Used Decoiler for sale (293)

Condition: used, Decoiler and recoiler for coil material HMS Type BA 1.5-06/80 Machine no. Year of manufacture: 1991 Coil weight max. 8000 kg Coil outside diameter max. 1600 mm (with coil car) Coil outside diameter max. 2000 mm (without coil car) Diameter of coil support disc Ø 1700 mm Coil inner diameter, expansion range: 460-520 mm Coil width, nominal width max. 630 mm Width of expansion jaws: 750 mm Height of mandrel above base plate: 1500 mm - Mandrel driven by hydraulic motor with gearbox and gearwheel - Pneumatic overrun brake on mandrel TWINFLEX - Hydraulic service brake - Hydraulic stop brake - Hydraulic expansion of the mandrel, centrally via wedge slider system - Hydraulic pressing arm with hydraulically driven double pivot roller Giedpfshx R Etjx Afnon - Coil car with 12 ton lifting capacity and 300 mm lift - Decoiler on above-floor traveling frame with powered cross-travel drive - Hydraulic unit installed externally (was also used for other functions on a strip processing line) - Without electrical control cabinet (there is a control cabinet which supplied the entire strip processing line) Transport dimensions L x W x H 3500 x 1900 x 2500 mm Net weight approx. 5 tons Good condition – not electrically operational

Condition: used, Strip Processing Line, Decoiler and Straightening Machine Year of manufacture: 1991 Strip width: 50 to 450 mm Sheet thickness with straightener inactive: 6 mm Sheet thickness with straightener active: 2 mm - Very well equipped with feed-in aids Required floor space for the entire line (L x W): approx. 7000 x 3000 mm Total weight: approx. 11 tons Good condition Straightening Machine HMS Type RS 47-04/1, Machine No. Strip width, nominal: 400 mm Strip width, max. pass-through: max. 455 mm Strip thickness at 400 mm width: max. 1.5 mm (steel) Strip thickness at 400 mm width: max. 2 mm (copper) Speed: max. 40 m/min Number of straightening rolls: 7 Straightening roll diameter: Ø 40 mm Number of pinch rolls: 2 Pinch roll diameter: Ø 80 mm Entry height/pass-through height: 1500 mm - Straightening rolls hardened, ground and hard-chromed, with central support - Pinch rolls hardened, ground and hard-chromed, with hydraulic lifting - Manual straightening roll adjustment - Feed assist with hydraulically extendable tongue and hydraulically adjustable deflection pulley - Adjustable side strip guides - All straightening rolls driven via distribution gearbox and cardan shafts - Both pinch rolls driven via gearbox with cardan shafts - Frequency-controlled drive via geared motors - Straightener opening stroke 250 mm for cleaning or for processing thicker material, lifting by trapezoidal-thread spindle - Ultrasonic loop control Transport dimensions (L x W x H): 3600 x 2200 x 2200 mm Net weight: approx. 4 tons Decoiler HMS Type BA 1.5-06/80, Machine No. Coil weight: max. 8000 kg Outer coil diameter: max. 1600 mm (with load carriage) Outer coil diameter: max. 2000 mm (without load carriage) Diameter of coil turntable: Ø 1700 mm Coil inner diameter, expansion range: 460–520 mm Coil width, nominal: max. 630 mm Expansion jaw width: 750 mm Height of decoiler drum above base plate: 1500 mm - Decoiler drum driven by hydraulic motor and gear - Pneumatic overrun brake on the decoiler drum (TWINFLEX) - Hydraulic expansion of the decoiler drum, centrally via wedge slider system - Hydraulic pressure arm with hydraulically driven double pendulum roller - Coil loading carriage with 12-ton lifting capacity and 300 mm stroke - Decoiler on elevated travel frame with motorized cross travel drive Transport dimensions (L x W x H): 3500 x 1900 x 2500 mm Net weight: approx. 5 tons Central Hydraulic Power Unit (adjacent) Tank capacity: 350 liters Drive power: 18.5 kW - Drive motor with 2x REXROTH tandem pumps - Oil cooler as air heat exchanger with fan motor Transport dimensions (L x W x H): 1600 x 850 x 1450 mm Gsdpfxeif Sg Sj Afnein Net weight: approx. 800 kg Electrical Cabinet (adjacent) - All cable connections via Harting connectors Transport dimensions (L x W x H): 2800 x 500 x 2250 mm Net weight: approx. 800 kg

Condition: used, Decoiler, pivoting decoiler GSW SCHWABE Type LHD 50/800 Sond Double decoiler, double mandrel decoiler Factory No.: 5775 Year of manufacture: approx. 1995 Coil weight: 50 kg per side Coil width: max. 130 mm Coil inner diameter: 155 - 445 mm Coil outer diameter: 850 mm Support discs: Ø 850 mm Start rings: Ø 850 mm Distance from center of mandrel shaft to base: 980 mm Gjdpohubgwsfx Afnein - Manual 180° rotatable decoiler assembly with locking positions - Central expansion via rotation lever adjustment - Mechanical disc brake, adjustable brake shoes with knurled screw Required space (L x W x H): 1000 x 850 x 1500 mm Weight: 190 kg Good condition

Condition: excellent (used), Year of construction: 2011, strip width: 100 - 800 mm Gedew U Rztspfx Afnjin strip thickness steel (aluminium): 0,8 - 4 (7) mm reference material (tensile strength): 600 N/mm² coil weight: max. 15 t coil OD: max. 2.000 mm year: 2011

Condition: excellent (used), Year of construction: 2011, strip width: 100 - 800 mm Gedjw U R Adjpfx Afnoin strip thickness steel (aluminium): 0,8 - 4 (7) mm reference material (tensile strength): 600 N/mm² coil weight: max. 15 t coil OD: max. 2.000 mm year: 2011

Condition: excellent (used), Year of construction: 2001, strip width: 100 - 800 mm strip thickness steel (aluminium): 0,8 - 4 (7) mm Gjdpornq T Nofx Afnjin reference material (tensile strength): 600 N/mm² coil weight: max. 13 t coil OD: max. 2.000 mm year: 2001

Condition: excellent (used), strip width: 160 - 1.050 mm strip thickness: 0,4 - 3 mm reference material (tensile strength): 420 N/mm² coil weight: max. 7,5 t Giodjxayy Iepfx Afnjn coil OD: max. 1.600 mm

Condition: excellent (used), Year of construction: 2001, strip width: 100 - 800 mm strip thickness steel (aluminium): 0,8 - 4 (7) mm reference material (tensile strength): 600 N/mm² coil weight: max. 13 t coil OD: max. 2.000 mm year: 2001 Gjdernq Ufepfx Afnsin

Condition: excellent (used), strip width: 160 - 1.050 mm strip thickness: 0,4 - 3 mm reference material (tensile strength): 420 N/mm² coil weight: max. 7,5 t Gisdsxayynepfx Afnen coil OD: max. 1.600 mm

Condition: excellent (used), Overall dimensions: 3700 x 1070 x 1700 mm Disc coil inner diameter: 460 - 600 mm Maximum sheet roll width: 1000 mm Direction of rotation: Bidirectional Hydraulic operation: - rotation - transverse movement on the chassis - shaft grip Giedpfxjpvia Ee Afnsn Pneumatic operation: - brake

Condition: used, functionality: fully functional, Year of construction: 1980, machine/vehicle number: D02L/7983, Offer Number: D02L/7983 Machinetype: decoiler (motorized) Info: horizontal Make: WAFIOS Giodpjwi Sx Rsfx Afnon Type: AHL2 Constr. year: 1980 max. coil diameter: 1000 mm Location: In our warehouse

Condition: used, functionality: fully functional, Year of construction: 1975, machine/vehicle number: D02L/7025, Offer Number: D02L/7025 Machinetype: decoiler (motorized) Make: WAFIOS Type: AHM2 Constr. year: 1975 max. coil diameter: 840 mm carrying weight: 250 kg Giodpfx Afswi Uakenen Location: In our warehouse

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, number of straightening rollers: 9, product height (max.): 3 mm, straightening roller diameter: 30 mm, working width: 400 mm, coil inner diameter: 360 mm, coil outer diameter: 1,700 mm, workpiece weight (max.): 2,000 kg, Straightening machine with double decoiler and loop Gedpexiyx Nefx Afnjin

Condition: used, Year of construction: 1984, material width:350 mm Giodpfx Afot Hmk Tonjn coil weight:1 t material thickness:0,5 - 6 mm coil internal diameter:380 - 540 mm coil external diameter:1500 mm no. of straightening rolls:9 straightening roll diameter:30 mm number of draw-in rolls:2 weight of straightening machine:2 t dimensions straightener (WxDxH):2,0 x 2,0 x 1,9 mm weight of decoiler:1,3 t dimensions decoiler (WxDxH):1,7 x 1,5 x 1,6 m

Condition: good (used), Year of construction: 1998, Manufacture: LIV Load capacity: 2x2t max plate width: 310 coil inner diameter: 380-460mm Gsdpfxji D D Eue Afnsin Max roll outer diameter: 1200mm

Condition: good (used), Manufacturer: LIV load capacity: 2x2t Giedpfx Afji Azy Hjnon maximum plate width: 310 coil inner diameter: 380-460 mm max. reel outer diameter: 1200 mm

Condition: good (used), load capacity: 200 kg material width: 200 mm coil inner diameter: 240-500mm Coil outer diameter: 1200mm Gsdsihvdrjpfx Afnoin

Condition: good (used), Year of construction: 1998, Manufacturer: LIV Gsdpoi D Dxyefx Afnjin load capacity: 2x2t maximum plate width: 310 coil inner diameter: 380-460 mm max. reel outer diameter: 1200 mm

Condition: used, Year of construction: 1974, machine/vehicle number: 00-0438-01, sheet width:100 - 500 mm coil weight:ca, 6 t coil internal dia.:400 - 500 mm coil external diameter:1500 mm sheet thickness - max.:0,8 - 3,5 mm feed length:max. 10 m Feed speed:max. 75 m/min. diameter of the mandrel:360 - 420, 460 - 520 mm Gedpfjh Ra Spsx Afnjin stroke height:550 mm :7500 kp weight of the machine ca.:ukb, t dimensions of the machine ca.:ca, 3,4 x 1,7 x 2,5 m HHS Automatic Decoiler, Model - BA 1.3-050/20 Decoiler for extra wide metal sheet (500 mm width, sheet thickness from 0.8 to 3.5 mm), with hydraulic loading / supporting table, Hydraulic operated expandable Coil Mandrel with pnematic cooling ventilation. Seperate Power cabinet with Electrial Wire Diagrams and Instruction manuals avilable.

Condition: used, Year of construction: 1985, machine/vehicle number: 30522, sheet width:120 mm Gjdecxxq Sepfx Afnein coil weight:75 kg dimensions of the machine ca.:2,50 x 1,25 x 1,50 m

Condition: used, Year of construction: 1974, sheet width:130 mm coil internal dia.:300 - 500 mm Giodpfx Afocxxprenon coil external diameter:1200 mm

Condition: excellent (used), functionality: fully functional, actuation type: mechanical, coil inner diameter: 200 mm, coil outer diameter: 800 mm, coil weight: 100 kg, coil width: 220 mm, for sale AMADA ORII manual sheet metal winder cable winder manufacturer/type AMADA ORII ST 02 Z coil width: max 220mm coil inner diameter 200-500 mm coil outer diameter: 1100mm coil weight max 100kg Gisdpexvitvofx Afnjn

Condition: good (used), dimensions (l x w x h)approx. : 3550 x 2400 x 2300 mm weight approx. 7000 kg coil weight : 6000 kg: Coil width 1250 mm Giodpshhyzcofx Afnon Max coil diameter: 2500mm Coil inside diameter: 480-510mm Without control cabinet!

Condition: good (used), load capacity: 200 kg material width: 300mm Gisdpfxsh Rfhhs Afnjn coil inner diameter: 240-580mm Coil outer diameter: 1200mm

Condition: good (used), Coil reel, decoiler, recoiler Load capacity: 10 tons Expansion range: up to 508 mm internal diameter Expanding mandrel length: 1500 mm Giedpfeipx Ufsx Afnsn Several units available Frequency inverter control (FU control) The control cabinet has been newly refurbished. Hydraulic clamping of the coil. The reel can be moved laterally by hand using 4 rollers. Year of manufacture and manufacturer unknown.
