Edgebander with material handling system

HOMAG KAL370 AMBITION 2474

Condition: excellent (used), Year of construction: 2015, I sell the fully equipped edge banding machine HOMAG KAL370 AMBITION 2474, year 2015: Configuration: Entry fence servomotorical adjustable Premilling pneumatic adjustable Edge banding with preheating tank + AirTec System Material pressure zone servomotorical adjustable End cutting saws pneumatic adjustable Gkodsxnb Uvjpfx Acmod Tilting radius milling top + bottom servomotorical adjustable Corner rounding 4-motor pneumatic adjustable Radius R2 + multiradius scrapers servomotorical adjustable Glue scrapers servomotorical adjustable Polishing brushes Separation fluid spraying in the front Cleaning fluid spraying in the back Entry magazine for two bands in rolls automatic Working thickness adjustment servomotorical driven Material height 8-60mm Edge thickness 0,4-20mm Feeding speed up to 25m/min. Total length including feeding plate 8365mm Kilometerstatus 1.166.000 Meters edgebanded. Including full documentation and CE. Very good condition, fully working!

Condition: used, machine/vehicle number: 007848, Type of edging: Thin edge, Thick edge, Solid wood Gkedpfxowkrqpo Acmed Gluing System: EVA Hotmelt, Hot Air Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 20 m/min Maximum panel thickness: 60 mm Operating Units: 8 nr

Condition: used, Year of construction: 2014, For inquiries: Zoltán Utasi +36 30 205 7380 • motorized pressure bridge adjustment • Electrical system for stepless feed 400 V / 50 Hz, 2.2 kW • “Control PPC 221 – with 8.4'' VGA color display” High-performance control with very simple operation • Edging pre-milling unit 1802, 400 V (2 x 2.0 kW, 200 Hz, 12,000 rpm) with 2 milling units for pre-milling the panel edge • Cutter, diamond Ø 70 x 64 x 30 mm, Z2, left-hand rotation For pre-milling unit 1801 / 1802 • Cutter, diamond Ø 70 x 64 x 30 mm, Z2, right-hand rotation For pre-milling unit 1801 / 1802 • Edge feeding unit 1903 SYNCHRO automatic transport of rolls and strip material • Glue application station Glu Jet GJ301 automatic (2.3 kW, 50 Hz) • Pressure unit 1913 pneumatic first roller driven, 2 additional pressure rollers with pneumatic individual control • Cut-off unit 1918 (60 mm) pneumatic (2 x 0.45 kW, 12,000 rpm) pneumatically swivelable 0/10° • Multifunction milling unit 1827 pneumatic (2 x 0.65 kW, 200 Hz, 12,000 rpm) • Vertical tracing rollers manual manual adjustment of the vertical tracing roller by 0.1 mm for milling edge overhang, e.g. for plastic edges • Cutter, diamond Ø 56 / 60 mm, Z = 2, R = 2.0 mm, left-hand rotation Diamond-coated, solid tool with CM technology (LEUCO system) with integrated chip extraction, patented ProLock-E • Cutter, diamond Ø 56 / 60 mm, Z = 2, R = 2.0 mm, right-hand rotation Diamond-coated, solid tool with CM technology (LEUCO system) with integrated chip extraction, patented ProLock-E • Corner copying unit 1832 (1 x 0.35 kW, 200 Hz, 12,000 rpm), for edge thickness up to 3 mm Gkjdpox Huhcjfx Acmsd • Cutter, diamond Ø 53 mm x 10 mm x 16 mm, Z = 3, R = 2 mm, with CM technology (LEUCO system) with integrated chip extraction, for profiling unit 1832 • Scraper unit 1929 pneumatic including pneumatic adjustment (separately for top and bottom) • HW reversible knives for scraper holder 1929 / 1927 R = 2.0 mm (2 pcs required) • Flat scraper unit 1964 Removing glue residue for a clean glue joint. • Buffing unit 1940 (2 x 0.12 kW, 50 Hz, 1400 rpm) For final cleaning and edge polishing. With 2 textile discs, swivel range 0–5°

Condition: excellent (used), Year of construction: 2020, Machine location and collection: Hohenems, Austria. Indicated location Stuttgart = DS-Maschinen company headquarters. HOMAG EDGETEQ S-380 - Edge bander Technical data and features - Type: OPTIMAT KDF 650 C - Year of manufacture according to nameplate: 2020 - Workpiece thickness 8–60 mm, depending on processing and tooling - Jointing cutter set 40 mm: maximum workpiece thickness 42 mm according to manufacturer's documentation - Edge band thickness 0.3–3 mm; strip thickness 0.4–12 mm - Feed rate 8–18 m/min - Machine length 4,555 mm; working height 950 mm - Jointing cutters 2 × 2.2 kW - IR workpiece preheating - Application unit QA65 N, suitable for EVA, PUR and polyolefin - Automatic edge band infeed and motorized pressure zone adjustment - Trimming unit 2 × 0.35 kW with softtouch - Multi-stage milling unit MS40 - Multifunction profiling milling unit / corner copying with FlexTrim - Multi-stage profile trimming blade MZ40 and glue joint trimming blade - Release agent and cleaning agent spray devices - Buffing unit with two motors - powerTouch 24-inch Full HD multi-touch control panel - Connection 400 V / 50 Hz, compressed air at least 6 bar Accessories A suitable XES 200 service station is available separately and is not part of this offer. Condition Very good condition. The machine can be inspected while in operation by prior appointment. Location and collection Machine location: Hohenems, Vorarlberg, Austria. Gsdps Adubrefx Acmjkd Dismantling and loading will be coordinated with DS-Maschinen and managed by us. Offer includes free loading onto a truck, including professional dismantling and loading by us. Transport, unloading, installation and commissioning are not included and can be arranged separately. Price on request. Contact DS-Maschinen for further information and a customized offer.

Condition: excellent (used), Year of construction: 2018, machine/vehicle number: 0-250-04-4777, functionality: fully functional, operating hours: 22,891 h, input voltage: 400 V, input current: 31 A, input frequency: 50 Hz, type of input current: three-phase, travel distance X-axis: 4,030 mm, travel distance Y-axis: 1,950 mm, workpiece length (max.): 3,100 mm, workpiece width (max.): 1,250 mm, workpiece height (max.): 160 mm, number of axes: 3, number of slots in tool magazine: 14, total height: 2,400 mm, total length: 6,850 mm, total width: 3,616 mm, overall weight: 3,250 kg, table length: 3,100 mm, table width: 1,250 mm, Equipment: documentation/manual, For sale is a 2018 HOMAG CENTATEQ P-110 3-axis CNC machining center, complete with all accessories shown in the pictures, clamping chucks, tools, replacement drive components, and an Extract DUO two-bag dust extraction unit. The machine has seen limited operating hours and has undergone annual brand-name servicing. The machine can be inspected while in operation. The selling price includes professional disassembly and crane loading onto a truck. The organization and costs of transport are the responsibility of the buyer. Primary usage: 272 h Secondary usage: 193 h Total usage: 22891 h Work table: X = 3100 mm, Front stop Y = 1250 mm, Rear stop Y = 1550 mm, Z = 160 mm Main spindle power: 10 kW Gksdpfxsz E Rinj Acmod Travel speed: X/Y = 60 m/min X = 35 m/min Y = 50 m/min Z = 15 m/min Bumper – safety system EN1760-3 14 tool storage spaces on the moving part, and an additional 8 on the fixed part. Extract Duo dust extraction unit technical specifications: Fan power kW: 5.5 Filter area m2: 36 Filter bag diameter mm: 800 Number of dust bags: 2 Delivered air volume m3/h: 6000

Condition: used, machine/vehicle number: 008690, X axis working area: 3100 mm Y axis working area: 1410 mm Gjdpszwdkfjfx Acmjkd Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 18 Total number of tool changer positions: 18

Condition: ready for operation (used), Year of construction: 2008, A screw compressor Atlas Copco with integrated refrigerated dryer including a 500l compressed air receiver is offered. Motor power: 22kW (30hp), Volume flow: 3.84m³/min (64l/s), max. operating pressure: 12.8bar, Operating hours: 29897h, Refrigerant dryer: R134a, 0.95kg. The compressor was serviced annually without interruption by a qualified specialist company. Documentation available. Inspection possible by appointment. Gedpezh Nizjfx Acmskd

Condition: used, Year of construction: 2012, Used machine Year of manufacture: 2012 Base machine - Dynestic 7521 20.6 Dynestic table For classic nesting machining with wear plate Machining length 6250 mm (DYNESTIC 20.6 additional 4th stop in Y already included) Machine frame in welded construction with ground and hardened prism guides for the traversing carriage, spindle head and consoles Traversing carriage in gantry design Rack and pinion drive, helical, in X and Y direction, ball screw spindles Z-axis for precise positioning Gedpfxew I U Ece Acmekd Technical data: The technical data refer to the DYNESTIC 7521 - 20.6 Please refer to the corresponding data sheets. Machining dimensions: Max. workpiece size for edge machining X = 6250 mm Y = 2100 mm Max. travel distances X = 7360 mm Y = 2720 mm Z = 325 mm Max. clearance height DYNESTIC table Z = 1st stage 318 mm / 2nd stage 418 mm from top edge of table (without tool, without chuck) Maximum programmable speed Vector speed: 128.0 m/min X = 80 m/min, Y = 100 m/min, Z = 25 m/min 4-stage extraction hood with pneumatic height adjustment and viewing window Voltage 400 V, 50/60 Hz CONTROL: Dual-Core processor Operating system Windows XP 80 GB hard drive / 1 GB RAM RJ45 network connection 10/100 Base-T Fast Ethernet US keyboard and Microsoft IntelliEye mouse (optical) CD-ROM / CD-RW drive (CD burner) Remote maintenance Integrated network card for data transfer of control and program data. Data transfer takes place via high-speed internet connection Requirement: High-speed internet connection at the machine. DYNESTIC table Solid, continuous machining table with grid division, continuous grooves in X and Y direction, groove spacing 50 mm with 25 meters of sealing cord for securing the wear plate 1 machining field with stop rails / stop Height 30 mm, pneumatically lowerable 2 stop rails in Y direction and 1 stop in X direction on the right (when viewed from the front of the machine) Vacuum fields 1-circuit vacuum system Boring unit 7976, 24 spindles Drive power 3.0 kW 18 vertical spindles individually selectable Arrangement in L-shape, 10 in X and 8 in Y direction 32 mm grid Max. drill diameter: 35 mm Total drill length: 70 mm from the mounting end (depending on plate thickness) Spindle extension stroke: 70 mm Rotation direction: alternating right-hand / left-hand rotation n(max.) 1000 - 5710 min-1, steplessly adjustable Chuck: M 10 thread - clearance fit 11 mm without tool, without chuck 6 horizontal spindles 2 double boring spindles in X direction (32 mm distance between 1st and 2nd horizontal boring spindle) 1 double boring spindle in Y direction Chuck: M 10 thread, clearance fit 11 mm Total drill length max. 70 mm from the mounting end without tool, without chuck Free space 1 for: Optional double boring spindle in X direction or Vertical adapter with double feed force Free space 2 for: Optional saw in X direction or Vertical adapter with double feed force Milling unit 7831, 2-stage Power: 11.0 kW (S6) n(max.) = 1000 - 24000 min-1, steplessly adjustable, two-stage feed stroke max. power at 12000 min-1 to 24000 min-1 air-cooled with HSK-F 63 tool holder with right-hand

Condition: used, Year of construction: 2021, functionality: fully functional, For Sale: Premium Holz-Her 1329 Multi Edgebander + Return-Master 5920 We are selling a high-end Holz-Her 1329 Multi edgebanding machine, including the Return-Master 5920 return system. The unit is 4 years old and in excellent condition. Original New Price: €138,000 + VAT Our Price: €69,000 + VAT (50% savings) Godpfeygrghox Acmekd Why choose this machine? Get a premium, lightly used machine for the same price as a subsidized unit, but without the paperwork, bureaucracy, or long-term obligations of a grant application. Maintenance: Regularly serviced by the expert Dimpex technical team. Performance: High-spec "Multi" version for versatile production needs. Serious inquiries only, please.

Condition: ready for operation (used), Year of construction: 2016, machine/vehicle number: AA1/018801, functionality: fully functional, power: 9.5 kW (12.92 HP), workpiece length (max.): 3,086 mm, workpiece width (max.): 2,155 mm, overall weight: 3,841 kg, year of last overhaul: 2016, Equipment: CE marking, documentation/manual, We are offering this ready-to-use SCM Pratix S22 machining center, manufactured in 2016. The machine features a 9.5 kW spindle (max. 24,000 rpm) and an F12 2.2 kW drilling unit (12 independently operated). Gsdez Sp N Uspfx Acmjkd The machine can be viewed in operation in October and the first week of November 2026. If you have any questions or would like more information, please feel free to send us a message or call us.
