Used Cnc Vertical Borer for sale (14,299)

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Rjdpsxpqm Refx Aa Uop Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Front door: partial opening M0 / full opening

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTC530, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 2 x 750 mm Rsdpfxoymz D Ns Aa Usp Travel Y-axis: 500 mm Travel Z-axis: 600 mm Rapid traverse X / Y direction: 25 m/min Rapid traverse Z direction: 20 m/min Feed force: 9 kN Spindle speed range: 30-12,000 rpm Tool changer: 22-position Tool holder: SK40 Maximum tool length: 400 mm Maximum tool diameter: 85 mm (135 mm with adjacent stations empty) Tool change time: 4.0 s Clamping area: 2 x 1,350 mm x 500 mm Maximum table load per table: 550 kg MACHINE DETAILS Control model: Heidenhain iTC530 Drive power: 30/20 kW Total power requirement: 55 kVA Dimensions & Weight Dimensions (L x W x H): 6.0 x 3.5 x 3.5 m Machine weight: 10,000 kg EQUIPMENT Internal cooling Coolant system with paper band filter Documentation

Condition: ready for operation (used), total height: 3,600 mm, empty load weight: 22,000 kg, Schiess Ø 2070 x H 1330 mm Chuck dia.: Ø 1700 mm Max turningdia -- passage: Ø 2070 mm - H 1330 mm Rjdpfx Aaeyl A H No Usp Power on the spindle: 30 kW Max hight of workpiece Z-axis: 1330 mm (Z: 1000mm) Number of speeds: 1.7 -> 53 rpm

Condition: ready for operation (used), chuck outer diameter: 1,620 mm, total height: 4,650 mm, empty load weight: 20,000 kg, + zijsteun Elektrisch vernieuwd in 2007!!! Max turningdia -- passage: 1700 mm Power on the spindle: 37 kW Max hight of workpiece Z-axis: 1290 mm Digital screen: Heidenhain 2 axes Number of speeds: 3,5 - 150 rpm Long: 4550 mm Wide: 2670 mm Rsdpfx Aaeyl A Hps Uop

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Intermac Vertamax 3.3 Good working order. Redpfxsyhpkgj Aa Usp Price includes dismantling and loading onto own transport. Transport and installation can also be arranged.

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at Rodpeymlf Dofx Aa Uep the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: like new (used), Year of construction: 2018, operating hours: 50 h, functionality: fully functional, Heavy Duty Elevating Crossrail Ram Type CNC Vertical Boring and Turning Machine with Hardened & Ground Box Guideways CAPACITY Maximum Turning Diameter - Ø 1,600mm Maximum Turning Height - 1,400mm Maximum Torque - 17,885 Nm Maximum Cutting Force - 3,000 kgf Maximum Workpiece Weight - 8,000 kg TABLE Table Diameter - Ø 1,250 mm Table Speed - 0.9 ~ 360 RPM Table Speed Range - Automatic 2 Step Redpfeuu Rybex Aa Uep RAM HEAD Tool Size - 32 mm² Spindle Taper - ISO 7/24 #50 Ram Cross Section - 220mm² TRAVEL AND FEEDRATE X-Axis Travel (Saddle Horizontal) - 1,060mm Z-Axis Travel (Ram Vertical) - 900mm Vertical Travel of Cross Rail - 700mm Maximum X / Z-Axis Cutting Feedrate - 7,500mm / Min X / Z-Axis Rapid Feedrate - 7,500mm / Min Cross Rail Rapid Traverse - 300mm / Min ATC Type of Tool Holder - MAS BT 50 12 Tool Magazine Capacity Maximum Tool weight - 50kg MOTOR Table Motor (Cont. / 30 min) - AC 37.0 / 45.0 kW X / Z-Axis Servo Motor AC - 7.0 kW POWER SOURCE Input Power Supply - 415V / 50Hz / 3PH Power Capacity - 80 kVA DIMENSIONS AND WEIGHT Height - 5,290 mm External Width (With Chip Conveyor) - 6,760mm External Depth - 4,565m Weight - 25,800 kg STANDARD SUPPLIED MACHINE FEATURES Fanuc 32i-A Control System Table, Servo Drives And Motors 4 Jaw Independent Chuck Automatic Tool Change System Lubrication Oil Cooler Hydraulic Power Unit Automatic Lubrication System For Guides Coolant System And Wash Gun Foundation Bolts And Nuts Tool Box Through Tool Coolant Operator And Programmer Manuals Splash Guard And Safety Guard Rail X-Axis Slideway Protect Steel Cover Work Light Patrol Lamp (Red, Yellow And Green) NC Power Off Chip Pan Levelling Blocks Electrical And Mechanical Manuals FANUC 32I CNC

Condition: used, Year of construction: 2008, functionality: fully functional, Control: MAZATROL 640 workpiece diameter, max.: 1.050 mm workpiece length, max.: 1.000 mm Rsdjynk Ugspfx Aa Usp Max. Spindle speed: 10.000 rpm table speeds: 500 rpm table drive: 37 kW number of tools: 80 number of paletts: 2 chucking diameter: 800 mm

Condition: used, Year of construction: 2006, functionality: fully functional, Control: MAZATROL 640 workpiece diameter, max.: 1.050 mm workpiece length, max.: 1.000 mm Max. Spindle speed: 10.000 rpm table speeds: 500 rpm table drive: 37 kW Rodpfxjynk Efs Aa Ujp number of tools: 80 number of paletts: 2 chucking diameter: 800 mm

Condition: excellent (used), Year of construction: 2021, operating hours: 2,500 h, functionality: fully functional, travel distance X-axis: 1,060 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain ITNC640, spindle speed (max.): 10,000 rpm, We offer in good condition with around 2.500 spindle hours Posmill CE1000 with following options: Heidenhain linear scales in X, Y and Z-axis Heidenhain TNC 640 control Air true spindel Spindel 10.000 RPM ISO40 Tool changer 40 tools ATC Internal coolant 20 bar Hexagon Touch probe Chip conveyor Rsdpfeyindajx Aa Usp Thermal spindel compensation Z-axis Technical specification:" X-Axis Travel: 1060 mm Y-Axis Travel: 600 mm Z-Axis Travel: 600 mm

Condition: excellent (used), Year of construction: 2014, table diameter: 1,600 mm, workpiece diameter (max.): 2,000 mm, overall weight: 25,000 kg, CNC Vertical lathe YOUji - VTL1600ATC+C Control: FANUC 18i-TB Year: 2014 Driven tooling Bt-50 with 2400 Rpm 8000 Kg Table load 4 heavy duty jaws Box Slideway structure Rsdoyimptspfx Aa Usp Chip conveyor Oil Chiller Coolant system Tooling package optional Automatic lubrication Max. turning Ø: 2000mm Table Ø: 1600mm Horizontal movement support: 1015mm Stroke ram left: 800mm ATC / revolver: 16 Single column or double column:single Speeds / ranges: 250Rpm Power: 45kW Maximum turning height: 1200mm C-Axis: 360000° Power live tools: 11kW Chip conveyor: Yes Length: 4500mm Width: 5500mm Height: 5800mm Weight: 25000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Year of construction: 2011, Ref. -No.: 10622 Manufacturer: BLANSKO Type: SKD 50 Year of construction: 2011 Type of control: CNC Control: SIEMENS SINUMERIK 840 D Storage location: Halberstadt Country of origin: Germany Z - stroke: 1950 mm Turning Height: 4130 mm Faceplate Diameter: 4770 mm Swing Diameter: 5300 mm Max. Load on the face plate: 100000 kg Traverse path of the crossbar: 3600 mm Adjustment speed of the crossbar: 500 mm / min Further information: Pickup magazine with 8 tool holder positions Automatic clamping of the tool holder in the ram 1x straight boring head 1x 90° angle head (not in the pickup magazine) 1x set of jaws Rjdpfx Aoym Nfzsa Usp The machine can be inspected under power.

Condition: good (used), Year of construction: 2010, Ref. -No.: 10436 Manufacturer: SCHERER FEINBAU Type: VDZ 120 rechts Year of construction: 2010 Type of control: CNC Control: SIEMENS SINUMERIK 840 Rodpfxsym Na Sj Aa Usp Storage location: Halberstadt Country of origin: Germany Machine-No.: 660XX Turning Speeds: 5500 RPM Swing Diameter: 260 mm Rapid Travel Speed X-Axis: 60 m / min Rapid Travel Speed Z-Axis: 30 m / min Travel -X Axis: 626 mm Travel -Z Axis: 250 mm Spindle bearing diameter: 32 mm Rated speed: 1200 1 / min Turret places: 12 Pcs Machine length: 1685 mm Machine width: 2400 mm Machine Height: 2850 mm Weight Of The Machine Ca.: 8 t Further information: Spindle head with short taper DIN 55026: A6 Pallet conveyor WPS KNOLL system (2010) SAUTER turret (12 places) Documentation available Tools in the pictures are sold with the machine. Machine can be inspected and demonstrated under power.

Condition: excellent (used), Year of construction: 2018, operating hours: 2,472 h, functionality: fully functional, travel distance X-axis: 470 mm, travel distance Z-axis: 876 mm, spindle motor power: 30,000 W, spindle speed (max.): 1,250 rpm, rapid traverse X-axis: 24 m/min, rapid traverse Y-axis: 24 m/min, turning diameter: 1,000 mm, total length: 2,375 mm, total height: 3,659 mm, total width: 4,558 mm, type of input current: three-phase, torque: 3,655 Nm, input voltage: 400 V, overall weight: 13,000 kg, Equipment: cooling unit, CNC Vertical Lathe MAZAK Mega Turn 900 TECHNICAL CHARACTERISTICS: Year of manufacturing: 2018 CNC control: MAZATROL SmoothG Max. turning diameter: 920 [mm] Max. cutting diameter: 1000 [mm] Stroke X axis: 470 [mm] Stroke Z axis: 876 [mm] Rapid traverse rate X axis: 24000 [mm/min] Rapid traverse rate Y axis: 24000 [mm/min] Spindle nose: A2-15 Max. spindle speed: 1250 [rpm] Redpfxoym Surs Aa Uop Spindle power: 30 [kW] Spindle torque: 3655 [Nm] Max. distance from spindle face to turret face: 1030 [mm] Max. workpiece weight: 3000 [Kg] Min. distance from spindle face to turret face: 154 [mm] Number of tool stations: 12 Turret indexing time: 0.4 [s/pos] Lubrication tank capacity: 516 [l] Total power required: 58.9 [kVA] Rated current: 109 [A] Supply voltage: 400 [V] Working hours: 2472 [h] Number of cutting hours: 2297 [h] Dimensions: 2375 × 4558 × 3659 [mm] Weight: 13000 [Kg] INCLUDED EQUIPMENT: x1 Ø800 mm chuck, KITAGAWA type NV-32C1515 x1 set of hard jaws x2 sets of soft jaws x10 tool holders (chair type) x24 KENNAMETAL type KM50 tool holders x1 retractable tool probe arm x1 double pedal unit for chuck clamping x1 coolant tank x1 chip conveyor x1 LOSMA type Galileo GP500 mist extractor x1 set of 4 lifting brackets x1 set of axis locking brackets (for machine transport) x1 MAZAK toolbox containing various service wrenches Various programming manuals Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machines similar to Biglia, Index, Tsugami, Miyano, Star, and DMG Mori Tornos lathes, but also milling machines, grinding machines, and CNC.

Condition: used, Year of construction: 2021, travel distance X-axis: 1,600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 740 mm, controller manufacturer: Fanuc, total height: 3,435 mm, total length: 5,575 mm, total width: 4,621 mm, overall weight: 18,000 kg, controller model: Series 0i-MF Plus, workpiece diameter (max.): 800 mm, Equipment: documentation/manual, CNC 5-axis Vertical machining Centre CNC Control Fanuc Series 0i - MF Plus Table size Ø 800 mm Number of pallets 1 Maximum workpiece dia x height Ø 1200 x 300 mm Movement X-Y-Z-axis 1600 x 700 x 400/740 mm C-Axis (table rotation) 360° B-Axis travel -11 /+30 ° Spindle speed 15.000 r/min Spindle Taper Big Plus BT40 Spindle motor 18,5/15 kW Magazin Capacity 60 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Redpfx Aajygw E Ne Uop Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2008, travel distance X-axis: 4,050 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 1,070 mm, controller manufacturer: Heidenhain, total height: 5,170 mm, total length: 12,500 mm, total width: 6,600 mm, overall weight: 48,000 kg, table length: 4,200 mm, table width: 2,040 mm, controller model: iTNC 530, spindle speed (max.): 6,000 rpm, Equipment: documentation/manual, CNC Double Column Vertical Machining Centre CNC Control Heidenhain iTNC 530 Table size 4200 x 2040 mm Table load 15.000 kg Number of pallets: 1 Movement X-Y-Z-axis: 4050 / 2600 / 1070 mm Spindle taper DIN 69871a- SK 50 Rsdpfx Ajygw Evsa Uep Spindle speed 6.000 RPM Number of tools in magazin: 60 pieces If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2006, travel distance X-axis: 1,050 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 560 mm, controller manufacturer: Mazatrol, total height: 2,700 mm, total length: 3,445 mm, total width: 3,301 mm, overall weight: 8,900 kg, table length: 550 mm, table width: 1,300 mm, controller model: 640 M, spindle speed (max.): 6,000 rpm, spindle speed (min.): 25 rpm, Equipment: documentation/manual, CNC Vertical Machining Centre CNC Control: Mazatrol 640M Table size: 1300 x 550 mm Table load: 1500 kg Rjdpfx Ajygw Ecja Uop Movement X-Axis: 1050 mm Movement Y-Axis: 510 mm Movement Z-Axis: 560 mm Spindle taper: MAS BT 50 Spindle speed: 25 -6000 1/min. Magazine capacity: 30 positions Weight of the machine: 8900 kg If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2000, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, workpiece weight (max.): 1,200 kg, total height: 2,900 mm, total length: 2,995 mm, total width: 2,350 mm, overall weight: 6,700 kg, table length: 550 mm, table width: 1,200 mm, coolant supply: 15 bar, rotational speed (max.): 12,000 rpm, rotational speed (min.): 35 rpm, table load: 1,200 kg, CNC Vertical Traveling Column Machining Centre CNC Control Mazatrol 640 M Table size 1200 x 550 mm Table load 1200 kg Number of pallets: 1 x Movement X-axis 1020 mm Movement Y-axis 510 mm Movement Z-axis 460 mm Spindle taper MAS BT 40 Spindle speed 35 - 12.000 1/min Spindle motor 22/15 kW Magazin capacity 30 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock. Rjdpfjygw D Eox Aa Uep

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: KMM526 1506, travel distance X-axis: 1,000 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 360 mm, controller model: FANUC SERIES 18i-MB 5, spindle speed (max.): 12,000 rpm, No reserve price – guaranteed sale to the highest bidder! By placing a bid, you are obligated to collect the item within the specified dates, either between 11.05.2026 and 13.05.2026, or between 18.05.2026 and 21.05.2026. TECHNICAL DETAILS Travel X-axis: 1,000 mm Travel Y-axis: 400 mm Travel Z-axis: 360 mm Rjdpfx Aaoym Nqko Ujp Table dimensions: 1,500 x 470 mm Overhang: 350 mm Tool holder: SK 40 Spindle speed: 36 to 12,000 rpm Spindle bearing diameter: 65 mm Max. tool diameter: 125 mm Max. tool length: 250 mm Feed rate X/Y/Z-axis: 1 - 10,000 mm/min Rapid traverse X/Y/Z-axis: 45 m/min MACHINE DETAILS Control: FANUC SERIES 18i-MB 5 Operating voltage: 400 V Frequency: 50 Hz Nominal current: 45 A Dimensions & Weight Dimensions (L x W x H): 2,700 x 2,700 x 3,300 mm Weight: 6,000 kg EQUIPMENT 4th axis 42-position tool changer Chip conveyor Coolant system Note: The clamping devices shown in the photos are not included. External reference: Elos – Lot 1

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Rodpfx Aajvt D D Ue Ujp Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition

Condition: used, Machine has a defect in the main spindle CNC vertical machining center CHIRON type FZ 22 L high speed Redpfx Aoquhbgea Usp Machining center with CNC control FANUC Series 21-M serial no. 179-98 year of construction 1999 Travel X: 2000 mm, Y: 520 mm, Z: 630 mm Table size 2700 x 570 mm Table load 525 kg (per meter) Tool holder SK 40 (DIN 69871) Drilling capacity 35 mm Tapping capacity M27 Tool diameter 75 mm Diameter with free secondary positions 105 mm Tool change speed tool - tool 2.0 sec. Tool change speed from chip to chip 4.8 sec. Distance spindle nose - table 190 to 820 mm Spindle speed max. 10,500 rpm Main spindle drive max. 18.5 kW Mains connection 400 Volt, 50 Hz, 32 kVA - Pendulum machining over 2 work areas (partition wall missing) - CNC control FANUC Series 21-M - Tool changer 40-fold - IKZ = internal coolant supply through the spindle - Spray protection cabin with sliding door - Indirect measuring system - Coolant device with chip conveyor opposite - Electronic handwheel Transport dimensions of the basic machine L x W x H 4600 x 2470 x 2950 mm Weight of the machine approx. 7.5 tons. Transport space requirement on the truck L x W x H 12000 x 2470 x 2950 mm Transport Weight on the truck approx. 10 ton. Weight 7.2 tons. good condition - machine has a defect on the main spindle

Condition: used, As-new CNC Vertical Machining Center, Milling Machine VMC, BAZ, HSC Milling, Machining Center TAIKAN B540Z Serial No. 1171009 Year of manufacture: 2017 CNC path control: SIEMENS Sinumerik 828 D Basic Travel range for working area X: 488 mm, Y: 400 mm, Z: 230 mm X-axis travel for tool change position X: 540 mm Table size 520 x 400 mm Spindle taper ISO 25 Distance spindle nose - table 165 - 395 mm Max. spindle speed 36,000 rpm, infinitely variable Feed rate 0 to 10,000 mm/min Rapid traverse 15 m/min Table load capacity 200 kg Max. tool length 120 mm Max. tool diameter 80 mm Max. tool weight 0.8 kg Tool change time approx. 10 sec. Axis drives 0.8 kW each Spindle drive 3.5 kW at 100% duty cycle Electrical connection 400 Volt, 50 Hz, 7.5 kW CNC path control SIEMENS Sinumerik 828 D Basic - Software: NCU V04.05+SP06+HF01 - Interfaces: LAN, USB and CF-Card - Measuring system for tool setting: METROL tool sensor - Vertical milling spindle = high-frequency spindle with liquid cooling and external recooling unit - Tool changer with 13 tool stations - Electronic handwheel - Coolant system - Protective enclosure with sliding door - Central lubrication - incl. 10 tool holders ISO 25 with ER20 collet chuck and a set of collets Transport dimensions (L x W x H): 1800 x 1500 x 2300 mm Weight: 2,900 kg Excellent condition – as new Rodpfx Aew Ed U Nsa Uep Machine comes from a showroom with very few operating hours.

Condition: used, machine/vehicle number: 008395, X axis working area: 3050 mm Y axis working area: 1250 mm Main Electrospindle power: 10 KW Number of controlled axes: 3 axes Rodpfx Aeygtcqoa Uep Total number of drilling spindles: 27 Total number of tool changer positions: 8

Condition: used, Year of construction: 2018, operating hours: 15,233 h, machine/vehicle number: 20180707, 3-axis, travels (x/y/z): 1060/600/600 mm, SK 40 tool holder, 40-position tool changer, read operating hours as of 05/25, spindle speed: 10,000 rpm, 3D probe, measuring axis, power: 30 kVA, weight: 7,800 kg, chip conveyor SIN MIN M1050, year of manufacture: 2018, serial no.: 646, coolant treatment system HOMEWAY PF-120, year of manufacture: 2018, without the depicted magnetic clamping plate and machine vices, NOTE: Removal only possible on 23/24.03.2026, position 123 must be removed beforehand. Rsdpfoyidkhox Aa Ujp

Condition: used, Year of construction: 2006, travel distance X-axis: 762 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, controller manufacturer: Haas, total height: 2,750 mm, total length: 2,250 mm, total width: 2,360 mm, table width: 914 mm, table length: 356 mm, table load: 680 kg, spindle speed (max.): 12,000 rpm, Equipment: documentation/manual, CNC Vertical Machining Centre CNC Control Haas CNC Table size 914 x 356 mm Table load 680 kg Number of pallets: 1 x Movement X-axis 762 mm Movement Y-axis 406 mm Movement Z-axis 508 mm Rjdoydn E Ispfx Aa Uop Spindle taper DIN 68971A Spindle speed 12.000 1/min Spindle motor 22,4kW Magazin capacity 24 + 1 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.
