Used Angle Drill for sale (10,930)

Condition: used, Year of construction: 1985, Weight: approx. 3000 kg Dimensions: approx. 3700 x 2000 x 1600 mm Machine without tools Guedpevvi Ttefx Aafjf Location: Nattheim

Condition: used, Precise angles and mitres from 0° to 46°, with digital display for angle indication Location: Nattheim Gujdpfx Aaewhzg Uefof

Condition: ready for operation (used), Column drill / ALZMETALL AB 3 ES - Well-maintained, original condition - Drilling capacity / steel max. 35mm - Arm reach approx. 280mm - Table size approx. 600x470mm - Drilling stroke approx. 180mm - Taper shank MK 3 - Stepless speed control - Speed range approx. 65 - 2000 RPM - Drilling depth stop - Spindle guard - Emergency stop - Foot switch - Analog speed display - Drill chuck - Documentation Gusdpfoztffcex Aafof Dimensions: L x W x H 1.2 x 0.8 x 2 meters / Weight approx. 500kg

Condition: good (used), functionality: fully functional, spindle mount: MK 4, For sale is a pillar drill press from the brand Alzmetall in good, used condition, as can be seen in the pictures. Technical data: • Manufacturer: Alzmetall • Model: AB4-SV • Speed: approx. 60 - 765 rpm • Spindle stroke: approx. 180 mm • Feed speeds: 0.15 / 0.2 / 0.3 / 0.36 mm/rev • Table size: approx. 600 x 450 mm • With coolant pump • Connection: 16A CEE plug • Condition: Used, functional Gjdezqnuuepfx Aafeuf The machine can be inspected and tested at any time! Shipping costs via freight forwarder: approx. €190 International buyers are welcome! You will receive an invoice with VAT shown. Inspection / collection is possible by arrangement in 42855 Remscheid. Sale from location 42855 Remscheid, free loading. Errors in technical data and prior sale reserved.

Condition: ready for operation (used), Steel angle / solid L x W x H 800mm x 710mm x 840mm Thickness 60mm Guedpfx Aajztfbdefof Weight 480 kg Errors and omissions excepted.

Condition: ready for operation (used), Steel angle / Clamping angle / Solid LxWxH 720mm x 650mm x 1550mm Thickness 65mm Gsdpfxsztd U Ao Aafeuf Weight 790 kg Errors and omissions excepted.

Condition: ready for operation (used), ERD Column Drilling Machine Type B35/40 - Machine type: ERD B35/40 - Design: Column drilling machine with gear drive - Drilling capacity in steel: up to 50 mm - Spindle mounting: MK 4 (Morse taper 4) - Quill stroke: 190 mm - Overhang (spindle to column): 325 mm - Column diameter: 140 mm - Table size: approx. 565 x 565 mm - Table adjustment: Height-adjustable, rotatable (360°) - Spindle speeds: 6-speed, manual via belt / lever - 670 / 470 / 295 / 210 / 150 / 90 rpm - Note on speed change: Change speed only when the spindle is running down - Feed types: Manual and automatic feed - Feed speeds: 0.1 / 0.2 / 0.3 mm per spindle revolution (switchable during operation) - Motor power: 2.2 kW (three-phase) Guedoztd Ivjpfx Aafjf - Supply voltage: 400 V Dimensions: L x W x H: 0.9 x 0.5 x 2.05 meters / Weight: 800 kg Errors and omissions excepted.

Condition: ready for operation (used), Danube DR 23 - High-speed radial drilling machine Godsztdz Aspfx Aafeuf - Drilling capacity / steel approx. 28 mm - Arm length approx. 700 mm - Morse taper MK 3 - Speed range 70-1550 rpm - gearbox - Feed rate range 0.075-0.3 mm - Drilling depth 130 mm - Threading device - Hydraulic clamping - Documentation Dimensions: L x W x H 2 x 1.7 x 1.9 meters / Weight 1900 kg Errors and omissions excepted.

Condition: ready for operation (used), H. Hartkämper Coordinate Drilling Machine -Drive: 400 V three-phase -Drilling capacity in steel: approx. 16–20 mm -Spindle mount: MK2 / drill chuck B16 -Speed range: approx. 250–3,000 rpm (multi-stage) -Quill stroke: approx. 80–100 mm -Table size: approx. 1,300 × 600 mm -Travel in X: approx. 350–450 mm -Travel in Y: approx. 180–250 mm -Base: integrated steel frame with storage compartments Gedpfx Aasztc A Esfsuf Dimensions: L x W x H 1.4 x 0.9 x 1.5 meters / Weight 350 kg Errors and omissions excepted.

Condition: used, Vertical milling head, milling head, angle milling head MAHO suitable for MH300 or MH400. Year of manufacture approx. 1990. Tool holder: SK 40. Quill stroke: 60 mm. Centering diameter on the flange plate: 102 mm. Outer diameter of flange: 180 mm. Bolt circle on flange plate: Ø 150 mm. Mounting holes on flange plate: 4x Ø 11 mm. - Quill feed: 0.015 / 0.03 / 0.06 / 0.12 mm/rev. - Head drive via shaft Ø 32 with 10 mm keyway. - Knurled wheel with scale for quill stroke. - Angle scale on angle milling head 2x 90°. Dimensions L x W x H: 300 x 280 x 300 mm. Total weight: 31.4 kg. In good condition. Gsdoxf Ur Nopfx Aafeuf

Condition: used, Universal Milling Machine DECKEL Type FP 1 Universal milling machine Machine No. 2101 – Year of manufacture: 1979 Gujdpfx Aaer U St Uefef Manual travel X: 300 mm, Y: 160 mm, Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2000 rpm, 16 steps Feed X and Y axes: 5 to 500 mm/min Rapid traverse: 1200 mm/min Motor power: 1.5 and 1.9 kW, pole-changeable Electrical connection: 380 Volt, 50 Hz - Stepless feed in X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill movement at the vertical milling head: 60 mm - Vertical milling head can be swiveled and extended horizontally by 100 mm - Fixed angle table 600 x 210 mm - Coolant system integrated in the machine base - Standalone control cabinet - Original chip tray for mounting on the machine base - Electrical schematic available Required space (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg Good condition

Condition: used, 4-axis CNC drilling and milling machine IXION Type 30 CNC W VMC, BAZ, machining center Year of construction approx. 1997, machine overhauled in 2020 Travel X: 600 mm Y: 350 mm Z: 600 mm Table size 800 x 400 mm T-slot spacing 75 mm Table load 300 kg Spindle holder SK 40 (tightening bolt DIN 69872 A) Spindle speed 20-5000 rpm Torque at the spindle max. 150 Nm Distance between spindle nose and table max. 660 mm Feed speed X, Y and Z 0 - 5000 mm/min. infinitely variable Rapid traverse speed X, Y and Z 15000 mm/min. Tool change time approx. 5 sec. Tool change time from chip to chip approx. 7.5 sec. Milling capacity in St 60 150 ccm/min. Drilling capacity in St 60 35 mm Thread cutting capacity in St 60 M24 Spindle motor drive power 5 kW (10 kW at 25% duty cycle) Mains connection 400 Volt, 50 Hz - CNC control Heidenhain TNC 415 with 12" TFT display - Electronic handwheel - RS 232 interface - 12-position tool changer - hydro-mechanical tool clamping - Rotary axis as dividing head on the table = 4th axis, MECATECNICA type DCN 250-8, jaws lathe chuck Ø 200 mm Speed approx. 25 rpm, transmission ratio 1:180 - Cabin lighting via 2x halogen spotlights - Chip conveyor with coolant pump - Switch cabinet fixed to the machine Space required for transportation Length 320 cm x width 230 cm x height 300 cm Footprint of the machine with chip conveyor L x W x H 3200 x 3100 x 3000 mm Weight of the machine 3100 kg Weight of the chip conveyor approx. 200 kg Gujdpfxju Tln Nj Aafsf good condition

Condition: used, Univ. universal milling machine DECKEL, Type FP 1 Machine No. 28317, Year of manufacture approx. 1960 Travel distances: X: 245 mm, Y: 150 mm, Z: 340 mm Table size: 600 x 210 mm Spindle mount, horizontal: MK 4 - S20 x 2 Spindle speed, vertical: 95-1900 rpm, 12 steps Spindle speed, horizontal: 60-1200 rpm, 12 steps Motor power: 0.8 and 1.1 kW, pole-changing Power connection: 380 Volt, 50 Hz - Spindle speed controlled via 2 motor speeds and 6 gear stages - Feed in the X and Z axes Guedpeiy Ekvsfx Aafof - Coolant system with mechanical pump in the machine base - Quill travel on the vertical milling head: 60 mm - Vertical milling head swivels +/- 90° - Metal substructure made of angle iron with machine feet Space requirement L x W x H: 1100 x 900 x 1650 mm Weight: 650 kg Good condition

Condition: used, CNC Universal Coordinate Drilling and Milling Machine FEHLMANN Type PICOMAX 100-CNC 3 CNC Control HEIDENHAIN TNC 155 Manufacturer's No. 16186651 Year of Manufacture 1986 Spindle Taper FEHLMANN SF32 Drilling Capacity Ø 30 mm in steel Thread Cutting up to M20 in steel Travel X: 850 mm, Y: 435 mm Godpfx Aaohik Ezofsuf Quill Stroke Z: 210 mm Vertical Movement of Milling Head 580 mm Feed X and Y 1 to 8000 mm/min. Feed Z 1 to 4000 mm/min. Rapid Traverse X and Y 8 m/min. Rapid Traverse Z 4 m/min. Table Clamping Surface 1570 x 500 mm Distance Spindle Nose - Table 130 - 720 mm Overhang Spindle - Column 450 mm Spindle Speed 50 - 7100 RPM, stepless Spindle Drive 10 kW Total Connected Load 20 kW Mains Connection 400 Volt, 50 Hz - CNC Control HEIDENHAIN TNC 155 with TFT monitor - 3 axes controlled, X, Y and Z quill adjustment - hydro-mechanical tool clamping FEHLMANN SF32 - threading device - cable remote control for machine operation and axis movements - motorized vertical movement of the milling head with shutdown via adjustable cams - 3D probe RENISHAW, Type MP 11F with FEHLMANN SF32 mount - 20 tool holders FEHLMANN SF32 - swiveling tool holder with 21 tool positions - coolant system in the machine frame - control cabinet fixed to the machine - documentation: operating manual, control manual and electrical diagrams Space Required L x W x H 2350 x 2000 x 2300 mm Weight 3.2 tons very good condition

Condition: used, Univ. universal tool milling machine DECKEL, Type FP 1 Machine No. 51265, Year of manufacture approx. 1967 Gedjghtvaspfx Aafjuf Travel distances X: 300 mm, Y: 150 mm, Z: 340 mm Table size 600 x 200 mm Spindle mounting SK 40 - S20 x 2 Spindle speed 40-2000 rpm, 16 speeds Motor power 1.0 and 1.6 kW, pole-changing Mains connection 380 volts, 50 Hz - Feed in the X and Z axes - Spindle speed via 2 motor speeds and 8 gear stages - Quill movement on the vertical milling head 60 mm - Swivel, rotary, and tilting angle table - Coolant pump in the machine base - Adjacent control cabinet Space required L x W x H 1100 x 1100 x 1600 mm Weight 690 kg Good condition

Condition: used, Universal Tool Milling Machine DECKEL Type FP 1 Universal Milling Machine Machine No. 2101 - Year of manufacture: 1979 Travel (manual) X: 300 mm, Y: 160 mm, Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 - S20x2 Spindle speed: 40-2000 rpm, 16 steps Feed X and Y axes: 5 to 500 mm/min Rapid traverse: 1200 mm/min Motor power: 1.4 / 1.8 kW, pole-changeable Power supply: 380 Volt, 50 Hz - Stepless feed in X and Z axes - Spindle speed via 2 motor speeds and 8 gearbox stages Guedpfxjr D T U De Aafof - Quill stroke at the vertical milling head: 60 mm - Vertical milling head tiltable and horizontally extendable by 100 mm - Fixed angle table 600 x 210 mm - Coolant system in the machine base - Separate control cabinet - Original chip tray mountable on machine base - Wiring diagram available Space required (L x W x H): 1350 x 1100 x 1700 mm Weight: 770 kg In very good condition

Condition: used, Fixed angle clamping table, fixed machine table, clamping angle, angle table for milling machine Clamping surface: 700 x 260 mm Guodpfx Aaoznn Hlsfjf Table size: 785 x 310 mm (external dimensions) Slot width: 12 mm Slot spacing: 50 mm - for table mounting surface at 90° - Table top with 5 T-slots - Mounting surface 90° = 600 x 195 mm, hole spacing center-to-center 560 x 125 mm with Ø 12 mm elongated hole, 12 mm guide slot Dimensions L x W x H: 785 x 320 x 263 mm Weight: 80 kg Good condition

Condition: ready for operation (used), GILLARDON GR 30/4 – Radial drilling machine -Drilling capacity in steel: Ø 30 mm -Spindle taper: MK 3 -Drilling stroke: 120 mm -Spindle speed: 45–1,850 rpm -Continuously variable speed control -Drilling depth stop -Analog speed display -Drive power per drilling head: 2.2 kW -Operating voltage: 380 V / 50 Hz -Overhang: 295 mm -Max. distance spindle – table: 550 mm Gjdpfozr U H Hsx Aafeuf -Table size: approx. 2,000 × 660 mm -Coolant system -Documentation Dimensions: L x W x H 2.0 x 0.7 x 2.0 meters / Weight 2000 kg Errors and omissions excepted

Condition: good (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: 42411/405, drilling capacity: 32 mm, overall weight: 2,300 kg, High-speed radial drilling machine ALZRAPID 32 D in very good condition, taken from ongoing operation, including Heidenhain digital display ND 1202 R. The machine has been regularly serviced and inspected. Gedpfx Aaeztkupefeuf *TOOLS SHOWN IN THE PICTURE ARE NOT INCLUDED* Clamping surface: approx. 1200x830 mm Base plate: approx. 1200x830 mm Tool holder: MK 4 short spindle Continuous drilling capacity in steel/cast iron: 30/32 mm Drilling capacity in steel: 40 mm Thread in steel: M24 Thread in cast iron: M30 Spindle speeds: 12 stages from 102 to 2,000 rpm Spindle stroke (quill stroke): 150 mm Three automatic feeds 0.1-0.2-0.3 mm/rev Overhang: max. 725 mm Weight: 2300 kg

Condition: used, Year of construction: 2000, functionality: fully functional, feed length X-axis: 4,000 mm, feed length Y-axis: 1,050 mm, feed length Z-axis: 200 mm, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Dimensions and Travel Ranges Tool holder: SK 40 Table dimensions: mm 4000 x 800 Number of T-slots: 6 T-slot spacing: mm 140 Distance: - Spindle bottom edge: min. mm 140 - Table top edge: max. mm 740 Boring radius: - min. mm 540 - max. mm 1590 Travel range U-axis: mm 2600 Travel range Y-axis: mm 1050 Quill stroke (Z-axis): mm 200 Column stroke (W-axis): mm 400 Machining Data Drilling performance in solid material: - St 60: mm 40 - GG 22: mm 50 Thread cutting: - St 60: M 36 - GG 22: M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle Speed range: min-1 15 - 2800 Torque: Nm max. 250 Constant from: min-1 15 - 200 Feed drives X-axis - AC servo motor kW 0.25 Y-axis - AC servo motor kW 0.25 Z-axis - AC servo motor kW 4.50 W-axis - AC servo motor kW 2.50 U-axis - AC servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min 7.5 / 7.5 / 5 Rapid traverse speeds (U/W): m/min 7.5 / 3 Feed rates, infinitely variable: mm/min 5 - 2000 Feed force: N 12000 Accuracy Positional accuracy X, Y axis at 1200 mm: mm ± 0.075 Repeatability X, Y axis: mm ± 0.03 Positional accuracy Z axis: mm ± 0.05 Repeatability Z axis: mm ± 0.03 Positional accuracy W axis: mm ± 0.05 Repeatability W axis: mm ± 0.03 Electrical data Operating voltage / frequency: V / Hz 400 / 50 Control voltage: V 24 Total connected load: kVA 13.0 CNC control Axes: 5 (X, Y, Z, W, U), expandable Screen: TFT flat screen, backlit, easily readable from all sides Position data: Cartesian or polar, dimensions absolute or incremental, Unit of measurement: mm or inch, or in degrees Interpolation: 2 axes (X, Y) Technology database: Tool management, tool suggestions according to machining process, material-dependent cutting data suggestions Tool management: max. 500 tools Subprogram technology: yes Machining cycles: Cycles for centering, drilling, threading, reaming, countersinking and boring, freely programmable cycle for special tools, dwell time possible in each cycle Chip breaking / chip removal: possible in drilling cycle Drilling patterns: Hole pattern, hole circle, matrix Basic software: Programming in dialog mode, 38 zero-point offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - aligning cast and sintered parts - Angle detection for round parts by probing the reference edges or surfaces Data interfaces Paint finish with signs of use Standard paint finish, two-component textured paint Machine upper part: light grey RAL 7035 Gjdpey Ttrtofx Aafsuf Machine lower part: light blue RAL 5012 Documentation Operating and programming manual Electrical wiring diagram Spare parts drawings Test report for mechanics, electrical system and safety devices

Condition: used, bore capacity in steel (diameter) 15 mm throat 215 mm Guedpfx Aaezpzb Ssfjf turning speeds 200 - 3600 U/min 350 x 300 mm total power requirement 1,0 kW / Volt tool taper MK 2 weight of the machine ca. 320 Kg dimensions 0,8 x 0,6 x 1,9 mm Bench drill - Base unit with drawers

Condition: used, Year of construction: 1997, Second-hand machine Year of manufacture: 1997 Features and technical specifications: - Number of drilling spindles: 21, spaced at 32 mm intervals - Drilling direction: Bottom & end face - Swivel range: 0–90 degrees via handwheel - Pneumatic workpiece clamps: 3 pcs. Gusdpfx Aaozn Ah Refsf - Opening: Max. 100 mm in height and max. 640 mm in width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a wide range of stops (see pictures) Availability: at short notice Storage location: 63934 Röllbach

Condition: used, Year of construction: 2011, total width: 1,500 mm, total length: 3,000 mm, total height: 1,750 mm, Colour: White Empty weight: 450 kg - Year: 2011 - Documentation available: No - CE certificate present: No - Serial number: 11060282 - Main motor power [kW]: 1.3 - Table length [mm]: 2000 - Table width [mm]: 520 - Max. drilling stroke [mm]: 60 - Number of spindles [pcs]: 27 - Spindle speed: Manual - Min. spindle speed [rpm]: 2820 - Max. spindle speed [rpm]: 2820 - Distance between spindles [mm]: 30 - Workpiece clamps [pcs]: 10 - Workpiece support/Guide: Traverses - Drills included: Yes - Voltage [V]: 400 - Current consumption [A]: 3 - Fuse [A]: 16 - Power [kW]: 1.5 - Transport dimensions: 3000mm x 1500mm x 1750mm (l x w x h) - Transport weight [kg]: 450kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Guedpfjzizqgjx Aafof Yorick Diebels

Condition: refurbished (used), functionality: fully functional, type of input current: three-phase, year of last overhaul: 2025, Drill grinding machine suitable for grinding/sharpening twist drills, countersinks, etc. with 2, 3, or 4 cutting edges, with diameters from 5 to 75 mm. The machine has been mechanically and technically overhauled, wearing parts replaced, grinding spindle new, newly painted. The machine features automatic feed including end stop. Guodjydc Htjpfx Aafjf Accessories: - Reducing sleeves MK5/MK4/MK3/MK2/MK1 including new quick-action chuck for small diameters - Diamond dresser - Operating manual - Ejector tool for MK5 to MK1 - Coolant system, new including new coolant pump - Machine LED light, new The machine can be tested under power or inspected upon request. Operating voltage: three-phase current

Condition: good (used), Year of construction: 2015, total width: 1,800 mm, total length: 3,700 mm, total height: 4,300 mm, overall weight: 14,000 kg, Maximum drilling capacity in steel: 75 mm Gjdpfxjzi S Sns Aafjuf Length:3700mm Width:1800mm Height:4300mm Weight:14000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
