Used Spark Erosion Edm for sale (739)

Condition: like new (used), Year of construction: 2023, operating hours: 16 h, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 350 mm, workpiece weight (max.): 800 kg, total height: 2,410 mm, total width: 2,110 mm, total length: 2,334 mm, table width: 400 mm, type of input current: three-phase, distance table to quill: 310,660 mm, table length: 700 mm, workpiece length (max.): 850 mm, workpiece width (max.): 850 mm, workpiece height (max.): 380 mm, input voltage: 415 V, overall weight: 2,500 kg, table load: 800 kg, input frequency: 50 Hz, tank capacity: 450 l, Equipment: documentation/manual, 2023 Excetek ED400C CNC Die Sink EDM Machine Used 2023 Excetek ED400C CNC Die Sink EDM Machine for Sale – C-Axis – EROWA 4-Station Automatic Tool Changer – Spinflo Oil Cooler – Magnetic Chuck – ViTiny Digital Microscope Manufacturer: Excetek Model: ED400C Machine Type: CNC Die Sink EDM / Sinker EDM / Spark Erosion Machine Year: 2023 Condition: Excellent Machine Description Modern 2023 Excetek ED400C CNC Die Sink EDM machine available for sale with an excellent specification and useful additional tooling and accessories. The Excetek ED400C is a compact CNC spark erosion / sinker EDM designed for accurate machining of complex cavities, moulds, dies, precision components and difficult-to-machine conductive materials. This machine is particularly well equipped and includes a C-axis, EROWA tooling, 4-station automatic EROWA tool changer, 600 x 200mm magnetic chuck, Spinflo ECEA oil cooler and ViTiny digital microscope with display screen. Bdodpfx Aez E A Hxoa Ijh Main Machine Specification X-axis Travel: 400mm Y-axis Travel: 300mm Z-axis Travel: 350mm Worktable Size: 700 x 400mm Maximum Workpiece Size: 850 x 850 x 380mm Maximum Workpiece Weight: 800kg Maximum Electrode Weight: 120kg Electrode Head to Worktable Distance: 310–660mm Approx. Machine Dimensions: 2,334 x 2,110 x 2,410mm Machine Weight: Approx. 2,500kg Dielectric Oil Filtration System The ED400C is supplied with an integrated oil filtration arrangement. Oil filter tank capacity: Approx. 450 litres Paper filters: 3 A clean and stable dielectric oil system is important for maintaining consistent EDM performance, flushing efficiency and surface finish during spark erosion operations. Spinflo ECEA Oil Cooler The machine includes a Spinflo ECEA oil cooler / dielectric chiller. C-Axis The ED400C is equipped with a C-axis, allowing controlled rotary positioning of the electrode. EROWA 4-Station Automatic Tool Changer The machine is fitted with a 4-position automatic EROWA tool changer. This enables several electrodes to be loaded and automatically changed during a machining cycle, helping increase unattended machining capability and reducing operator intervention The machine also includes EROWA tooling, providing a recognised precision electrode holding and referencing system. 600 x 200mm Magnetic Chuck Included with the machine is a: 600 x 200mm magnetic chuck This provides an additional workholding option for suitable ferrous components and adds to the versatility of the machine for general precision EDM work. ViTiny Digital Microscope & Screen The machine also includes a ViTiny digital microscope with separate display screen. A digital microscope is particularly useful for close inspection of electrodes, fine features and machined surfaces and can assist with setup, inspection and process verification. Key Equipment Included Excetek ED400C CNC die-sink EDM C-axis EROWA tooling 4-station automatic EROWA tool changer Spinflo ECEA dielectric oil cooler 600 x 200mm magnetic chuck ViTiny digital microscope ViTiny display screen Integrated dielectric filtration system Approx. 450-litre oil tank 3 paper filters CNC control and EDM generator Please Note: All specifications, dimensions, capacities, accessories and machine details quoted above are approximate and are provided for guidance only.

Condition: used, Year of construction: 2011, Wire erosion / EDM Travel distance X: 370 mm Travel distance Y :270 mm Travel distance Z: 255 mm Bdodsz Eqk Sspfx Aa Ioh max. workpiece size X: 700 mm max. workpiece size Y: 600 mm max. workpiece size Z: 250 mm max. workpiece weight: 500 kg with AWF ( Automatic Wire Feeding ) U / V axis: 60 generator: 13 Ampere submerged cooling unit FANUC Series 31i-WA control Automatic wire threading Cutting in water bath Cooling unit Filtration system

Condition: used, Year of construction: 2008, Wire erosion / EDM Travel distance X: 600 mm Travel distance Y :400 mm Travel distance Z: 310 mm max. workpiece size X: 1050 mm max. workpiece size Y: 820 mm max. workpiece size Z: 300 mm max. workpiece weight: 1000 kg with AWF ( Automatic Wire Feeding ) U / V axis: 200 / 200 mm submerged cooling unit FANUC Series 310iS-WA5 control Automatic Wire Feeding (AWF) Additional precision rotary/indexing unit by Detlev Hofmann 6 axes according to the machine control Bjdpfxez D U H Ue Aa Iodh Chiller included Work area lighting Glass scales on X/Y axes Touch probe Work tank interlock and wire break detection Machine weight: approx. 3,000 kg Connected load: 13 kVA

Condition: used, Year of construction: 2011, Wire erosion / EDM Travel distance X: 700 mm Travel distance Y :450 mm Travel distance Z: 420 mm max. workpiece size X: 910 mm max. workpiece size Y: 660 mm max. workpiece size Z: 400 mm max. workpiece weight: 1200 kg table size X: 650 mm table size Y: 400 mm with AWF ( Automatic Wire Feeding ) U / V axis: +101 generator: 30 Ampere submerged cooling unit CNC wire EDM machine 5 CNC axes: X / Y / Z / U / V Automatic wire threading Dual Water Jet with Annealer Automatic wire break recovery 15" TFT touchscreen Linear glass scales in X / Y Dielectric chiller Automatic temperature control Max. table load: 1,200 kg Max. machining current: 30 A Programmable wire tension: 2–30 N Bdedpfx Aasz Aq Dvs Ish Standard wire spool: 16 kg Machine weight: approx. 6,000 kg

Condition: like new (used), Year of construction: 2024, operating hours: 18,000 h, functionality: fully functional, machine/vehicle number: 574525, travel distance X-axis: 420 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 400 mm, total length: 3,500 mm, total width: 2,100 mm, table load: 500 kg, Gantry Eagle 400 including MultiChange Light handling system, year of manufacture 2024. Serial No.: 574525 Serial No. handling system: 583328 Total weight approx. 6000 kg including handling system Commissioned: 04/2024 Accessories: MultiChange Light handling system, 70 electrodes and 8 pallets The machine is being sold on behalf of the owner. Attractive offer – flexible & worry-free We offer not only a high-quality product, but also tailor-made financing options that are adapted to your needs. Whether it's a down payment, installment payments, or individual financing models – together we will find the right solution. On request, we also take over the complete transport organization. From planning to reliable delivery, we ensure a smooth and timely process, so you don't have to worry about anything. Bodpfx Aasz Dazds Iodh 📞 Please contact us for further information or a non-binding offer. We will advise you personally and competently. Subject to prior sale, changes and errors!

Condition: refurbished (used), Year of construction: 2002, functionality: fully functional, Control: Multipulse 64 4 axes – including C-axis Working area: 600 x 500 x 340 mm Head travel: 400 x 300 x 300 mm Table load capacity: 500 kg 20-position electrode changer Erowa electrode clamping system Documentation. The machine is currently still in operation and was completely overhauled a few years ago. Bsdpfsyllaxox Aa Iodh The machine's dielectric cooler is supplied by the central cooling system.

Condition: used, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 400 mm, workpiece weight (max.): 4,000 kg, table width: 700 mm, table length: 1,100 mm, Capacity: 120 Amp. – 19 kVA X-travel: 800 mm Bodpfx Aoyg Hpdea Ijdh Y-travel: 600 mm Z-travel: 400 mm Table size: 1.100 x 700 mm Distance Head to table: 950 mm (max) Oil tank: 1.700 x 1.000 x 650 mm Weight of workpiece: 4.000 kg (Max) Controller: CNC Datic S120

Condition: good (used), Year of construction: 2009, functionality: fully functional, Table size: 600 x 400 mm Maximum workpiece size: 900 x 600 x 330 mm Maximum workpiece weight: 750 kg X-axis travel: 400 mm Y-axis travel: 300 mm Z-axis travel: 300 mm Generator output: 60 A Machine dimensions: 2190 x 1880 x 2360 mm Machine weight: 2800 kg Accessories: - Magnetic table and EROWA clamping system - Machine manual and operating instructions Bdodpsyity Uefx Aa Ish The machine is in very good condition and comes from a small family business that recently closed down.

Condition: used, TECHNICAL DETAILS - Travels on X/Y/Z axes : 400 x 300 x 350 [mm] - Rapid traverses rates (X/Y/Z) : 6 / 6 / 15 [m/min] - Min./max. distance between table and chuck : 170 / 520 [mm] - Max. part dimensions : 820 x 580 x 250 [mm] - Max. part weight : 800 [kg] - Max. electrode weight : 50 [kg] - C axis : 0 - 100 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 9.1 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 4.700 x 2.750 [mm] - Machine height : 2.680 [mm] - Machine weight : 3.830 [kg] - Number of working hours : 13659 [h] EQUIPMENT - CNC : AGIEVISION 5 - Spindle nose : System 3R Bjdpfjzlk E Sjx Aa Isdh - Dielectric capacity : 600 [l]

Condition: ready for operation (used), Two identical machines are available. Connected load: 32kW, length: 3500mm, width: 2400mm, height: 2400mm, weight: 3t. On-site inspection is possible. Bdjdpfx Aouyk Rlsa Ioh

Year of construction: 2004, condition: ready for operation (used), Travel X/Y/Z: 620mm/420mm/400mm, C-axis: 360°, workpiece clamping plate X/Y: 1000mm/600mm, working tank dimensions X/Y: 1070mm/670mm, max. liquid height: 400mm, max. table load: 1500kg, max. electrode weight: 50kg/250kg, pulse generator: EroForm 60A, filling volume: approx. 1200l, tool changer: disc changer, tool positions: 20. Machine dimensions X/Y/Z: approx. 2450mm/2550mm/2450mm, weight: approx. 4500kg, control: EXMF 10, generator hours: approx. 19300h. Documentation available. An on site inspection is possible. Bdedpfx Aaoxwywus Ieh

Condition: used, TECHNICAL DETAILS - Travels on X/Y/Z axes : 400 x 300 x 350 [mm] - Rapid traverses rates (X/Y/Z) : 6 / 6 / 15 [m/min] - Min./max. distance between table and chuck : 170 / 520 [mm] - Max. part dimensions : 820 x 580 x 250 [mm] - Max. part weight : 800 [kg] - Max. electrode weight : 50 [kg] - C axis : 0 - 100 [rpm] POWER SUPPLY - Supply voltage : 400 [V] Bedpfx Aaewl Rh Nj Iodh - Total installed power : 9.1 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 4.700 x 2.750 [mm] - Machine height : 2.680 [mm] - Machine weight : 3.830 [kg] - Number of working hours : 13659 [h] EQUIPMENT - CNC : AGIEVISION 5 - Workpiece loading / unloading robot - Spindle nose : EROWA - Dielectric capacity : 600 [l]

Condition: excellent (used), Table 600 x 450 mm Work piece 650 x 580 x 250 mm Work piece weight max. 400 kg C-axis spindle speeds 60 rpm With pallets changer With tool changer Working head for 3 dimensional operation Bdodpfjzi Nnmsx Aa Ijh Misc. accessories MARCELS MASCHINEN AG

Condition: used, TECHNICAL DETAILS - Strokes X x Y x Z : 350 x 250 x 350 [mm] - Max. part dimensions : 650 x 580 x 250 [mm] - Max. part weight : 400 [kg] - Machining intensity : 72 [A] - Tools magazine capacity : 28 - Dielectric volume : 415 [l] - Machine floor space : 2.689 x 1.855 [mm] - Machine height : 2.593 [mm] - Machine weight : 3.000 [kg] - Welding hours : 39.554 [h] Bjdpfx Aeuhcbija Iedh EQUIPMENT - CNC AGIEVISION with color screen LCD : 10,4 ['] - Deported electronic crank-handle - Axis C - Spindle chuck : EROWA - Automatic retractable tank - Integrated filtration : DAI 2

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 930088, Country of manufacture: CH Voltage: 400V / 50/60Hz / 3ph. Net weight (machine + control cabinet): 3,250 kg + 400 kg Bedpfx Aasw Ucyuo Ijdh Customs tariff number: 8456.30 20 Dimensions: 260 x 281 x 225 cm TECHNICAL SPECIFICATIONS Machining type: immersion Maximum workpiece dimensions: 1200 x 700 x 400 mm Maximum workpiece weight: 1,500 kg Table size: 900 x 600 mm Floor to table distance: 900 mm Total dielectric volume: 1,200 L Axes X, Y, Z, U and V Travel on X, Y, Z axes: 550 x 350 x 400 mm Travel on U, V axes: 550 x 350 mm Anti-collision protection: X, Y, Z, U, and V axes Taper cutting, max. taper: +/- 30° / 400 mm Available wire diameters: Ø 0.25 mm (options: 0.1/0.2/0.3 mm) Wire guide type: closed diamond, gapless Available spool weights and types (DIN standard): 1.6 kg (K 100) to 8 kg (K 160) Available spool weights and types (JIS standard): 3 kg (P3) to 5 kg (P5) Dielectric Paper filters: 2 cartridges Dielectric temperature: +/- 1°C Total deionization resin volume: 20 L Maximum injection pressure: 20 bar Generator: dual Isopulse source Power supply: 380/400V 3-phase Total power: 10 KVA Maximum cutting speed: 400 mm²/min Minimum surface roughness: 0.20 micron Ra Measuring system: glass linear scales Measurement resolution: 0.5 micron Servo motors: AC type Unless otherwise stated, technical specifications are provided without commitment and subject to error or omission.

Condition: used, Year of construction: 2006, Wire erosion / EDM Travel distance X: 300 mm Travel distance Y :200 mm Travel distance Z: 200 mm max. workpiece size X: 500 mm max. workpiece size Y: 300 mm max. workpiece size Z: 200 mm max. workpiece weight: 300 kg table size X: 536 mm table size Y: 337 mm with AWF ( Automatic Wire Feeding ) U / V axis: 80x80 generator: 60 Ampere Bdjdjy Uvpdjpfx Aa Ieh submerged Control: Sodick LN1W Taper Cutting Capacity: ±20° / 80 mm Wire Diameter: 0.15–0.30 mm

Condition: used, Year of construction: 2006, Wire erosion / EDM Travel distance X: 500 mm Bodsw S Egfjpfx Aa Ijdh Travel distance Y :350 mm Travel distance Z: 300 mm max. workpiece size X: 1050 mm max. workpiece size Y: 800 mm max. workpiece size Z: 295 mm max. workpiece weight: 1500 kg table size X: 780 mm table size Y: 630 mm with AWF ( Automatic Wire Feeding ) U / V axis: 42 mm generator: 50 Ampere submerged

Condition: used, Year of construction: 2002, Wire erosion / EDM Bsdpfsw Ei Stox Aa Iedh Travel distance X: 750 mm Travel distance Y :500 mm Travel distance Z: 400 mm max. workpiece size X: 1050 mm max. workpiece size Y: 750 mm max. workpiece size Z: 400 mm max. workpiece weight: 1500 kg U / V axis: 770 x 520 mm generator: 60 Ampere Linear drives

Condition: used, Year of construction: 2003, Wire erosion / EDM Bdodpow Ekr Ijfx Aa Ijh Travel distance X: 350 mm Travel distance Y :250 mm Travel distance Z: 256 mm max. workpiece size X: 750 mm max. workpiece size Y: 550 mm max. workpiece size Z: 250 mm max. workpiece weight: 450 kg with AWF ( Automatic Wire Feeding )

Condition: used, Year of construction: 2004, Wire erosion / EDM Bdsdpjwf I Imofx Aa Ish Travel distance X: 350 mm Travel distance Y :250 mm Travel distance Z: 256 mm max. workpiece size X: 750 mm max. workpiece size Y: 550 mm max. workpiece size Z: 250 mm max. workpiece weight: 200 kg submerged cooling unit The machine has been serviced annually by the manufacturer.

Condition: good (used), ONA Poli Spark die-sinking EDM machine Type: IN 260 S2000-60A Bed: 410 x 645 mm Bdsdpeq Eh Skofx Aa Ijh Documentation included Machine dimensions: 160x130x215 cm LxWxH Cabinet dimensions: 130x95x210 cm LxWxH Cabinet dimensions: 60x70x170 cm LxWxH

Condition: used, Mitsubishi Wire EDM Machine, Spark Erosion Machine, Mitsubishi DWC 150 SZ, Used Machine Manufacturer: Mitsubishi Type: DWC 150 SZ Year of Manufacture: 1994 Overall Dimensions (Main Unit): Width: 1860 mm Depth: 2050 mm Height: 2400 mm Electrical Data: 400V; 21.5A Weight: 3500 kg Water Tank Size: 750 x 780 mm Electrical Cabinet Dimensions: Width: 1150 mm Depth: 2700 mm Height: 1050 mm Wire Feeder Unit Dimensions: Width: 320 mm Depth: 580 mm Height: 1380 mm Transformer Dimensions: Width: 510 mm Depth: 590 mm Bdedpjyxfqrofx Aa Ish Height: 640 mm Water Treatment System Dimensions: Width: 1320 mm Depth: 1460 mm Height: 1360 mm Condition: Untested, sold in "as-is" condition. The machine is available for sale with the accessories and in the aesthetic condition shown in the photos.

Condition: like new (used), Year of construction: 2003, TECHNICAL SPECIFICATIONS X axis travel: 1,500 mm Y axis travel: 750 mm Z axis travel: 500 mm Worktable height: 820 mm Open height (clearance): 920 mm Maximum workpiece weight: 100,000 N Maximum load on head: 4,000 N Tank type: Fixed Tank dimensions: 2,300 x 1,300 x 700 mm Worktable size: 1,700 x 1,000 mm Usable dielectric height: 620 mm GENERATOR Standard minimum surface finish: VDI = 0 Power: 60 A MACHINE EQUIPPED WITH Generator with 120 A Expert System Fixed worktable 1,700 x 1,000 mm Bdsdpfxoxwma Ae Aa Ioh CNC for simultaneous axis control Integrated ONA C-axis with automatic System 3R Macro Standard chuck Eco-friendly filter with automatic cleaning cycle Dielectric temperature control system Year of manufacture: 2003 MACHINE FEATURES Fixed-table structure ensuring stable operating conditions, equipped with leveling supports Stabilized grey cast iron structure (base, column, tables) X-Y-Z movements via high-precision class A ball screws, driven by three DC motors Motion on prismatic roller guideways Position detection via linear glass scales Improved front accessibility with retractable front door system Fixed working tank Integrated C-Axis (mounted on the head) Maximum speed: 40 rpm Resolution: 0.001° Maximum load (static C-axis): 500 N Maximum load (dynamic C-axis): 120 N Heidenhain encoder Toothed belt transmission Maximum current without rotation: 120 A Maximum current with high-speed rotation: 60 A Maximum current with slow rotation (0–1 rpm): 12 A Moment of inertia: 2,000 kg/cm³ GENERATOR FEATURES Modular design Programmable parameters Maximum power: 60 A EXPERT SYSTEM Controls the entire erosion cycle, from roughing to final surface finish, automatically adjusting spark parameters to ensure maximum generator efficiency and highest machining speed. Dedicated software for deep ribs Dedicated software for finishing large homogeneous surfaces Fully unattended machining capability with maximum productivity and excellent final quality Process parameter monitoring via screen and control panel display Automatic anti-collision system preventing electrode damage in case of accidental contact with the workpiece TECHNICAL DATA Pulse duration (Ton): continuously adjustable from 1 to 6,500 microseconds Pulse interval (Toff): continuously adjustable from 1 to 6,500 microseconds Copper electrode volumetric wear: 0.2% Graphite electrode volumetric wear: 0.1% Surface finish Ra (CLA): 0.1 micron – VDI = 0 Maximum material removal rate: 600 mm³/min Power consumption: 10.7 kVA Current intensity: adjustable from 1 to 12 (manually or via program) Highly sensitive servo control system High erosion stability

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 525 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, workpiece weight (max.): 1,000 kg, workpiece height (max.): 375 mm, General overhauled OPS Ingersoll Gantry 500 Wire EDM machine – in top technical and optical condition. The machine has been comprehensively and professionally overhauled in our workshop and is in very good condition both technically and visually. Bjdjyrqpfspfx Aa Ijdh During the overhaul, the machine was disassembled by over 70%. All relevant wear parts were carefully inspected and replaced if necessary, including ball bearings and drive spindles. Subsequently, a complete geometric measurement, alignment, and additional check using a laser measuring system were performed. The machine bed and the entire base were thoroughly cleaned. All pumps were disassembled, cleaned, and overhauled. All hoses, including hydraulic and compressed air hoses, were completely replaced. In addition, the machine was completely repainted and is now in very good cosmetic condition. The generator and control unit were cleaned and technically inspected. The air conditioning unit of the generator was also cleaned to ensure reliable cooling and stable operation. Finally, the machine was subjected to an extensive erosion test according to the quality and testing specifications of OPS Ingersoll. The machine is immediately ready for operation and is ideal for reliable production. Technical data: Ingersoll (OPS Ingersoll) Wire EDM machine OPS INGERSOLL GANTRY EAGLE 500 Year of manufacture 2009 Control system EAGLE Powertec PC/NC 2060 MultiProg Powertec technology programming on PC/NC Powertec Easy Burn quick programming Powertec Handheld - multifunctional handheld device Manual erosion with Powertec Handheld High-speed jump max. 18 m/min Generator output 60 amps, EAGLE Powertec Travel ranges (X, Y, Z) 525 x 400 x 450 mm Electrode changer 20-position pick-up disc changer Work tank (W x D x H) 770 x 670 x 440 mm Work table (W x D) 750 x 650 mm Load capacity 1,000 kg Accessories: CO2 fire extinguishing system Integrated cartridge filter system Special equipment: Linear measuring system in all axes (Z as standard) 30.09

Condition: used, Year of construction: 1989, functionality: fully functional, workpiece weight (max.): 13,000 kg, PARALLEL LATHE used, 500x5000mm, TIANSHUI SPARK mod. CW61100E, year '89: Center height mm 500, Bodpfjzg Tz Sex Aa Iodh Max turning diameter on bed mm 1000, Max turning diameter on carriage mm 680, Distance between centers mm 5000, Bar passage mm 140, Spindle nose attachment: ASA 11, Spindle speed: 5 - 400, Spindle power: 36 Kw, Overall dimensions mm (LxWxH) 7100x2500x1700, Machine includes: 4-jaw independent self-centering chuck mm 1000, Fixed steady rest, Fixed steady rest mm 460, Traveling steady rest mm 220, Tailstock with Metric 80 taper, Tool turret type: rotary, fixed, Coolant system.
