Used Doosan Puma 280 for sale (324)

Condition: used, Year of construction: 2008, functionality: fully functional, DOOSAN PUMA 280 LM CHOICE OF TWO MACHINES FOR SALE 2007,2008 Hodpfx Aexbgpfsacsfn TURNING DIA 420 MM MAX TURNING LENGTH 706/1030 76 MM SPINDLE BORE MAX SPINDLE SPEED 3500 RPM 12 STATION TURRET SPINDLE INDEXING C AXIS 0.001 ROTARY TOOL SPEED 5,000 RPM QUILL TAPER 5 MT MAIN SPINDLE 18.5 KW OVER ALL DIMS OF MACHINE NOT INCLUDING BAR FEED 3838 MM LONG X 1670MM WIDE X 1735MM HEIGHT MACHINE WEIGHT 5.9 TON THIS MACHINE WILL COME WITH DRIVEN TOOLING AND A BARFEED

Condition: used, Control – Fanuc 31i Max. turning diameter: 760 mm Max. turning length: 1540 mm Chuck size: 10" inches Bar working diameter: 76 mm Max. spindle speed: 4000 rpm Hsdoxlbvujpfx Aacefn Max. spindle motor power: 26 kW Milling spindle speed: 12,000 rpm Y-axis travel: 230 (±115) mm

Condition: used, Year of construction: 2008, turning diameter 900 mm turning length 1.600 mm control FANUC 21i TB turning diameter over bed 1.030/800 mm bar passage 160 mm Hedpfx Asvzhcdsacofn travel -x axis 450 mm travel -z axis 1.650 mm speed X/Z 12 /16 m/min Machine on 30.337 h Cutting time 16.067 h total power requirement 64,4 kVA weight of the machine ca. 16 t dimensions of the machine ca. 5.760 x 3.145 x 2.780 mm

Condition: good (used), Year of construction: 2012, functionality: fully functional, CNC long turning lathe Doosan Puma St20G Hfsdpfowtg Diox Aacen Year of manufacture 2012 Bar feeder FMB turbo 3-26 Chip conveyor

Condition: good (used), Year of construction: 2008, functionality: fully functional, turning length: 1,520 mm, turning diameter: 540 mm, spindle speed (max.): 10,000 rpm, travel distance X-axis: 550 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,595 mm, rotational speed (max.): 3,500 rpm, number of slots in tool magazine: 40, swivel angle B-axis (min.): -120 °, swivel angle B-axis (max.): 120 °, TECHNICAL DETAILS CNC control: Fanuc 18iT-B Turning length: 1,520 mm Swing diameter: Ø 540 mm Turning diameter over bed: Ø 750 mm Turning diameter over cross slide: Ø 600 mm Bar capacity: 76 mm Turning-milling spindle X-axis travel: 555 mm Y-axis travel: ±80 mm (160 mm total) Z-axis travel: 1,595 mm B-axis indexing: ±120° (240° total) Tool system: Capto C6 Max. tool diameter (continuous): 90 mm Max. tool diameter (without adjacent tools): 120 mm Max. tool length: 300 mm Max. tool weight: 8 kg Tool change time (tool to tool): 1.5 s Number of tools in the magazine: 40 Max. spindle speed: 10,000 rpm Milling spindle motor power (30 min / continuous operation): 15 / 11 kW Lower turret X-axis travel: 185 mm Y-axis travel: 1,640 mm Hfedpsxf Hrnjfx Aacjn Number of tool positions: 12 Max. speed of driven tools: 4,000 rpm Main spindle Max. spindle speed: 3,500 rpm Chuck size: Ø250 mm Spindle mount: ASA A2-8 Spindle bore: Ø86 mm Draw tube bore: Ø77 mm C-axis – max. indexing angle: 0.001° Main spindle motor power (30 min / continuous operation): 26 / 22 kW Counter spindle Max. spindle speed: 3,500 rpm Counter spindle travel: 1,565 mm Travels and rapid traverses X1 axis travel: 555 mm X2 axis travel: 185 mm Z1 axis travel: 1,595 mm Z2 axis travel: 1,640 mm Y axis travel: ±80 mm (160 mm total) A axis travel: 1,565 mm C1, C2 axis travel: 360° (0.001° resolution) B axis travel: ±120° (240° total) B axis coupling angle: 15° X1, Z1, Z2 axis: 24 m/min Y axis: 16 m/min A axis: 24 m/min C1, C2 axis: 200 rpm B axis: 27 rpm MACHINE DETAILS Weight: 15.5 t Connected load: 93.92 kVA Dimensions: 5,550 x 2,560 x 2,645 mm EQUIPMENT - Fanuc 18iT-B CNC control - Capto C6 tool system - 40-position tool magazine - Lower turret with 12 tool positions

Year of construction: 2014, condition: ready for operation (used), Control Unit Brand FANUC Movement X-Axis Movement 578 Z-Axis Movement 2033 Tail Stock Pinol tool taper Morse Taper MT6 Additional Equipment Stations: 12 Type: BMT75P Tooling: All tooling available, including boring bar holders, general turning tool holders, facing tools Hfedjw U E Tkepfx Aacon Collets: ER40 Collets Control Unit Brand FANUC Movement X-Axis Movement 578 Z-Axis Movement 2033 Tail Stock Pinol tool taper Morse Taper MT6 Additional Equipment Stations: 12 Type: BMT75P Tooling: All tooling available, including boring bar holders, general turning tool holders, facing tools Collets: ER40 Collets This DOOSAN Puma 400LM was manufactured in 2014. A robust horizontal turning machine featuring a spindle speed of 1500 rpm and a 12 station turret BMT75P compatible with ER40 collets. It comes with a comprehensive set of tooling, including boring bar holders, general turning tool holders, and facing tools. If you are looking to get high-quality turning capabilities, consider the DOOSAN Puma 400LM machine we have for sale. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2007, turning diameter 300 mm turning length 600 mm control FANUC, 18i-TB turning diameter over bed slide 230 mm travel x1 165 mm travel z1 700 mm travel x2 190 mm travel z2 720 mm travel -y axis +/- 50 mm main spindle bore 76 mm main spindle speed 5.000 U/min main spindle drive 22 kW max. torque on the spindle 208 Nm sub spindle bore 76 mm sub spindle speed 5.000 U/min sub spindle drive 22 kW max. torque on the spindle 208 Nm tool turret 2 x 12 Stat. number of driven tool stations 2 x 12 speed of driven tools 5.000 U/min max. torque 47 Nm work piece power 5,5 kW Hsdpfjxn Amtjx Aacsfn C-axis resolution 0,001 ° rapid traverse x + z axis 20 / 40 m/min rapid traverse y-axis 7,5 m/min total power requirement 68,4 kVA weight of the machine ca. 7,8 t Accessories: collet fixture on main spindle, hydr. 3-jaw chuck make KITAGAWA, BB 208, 210 mmø, on sub spindle, various tool holders for turret, bar loader make HYDRAFEED, model MULTIFEED MX-1B for bar dia. 3 - 80 mm and bar length up to 1650 mm, chip conveyor, coolant with belt filter device

Year of construction: 2004, condition: good (used), We are offering a Doosan Puma 2000 LSY with bar feeder: - Year 2004, 9,400 operating hours - Fanuc 18i-TB - LNS Servo 2 bar feeder - Tool measurement system Hedpfxjxk Uz Io Aacjfn - Chip conveyor - 12 tool stations - x, y, x, b = 250, ±50, 830, 830 Under power

Condition: good (used), Year of construction: 2018, CNC lathe DOOSAN Puma 4100XLMC with Fanuc control; Only 2,000 spindle hours!!! 3m turning length with programmable hydraulic steady rest SLU 4; Spindle bore 165 mm; All axes are flat-guideways – suitable for heavy-duty machining; Spindle with gearbox – over 2,400 Nm; Chip conveyor, tool setter, extraction system; 380 mm chuck installed, plus an additional 530 mm chuck; Hsdpfexn Th Uox Aacjfn Various fixed and driven tool holders;

Condition: good (used), Year of construction: 2001, turning length: 580 mm, travel distance X-axis: 205 mm, mount diameter: 12 mm, LNS Barfeeder 1000 mm Tool eye Part chatcher Kitagawa chuck for main & sub spindel Collet device for mail & sub spindel Live driven tooling Max. turning Ø: 290mm X-Axis: 205mm Z-Axis: 580mm Spindle bore: 51mm Speedrange: 4500Rpm Spindle power: 15kW Subspindle speeds:4500Rpm Subspindle bore: 51mm Subspindle power:15kW ATC / revolver: 12 Speed live tools:4500Rpm Power live tools:7.5kW Hjdpfx Aajxdxc Aocefn Chip conveyor: Yes Tool eye: Yes Length: 3500mm Width: 2000mm Height: 2300mm Weight: 4200kg

Condition: excellent (used), Year of construction: 2012, Offered here is a Doosan Puma TT1800SY-GL CNC lathe including portal loader. The machine is in good condition and can be inspected under power in our warehouse. The scope of delivery includes various static tool holders and 4 driven tool holders. The machine will be loaded free onto truck by overhead crane. Make: Doosan Model: Puma TT 1800SY-GL Control: Fanuc 31i Year of manufacture: 2012 Technical Data: Turning diameter (lower and upper turret): 230 mm Turning diameter over bed: 230 mm Turning diameter over slide: 230 mm Recommended turning diameter: 210 mm Chuck size (both spindles): 210 mm/ 8 inch Spindle bore: 65 mm Travel: X1-Z1 (upper turret): 165x700 mm X2-Z2 (lower turret): 190x720 mm Y (upper turret): 100 mm A (sub spindle): 770 mm C-axis: 360° (0.001° increment) Feed rates: X1-X2-Z1-Z2: max. 20 m/min Y: 7.5 m/min A: max. 40 m/min Spindle speeds (both spindles): 6000 rpm Spindle power S1: 22/19.6 kW Spindle power S2: 22/18.5 kW Torque (both spindles): 208 Nm Number of tool stations: 24+24 (lower and upper turret) Rotational speed of driven tools: max. 6,000 rpm Torque driven tools: 5.5/2.2 kW (7.4/3.0 kW) Power consumption: 64.86 kVA Hfodpfsxmkfhex Aacen Dimensions: 3905x2250x2600 mm (machine only) + portal loader

Year of construction: 2015, condition: ready for operation (used), General Data Measurements width 2440 mm Measurements depth 6642 mm Measurements height 2060 mm Machine weight 11000 kg Control Unit Brand FANUC Model 32i control Main Drive Spindle speed range 2000 rpm Spindle motor power 26 kW (Gearbox) Additional Equipment Turret Positions: 10 station This DOOSAN Puma 400LB was manufactured in 2015. A robust horizontal turning machine featuring a FANUC 32i control, it has a chuck size of 381mm and a bar capacity of 117mm. The machine offers a maximum cutting diameter of 550mm and a length of 2093mm. With a 10 station turret and rapid feedrates of X x Z: 16 x 18m/minute, it's ideal for efficient machining. Contact us for further details regarding this machine. Application Types Turning Hfedpow Uahisfx Aacsn

Condition: used, Year of construction: 2004, operating hours: 10,000 h, Doosan PUMA 2000 LSY with bar feeder Year of manufacture/new: 2004 Operating hours: 9,400 Control: Fanuc 18i-TB Bar feeder: LNS Servo 2 Tool measurement: available Chip conveyor: available Tools: 12 stations Axes Hfjdpfx Aaexizdgjcjn X: 250 mm Y: ±50 mm Z: 830 mm B: 830 mm

Condition: excellent (used), Year of construction: 2014, 1000mm Swing, 760mm max. machining diameter, 1540mm max turning length, Hfodpfxjw I Tnij Aacsn 4000rpm main spindle, 76mm bar capacity, 12000rpm milling 18.5kW, C axis 0.001 degrees, Y axis -/+115mm, 40 station ATC, 12 station lower turret, milling speed 4,000rpm, 22kW spindle motors, FANUC 31i control, 3 Jaw Power Chuck, Swarf Conveyor, Coolant

Condition: good (used), Year of construction: 2003, Ref. -No.: 10454 Manufacturer: DOOSAN Type: DAEWOO PUMA 300 MSC Hfsdpfx Asxc Trpoacsn Year of construction: 2003 Type of control: CNC Control: FANUC 18i-TB Storage location: Halberstadt Country of origin: South Korea Machine-No.: 0MS19XX Turning Speeds: 4500 RPM Bar passage: 62 mm Turning Length: 595 mm Turret places: 12 Pcs Further information: - 4 axes (X/Z/C/B) - counter spindle - driven tool station - finished part removal system - conveyor belt - chip conveyor - Powercool coolant system - LNS Quickload Servo 3 bar loader - tool holder - collet holder - collets Machines can be inspected under power by appointment.

Condition: excellent (used), Year of construction: 2011, FANUC 32i A CNC Control Spindle Hours: 8,541h Technical Details Travel over Slide: 900 mm Turning Length: 3,200 mm Travel over Bed: 1,030 mm Standard Turning Diameter: 750 mm Spindle Bore: 110 mm X Stroke: 471 mm Z Stroke: 2,100 mm Rapid Feed - Longitudinal/Transverse: 15/20 m/min Spindle Speed: 3,000 rpm Spindle Motor: 45 kW Turret: 12/6 BMT 85 Hedswqpn Espfx Aacofn Electric Motor: Tools: 7.5/5.7 kW Driven Speed: Tools: 3,000 rpm Total Power Requirement: 62.2 kVA Machine Weight: Approx. 22 t Dimensions: 7,357 x 2,710 x 2590 mm Accessories: 12-position turret for driven tools Hydraulic tailstock Sandvik Capto C6 tool holders – 4 pcs Hydraulic chuck Ø630 mm SMW Autoblock Hydraulic steady rest (min. 110 mm, max. 530 mm)

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, turning diameter over cross slide: 590 mm, turning length: 2,129 mm, turning diameter: 550 mm, spindle bore: 102 mm, spindle speed (max.): 3,000 rpm, travel distance X-axis: 362 mm, travel distance Z-axis: 2,155 mm, spindle motor power: 26 W, rapid traverse X-axis: 16 m/min, rapid traverse Z-axis: 18 m/min, quill diameter: 120 mm, Fanuc 21i-TB CNC STRUCTURE Cast iron tilted bed, 45° tilt Prismatic guides and counterguides coated with anti-friction material Weight (approximately): 10.500 kg SPINDLE Spindle nose: ASA A2-8 Standard 3-jaw hydraulic chuck, diameter 305 mm Set of soft jaws and set of reversible hardened jaws Continuously variable spindle rotation speed: 30-3000 min-1 Speed ranges with automatic change: 2 Spindle motor power (continuous/30 min-1): 22/26 kW Maximum power available starting at: 251 min-1 Hfjdpjw Avxhofx Aacon Max. Spindle motor torque (cont./30 min.): 837/989 Nm Front bearing diameter: 160 mm Spindle bore diameter: 102 mm Internal tie rod diameter: 91 mm TRAVEL X-axis travel: 362 mm Z-axis travel: 2,155 mm 2-axis CNC lathe FEEDS X/Z-axis rapid feeds: 16/18 m/min X/Z-axis feeds in linear interpolation (max.): 500/500 mm/rev X/Z-axis ball screw diameter: 40/50 mm TURRET Automatic bidirectional turret, with hydraulic locking Turret stations: no. 12 Indexing time (1 station): 0.9 sec Coupling disc diameter: 320 mm Turning/boring tool size: 32 x 32 mm/Ø60 mm TAILSTOCK Tailstock body in cycle (via automatic coupling to the carriage) Tailstock quill in cycle Rotating tailstock incorporated in the quill, Morse taper 5 connection Quilt diameter/stroke: Ø120/120 mm Thrust (pressure 40 bar): 1.456 kg CAPACITY Maximum rotating diameter on the bed: 770 mm Maximum rotating diameter on the carriage: 590 mm Maximum turning diameter on the bed: 550 mm Maximum turning length between centers: 2,129 mm Maximum turning diameter from bar: 90 mm Maximum permissible overhanging weight (chuck weight: 55 kg): 400 kg Maximum permissible weight using the tailstock (chuck weight: 55 kg): 1.600 Equipment supplied • Morari automatic steady rest, diam. 250 • Automatic lowering/rising tool presetting (with button and M code) • Automatic high-pressure coolant system: 6 bar • Coolant collection tank, capacity: 370 liters • Chip conveyor with right-side outlet • Hydraulic power unit with chiller for service supply • Automatic lubrication system • On-board electrical cabinet with heat exchanger • 3-color alarm and end-of-cycle light • Halogen work area lighting • Transformer • Installation equipment • Toolbox with essential tools and spare parts (e.g., fuses) • Instruction manual and test certificate • CE declaration of conformity Year of manufacturing: 2007

Year of construction: 2015, operating hours: 7,200 h, condition: ready for operation (used), Control Unit Brand FANUC Main Drive Spindle speed range 2000 Number of axis 2 Movement X-Axis Movement 352 mm Z-Axis Movement 1105 mm This DOOSAN PUMA 4100B was manufactured in 2015. A robust horizontal turning machine featuring a Fanuc 32i CNC system, it offers a maximum turning diameter of 550 mm and a length of 1,042 mm. Equipped with a 10-station turret and a chip conveyor, it's ideal for efficient machining with 7,200 hours of operation. If you are looking to get high-quality turning capabilities, consider the DOOSAN PUMA 4100B machine we have for sale. Contact us for more information. Hfodexlvbropfx Aacjn Application Types Turning

Condition: excellent (used), Year of construction: 2014, 1000mm Swing, 760mm max. machining diameter, 1540mm max turning length, 4000rpm main spindle, 76mm bar capacity, 12000rpm milling 18.5kW, C axis 0.001 degrees, Y axis -/+115mm, Hedpfjw Azz Ujx Aacjfn 40 station ATC, 22kW spindle motors, FANUC 31i control, 3 Jaw Power Chuck, Swarf Conveyor, Coolant

Year of construction: 2008, condition: ready for operation (used), General Data Measurements width 1900 mm Measurements depth 4200 mm Measurements height 1750 mm Machine weight 4140 kg Control Unit Brand FANUC Main Drive Spindle speed range 4500 Number of axis 2 Movement X-Axis Movement 205 mm Z-Axis Movement 580 mm Workpiece Workpiece drm over bed 550 mm Workpiece drm over support 300 mm Hodpfx Aasxg Unyecefn Tools Number of station 12 This 2-axis DOOSAN PUMA 240MB was manufactured in 2008. It features a maximum swing over bed of 550 mm, a bar capacity of 65 mm, and a spindle speed up to 4500 rpm. Equipped with a FANUC i-series CNC, 12-station turret with driven tools, and a chip conveyor. Ideal for precision turning operations. Contact us for more information about this machine. Application Types Turning

Condition: good (used), Year of construction: 2016, 600mm Swing, 300mm Max Diameter, Hfodpfxjw Awg Hs Aacsn 501 mm max length, 12 Station Turret, 65mm bar capacity, 3500rpm 18.5kW Spindle, Fanuc I series, Tool setter, tooling, Low Volt Light, Tailstock, Swarf Conveyor

Condition: ready for operation (used), Year of construction: 2013, operating hours: 15,000 h, Main Drive Spindle speed range 12000 Tool taper Capto C6 Number of axis 5 Movement Hsdsxn Dl Dopfx Aacsfn Y-Axis Movement 230 mm A-Axis Movement 1550 mm Workpiece Workpiece drm over bed 1000 mm This 5-axis DOOSAN Puma MX2600ST turn-mill centre was manufactured in 2013. It features a maximum turning diameter of Ø 760 mm, part length up to 1540 mm, and bar capacity of Ø 76 mm. Equipped with a Fanuc 31i-A control, dual spindles with speeds up to 4000 rpm, and a milling spindle at 12,000 rpm. Includes a tool magazine with 80 positions and a swarf conveyor. Consider the opportunity to buy this DOOSAN Puma MX2600ST turn-mill centre. Contact us for more information. Application Types Turning

Condition: excellent (used), Year of construction: 2022, Swing over bed 850mm, Swing over cross-slide 670mm, maximum machining diameter 420mm, Hfodpfxoww E Ins Aacon maximum machining length 765mm, bar capacity 102 mm, Y axis -/+ 65mm, 12 station turret, spindle speed 2,800 rpm, milling speed 5,000rpm, Fanuc I control ,12” 3 jaw, tool setter, swarf conveyor.

Year of construction: 2008, condition: ready for operation (used), General Data Measurements width 2200 mm Measurements depth 5000 mm Measurements height 2340 mm Machine weight 11700 kg Main Drive Spindle speed range 3500 Number of axis 5 Movement Y-Axis Movement 100 mm Hodpfx Asxdfk Hoacefn X-Axis Movement 255 mm Z-Axis Movement 800 mm Table Number of tslots 2x12 This 6-axis DOOSAN Puma TT 2500 SY was manufactured in 2008. It features a max turn diameter of 390mm, bar passage of 76mm, and a max working length of 700mm. Spindle speeds reach up to 3500 RPM with live tools at 4000 RPM. Ideal for complex turning tasks. Contact us for more information about this machine. Application Types Turning

Condition: good (used), Year of construction: 2014, 900mm Swing, 650mm max. machining diameter, 992 mm maximum turning length, 1000rpm spindle, Spindle bore 275mm, 10 station turret 45kW spindle motor, Hfsdswwtrbepfx Aacjn FANUC Series 32i control, 3 Jaw Power Chuck, Tailstock, Swarf Conveyor, Coolant,
