Used Weiler Ergodor for sale (177)

Condition: excellent (used), Weiler Ergodor lathe Max. Turning diameter over bed: approx. 320 mm Max. Turning diameter over support: approx. 160 mm Max. Turning length: approx. 470 mm Bar passage: approx. 36 mm Spindle: Speed range: approx. 30 - 3550 rpm Spindle nose: A 2 - 5 Drive power: approx. 3.0 kW Automatic longitudinal & face feeds: Feed range: approx. 0.020 - 2.0 mm/rev Suitable for threads: - metric 0.20 - 12 mm Nodpfjq Ixxyox Aa Eelk Inch 80 - 2 Gg/ Diametral - Pitch thread 160 - 5.5 Dp Module 0.1 - 4

Condition: like new (used), Year of construction: 1992, Lathe WEILER Precision center lathe in ergonomic design The Weiler Ergodor is the first German ergonomically designed lathe. It creates a more humane workplace and prevents health problems. The key feature is that the employee can operate this lathe while standing or sitting. Technical data Center width 470 mm Turning length 430 mm Center height 145 mm Rotation Ø over cross slide 160 mm Nsdpjvgqu Hjfx Aa Eolk Rotation Ø over bed 300 mm Spindle head, short taper flange Bayonet mounting DIN 55022 size 5 or Camlock clamping D 1-ASA-4 Spindle bore 36 mm DIN 55022 size 5 Spindle inner taper Spindle speeds Speeds 30 - 3550 rpm S Speeds 15 - 3550 rpm Brake motor 3 kW Brake motor 1.5/3 kW Face slide travel 150 mm Travel of the top slide 100 mm Feed rates and thread pitches on the gearbox switchable steps 30 Section 2 1.5/3 kW 38 Gear ratio in headstock 3 20 Long feeds 150 mm via change gears 100 mm via toothed belt Face feeds = 1/2 Longitudinal feed values Metric pitches 0.2 - 12 mm Module pitches 0.1 - 4 Dimensions 1450 x 640 x 1500 mm Dimensions 1450 x 640 x 1500 mm Net weight 1000 kg Acceptance according to toolmaker's accuracy DIN 8605 20 Built according to the rules of occupational safety, official test no. A. EM 11 1545/80. Encombrement 1450 x 640 x 1500 mm

Condition: good (used), Weiler E70 Hollow Spindle CNC Lathe Year: 2003 Distance Between Centres: 2000mm Spindle Bore: 8" (200mm) Machine with: Front & Rear chucks Tailstock Nledowmqkyopfx Aa Eek Fixed Steady

Condition: excellent (used), functionality: fully functional, Provisur Weiler 878 grinder, 50hp model. Greta machine for burger, sausage, Petfood manufacturer. Can mince fresh or frozen flaked meat. Extended hopper. Nlodpfxsx Av Rus Aa Ejk

Condition: used, Year of construction: 1997, - Year: 1997 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 270 - Drive system: Teach-in - Centre height [mm]: 210 - Swing over bed [mm]: 420 - Distance between centres [mm]: 900 - Spindle bore [mm]: 55 - Min. spindle speed [rpm]: 4 - Max. spindle speed [rpm]: 3000 - Options: Digital readout - Type of digital readout: Weiler - Control: CNC Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Nlsdpjwnh I Sefx Aa Eek Lukas van Rossum

Condition: ready for operation (used), functionality: fully functional, Weiler Commodor in good working condition. Specifications: Swing diameter over bed: 380 mm Swing diameter over cross slide: 190 mm Distance between centers: 1000 mm Nlodpfx Aajx Ngpdo Eok Spindle bore: 56 mm Speed: 25–2000 rpm Motor power: 4 kW Machine equipped with: 3-axis digital readout 3-jaw chuck with multiple jaws Coolant system Multifix quick-change tool post with 4 holders Collet system with collets Bed stop

Condition: excellent (used), Year of construction: 2017, Weiler Primus VCD (2017) Precision Lathe Manufacturer: Weiler Model: Primus VCD Precision Lathe Nodpfxjx Nkdxj Aa Eslk Year of manufacture: 2017 Condition: used, very good, as new, recently serviced according to factory specifications with acceptance protocol Scope of delivery: - Documentation

Condition: used, turning diameter over bed 280 mm turning diameter over slide rest 160 mm turning length 500 mm centre height 140 mm centre distance 500 mm spindle bore 36 mm spindle turning speed range 15 - 3550 U/min spindle head DIN 55022 Gr. 5 feeds - longitudinal 0,008 - 0,560 mm/U Nsdpsx Ni Dkofx Aa Eelk feeds - cross 0,004 - 0,280 mm/U thread - mm pitch 0,2 - 12 mm dia. of leadscrew 24 mm lead of leadscrew 6 mm tailstock taper MT 3 tailstock quill stroke 90 mm tailstock adjustment out of the central pos. 15 mm total power requirement 2,2 kW weight of the machine ca. 0,6 t - machine out of teaching shop - Accessories: DRO on 3 axis, 3-jaw chuck RÖHM 160 mmø, MULTIFIX-head A, running center

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Weiler Praktikant 160 B Lead and Feed Screw Lathe with K&C 3-Axis Digital Readout, from Vocational School Technical Data: >> Year of manufacture: 1992; Machine No.: 92 160 3271 Nlsdpex H S D Iofx Aa Esk >> Center height: 160 mm >> Distance between centers: 650 mm >> Spindle speeds: from 24 to 2500 rpm >> Spindle bore: 40 mm >> Short taper spindle nose DIN 55027, size 5 with bayonet lock >> Tailstock: Morse taper 3 >> Feeds: from 0.02 to 0.63 mm/rev >> Thread cutting capability: metric, inch, module, and diametral pitch threads >> Metric thread pitches: from 0.25 to 8 mm >> Weight: approx. 680 kg >> Switchable spindle brake >> Dimensions: 1.6 m (L), 1.25 m (H), 0.7 m (D) Accessories and Features: >> 3-axis digital readout by K&C incl. operating manual Functions: mm/inch switching, coordinate selection ABS/INC, display value halving, reference mark, tool programming for up to 200 tools, taper calculation, radius/diameter, quick zeroing, count direction switching >> Collet system with NEW collets from 3 to 26 mm in 1 mm increments >> 160 mm 3-jaw chuck (clamping jaws) with 1 set of jaws >> Quick-change system with 4 toolholders >> Bed stop >> Electronic spindle guard >> Rear cover >> Coolant system >> Operating manual, spare parts diagram About the Machine: Offered is a Weiler Praktikant 160 B lead and feed screw lathe, toolroom accuracy, year 1992, in very good condition. The machine is, of course, fully functional. All slides move smoothly and evenly. Even at high spindle speeds, the Weiler runs quietly. This newer generation of Weiler lathes is very user-friendly and enables the production of ground-like surface finishes. Take the opportunity to inspect this machine under power on-site and see for yourself its excellent condition.

Year of construction: 2010, condition: like new (used), We have the following accessories for Weiler E30 lathe. 1.piece .faceplate Schunk 250mm price:600,-€ Spindle head DIN 55027 size 5 2.pieces.faceplate Röhm 260mm price each 1.piece:650,-€ spindle head DIN 55027 size 5 1.piece.travelling steady rest Price: 450,-€ 2.pieces.driving flange Price per. 1 piece: 210,-€ Njdpfx Aasgabvne Eolk Spindle head DIN 55027 size 5 All parts are in very good condition.

Condition: used, total length: 1,500 mm, total width: 750 mm, total height: 1,350 mm, Empty weight: 700 kg - Documentation available: Yes - CE certificate present: No - Drive system: Conventional - Centre height [mm]: 150 - Swing over bed [mm]: 300 - Carriage turning diameter [mm]: 160 - Distance between centres [mm]: 500 - Bed width [mm]: 210 - Spindle bore [mm]: 36 - Min. spindle speed [rpm]: 15 - Max. spindle speed [rpm]: 3550 - Transport dimensions: 1500mm x 750mm x 1350mm (l x w x h) - Transport weight [kg]: 700kg - Transport packages [pcs.]: 1 Nedpfsx D Tlrex Aa Ejlk Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: ready for operation (used), Year of construction: 1989, functionality: fully functional, For sale is a lathe of the brand Weiler type Primus LZ-GS The machine is in very good condition Technical data Year of construction 1989 Machine no. 4443 Operating voltage 380 V Center height 120 mm Center width 430 mm Speed:60 - 3000 rpm in 18 gear stages Spindle clearance 23 mm Short taper spindle head DIN 55027 Tailstock MK 2 Feed rates from 0.03 to 0.15 mm /rev Possible threads metric, inch, module and diametral pitch Metric thread pitches from 0.25 to 2.5 mm Length 1.2 m, height 1.3 m, depth 0.65 m Prices plus VAT Nlodpfx Aeihig Iea Esk Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: like new (used), Year of construction: 2021, functionality: fully functional, Weiler Praktikant VCD Precision Lathe Manufacturer: Weiler Model: Praktikant VCD Precision Lathe Year of manufacture: 2013 Condition: used, very good, as-new condition, no signs of wear, incl. new servicing and measurement protocol prior to sale Centre distance: 650 mm Centre height: 160 mm Swing diameter over bed: 320 mm Swing diameter over cross slide: 190 mm Cross slide travel: 150 mm Top slide travel: 110 mm Top slide swivel range: +/-65° Bed slide guide length: 350 mm Bed width: 205 mm Turning tool cross-section (height x width): 20 x 20 mm Height from top slide to centre: 30 mm Spindle nose according to ISO DIN 702-3 (DIN55027) size 5 Spindle diameter at front bearing: 70 mm Spindle bore: 43 mm Nljdpox I Rtkjfx Aa Ejk Main spindle taper metric 50 Drive power: 6 kW Speed range: 30 – 4000 rpm Number of gear stages: 1 Number of speed ranges: stepless Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Facing feed: 0.006 – 0.2 mm/rev Quill diameter: 40 mm Quill travel: 85 mm Quill taper: 3 Morse taper Weight, without packing and accessories, approx. 1150 kg Length / Width / Height, net: 1720 x 890 x 1700 mm Headstock / rear wall / sliding safety cover: Light grey RAL 7035 Machine base / machine bed: Basalt grey RAL 7012 Screen display housing: Blue NCSS 4550-R80B

Condition: excellent (used), turning diameter over bed 280 mm turning diameter over slide rest 160 mm turning length 500 mm centre height 140 mm centre distance 500 mm spindle bore 36 mm spindle turning speed range 15 - 3550 U/min spindle head DIN 55022 Gr. 5 feeds - longitudinal 0,008 - 0,560 mm/U feeds - cross 0,004 - 0,280 mm/U thread - mm pitch 0,2 - 12 mm Nlodpfjwm Rmuox Aa Eok dia. of leadscrew 24 mm lead of leadscrew 6 mm tailstock taper MT 3 tailstock quill stroke 90 mm tailstock adjustment out of the central pos. 15 mm total power requirement 2,2 kW weight of the machine ca. 0,6 t dimensions of machine L x W x H 1,40 x 0,70 x 1,20 m - machine out of teaching shop - Accessories: DRO on 3 axis, 4-jaw chuck RÖHM 140 mmø, MULTIFIX-head A,

Condition: good (used), Year of construction: 1988, 1 used lead and feed screw lathe Make: Weiler Model: 160 B Year of manufacture: 1988 Technical specifications Centre distance: 650 mm Swing over bed: 320 mm Swing over cross slide: 192 mm Centre height: 160 mm Spindle bore: 40 mm Rated power: 2.4 / 3 kW Spindle speeds: 48 – 2500 rpm Dimensions: approx. L 2.20 x W 1.10 x H 1.40 m Nledpfx Asw Sdr Hea Esk Weight: approx. 1 t Equipment Heidenhain digital readout Multifix toolholder with various inserts 3-jaw chuck Emergency stop

Condition: excellent (used), Year of construction: 2020, Fixed steady rest for WEILER E 50 lathe in very good condition. Clamping range : 10 -150 mm. Nlsdpfx Aotx Avkoa Eek

Condition: used, Year of construction: 2013, Lathe, used Manufacturer: WEILER Model: DA 210 AC x 1500 Year of manufacture: 2013 Swing diameter over bed: 435 mm Swing diameter over support: 245 mm Center distance: 1,500 mm Speed range: 20 - 2,000 rpm (2 ranges, infinitely variable) Spindle bore: 52 mm Equipment: - Infinitely variable speed control - HEIDENHAIN 3-axis digital readout - Multifix toolpost + 10 tool holders - 3-jaw chuck RÖHM DURO - 4-jaw chuck RÖHM - Collet chuck Fahrion + approx. 33 collets - Fixed and travelling steady rests - Various live/dead centers + drill chuck (see photos) Nljdpfx Aaox I S I No Ejk - Coolant system - Documentation The machine was used in-house by a manufacturer of automation technology for their own products. The machine has been tested for basic functions; everything worked except for the spindle brake.

Condition: good (used), Year of construction: 1994, functionality: fully functional, turning diameter: 410 mm, spindle bore: 54 mm, rotational speed (max.): 3,000 rpm, total height: 1,800 mm, total length: 2,200 mm, total width: 1,500 mm, workpiece weight (max.): 700 kg, overall weight: 2,100 kg, For sale is a Weiler E35 lathe. The machine is in good condition and fully operational. Nlsdpexu Ehgofx Aa Esk Technical data: Year of manufacture: 1994 Control: Siemens Sinumerik 805 Centre height: 200 mm Between centres: 950 mm Max. turning diameter over bed: 410 mm Max. turning diameter over cross slide: 200 mm Max. spindle speed: 3,000 rpm Tool changer: Multifix Spindle bore: 54 mm Max. workpiece weight: 700 kg Dimensions (approx.): 2,200 x 1,500 x 1,800 mm Weight (approx.): 2,100 kg Transport and loading can be organized Europe-wide for an additional charge, upon request. Prices are exclusive of VAT. Inspection possible by prior appointment. Please contact us – our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase / sales PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality but affordable metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website.

Condition: like new (used), Year of construction: 2021, functionality: fully functional, Weiler Praktikant VCD Precision Lathe (2021) Manufacturer: Weiler Model: Praktikant VCD Precision Lathe Year of manufacture: 2021 Condition: Used, excellent, like new, incl. new maintenance and measurement protocol prior to sale Centre distance: 650 mm Njdpfx Aaex Ivy Ne Eolk Centre height: 160 mm Swing over bed: 320 mm Swing over cross slide: 190 mm Cross slide travel: 150 mm Top slide travel: 110 mm Top slide swivel range: +/-65° Bed saddle guideway length: 350 mm Bed width: 205 mm Tool shank cross-section (H x W): 20 x 20 mm Height from top slide to turning centre: 30 mm Spindle head according to ISO DIN 702-3 (DIN55027) size 5 Spindle diameter in front bearing: 70 mm Spindle bore: 43 mm Main spindle taper metric 50 Drive power: 6 kW Speed range: 30 – 4,000 rpm Number of gear stages: 1 Number of speeds: stepless Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Facing feed: 0.006 – 0.2 mm/rev Quill diameter: 40 mm Quill stroke: 85 mm Quill taper: 3 Morse taper Weight, without packaging and accessories: approx. 1,150 kg Dimensions (L x W x H), net: 1,720 x 890 x 1,700 mm Headstock / Rear cover / Sliding guard: Light grey RAL 7035 Machine base / Machine bed: Basalt grey RAL 7012 Display housing: Blue NCSS 4550-R80B

Condition: good (used), Year of construction: 1988, Weiler lathe Type Condor B 2-axis digital readout Nlsdpfx Aevgmbvea Eek Center height 165 mm Center distance 750 mm Rotation over bed 330 mm Rotation over cross slide 185 mm Spindle bore 40 mm Connected load 3 kw Speed 22-2800 rpm Tailstock MK 3 Coolant pump (not connected) work light Automatic longitudinal and planar feed spindle brake - Folding jaw chuck guard - splash guard Weight approx. 1040 kg 3 jaw lathe chuck Multifix B Rotating center point

Condition: ready for operation (used), Year of construction: 1966, Immediately available from location: L & Z Lathe Weiler Year of manufacture approx. 1966 Centre height 140 mm Swing diameter 280 mm Over carriage 180 mm Nlsdpfx Aex Icidja Eok Turning length 800 mm Spindle bore 24 mm Spindle speeds up to 1600 rpm Drive power 2 kW Chuck diameter 140 mm Multifix tool holder with inserts Weight 1 ton Priced at EUR 1,500.— plus VAT ex location

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Weiler Praktikant 160 B Lead and Feed Screw Lathe with 3-Axis Digital Readout by K&C from Technical College Inventory Technical Data: - Year of manufacture: 1992, Machine No. 92 160 3273 - Center height: 160 mm - Center distance: 650 mm - Spindle speeds: from 24 to 2500 rpm - Spindle bore: 40 mm - Short taper spindle nose DIN 55027 size 5 with bayonet lock - Tailstock Morse taper 3 - Feeds from 0.02 to 0.63 mm/rev - Thread cutting options: metric, inch, module, and diametral pitch - Metric thread pitches from 0.25 to 8 mm - Weight approx. 680 kg - Spindle brake can be engaged - Length 1.6 m, height 1.25 m, depth 0.7 m Nsdpfx Aasx Eb D Ej Eslk Accessories and Features: - 3-axis DRO by K&C with operating manual Functions: mm/inch switching, coordinate selection ABS/INC, value halving, reference mark, tool programming for up to 200 tools, taper calculation, radius/diameter display, quick zeroing, counting direction reversal, - Collet chuck with NEW collets from 3 to 26 mm in 1 mm increments - 160 mm three-jaw chuck (with 1 set of jaws) - Quick-change tool post with 4 tool holders - Bed stop - Electronic spindle guard - Rear splash guard - Coolant system - Operating manual, spare parts diagram About the Machine: Offered is a Weiler Praktikant 160 B lead and feed screw lathe with toolroom accuracy, year 1992, in very good condition. The machine is, of course, fully functional. All carriage slides move very smoothly and evenly. The Weiler also runs quietly at high speeds. This newer generation of Weiler lathes is very user-friendly and allows for finishes similar to grinding. Take the opportunity to inspect this machine under power at our premises and see the condition for yourself. Immediately available.

Condition: used, Year of construction: 2000, used CONDOR AC, partially overhauled Centre height: 165 mm Between centres: 750 mm Spindle bore: 40 mm Spindle speeds: 22–2,800 rpm, infinitely variable - Quick-change tool post size B - WEILER DZ-V digital readout Nodpfxjx E Um Ne Aa Eolk - Hollow spindle stop - Fixed steady rest - 7 Multifix tool holders - Flat splash guard - Electrically interlocked chuck guard - Change gears and various soft jaws The machine is partially overhauled: - Bed slide: guideways re-coated and hand-scraped, gibs and lower guide strips adjusted - Cross slide measured and aligned on bed slide; cross slide dovetail guide newly scraped, gibs adjusted and scraped - Top slide newly scraped and gib matched - All measuring scales overhauled and cables replaced The machine is located in our showroom at 71334 Waiblingen-Beinstein and is immediately available. For details on equipment, please contact us.

Year of construction: 2005, operating hours: 20 h, condition: ready for operation (used), Control Unit Brand SIEMENS Main Drive Spindle speed range 1-4500 Spindle motor power 100% / 60% duty cycle: 7/9 kW Spindle bore 41 mm Tool taper Mk.5 Workpiece Workpiece drm over bed 330 mm Workpiece drm over support 160 mm Workpiece drm 160 mm Tail Stock Pinol diameter 50 mm Pinol way 130 mm Pinol tool taper Mk.3 Tools Type of tool holder Multifix Gr. B or Parat Gr. 2 This horizontal turning machine was completely retrofitted 2020. A Weiler C 30x750, it features a swing diameter over bed of 330mm and a spindle bore of 41mm. The main drive offers a power of 7/9 kW and a torque of 90Nm, with a speed range up to 4500 rpm. If you are looking to get high quality turning capabilities consider the Weiler C 30x750 machine we have for sale. Recently overhauled, it includes renewed bearings and guideways, ensuring high precision. Contact us for more information. Application Types Turning Nljdpfxjx D I Nfe Aa Esk

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Weiler Praktikant 160 B Lead and Feed Screw Lathe with 3-Axis Digital Readout by K&C from Vocational School Technical Data: >> Year of manufacture: 1992; Machine No. 92 160 3260 >> Centre height: 160 mm >> Centre distance: 650 mm >> Spindle speeds: from 24 to 2500 rpm Nlsdpox Eb A Usfx Aa Esk >> Spindle bore: 40 mm >> Short taper spindle nose DIN 55027 size 5 with bayonet lock >> Tailstock: Morse taper 3 >> Feeds: from 0.02 to 0.63 mm/rev >> Thread cutting: metric, inch, module, and diametral pitch threads possible >> Metric thread pitches from 0.25 to 8 mm >> Weight approx. 680 kg >> Spindle brake can be engaged >> Length 1.6 m, Height 1.25 m, Depth 0.7 m Accessories and Equipment: >> 3-axis digital readout by K&C with manual Features: switching mm/inch, coordinate mode selection ABS/INC, halving of display value, reference mark, 200-tool programming, taper calculation, radius/diameter, quick zeroing, counting direction reversal >> Collet chuck with NEW collets from 3 to 26 mm (in 1 mm increments) >> 160 mm 3-jaw chuck (Kelistangen) with 1 set of jaws >> Quick-change toolpost with 4 steel holders >> Bed stop >> Electronic spindle guard >> Rear panel >> Coolant system >> Operating manual, spare parts diagram About the machine: For sale is a Weiler Praktikant 160 B lead and feed screw lathe, toolroom accuracy, year 1992, in very good condition. The machine is of course fully functional. The carriages all run very smoothly and evenly. Even at high speeds, the Weiler runs quietly. This newer generation of Weiler lathes is very user-friendly and can produce surfaces with ground finish quality. Take the opportunity to inspect this machine under power on site and convince yourself of its condition.
