Used Harding Cnc Lathe for sale (12,830)

Condition: used, turning diameter max. 360 mm turning length 505 mm control Mazatrol SmoothC max. swing diameter over bed 660 mm swing diameter over slide guides max 255 mm bar material dia. max. 80 mm turning speed range - spindle 35 - 4000 U/min max. torque on the spindle 358 Nm x-axis 225 mm rapid traverse X-axis 30 m/min z-axis 605 mm rapid traverse Z-axis 33 m/min spindle nose A2-8'' spindle bore 91 mm spindle hollow 80 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40%ED) kW tailstock quill taper MT 5 Travel- tailstock 565 mm Axial pressure max 5000 Nm Tool turret 1 Numbers of tools 12 (angetrieben) turning tool - shaft cross cut 25 x 25 mm tool taper BMT Required air-pressure 5 / 160 bar / l/min voltage 400 V coolant tank 180 l engine output 18,5 (30min Betrieb) kW Rated power (100% continuous operation) 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 3,6 x 2 x 1,8 m Machine incl. the following special accessories: Chip conveyor on the right side Productivity package C - special according to storage machine This package includes: High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min Preparation for chip conveyor (lateral) Automatic tool eye STANDARD ACCESSORIES Transformer for the European market Use of linear systems with guide carriage SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB memory interface (1 slot) Spindle bore 91 mm Set of manuals in electronic form on CD Mazak standard colour CE marking, metric, 50 Hz C-axis input accuracy 0.0001° NC controlled tailstock Tailstock pressure adjustment Tailstock with fixed quill MK5 SAFETY DEVICES Operator door with interlock switch Double foot switch Hydraulic pressure lock Fully enclosed work area Work area lighting Safety precautions according to global standard COOLANT SUPPLY Grundfos coolant pump type MTA (0.25kW / 7.6L/min) Complete coolant system Automatic switch-off via circuit breaker triggering MESSSYSTEM Absolute positioning system Gedpfx Abev Dxw Ro Isip NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothC 10.4’ colour screen User macro (600 variables) EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN Various tool holders - All dimensions, weights and performance data are non-binding - Used machine without warranty -

Condition: used, Year of construction: 2022, turning diameter 276 mm turning length 500 mm control Mazatrol Smooth G max. swing diameter over bed 695 mm Distance spindle end - turret 710 mm bar material dia. max. 65 mm turning speed range - spindle 35 - 5000 U/min max. torque on the spindle 465 Nm x-axis 234 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 21 m/min z-axis 625 mm rapid traverse Z-axis 33 m/min spindle nose A2-6 spindle passage 76 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW tailstock quill taper MT 5 Travel- tailstock 550 mm Tool turret 1 Numbers of tools 12 (angetrieben) tool taper VDI 30 min rated capacity 42,6 kVA Required air-pressure 0,5 / 330 MPa / l/min distance spindle /table 710 mm total power requirement 37 kW weight of the machine ca. 5,7 t dimensions of the machine ca. 2,8 x 2 x 1,9 m With the following special accessories: - Mayfran chip conveyor, side ejector, hinged belt conveyor - Engraving function ACCESSORIES / MACHINE OPTIONS Automatic on/off switch and warm-up function A warm-up is necessary to avoid problems such as abnormal wear of the sliding surfaces and sluggish movement. A sufficient warm-up provides the machine with the heat resistance it needs to machine workpieces with consistent, high precision. Transformer for the European market 8" chuck for main spindle with enlarged passage USB connection (1 connection) Mazak standard colour Main spindle motor AC 26 kW Tool turret with 12 stations VDI, also for driven tools in every position. For maximum performance, only the cutting tool is driven. Programmable tailstock (MK5) Tailstock quill (MK5) Y-axis control SAFETY DEVICES Operator door with lock switch Double foot switch Opening and closing of the chuck by means of a separate switch. Hydraulic pressure lock Fully enclosed work area Work area lighting COOLANT SUPPLY High-performance coolant system (520W) Flow rate max. 11.5 l/min. Complete coolant system CHUCK, ETC. Automatic opening/closing of chuck jaws 8" power chuck with enlarged passage (main spindle) Kitagawa BB208 Gisdpfxjynbd So Ab Ijp MEASURING SYSTEM Automatic Tool Eye NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothG control 19" LCD colour screen (touch screen) User macro (shared variables: 600 pairs) Mazak tapping/drilling cycle Tornado in EIA/ISO. (Only possible on machines with Y-axis. EIA/ISO package EIA/ISO input function EIA/ISO additional functions - Helical interpolation - 3D tool correction - Workpiece coordinate rotation - Geometric function - Scaling - External data input/output Thread cutting function (G33) Reverse time feed G93 G37 Tool length measurement Polar coordinate input (EIA) Optional stop (optional stop) Additional workpiece coordinate systems 300 pieces User macro (600 variables) Mazak thread tapping/drilling cycle Tornado in EIA/ISO. EIA/ISO drilling cycles (arc, grid, circle, circular arc, line) Machining on inclined surfaces EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Interface for LAN SD memory card I/F Smooth standard software for lathes (milling) MAZACC 2D software Workpiece shape compensation Rapid traverse paths Rounding function - Seamless co...

Condition: used, Year of construction: 2020, turning diameter 380 mm turning length 511 mm control Mazatrol SmoothG turning diameter over slide 276 mm max. swing diameter over bed 675 mm Standard machining diameter 276 mm bar material dia. 65 mm x-axis 234 mm rapid traverse X-axis 30 m/min z-axis 625 mm rapid traverse Z-axis 33 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 Gijdpfx Abstugggo Iep spindle bore 76 mm Motor output (40%ED) 26 KW 22 KW Max. Torque 465 Nm turning speeds 6000 U/min Main drive power 11 KW Max. Torque 90 Nm Milling spindle speeds ( driven tools) 35-6000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20x2,5 Switching time one turret station ca. 0,20 sec coolant tank 180 l connected load 46,2 kW weight of the machine ca. 5,9 t dimensions of the machine ca. 2,7 x 1,9 x 1,9 m incl. the following accessories: - Signal light (3-colour LED), rectangular - High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min, pressure (at pump) 5 bar. - Additional coolant nozzle main spindle - Preparation for oil mist extraction electrical/mechanical flange 98mm - Preparation for bar feed - Robot interface (Advance/Profibus) - Chip conveyor with low ejection height - Overload monitoring system - Drilling cycle with torque-dependent chip breaking - Preliminary use of a hollow clamping cylinder on counter spindle - Hollow clamping device incl. draw tube + cylinder - Clamping chuck Hainbuch Spanntop Nova Axfix mini size 52 - Chuck Hainbuch Spanntop Nova Axfix special mini size 52 - 2 x collets - Changing device for collet chuck STANDARD ACCESSORIES Automatic on/off and warm-up function Air blowing device on the chuck on the counter spindle Use of linear systems with guide carriage USB connection (1 connection) Set of manuals in electronic form on CD C-axis main spindle Input accuracy 0.0001° Spindle positioning counter spindle without C-axis Input accuracy 0.001° Tool turret with 12 stations VDI, Operator door with locking switch Double foot switch for both main and counter spindle Hydraulic pressure interlock Fully enclosed work area Work area lighting Safety precautions in accordance with global standards High-performance coolant system (520W) Flow rate max. 11.5 l/min. Complete coolant system Automatic opening/closing of the chuck jaws Automatic tool eye Absolute positioning system Preparation for chip conveyor (lateral) Synchronisation of main and counter spindle Synchronised tapping with milling spindle Relocation Detector Mazatrol SmoothG control 19" LCD colour screen (touch screen) User macro (600 variables) EIA/ISO input function Optional stop (optional stop) Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN SD memory card I/F - Second-hand machine without warranty - All dimensions, weights and performance specifications are non-binding

Condition: used, turning diameter 340 mm turning length 575 mm control Mazatrol SmoothEZ max. swing diameter over bed 695 mm Standard machining diameter 235 mm bar material dia. max. 65 mm x-axis 215 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 10 m/min z-axis 605 mm rapid traverse Z-axis 30 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 spindle bore 76 mm Motor output (40%ED) 15 KW 11 KW Max. Torque 167 Nm turning speeds 35 - 6000 U/min spindle nose A2-5 Motor output (40%ED) ca. 7,5 KW Power (continuous operation) 5,5 KW Max. Torque 53 Nm Milling spindle speeds ( driven tools) 20 - 4500 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20 coolant tank 225 l Chuck diameter main spindle 8 '' Chuck diameter counter spindle 6 '' w-axis 585 mm rapid travel W 30 m/min c-axis 555 weight of the machine ca. 4,9 t dimensions of the machine ca. 2,8 x 2 x 1,8 m Special accessories: - Chip conveyor, hinged belt, side ejector - Production package, this package includes Preparation for bar feed Automatic parts catcher (Ø:80mm x L:120mm x 2.5 kg) 15 bar high-pressure coolant system Preparation for chip conveyor (lateral) Signal light (3-colour LED), rectangular C-axis counter spindle 0.0001° Automatic tool eye 8" power chuck Kitag. BR08 & Cyl. SR1566C (HD1) GENERAL MACHINE OPTIONS Air blowing device on the chuck (counter spindle) Transformer for the European market Linear roller guides SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB - Memory Interface (1 slot) CE marking CE marking, metric, 50 Hz Counter spindle positioning 0.0001 degrees without C-axis Tool turret with 12 stations Y-axis control ADDITIONAL PROCESS SOFTWARE Smooth restart function / restart mode Set of manuals in electronic form on CD Main spindle motor AC 15 kW (20 hp) 2nd spindle motor AC 7.5kW (20 hp) Main spindle motor AC 7.5kW MAIN SPINDLE C-axis main spindle Input accuracy (contour/index) 0.0001° Mazak standard colour (F white(fine)/S black) Automatic switch-off via circuit breaker trip Double foot switch Hydraulic pressure interlock RFID door interlock Safety foot switch with locking mechanism Safety measures according to worldwide standard Work area lighting Complete coolant system Automatic opening/closing of chuck jaws (main and counter spindle) Feedback of the chuck status (main and counter spindle) Feedback of the chuck status via sensors. 8" power chuck 6" power chuck (counter spindle) Absolute positioning system Synchronous tapping with milling spindle Relocation Detector NC control Mazatrol SmoothEz 15" colour Lcd (touch screen) User macro (common variables: 600 pairs) EIA/ISO package EIA/ISO - input function EIA/ISO - additional functions Bolt line interpolation 3D tool compensation Workpiece coordinate rotation Geometric function Gjdpswngklefx Ab Ieip Scaling External data input/output Tapping function (G33) Reverse feed rate G93 G37 Tool length measurement Polar coordinate input (EIA) Optional stop Additional workpiece coordinate systems 300 pieces User macro (600 variables) Mazak tapping/drilling cycle EIA/ISO - input function Scaling External data input/output Thr...

Condition: used, Year of construction: 2012, turning diameter 203 mm turning length 300 mm control Mazatrol Smart Distance spindle end - turret 99-434 mm max. turning diameter 280 mm bar material dia. 51 mm travel -x axis 200 mm travel -z axis 340 mm spindle turning speed range 35 - 6000 U/min rapid traverse X-axis 33 m/min rapid traverse Z-axis 36 m/min spindle bore 61 mm Tool turret 12 -fach turning tool - shaft cross cut 20 Boring bar- Ø 32 mm workpiece weight 150 kg spindle nose A2-5 taper in tailstock-quill MK4 Gsdeynbd Eopfx Ab Ieip Travel- tailstock 350 mm total power requirement 16,3 kW weight of the machine ca. 3,5 t dimensions of the machine ca. 1,9 x 1,6 x 1,8 m Special accessories: Autom Tool Eye Spindle orientation Signal light Additional coolant nozzles above the chuck Automatic switch-off Interface for bar feed Automatic parts catcher Ø 51 x L:100 x 2.5 kg Workpiece conveyor for automatic parts catcher with workpiece tray Chip conveyor, side ejection Includes: Automatic short bar loading magazine LNS QUICK LOAD SERVO 80_S2 Diameter range: 6 - 80 mm round and hexagonal material Bar lengths: 350 - 1600 mm, however max. headstock length /UVV Weight max. 67 kg / bar Burr-free bars or bar sections Depth 600 mm for holding bars Input voltages from 200 – 460 volts / operating voltage 24 V DC, LNS control programmed on SIEMENS STEP 7 PLC, flexible control panel with large screen, user guidance via symbols for easy operation and adjustment. Device cover with 2 viewing windows made of Plexiglas.

Condition: like new (used), Year of construction: 1999, functionality: fully functional, MORI SEIKI SL-600B/2000 CNC LATHE Category: CNC Turning Centers Reference No.: 400212 Capacity: Ø900 X 2000 MM Year of Construction: 1999 Technical Specification: CNC Control : Fanuc 18iT WORKING CAPACITY Max Turning Diameter : 900 mm Max Turning Length : 2000 mm Swing over bed : 994 mm Distance Between Centers : 2300 mm Swing over cross slide : 733 mm Travels (X) : 485 mm (440 + 45) mm Travels (Z) : 2150 mm TURRET Turret : 12 Station Square tool shank size : 32 mm Boring bar shank diameter : 65 mm TAILSTOCK Tailstock : MT5 Tailstock Quill Travel : 150 mm Tailstock Quill Dia : 150 mm SPINDLE Max Rotation Speed : 1500 RPM Main Spindle Nose : JIS A2-15 Main Spindle Bore : 185 mm Spindle Type : 3 Step Gearbox Spindle bearing inner diameter : 260 mm MACHINE DIMENSIONS Weight : 16T Additional Details: Gedpjx Nv Shsfx Ab Ieip All Specifications are found online, and subject to verification by buyer.

Condition: used, Year of construction: 2003, functionality: fully functional, machine/vehicle number: 06800001511, Used: CNC vertical lathe Manufacturer: DMG/ GILDEMEISTER Model: CTV250 Year of manufacture: 2003 Serial number: 06800001511 Giodpfxowzk D As Ab Iop

Condition: excellent (used), Year of construction: 2018, operating hours: 21,000 h, functionality: fully functional, machine/vehicle number: S4E184001, turning diameter over cross slide: 430 mm, turning length: 670 mm, turning diameter: 220 mm, spindle bore: 45 mm, spindle speed (max.): 6,300 rpm, overall weight: 4,300 kg, Used CNC hard turning lathe with counter spindle Manufacturer: EMCO Model: Emcoturn 45E Year of manufacture: 2018 Few operating hours Control: Siemens 828D Number of tools: 12 driven units Godpow Rrvwjfx Ab Ijip Max. speed: 0-6000 rpm

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 1114.3705-24, Used CNC Lathe Make: Boehringer Type: VDF 250Cm Year of Manufacture: 1997 VDF Boehringer 250C The machine has the following features: 1000mm turning length No tailstock Driven tools Special indexing chuck Siemens 840C control system The Boehringer VDF 250Cm is a CNC lathe designed for machining chucked parts. It is characterized by its robust construction and precise machining capabilities. Technical Specifications (Model Year 1997) Working Area: Swing over Bed: 550 mm Swing over Cross Slide: 480 mm X-Axis Travel: 405 mm Z-Axis Travel: 1,099 mm Maximum Turning Length: 1,000 mm (None) Tailstock: Tool Turret: Number of Positions: 12 Tool Holder: VDI 50 DIN 69880 Live Tools: YES Gijdpfswlap Asx Ab Ijp Spindle: Spindle Head Size: 8 DIN 55026 Spindle Bore: 103 mm Max. Chuck Diameter: 315 mm Max. Drive Power (50% Duty Cycle): 53 kW Max. Torque: 780 Nm Speed Range: 30–3,000 rpm Feeds: Automatic Feeds: 1–10,000 mm/min Rapid traverse speed: 10 m/min (X and Z axes) Max. feed force: 15 kN Dimensions and weight: Machine dimensions (L × W × H): approx. 5,400 × 3,200 × 2,400 mm Machine weight: approx. 11,000 kg Equipment: Pivoting control panel Hydraulic system from HYDROKRAFT Coolant system with 600 l tank, max. pump pressure 5.5 bar, flow rate 60 l/min, pump power 1.1 kW Chip conveyor with 325 l tank capacity, right-hand discharge 3-jaw power chuck Oil mist extraction Control cabinet with cooling unit and temperature controller from RITTAL Control system: SIEMENS SINUMERIK 840 C Variants and Differences There are various variants of the VDF 250 series, such as the VDF 250 CU, which can be equipped with different control systems (e.g., PHILIPS B2T) and technical specifications. Some models feature driven tools and a tailstock, while others are designed as pure chuck-type lathes without a tailstock. Conclusion The Boehringer VDF 250 Cm is a versatile CNC lathe characterized by its stability and precision. With its robust construction and extensive features, it is ideally suited for machining chucked parts in a variety of production environments.

Condition: excellent (used), Year of construction: 2007, Fagor CNC lathe Gedpfoym Ef Rex Ab Ieip Full specifications available in photos Machine in excellent condition

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Gjdpfx Aeyrpyveb Ijip Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: excellent (used), Year of construction: 2014, turning length: 700 mm, travel distance X-axis: 205 mm, travel distance Z-axis: 700 mm, spindle motor power: 22,000 W, total height: 2,800 mm, total length: 6,000 mm, total width: 3,900 mm, overall weight: 9,800 kg, Complete machining with twin spindel, upper and lower turrets Kitagawa 3 chuck left and right Tool holders with driven tools axial and radial Large jaws cabinet with inserts OGL Gantry loader with ca 10 Kg load capacity Chip conveyor Paper Filtration Pressure Tank Max. turning Ø: 400mm X-Axis: 205mm Z-Axis: 700mm Spindle bore: 62mm Speedrange: 6000Rpm Spindle power: 22kW Subspindle speeds: 6000Rpm Subspindle bore: 62mm Subspindle power: 15kW ATC / revolver: 16 Speed live tools: 6000Rpm Positions lower revolver:16 Gedpoyn Em Rjfx Ab Ieip Speed live tools: 6000Rpm Power live tools: 7kW Chip conveyor: yes Tool eye: yes Length: 6000mm Width: 3900mm Height: 2800mm Weight: 9800kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: not inspected (used), Year of construction: 2002, turning diameter over cross slide: 340 mm, turning length: 2,000 mm, turning diameter: 570 mm, spindle speed (max.): 2,500 rpm, overall weight: 5,000 kg, Fagor 8055 Spindle bore 108 mm Capacity 2000 x 570 mm Steady rest Gjdpjx E Au Iofx Ab Ieip

Condition: used, Year of construction: 2006, functionality: fully functional, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Equipment Gisdeyuflgepfx Ab Iep SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600 4 driven axial tool holders 2 driven radial tool holders

Condition: defective spare-parts repository (used), Year of construction: 1987, functionality: not functional, Fault: Short circuit in motor control board (see display) Max. turning diameter over bed: 280 mm Max. turning diameter over cross slide: 140 mm Travel: Z = 350 mm, X = 230 mm Spindle bore: 41 mm Max. spindle bore: 41 mm Tool holder: Baruffaldi 4-position Giedpsyrqwiofx Ab Isp Tailstock Dimensions LxWxH: 2600 x 2000 x 1900 mm Weight: 1,500 kg

Condition: used, Year of construction: 2016, Technical details: Number of axes: 8 Max. machining diameter: 32 mm Max. headstock stroke: 600 mm spindle speed: 8500 min-1 workpiece diameter: 32 mm workpiece length: 240 mm X-axis : 70 mm Gjdpsytp Rqjfx Ab Ijip y-axis: 405 mm z-axis: 100 mm number of tools: 22 Main spindle capacity: 7,5/5,5 kW : 2,2 kW weight: 3,5 t

Condition: used, Year of construction: 2002, turning diameter max. 480 mm turning length max. 2.000 mm Godevy Ig Topfx Ab Isip control Sinumerik 840 D Siemens swing diameter max. over bed cover 520 mm turning speed range - main spindle 7 - 2.800 min/-1 transmission ratio 2 power capacity - main spindel 53 kW max. Torque 3.456 Nm spindle nose 11 DIN 55026 chuck diameter 315 mm spindle bore 103 mm usable bar diameter 82 mm x-travel 405 mm z-travel 2.049 mm diameter of quill 100 mm quill stroke 100 mm tension force 14 kN capture 30 DIN 2079 rapid traverse 10 m/min Working speed 0,1 - 10.000 mm/min feed power 15 kN number of toolpositions 12 pos. driven statition 6 pos. Shank diameter 50 mm power capacity 5,4 kW Max. Speed 2.500 / 625 min/-1 max. Torque 25 / 100 Nm total power requirement ca. 50 kW weight of the machine ca. 14 t dimensions of the machine ca. 6,4 x 3,8 x 3,0 m CNC-Lathe VDF BOEHRINGER - VDF 315 Cm / DL 2000 - incl. 2x Workbench

Condition: used, Doosan Model S 550L CNC Lathe Control Fanuc 21T Swing over bed 710.0 mm Max turning dia 550.0 mm Max turning length 1130.0 mm Chuck dia 400.0 mm Spindle bore 102.0 mm Spindle nose 6 mt Spindle speed 30 – 2500 rpm Spindle motor power 22 kw Turret 12 stations, Feeds 0.001 – 133 mm/rev Rapid X 20m/min Z 24m/min Gijdpfeyka Sysx Ab Iep Bar capacity 90.0 mm Tailstock Swarf conveyor Manuals

Condition: excellent (used), ECOCA MT 312-750 CNC Lathe Year 2006 CNC Control Fanuc 21i-TB Swing over bed 600mm Swing over saddle 450mm Turning dia 450 over bed Spindle bore 102mm Spindle speeds 0-3200rpm Spindle power 18.5/22kw Gsdpfjyka Smsx Ab Ieip Turning length 730mm Tailstock Tool arm 12 station turret 12” 3 Jaw Chuck Swarf conveyor Filtermist extraction Tool holders

Condition: good (used), Mazak Integrex E-410H Multi-Tasking Lathe Mazatrol 640M Pro Control, Gisdpfx Absvgzuwo Iep 610mm Turning Dia Serial No. 164385 (2003)

Condition: used, turning length / mm control / centre height / mm MAZAK SUPER QUICK TURN 15M-Y MARKII CNC lathe Travel distances X-axis: 180 mm Gjdpfxjyukide Ab Isip Y-axis: 100 mm (± 50 mm) Z-axis: 620 mm Spindle Speed range: 35 – 5,000 rpm Power Motor power: 15 kW (approx. 20 hp) Equipment/accessories Extensive accessory package (see images) Various tools and holders Additional accessories included in delivery as shown in the image

Condition: used, Year of construction: 2013, 370mm max. machining diameter, 651mm swing over bed, 461mm swing over cross-slide, 712mm max turned length, 3500rpm spindle, 76mm bar capacity, Gedpsyffz Nefx Ab Ijip 12 station turret, 15kW spindle motor, FANUC Oi control, collet chuck , C axis & Milling, Tool presetter, Tailstock, coolant, swarf conveyor, parts catcher.

Condition: new, Year of construction: 2025, 0400 mm Gisdpfx Ajwp Tckob Ijp 1250 mm 200 mm 55 mm 315 mm 2700 U/min D1-6 DIN 55029 73 mm 140 mm

Condition: used, Year of construction: 2010, turning diameter over bed 0316 mm turning length 340 mm control ultimax Hurco turning diameter over bed slide 240 mm swing dia. 402,5 mm spindle turning speed - stepless 0- 6000 U/min- rpm Godpfx Ajydqpisb Ieip spindle bore 45 mm feeds 0- 30 m/min voltage 400 V connected load 14 KW face slide travel 185 mm longitudinal travel 340 mm dimensions of the machine ca. 3,76 x 2,92 x 2,15 m taper diameter VDI 20 mm main drive motor 11,5 kW weight of the machine ca. 3,2 t Machine has 12 position turret and a bar loader.

Condition: used, Year of construction: 2007, turning diameter over bed 0140 mm turning length 285 mm Gisdex Hpyyepfx Ab Iep control 810D Siemens turning diameter over bed slide 140 mm swing dia. 300 mm spindle turning speed - stepless 0- 5000 U/min- rpm spindle bore 45 mm feeds 0- 12 m/min voltage 400 V connected load 14 KW face slide travel 250 mm longitudinal travel 285 mm dimensions of the machine ca. 2,7 x 1 x 1,6 m taper diameter VDI 20 mm main drive motor 10,2 kW weight of the machine ca. 1,7 t Machine is without live tooling and without tailstock.
