Column drilling machine

ALZMETALL AX 3 SV

Condition: new, ALZMETALL AX3/SV pillar drilling machine NEW Manufacturer: Alzmetall Type: AX3 SV Condition: New Drilling capacity steel 40 mm Thread cutting steel M24 Cast M30 Crjdpfxoxd Trfs Ac Hjh Short spindle MK 3 Spindle stroke 120 mm Usable projection 293 mm Column diameter 115 mm Machine table 515 x 360 mm Distance spindle-table 117/701 mm T-slots 2 x 14 x 224 mm Feed 0.1 + 0.2 mm/rev Machine height approx. 1840 mm Net weight approx. 270 kg Drive continuously variable Motor 750/ 1500 rpm Power 1.0 / 1.6 kW Spindle speed rpm 80-1125 Additional equipment: - Reversing switch - Machine light LED - Thread cutting device - Coolant device B Available immediately from stock

Condition: good (used), Year of construction: 1985, machine/vehicle number: 4888, Offer 25234 Technical Data: - Drilling capacity in steel ST 60: 32 mm - Maximum drilling diameter in steel ST 60: 40 mm - Long spindle MK 3 - Drill spindle speeds steplessly adjustable - Range 1: 160 – 1125 rpm - Range 2: 320 – 2250 rpm - Drill spindle stroke: 120 mm - Feeds: 0.1 + 0.2 mm/rev - Throat depth: 293 mm - Column diameter: 115 mm - Table size: 300 x 300 mm Credpfxewylvqs Ac Hsh - With 2 T-slots 14 x 224 mm - Emergency stop button - Machine vice - 10 pcs. HSS drill bits 10 – 25 mm - Required space approx.: W 500 x H 1750 x D 900 mm - Weight approx.: 270 kg

Condition: new, bore capacity in steel (diameter) 40.0 mm threading M 24 throat 293 mm bore stroke 120 mm morse taper 3 Kurzspindel MK table: 515 x 360 mm turning speeds 80 - 1125 U/min feed 0.10 + 0.20 mm/U column diameter 115 mm distance spindle /table 117 / 701 mm total power requirement 1.0 / 1.6 kW weight 270 kg height of the machine 1840 mm Furnishing: - Lockable main switch with motor protection switch - Mushroom pushbutton (latching) for EMERGENCY STOP - Infinitely variable speed adjustment - Digital speed display - Feed overload protection Cjdpfxexaar Re Ac Hsrh - Protection class IP 54 - Spindle protection with electrical fuse - Operating instructions in German including special equipment: - Thread cutting device pos. 20.0 (Thread cutting with stop) - Coolant device "B" pos. 25.

Condition: good (used), Year of construction: 1998, Drilling capacity steel/cast iron: 32/38 mm Spindle mount: 3 MT Throat: 293 mm Csdpfx Ajwup Exsc Hjrh Table size: 300 x 300 mm Quill stroke: 120 mm Feed rates: 0.1/0.2 mm Drive motor: 1.5/1.9 kW Space required: 900 x 450 x 1870 mm Weight: 270 kg

Condition: used, Year of construction: 1999, Technical details: Crsdpeva Hmrjfx Ac Hoh bore capacity in steel (diameter): 32 mm throat: 293 mm bore stroke: 120 mm bore capacity in cast iron: Ø 38 mm spindle taper MT: MK 3 spindle throat: 293 mm spindle speed:: 160 - 2250 / seples U/min feed: 0,10 - 0,20 / manuell+automatisch mm/U Distance spindle/table max.: 55 - 642 mm table clamping surface:: 300 x 300 mm drill table adjustment: ja mm column diameter: 115 mm distance spindle center to floor plate:: 1207 mm total power requirement: 1,9 kW weight of the machine ca.: 280 kg dimension machine xH: 0,7 x 1,0 x 1,9 m Column drilling machine with infinitely variable speed adjustment and automatic feed. Tapping with changeover switchEquipment: RÖHM 3 - 16 mm chuck, operation by foot switch left/right *

Year of construction: 1987, condition: used, 1 pillar drilling machine ALZMETALL AX 3SV, serial no. 5739, year of manufacture 1987 Codpfei Apu Tox Ac Herh

Condition: good (used), Year of construction: 2002, 1 used pillar drill Crjdpfx Acovm Un Dj Hsh Brand Alzmetall Type AX 3 SV Year of manufacture 2002 Drilling capacity in steel 60 steel: 40 mm Tapping capacity in steel 60 steel M 24 Tapping capacity in cast iron 20 steel M 30 Spindle speeds - continuously variable 160-1250 rpm Short spindle MT 3 Spindle stroke 120 mm Thrust 293 mm Column diameter 115 mm Machine table - usable support 515 x 360 mm Distance between spindle and table min./max. 117/701 mm T-slots number - width - spacing: 2 x 14 x 224 mm Feed rate: 0.1 + 0.2 mm/rev Machine height: 1840 mm Equipped with: Tapping device Mushroom push button (latching) for emergency stop Infinitely variable speed adjustment Technical specifications: Errors excepted

Condition: used, Year of construction: 1997, bore capacity in steel (diameter) 28 mm throat 293 mm bore stroke 140 mm Credpfxewli Hqo Ac Heh table surface area 415 x 300 mm spindle turning speed range 160 - 2250 U/min feeds 0,1 / 0,2 mm/U total power requirement 1,9 kW weight of the machine ca. 0,3 t - machine out of teaching shop - Accessories: DRO for spindle speed and quill stroke, drill chuck RÖHM 1 - 13 mm

Condition: not inspected (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: AB4SV-15266, spindle speed (max.): 2,250 rpm, spindle speed (min.): 160 rpm, drilling capacity: 32 mm, Alzmetall AX 3-SV column drilling machine – Automatic feed Year approx. 1992–1999, Serial No. 642 Drilling capacity in steel Ø 32 mm, MK 3 spindle Spindle speeds 160–2,250 rpm, stepless Automatic feed 0.10/0.20 mm/rev Fully functional: spindle & feed checked Incl. drill chuck, workpiece clamp, documentation Credpfxowr Uq Us Ac Heh

Condition: new, Column drilling machine Make: ALZMETALL Model: AX 3/SV Condition: New machine Speed 80 - 1.125 RPM serially equipped with: - Speed adjustment, infinitely variable - Speed display, digital - feed overload protection - spindle protection - Instruction manual Credpfx Acjb Archj Hjh further important technical data: - 40 mm drilling capacity in ST 60 - 120 mm quill stroke - spindle cone MK 3 - 115 mm column diameter - feed rate 0,1 + 0,2 mm/rev - 1,0 / 1,6 kW motor power - 515 x 360 mm Table dimension
