Condition: used, Functionality: fully functional, turning diameter over cross slide: 1,100 mm, spindle bore: 220 mm, turning diameter: 1,500 mm, turning length: 7,000 mm, Tacchi FTC Lathe with 7,000 mm between centers Description Manufacturer: Tacchi Model: FTC Capacities: Distance between centers: 7,000 mm Swing over bed: 1,500 mm Swing over cross slide: 1,100 mm Swing over gap: 1,850 mm Spindle bore diameter: 220 mm Speeds: Kslhcowulimocqrolu 8 speeds from 24 to 485 rpm Rapid feeds: Rapid traverse on both carriage axes Equipment: 3 fixed steadies and 1 movable steady 4-jaw chuck Ø 1,000 mm mounted on the lathe Additional heavy-duty 4-jaw chuck Ø 1,200 mm General condition: Lathe in good condition

Condition: excellent (used), Functionality: fully functional, spindle bore: 180 mm, MACHINE CAPACITY: Maximum diameter on the bed: mm 1.250 Maximum diameter on the carriage: mm 940 Height of the centers: mm 625 Width and height of the bed: mm 800 x 630 Maximum weight of the piece between the centers: kg 5.000 Maximum weight of the piece between the steady rest: kg 6.000 Distance between the centers: mm 6.000 Maximum torque at the spindle: kpcm 125.000 Maximum cutting force: kp 5.000 SPINDLE: Front side shaft diameter: mm 180 Boring diameter: mm 102 Spindle taper 1:10: mm 120 Front end of the spindle CSN 20 1010: mm 290 Spindle speed in 24 steps: rpm 1,8 – 355 CARRIAGE: Longitudinal feeds at all spindle speeds in 54 steps: mm/rev 0,8 - 7 Longitudinal feeds with spindle idler shaft in 54 steps: mm/rev 0,66 - 56 Cross feeds: mm/rev 0.33 of the longitudinal. Longitudinal rapid movement: mm/min 3.600 Useful stroke of the cross carriage: mm 530 Useful stroke of the tool holder slide: mm 340 Max. tool section for the tool holder: mm 60 x 60 THREADS: A .For rack gear 27 metric threads at a pitch of: mm 0.125 – 56 b. For main screw 40 metric threads at a pitch of: mm 1 – 112 42 Whitworth threads, number of threads per inch: ¼ - 28 Kleljwt T Dcshccqrou 32 module threads: module 0,5 – 28 36 Diametral Pitch D.P. 56 – 1 36 Circular Pitch C.P. 1/16 – 3 ½ MAIN SCREW: Diameter per pitch: mm TR 65 x 12 TAILSTOCK: Diameter of the tailstock hole: mm 150 Diameter of the tailstock quill: mod. 200 Diameter of the hole cone: mm 100/1:20 Transverse movement of the tailstock: mm +/- 10 Max. axial load of the tailstock: kp 5.000 Machine weight: kg 10.500 Equipped with: - Fixed steady rest - Instruction manuals

Condition: ready for operation (used), Functionality: fully functional, turning diameter over cross slide: 1,050 mm, spindle bore: 104 mm, turning diameter: 1,400 mm, turning diameter over bed slide: 1,400 mm, Manufacturer: Geminis Model: GE 1400 Admissible dimensions: Distance between centers: 8,000 mm Diameter over bed: 1,440 mm Diameter over cross slide: 1,070 mm Diameter over gap: 1,800 mm Gap length from chuck nose: 500 mm Bed width: 850 mm Spindle bore: 104 mm Travels: Cross slide travel: 500 mm Tool post travel: 220 mm With rapid traverse Speeds: 24 speeds from 2.8 to 360 rpm Motor: Power: 30 HP Equipment: Digital readout 4-jaw independent chuck Ø 1200 mm Kelhcowtwmhocqrolu 3 steady rests Interior deep-hole machining tooling set included General condition: Lathe in good condition total length for transport 11,5mts

Condition: used, Year of construction: 2002, Tacchi HD-1450 CNC 725 x 4000 Heavy Duty Centre Lathe. S/No. 6954 (2002) with Siemens Sinumerik 828D, 1000mm Diameter 4 Jaw Double Chuck, Chuck Bore Diameter 515mm, Barrufaldi Ban 400/4 4 Way indexing Tool Post (2) x 3 Point Steadies, Tailstock, Swarf Conveyor, Centre Height 725mm, Max Swing 1450mm Distance between centres 4000mm, Main Motor 60kw, Max Workpiece Weight 15,000kg Kslowr A T Rohccqrelu Location: This lot is located in Aberdeen, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2002, Tacchi HD-1450 CNC 725 x 4000 Heavy Duty Centre Lathe. S/No. 6954 (2002) with Siemens Sinumerik 828D, 1000mm Diameter 4 Jaw Double Chuck, Chuck Bore Diameter 515mm, Barrufaldi Ban 400/4 4 Way indexing Tool Post (2) x 3 Point Steadies, Tailstock, Swarf Conveyor, Centre Height 725mm, Max Swing 1450mm Distance beween Centres 4000mm, Main Motor 60kw, Max Workpiece Weight 15,000kg Location: This lot is located in Aberdeen, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described. Klolhcswr A N Escqrju

Condition: used, Year of construction: 2007, Tornos Gurutzpe A-1200 46 Heavy Duty Lathe. S/No. 8184 (2007) with GE Fanuc Series 21i-TB Control, between Centres 5000mm, Centre Height 600mm, Workpiece Height 5,000kg, Spindle Bore 150mm, 800mm Diameter 4 Jaw Chuck, Chuck Bore Diameter 190mm, SMW Autoblok, SLU-6-25 185 - 520mm Hydraulic Steady, Sauter 0.5.320.632 4 Way Indexing Toolpost, 3 Point Steady, Tailstock, Swarf Conveyor Location: This lot is located in Aberdeen, UK. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described. Kjlhccqowr A Emjrjlu

Condition: good (used), Year of construction: 1988, spindle bore: 105 mm, turning diameter: 1,150 mm, turning length: 5,000 mm, total length: 8,000 mm, total width: 1,800 mm, total height: 1,550 mm, bed width: 650 mm, Motorized tailstock CE-Chuck cover protection Telescopic guide cover over guideways Steady rest  4 chuck 1000 mm diameter 3 chuck 500   mm diameter   2 Axis digital read out system DBC Turning Length: 5000mm Swing over bed Ø: 1150mm Swing over cross slide Ø:850mm Spindle bore: 105mm Bed width: 650mm Tailstock spindle Ø: 140Ø Stroke pinole: 300mm Spindle taper: 6Mk Speeds / ranges: 4,5 - 900Rpm Workpiece load: 8000 Length: 8000mm Width: 1800mm Klelowrxpbjhccqrju Height: 1550mm Weight: 13800kg

Condition: ready for operation (used), Year of construction: 1980, turning diameter: 1,040 mm, turning length: 2,000 mm, sliding bed lathe EST TICINO - ET BM 520 x 3000 Turning length: 2000mm Turning Ø over bed: 1040mm Turning diameter over support:710mm Turning Ø in pocket: 1780mm Pocket length: 1000mm Throughput - spindle bore:130mm Bed width: 600mm Pinole: 130Ø Tack centre stroke: 300mm Klelewq Rqzehccqrsu Spindle pinole recording Mk: 6Mk Power kW: 22kW Speed - Range: 600Rpm Feed X-axis: 4000mm/min. Feed Z-axis: 4000mm/min. Length: 6000mm Width: 2100mm Height: 2100mm Weight: 8300kg

Condition: good (used), Year of construction: 1980, turning diameter over cross slide: 1,020 mm, turning diameter: 1,380 mm, turning length: 3,000 mm, Manufacturer: Leopoldo Pontiggia Type: SFE 700 Year of construction: 1980 3-jaw chuck 1200 mm Heidenhain digital readout system X / Z Axis Feeds in 2 directions Multi-fix tool system with inserts Specifications Metric US Standard Turning length 3000 mm Swing over bed Ø 1390 mm Swing over cross slide 1020 mm Spindle bore 150 mm Bed width 700 mm Quill travel 300 mm Spindle mount Metric 80 Mk Power 18 kW Kljlhcewp H Ruecqrou Speed 0 - 350 rpm Workpiece weight 8000 Dimensions (estimated) Length 6600 mm Width 1800 mm Height 2000 mm Weight 18000 kg Please note: The information on this page has been provided to the best of our knowledge and, where possible, taken from the manufacturer. The information is given in good faith, but accuracy cannot be guaranteed. Accordingly, they will not constitute representations or terms of contract. We recommend verifying all important details.

Condition: good (used), turning diameter over cross slide: 1,520 mm, turning diameter: 1,900 mm, turning length: 2,500 mm, Manufacturer: Leopoldo Pontiggia Type: SFE / CC 950 1R Year of manufacture: 1982 Specifications Metric US Standard Turning length 2500 mm Turning diameter bed Ø 1900 mm Turning diameter carriage 1520 mm Spindle bore 102 mm Spindle power 45 kW Quill 130 Ø Quill stroke 300 mm Spindle mount 6 Mk Dimensions (Estimated) Length 6800 mm Width 2800 mm Height 2800 mm Weight Kslhcowp H H Necqrelu 10000 kg Please note: The information on this page has been obtained by us to the best of our knowledge and, where possible, from the manufacturer. The information is given in good faith but accuracy cannot be guaranteed. Accordingly, they do not constitute representation or contractual terms. We recommend that you verify all important details.

Condition: ready for operation (used), Year of construction: 1990, spindle bore: 105 mm, turning diameter: 1,600 mm, center height: 800 mm, center width: 10,000 mm, turning length: 10,000 mm, overall weight: 19,000 kg, Capacity: 10000 x 1600 mm Broken bed 4-jaw chuck Kslhcowpqizscqrelu 3 steady rests Revised electrical cabinet

Condition: good (used), Year of construction: 1975, machine/vehicle number: D 4042, Offer 25216 Technical Data: - Max. turning diameter over bed: 1025 mm - Max. turning diameter over support approx.: 760 mm - Distance between centers: 4000 mm - Spindle bore: 180 mm Klelhccqewpfm Ujrju - Spindle speeds: 70 to 450 rpm - 300 to 630 rpm - Feeds longitudinal / cross - Tailstock: MK 6 - Tailstock quill travel: 370 mm - Chuck: 1000 mm - Quick-change tool holder with various inserts - 2 x steady rest - Digital display HEIDENHAIN - Drive: 400 V / 20 kW - Space required approx.: W 6500 x H 2250 x D 2350 mm - Weight approx.: 11000 kg

Condition: used, Type: 25 x 120 Straight Bed Lathe Distance between centers: 72″ Swing over bed: 26″ Swing over cross-slide: 16″ Spindle speeds: 7.4 to 600 (24) Spindle bore: 4 1/8 Full length screw cutting: yes Chuck mounting: D1-11 Tailstock taper: No.5 Morse Power compound Kslhewmlckjccqrelu Power traverse Slide along chuck guard and we have rear splash guarding Main motor: 15kw 3 phase Weight: approx 5 tons Condition: Slideways very good Can also be repainted at extra cost Cleaned and serviced

Condition: excellent (used), Broadbent Heavy Duty Lathe 1041mm x 10,000mm Year approx. 1973. Swing over bed 1041mm (41”) Swing bin gap1575mm (62”) Distance between centres 9300mm (30’ 6”) Spindle bore 115m (4 ½”) Spindle speeds (18) 3.3 – 360 rpm Spindle motor 30 HP or 40 HP (To be confirmed) Klolowhylvshccqrsu Tailstock 6 MT Imperial & Metric screw-cutting with change gears. 36” Faceplate with 4 adjustable jaws, 54” Faceplate, Taper turning attachment, Power feed to top slide, 2 x 18” 3 point steadies, 24”/28” Steady.

Condition: used, Year of construction: 1999, faceplate diameter 1000 mm turning diameter over bed . mm turning diameter over slide rest . mm weight of the machine ca. 6 t turning length . mm Klelhcjwg Hubscqreu total power requirement . kW dimensions of the machine ca. . m

Condition: good (used), center height: 1,050 mm, center width: 3,000 mm, Lathe Heyligenstedt brand Faceplate diameter 1720 mm Center height 840 mm in the offset 1050 mm Klelhccewb Dx Hsqrou Center width 3000 mm Anima digital display Space requirements: Length 6000 mm Width 2700 mm 2000 mm without support Height 2200 mm Motor 380 volts 24/18.5 kW The machine can be inspected with power at the supplier's factory.

Condition: used, Year of construction: 1971, turning diameter over cross slide: 2,000 mm, turning length: 10,000 mm, Heavy-duty lathe Manufacturer: Skoda Year of manufacture: 1971 Turning diameter: 2000 mm Turning length: 10000 mm Kelhccqswbu Averolu With steady rests Digital display New electrical system

Condition: refurbished (used), Conventional parallel lathe MORANDO Mod. SR26 1300 X 7000 mm Completely reconditioned CE machine. New Turcite, new electrical/hydraulic part. Grinding. Accident prevention regulations with guards. Heavy series with a single cast iron casting. Guides like new. 4-jaw platform diameter mm 1700. Nr.02 Steady rests. Admissible weight between the centers without steady rests Kg 25,000 – 30,000. Admissible weight between the centers with steady rests and tailstock kg 38,000. Height of points: 1300 mm. Klslhcjwbfw Dscqreu Vaulting above the guides: 2615 mm. Vaulting above the carriage: 2240 mm. Bench width: 1500 mm. Distance between points: 7000 mm. Platform diameter: 1700 mm. Spindle motor: 50 – 80 Hp. Speed ranges: No. 24. Spindle speed range: 1 – 200 rpm. Dimensions: Length 11,800 mm. Height 3000 mm. Weight approx. 35,000 kg. Visible in operation.

Condition: ready for operation (used), Year of construction: 1973, turning diameter: 2,000 mm, center width: 10,000 mm, spindle speed (max.): 100 rpm, Capacity: 10000 x 2000 mm 2000 mm chuck 3 bezels Klslhccjwbdq Aoqrou

Condition: excellent (used), Year of construction: 1991, The machine is in very good condition Klolhccqowa S S Ejrsu visible under power

Condition: ready for operation (used), Romanian Lathe SN 1800x3000 Manufacturer Uppetrom 1 MAY Chuck diameter 1800 mm Max swing over bed 1800 mm Klelhccov Uaufoqreu Length between centers 3000 mm Max swing over slide 1450 mm Max weight of work piece between centers 25,000 kg Movie with machine underpower available

Condition: excellent (used), Year of construction: 2008, KAMI DKM 1000 lathe Year: 2008 Center height: 500 mm Swing diameter over bed: 1000 mm Distance between centers: 3000 mm Swing diameter in gap: 1240 mm Swing diameter over cross slide: 705 mm Spindle bore: 120 mm Spindle type Camlock D1-15/MK6 Spindle speeds: 18 steps, 14 - 750 U/min (reverse) 24 - 857 U/min Tailstock diameter: 120 mm Tailstock pinola travel: 205 mm Tailstock pinola: Morse 6 Motor power: 11 kW Weight: 6200kg Dimensions of the machine: 5400 x 1820 x 1800 mm Accessories/options: Kjlhccqev Tppcerslu DRO system for 3-axis fix steady travelling steady faceplate chuck coolant tank tool holders

Condition: used, Year of construction: 2018, Functionality: fully functional, turning diameter: 1,000 mm, turning diameter over bed slide: 710 mm, turning length: 8,000 mm, Used heavy-duty lathe with extensive steady rest equipment – ideal for pipe machining and long rolls! This robust conventional lathe with an impressive turning length of 8,000 mm was specifically designed for pipe machining applications. The sophisticated machine design allows the cutting edge to easily pass the open steady rests – ideal for precise machining of long, hollow workpieces. Technical Highlights: • Turning diameter over bed: 1,000 mm • Turning diameter over support: 710 mm • Center height: 900 mm • Turning length: 8,000 mm • Spindle bore: 155 mm • Machine weight: approx. 18.2 tons • Main drive: 30 kW with frequency converter, continuously variable Design advantages: • Machine bed cast in one piece and artificially aged – for maximum stability and stress-free operation • 5 hardened and ground guideways for maximum precision • Continuous feed control of the longitudinal axis via ball screw – no Norton or lock-box gearing • Electric-driven tailstock with hydraulic clamping Klelhev Tntteccqrou • Manually adjustable cross support with trapezoidal thread spindle • 4-station tool carrier, manually pivoting • Triple-guided turning support – for extremely smooth running Steady rests & tube processing: • Various steady rests (stationary and follow-on) optional Available • Motorized steady rest carriers with hydraulic clamping • Spindle adjustment conveniently possible from the operator's side • Traveling steady rests can be mounted either on the left or right Application: Thanks to its sophisticated design, the machine is ideally suited for light to medium-duty machining – especially for the precise machining of tubes. The continuously variable speed and feed control ensures high flexibility and ease of use.

Condition: good (used), Year of construction: 1987, turning diameter over cross slide: 810 mm, spindle bore: 130 mm, turning diameter: 1,140 mm, turning length: 7,500 mm, quill stroke: 300 mm, total length: 7,500 mm, total width: 2,300 mm, total height: 1,650 mm, bed width: 600 mm, Please note: not original pictures its only 3000 length not 5000 mm   3 Guide way construction 2 Axis HeidenHain Digital readout Feed in 3 directions all tool post slide Central lubrication   Work load flying in chuck 2500 kg Work load NOT supported 8500 Kg Work load supported 10000 kg   Optional 4 chuck approx. 1200 mm Optional 4 chuck approx. 1500 mm Optional package with 3 steady rest fixed model from  .... to ....  Kljlsv S Dp Ijhccqreu Turning length: 5000 / 7500mm Turning diameter bed Ø: 1140mm Turning diameter slide: 810mm Turning diameter pit Ø: 1500mm Pit length: 2500mm Spindle bore: 130mm Bed width: 600mm Quill: 130Ø Quill stroke: 300mm Spindle mount: 6Mk Power: 25kW Speed: 9 - 900rpm Length: 7500mm Width: 2300mm Height: 1650mm Weight: 12000kg

Condition: good (used), Year of construction: 1999, Center height 550 mm Turning diameter over bed 1100 mm Turning diameter over support 830 mm Center distance 2000 mm Spindle bore 95 mm Spindle mount DIN 55027 size 11 Bed width 700 mm 21 speed settings 8 – 800 rpm Klelhccqov Rvzterou Workpiece weight between centers 6000 kg Workpiece weight between centers and 1 steady rest 7600 kg Workpiece weight in 3-jaw chuck 1000 kg Feed range longitudinal 0.010 – 12.8 mm/rev transverse 0.05 – 6.4 mm/rev Rapid traverse Z/X 4/2 m/min 60 metric threads 1 – 120 mm 56 inch threads 30 – 1/4" 45 module threads 30 – 0.25 module Tailstock mount MT 6 Quill travel 300 mm Quill diameter 130 mm Drive power 27/17 kW Dimensions L x W x H 4500 x 1750 x 1700 mm Weight 7800 kg Accessories / Special Features: • 3-axis digital readout, HEIDENHAIN • 3-jaw BISON face-to-face scroll chuck, Ø 630 mm • 1 stationary steady rest with rollers up to Ø 750 mm • Automatic top support feed • "Multifix" quick-change system, size D2 • Main drive 27/17 kW • Tailstock quill with reduction gear for quill adjustment 1:1 + 1:5 • Large, movable chuck guard • Leadscrew and feed screw guards • Machine light • Feed + rapid traverse in all axes • Coolant system • CE-compliant Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel
