spindle Motor - RH 15.0 / 11.0 KW Turret Driven Tool Motor 7.5 / 3.7 KW Axis Feed Motors - X1 / Y1 / Z1 2.5 / 2.5 / 2.5 KW Axis Feed Motors - X2 / Y2 / Z2 2.5 / 1.2 / 2.5 KW SUPPLY 50 KVA MACHINE L 4,741 MM W 2,748 MM H 2,444 MM 9,370 KG

Condition: like new (used), Year of construction: 2007, HYUNDAI WIA KH63G - YOM 2008/ FIRST INSTALLED 2010 - SERIAL NUMBER G3641-071 MACHINE CONSTRUCTION & FEATURES • Twin Pallet Horizontal Machining Centre. • One Piece Heavy Duty Cast Iron Bed Construction for High Accuracy & Rigidity. • Heavy Duty Oil Cooled 2 Stepped Geared High Torque Spindle. • Shuttle Type Pallet Changer. • Pre-Tensioned Double Anchored Ballscrews. TABLE Table Size 630 X 630 MM Maximum Load Capacity 1,000 KGS Maximum Working Size Ø 1,120 X H 875 MM Minimum Index Angle 1° FEED X-Axis 950 MM Y-Axis 825 MM Z-Axis 760 MM Distance from Table Surface to Spindle Centre 175 ~ 935 MM Distance from Table Centre to Spindle Nose 0 ~825 MM Guide Type HARDENED & GROUND BOX GUIDEWAYS SPINDLE Spindle Taper #50,DIN 69871 Spindle rpm 4,500 RPM Spindle Motor Output (Max/Cont.) 26.0 / 22.0 KW Spindle Torque (Max/Cont.) 1,267 / 1,071 NM Type 2 STEPPED GEAR FEED RATE Cutting Feed Rate X, Y and Z-Axis 5 M / MIN Rapid Feed Rate X, Y and Z-Axis 20 M / MIN ATC Number of Tools 60 Tool Type ISO 50, DIN69871 Maximum Tool Diameter Ø 110 MM Max. Tool Diameter without Adjacent Tools Ø 245 MM Maximum Tool Length 600 MM Maximum Tool Weight 20 KGS Tool Selection Method FIXED ADDRESS Tool Change Time – Tool to Tool 6 SEC Tool Change Time – Chip to Chip 11 SEC APC Number of Pallets 2 APC Type SHUTTLE Hjdpfx Aolrqiqecvsk TANK CAPACITY Coolant Tank 400 L POWER SUPPLY Electric Power Supply 36 KVA Voltage 415 V / 50 HZ / 3PH MACHINE Floor Space (L x W) 3,530 X 5,320 MM Height 3,106 MM Weight 14,000 KGS STANDARD SUPPLIED MACHINE FEATURES • Total Splash Guard • Door Interlock • APC (2 Pallets) • Remote MPG • Coolant Tank • Internal Chip Conveyor (2 Sets) • Work Light • Tapped Holes in Pallets • Levelling Pads and Bolts • Operation/Programming Manuals • Call Light • Selection of Spindle Tooling

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD2200Y FANUC 0IT PLUS CNC LATHE WITH Y AXIS. MACHINE CONSTRUCTION & FEATURES ▪ ONE PIECE HEAVY DUTY CAST IRON BED CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ 4,000 RPM MAIN SPINDLE. ▪ 6,000 RPM LIVE TOOLING SPEED. ▪ HEAVY DUTY CUTTING WITH EXCELLENT PERFORMANCE. ▪ WEDGE TYPE Y-AXIS. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET - BMT55P ▪ HARDENED & GROUND BOX GUIDEWAYS Swing Over the Bed Ø 820 MM Swing Over the Carriage Ø 650 MM Maximum Turning Diameter Ø 300 MM Hsdpfxex Th Nye Acvek Maximum Turning Length 610 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 76 MM Spindle Speed (Rpm) 4,000 RPM Motor (Max / Cont.) 18.5 / 15.0 [22.5 / 15.0] KW Torque (Max / Cont.) 206.2 / 125.4 [215.0 / 143.3] NM Spindle Type BELT Spindle Nose A2-6 Travel X 215 MM Travel Y 110 (± 55) MM Travel Z 680 MM Rapid Speed X 24 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 30 M / MIN HARDENED & GROUND BOX GUIDEWAYS Number of Tools 12 [24] Tool Size - OD 25 MM² Tool Size - ID Ø 20 MM Indexing Time 0.2 SEC / STEP Y-Axis Type WEDGE TYPE LIVE TOOL Motor (Max / Cont.) 5.5 / 3.7] KW Milling Tool Speed 6,000 RPM Torque (Max / Cont.) 52.5 / 26.5 NM Collet Size Ø 16 – ER25 Type BMT-55P TAILSTOCK Taper MT 4 Quill Diameter Ø 80 MM Quill Travel 120 MM Travel 680 MM TANK CAPACITY Coolant Tank 200 L Lubricating Tank 2.0 L Electric Power Supply 27 KVA Thickness of Power Cable OVER 25 MM² Voltage 415 V / 50 HZ / 3PH Floor Space (L x W) 3,380 x 1,800 MM Height 1,950 MM Weight 4,700 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CHIP - CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 6.0 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD TURRET UPGRADE - 12 STATION 24 POSITION BMT55P, LIVE TOOLS 6K RPM, 5.5 KW STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) FRONT DOOR INTERLOCK TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER

Condition: like new (used), Year of construction: 2020, functionality: fully functional, operating hours: 1,500 h, USED Akira Seiki 1600XP Fanuc 0iMF Open Fronted Vertical Machining Centre with Fanuc Ex Stock - Subject to Prior Sale. YOM 2020, Machine with Very Low Hours Usage. Approx 1500 Hours  12,000 RPM Spindle with Refrigeration System  36 Station Arm Type ATC  Full Splash Guard  Fully Integrated Detron GXA-255h 4th Axis Nc Rotary Table with SR255H Tailstock Support Unit  Chip Conveyor & Chip Bin (Scraper Type)  Chip Flushing System Including Coolant Wash Gun  Through Spindle Coolant System - 35 Bars with Filter  Fanuc Memory Extension - 2 Mb  Fanuc 10.4 “ Screen with Manual Guide-I  Coolant Tank Capacity - 640 Litres Hedpfx Acsq Nmm Tsvjk  THK Heavy Duty Linear Guideways  Manual Pulse Generator  3 Colour Signal Lamp  Automatic Lubrication System  Rigid Tapping & Helical Interpolation Function TABLE Working Surface 1,750 X 800 MM Tee Slots 18 x 125 x 6.0 MM Spindle Nose to Table 100 ~ 915 MM Spindle Centre to Column 865 MM Table Load Capacity 2,300 KGS TRAVEL X-Axis Travel 1,630 MM Y-Axis Travel 850 MM Z-Axis Travel 815 MM SPINDLE Spindle Nose Taper BT-40 Spindle Speed - Max 12,000 RPM FEED Rapid Traverse (X & Y-Axis) 33 M / MIN Rapid Traverse (Z-Axis) 25 M / MIN Cutting Feedrates - Max 12 M / MIN ACCURACIES Positioning 0.01 MM Repeatability + - 0.003 MM ATC Tool Storage Capacity ARM TYPE - 36 STATIONS Maximum Tool Weight 7.0 KGS Tool Diameter - Max 75 MM Tool Length - Max 250 MM Tool Shank BT-40 Tool Exchange Time 2.2 SEC MOTOR Spindle Drive Motor (FANUC) 18.5 KW POWER SUPPLY Voltage 415V / 3PH / 50HZ Power Requirement 30.0 KVA MACHINE DIMENSIONS Machine Floor Space Requirement 4,820 x 3,576 MM Machine Weight 12,600 KG

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA SE2200LY WITH FANUC 0i-T PLUS CONTROL CNC LATHE WITH Y AXIS. TURRET UPGRADE - 12 STATION 24 POSITION BMT45, LIVE TOOLS 6K RPM, 2.75 KW MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HIGH PERFORMANCE ROLLER LM GUIDEWAYS. ▪ 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET - BMT45. [24 POSITION OPTION] ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 30 X 36 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ C-AXIS SPINDLE & WEDGE TYPE Y-AXIS. Swing Over the Bed Ø 600 MM Swing Over the Carriage Ø 600 MM Maximum Turning Diameter Ø 300 MM Maximum Turning Length 508 MM Bar Capacity – Main Spindle Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” - 203 MM Spindle Bore Ø 75 MM Spindle Speed 4,500 RPM Motor (Max / Cont.) 15.0 / 11.0 KW Torque (Max / Cont.) 167 [150.3] NM Spindle Type BELT Spindle Nose A2-6 FEEDS Travel X 210 MM Travel Y 110 (± 55) MM Travel Z 560 MM Rapid Speed X 30 M / MIN Rapid Speed Y 10 M / MIN Rapid Speed Z 36 M / MIN Slide Type ROLLER LM GUIDEWAYS TURRET Number of Tools 12 [24 POSITION INDEX] Tool Size - OD 20 MM² Tool Size - ID Ø 32 MM Indexing Time 0.15 SEC / STEP Y-Axis Type WEDGE TYPE Milling Tool Speed 6,000 RPM Motor (Max / Cont.) 2.75 / 1.85 [2.8 / 3.8] KW Torque (Max / Cont.) 26.2 [27.0] NM Collet Size ER 20 - Ø 13 Type BMT45 HYDRAULIC NC TAIL STOCK (STD. LIVE CENTER) Taper MT#4 Quill Diameter Ø 56 MM Travel 580 MM Coolant Tank 200 L POWER SUPPLY Electric Power Supply 18 KVA Thickness of Power Cable OVER 16 MM² Voltage 415V / 50HZ / 3PH Floor Space (L x W) 2,960 X 1,730 MM Height 1,920 MM Weight 4,200 KGS STANDARD FACTORY FITTED MACHINE OPTIONS SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3-JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) MANUAL VIEWER OPERATION MEMO PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) PREMIUM TOOL OPERATION SCHEDULING SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 200 LITRES FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) BACK SPIN TORQUE LIMITER FRONT DOOR INTERLOCK TOOLBOX MAIN SPINDLE - 4,500 RPM, 15.0 / 11.0 KW, 167 NM BELT DRIVEN STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE HYDRAULIC TYPE NC TAILSTOCK - MT#4 56 MM QUILL, STD LIVE CENTER 12 STATION BMT45 TURRET, LIVE TOOLS 6K RPM, 2.75 KW, 26 NM INCLUDED FACTORY FITTED MACHINE OPTIONS CHIP - BUCKET STANDARD CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD CALL LAMP (3 COLOUR) - IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE Hedpfx Acjx Tqkmjvok PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO QUILL FORWARD / REVERSE CONFIRMATION DEVICE

Condition: like new (used), Year of construction: 2023, machine/vehicle number: 0-250-88-8729, functionality: fully functional, operating hours: 221 h, input voltage: 400 V, input current: 42 A, input frequency: 50 Hz, type of input current: three-phase, workpiece length (max.): 3,275 mm, workpiece width (max.): 1,405 mm, workpiece height (max.): 260 mm, number of axes: 5, number of slots in tool magazine: 24, total height: 2,650 mm, total length: 6,850 mm, total width: 3,616 mm, Equipment: CE marking, documentation/manual, We offer this as new HOMAG CENTATEQ P-110 CNC horizontal pod & rail machining centre. This machine has had very light usage. 5 Axis Head for trimming, drilling and sawing 10no. position linear tool changer plus 14no. position carousel tool changer HSK-F63 12no. Spindle Vertical Quick Release Drill Heads 4no. Spindle Horizontal Quick Release Drill Heads H4X X Axis Hedpfeyx Hnxjx Acvsk 2no. Spindle Horizontal Quick Release Drill Heads H2Y Axis 1no. Groove Saw 1no. Tool length check measuring unit 1no. Portable console unit. 2no. Vacuum pumps If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2012, machine/vehicle number: 0-250-11-2362, functionality: fully functional, operating hours: 1,974 h, power: 11.5 kW (15.64 HP), input voltage: 415 V, input current: 21 A, input frequency: 50 Hz, type of input current: three-phase, workpiece length (max.): 3,050 mm, workpiece width (max.): 850 mm, workpiece height (max.): 60 mm, number of axes: 3, number of slots in tool magazine: 4, total height: 2,050 mm, total length: 1,500 mm, total width: 1,650 mm, Equipment: CE marking, documentation/manual, We offer this very good WEEKE BHX 055° Optimat vertical wood machining center, year of manufacture 2012. Manufacturer: WEEKE Model: BHX 055° Optimat Year of manufacture: 2012 Condition: very good Category ID: 2502 Hodpfsyx Duisx Acvok Type ID: 4257 Machine type: vertical wood machining center If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2021, Traverses X Y Z: 508 x 406 x 356mm, Table 1016 x 353mm, Spindle taper BT40, Hjdpeyw R Hpofx Acvsk 20Hp spindle motor, Spindle Speed 10000rpm, HAAS Control, 20 Station ATC, coolant.

Condition: excellent (used), Year of construction: 2022, Standard turning length 125mm, Hjdpfoyw Ilvex Acvjk Maximum cutting diameter 210mm, bar capacity 64mm (main), 54mm (sub) spindle speed 4,000 rpm, sub spindle speed 5,000rpm, milling speed 6,000rpm, C axis 0.001 degrees, spindle power 15/11Kw, 12 station upper & lower turrets, Y axis +/- 40mm to both turrets. Fanuc 31i-Bcontrol, swarf conveyor, barfeed unit.

Condition: good (used), Year of construction: 2010, (ex Formula 1 ) Traverses XYZ: 800 x 800 x 550mm, 500 x 500mm table, Hodpfjywv N Aox Acvok A axis -91 / + 121 degrees, C axis, 360 degrees, Heidenhain TNC530, Spindle Speed 20000rpm, 36kW Spindle Motor, HSK A63 Spindle Taper, 30 tools, swarf conveyor, through spindle coolant,

Condition: excellent (used), Hurco VMX50i (2014) 3-Axis Vertical Machining Centre Control: Hurco WinMax Travels & Capacity X Axis Travel: 1270 mm Y Axis Travel: 660 mm Z Axis Travel: 610 mm Table Size: 1500 x 660 mm Hjdpfx Ajyx H Rtocvsk Max Table Load: 2000 kg

Condition: excellent (used), Mazak 18M Super Quick Turn 'C' Axis, Driven Tool Lathe With Mazatrol T-Plus Control Kitagawa B210 3 Jaw Power Chuck. Swing Ø531mm. Maximum Machining Ø300mm. Maximum Machining Length 507mm. Distance Between Centres 864mm. Bar Capacity Ø64mm. Axis Travel 'X'180mm, 'Z'=575mm. Main Spindle Speed Range 35-4,000rpm. Driven Tool Speed Range 120-3,000rpm. 12 Station Automatic Turret. S/No. 119752 (1996). Note: This lot is located in Hampshire (full site address to be added to the buyer’s invoice). Hedpfoyw Tigjx Acvek With Coolant System, Chip Conveyor, Filtermist FX4000 Mist Extraction Unit, Tool Presetter, Tailstock, & Foot Switches. Approx Machine Weight 4,750kg. Note: This lot is located in Hampshire (full site address to be added to the buyer’s invoice).

Condition: used, Year of construction: 2007, (2007) Matsuura HPlus 300 PC11 CNC Horizontal Pallet Changing Machining Centre With Matsuura G-Tech 30i Contro Hodpjyw Thcsfx Acvsk Table Dimension 300 x 300mm. Maximum Table Load 250kg. Maximum Component Dimension Ø530mm x H760mm. Axis Travel 'X'=500mm, 'Y'=560mm, 'Z'=500mm, 'B'=0-360° (0.001° Increment). Distance Spindle Nose To Table 80-640 mm. Rapid Traverse 'XYZ'=60,000mm/min, 'B'=100rpm. Spindle Speed Range 50-15,000rpm (15kW Motor). Spindle Taper BT 40. 150 Position ATC. Maximum Tool Ø90mm (Ø150mm No Adjacent Tool), Maximum Tool Length 300mm, Maximum Tool Weight 8kg. S/No. 16950 (2007). Note: This lot is located in Hampshire (full site address to be added to the buyer’s invoice). With Dual Auger To FSE Chip Conveyor, FSE Through Coolant High Pressure Filtration System, Quantity Of Pallets With Tombstones, Spin Window, Hand Wheel, Signal Tower, Full Manuals, Tool Holders, Back Up CD/USB & Maintenance Records. New Spindle 18 Months ago at a cost of £20,000. Note: This lot is located in Hampshire (full site address to be added to the buyer’s invoice).

Condition: excellent (used), Year of construction: 2005, FOR SALE - Emcomat 17D Lathe Year 2005 Travel in X/Z 220 / 710 mm Distance between centers - 700 mm Distance above centers - 170 mm Max. speed - 3000 rpm Spindle nose - DIN 55029 Max. drive power - 5.3 kW Quill diameter 50 mm Inner cone MT3 Quill travel 120 mm Dimensions (LxWxH) 1650 x 1060 x 1635 mm Hsdpfx Aoxyzikscvsk Machine weight 755 kg 3 & 4 Jaw Chuck

Condition: good (used), Year of construction: 2004, functionality: limited functionality, travel distance X-axis: 560 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 625 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, controller manufacturer: Okuma, controller model: OSP-E100M, workpiece length (max.): 600 mm, workpiece width (max.): 710 mm, workpiece weight (max.): 400 kg, total height: 2,760 mm, total length: 4,535 mm, total width: 2,415 mm, table width: 400 mm, table length: 400 mm, table load: 400 kg, overall weight: 11,500 kg, spindle speed (max.): 10,000 rpm, distance table center to spindle nose: 710 mm, spindle motor power: 15,000 W, spindle nose: BT40, number of spindles: 1, number of slots in tool magazine: 40, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, rotational speed infinitely variable, Okuma Space Center MA400HA Horizontal Machining Centre Machine Type: CNC Horizontal Machining Centre Year: 2004 Control: OSP-E100M Axes: 4 No. of Pallets: 2 Condition: Good - There is an issue with the pallet changer. Includes Cromar Swarf Conveyor Hsdowcd Evopfx Acvjk Coolant Filtration System Technical Specifications Pallets: 2 Size of Pallets: 400 x 400mm X Axis Travel: 560mm Y Axis Travel: 610mm Z Axis Travel: 625mm B Axis Travel: 360 Deg Rapid Traverse: 60m/min Spindle Centre to Pallet Top: 50 - 660mm Spindle Nose to Pallet Centre: 85 - 710mm Max Pallet Load: 400kg Max Workpiece Dimensions: 600 x 710mm Tool Pockets: 40 Spindle Taper: BT40 Spindle Power: 15kW Spindle Speed: 10,000rpm Machine Dimensions: 4535 x 2415 x 2760mm Machine Weight: 11,500kg Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, type of input current: three-phase, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, workpiece weight (max.): 800 kg, number of slots in tool magazine: 30, controller manufacturer: Fanuc, total height: 2,700 mm, total length: 4,080 mm, total width: 2,400 mm, overall weight: 7,000 kg, table length: 1,200 mm, table width: 510 mm, controller model: Oi-MC, coolant supply: 15 bar, spindle motor power: 15,000 W, number of spindles: 1, rapid traverse Z-axis: 30 m/min, rapid traverse X-axis: 36 m/min, rapid traverse Y-axis: 36 m/min, spindle nose: BT40, spindle speed (max.): 12,000 rpm, table load: 800 kg, Equipment: chip conveyor, rotational speed infinitely variable, Doosan NM510 Vertical Machining Centre Machine Type: 3 Axis Vertical Machining Centre Year: 2008 Control: Fanuc Series Oi-MC Condition: Very Good Includes Swarf Conveyor Chiller MCF20 Coolant Filter Autolube 6 x Tool Holders Notes Vice and clamping block in photos not included Technical Specifications Table Size: 1200 x 510mm Table Load: 800kg Travel (X-Axis): 1020mm Travel (Y-Axis): 510mm Travel (Z-Axis): 510mm Max Spindle Speed: 12,000rpm Spindle Power: 18.5/15/11kW Hjdpfxev Iq Ezo Acvjk Spindle Taper: BT 40 Rapid Traverse (X/Y/Z): 36/36/30m/min Tool Storage Capacity: 30 tools Tool Change Time (T-T/C-C): 1.7/3.5sec Machine Dimensions: 4080 x 2400 x 2700mm Machine Weight: 7,000kg Notes: *Specifications are given in good faith but not guaranteed*
