Used Guide Rail Grinding Machine for sale (72,504)

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, spindle speed (max.): 7,000 rpm, type of input current: three-phase, grinding wheel diameter: 200 mm, overall weight: 4,650 kg, grinding length: 350 mm, center height: 190 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, travel distance X-axis: 490 mm, travel distance Y-axis: 320 mm, travel distance Z-axis: 660 mm, grinding spindle motor power: 24,000 W, workpiece diameter (max.): 320 mm, input voltage: 400 V, nominal power (apparent): 35 kVA, spindle nose: ISO 50, swivel angle A-axis (min.): 360 °, CNC tool grinding machine WALTER Helitronic Power Production TECHNICAL CHARACTERISTICS: CNC control: HMC 500 Software installed: Tool Studio 2.1 R4 Number of axes: 5 Height of centers: 190 [mm] Stroke X: axis 490 [mm] Resolution X axis: 0.00001 [mm] Stroke Y axis: 320 [mm] Resolution Y axis : 0.00001 [mm] Stroke Z axis: 660 [mm] Resolution Z axis: 0.00001 [mm] Traversing feeds X, Y and Z axes: 15000 [mm/min] A axis: 360 [°] C axis: +/- 200 [°] Resolution C axis: 0.0001 [°] Max. workpiece lenght: end face grinding: 320 [mm] Max. grinding length: 350 [mm] Max. grinding diameter: 320 [mm] Grinding spindle attachment: NCT Grinding spindle diameter: 80 [mm] Grinding wheel max. speed: 7000 [rpm] Grinding spindle motor power: 24 [kW] Max. diameter grinding wheel: 200 [mm] Internal workpiece spindle nose: ISO 50 Workpiece spindle max. speed: 60 [rpm] Total power required: 35 [kVA] Weight: 4650 [Kg] EQUIPMENT INCLUDED: x1 TRANSOR 12290-800A filtration unit Hfjdpfx Afsyh Nf Ijnoc x1 MTA oil chiller model TAE 015 x1 DSL oil mist extractor model AES-GAMMA 30 x1 RENISHAW part probe x1 disc-type tool loader 40 positions x1 SCHUNK gripper x2 grinding wheel arbor adapters x1 fire protection system - to be inspected by the buyer through a certified organization x1 electrical schematic manual x1 Service Instructions manual LICENSED WALTER WINDOW MODE (WWM) PACKAGES: - Package 001 (cylindrical mills) - Package 002 (tapered mills) - Package 003 (drills) - Package 004 (step drills) - Package 006 (woodwork tools) - Package 013 (reamers) - Package 015 (insert seats) - Package 016 (warmup program) - Package 027 (flexible program) - Package 090 (loader package) - Package 091 (acm) - Package 098 (loader package) - Package 099 (loader package) - Package 100 (reference data m.) - HELICONE (flute calc. conical.) - HELIDRILL (flute calc. drills) - HELIFLUTE (flute calc. cyl. mill.) - MCS (machine control .) - SCHEIBE (wheels menu) - TS_ADVANCED (toolstudio (v1.0-v.) - TS_STANDARD (toolstudio (v1.0-v.) - TS_STEPTOOLS (toolstudio (v1.0-v.) LICENSED TOOLSTUDIO OPTIONS: - Tool Studio 2.0 server/machinecontrol - Tool Studio 2.0 standard license - Tool Studio 2.0 advanced license - Tool Studio 1.9 upgrade options - Tool Studio 2.0 upgrade options - Option steptools - Option profile light (contour roughing ...) - Option calibration w/ touch probe - Option drills Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed.

Condition: like new (used), functionality: fully functional, Year of construction: 2017, operating hours: 2,600 h, control type: CNC control, controller model: Fanuc 32 C, Equipment: documentation/manual, Standard programs such as parameter settings Dressing settings Speed settings Program management settings Limitation of travel distances x + y Basic parameter settings Grinding wheel management program Warming-up cycle program Surface plunge grinding program Measuring program 15 kVA transformer Full enclosure Meister G3 Spindle upgrade to 3.7 kW, disc 225 mm ETHER interface for network connection Control module with extended memory Fanuc Macro B option Program creation for batch programs Programmable spindle speed WinWop program for contour creation (Windows) WINWop program for error compensation WinWop postprocessor CGS Complete Grinding Solutions software Option Dressing Swiveling profile dressing device Diamond dressing wheel Pre-dressing device VPA 100 L Diamond wheel 100 mm for pre-dressing device Regrinding package diamond wheel G3 / W Option – Clamping and Balancing Magnetic chuck 400 x 200 400 mm stop bar with prism Fully automatic balancing device, size 1 Hedow I Tt Sjpfx Afnefc Grinding wheel flange for G3, bore 51 mm Option Filter Systems Belt filter system 175 l Extraction unit for emulsion mist 500 Inquiries only from Europe, preferably the EU.

Condition: ready for operation (used), Year of construction: 1972, Immediately available from university: Hydraulic horizontal surface grinding machine Blohm, type HFS 204 A, year of manufacture 1972. Grinding length 400 mm, grinding width 220 mm, X travel 500 mm, installation height (grinding wheel to table) 520 mm. Automatic feed, weight 2.5 t, magnetic chuck, coolant system. Priced at EUR 2,750.— plus VAT ex location. Hsdpfx Afsykngxenefc

Condition: excellent (used), functionality: fully functional, Grindable diameter from 2 to 40 mm. Smallest and largest point angle: 40 – 180°. Hfodpfxeyiukne Afnjc For right- and left-cutting tools, 1-12 cutting edges. Suitable for sharpening twist drills, step drills, and taps. Accessories and an operating manual are included.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: UWID/5000/97, grinding spindle speed: 10,000 rpm, feed rate X-axis: 20 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 20 m/min, center height: 150 mm, TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 250 mm Travel Z-axis: 250 mm Feed rate X-axis: 0 - 20 m/min Feed rate Y-axis: 0 - 10 m/min Feed rate Z-axis: 0 - 20 m/min Centre height: 150 mm Usable table area: 980 x 185 mm Grinding head Swivel range: 240° Rotation speed: 120°/s Spindle diameter: 170 mm Spindle speed: 2,000 – 10,000 rpm Workpiece holder A-axis Indexing accuracy: ± 15″ Cumulative indexing error (at ∅ 100 mm): 8 µm Mount: ISO 50 Max. rotational speed: 50 rpm Position measuring systems resolution: 0.0001 mm / 0.0001° Tool magazine: 70 tools MACHINE DETAILS Control: NUM 1050 M with PC; Program memory: 512 KB Drive capacities Grinding spindle motor: 10 kW Table drive X-axis: 1.5 kW Workpiece holder A-axis: 1.5 kW Cross slide Z-axis: 1.5 kW Grinding head column Y-axis: 3 kW Grinding head rotation B-axis: 3 kW Electrical connection Connected load: 23 kW Main fuse: 63 A Operating voltage: 400 V, 50 Hz Control voltage: 24 V Lighting voltage: 230 V, 50 Hz Compressed air Air consumption: 10-12 Nm³/h Pressure min/max: 5/8 bar (500/800 kPa) Compressed air quality: ISO 8573-1, class 4 Ambient temperature Hedpfx Afjyh I U Ijnefc Operation: 15°C - 35°C Weight: 7,400 kg Further documentation for the machine is available on request.

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, CNC Tool Grinding Machine Walter Helitronic Power FH, Hodpfxoyh Dl Ns Afnofc Year of manufacture: 2015 Fanuc control system with cylindrical pallet loader, pallets from 4 mm to 25 mm 8-position disc changer, electrostatic mist collector fire extinguishing system, Software: Walter Window Mode and Toolstudio, Software packages: 001, 002, 003, 016, 017, 026, 090, 091, 098, 099, 032, Helicone, Helidrill, Heliflute, NC-Mode, Power-IMS, Toolstudio_Standard, with preparation for hydraulic unit (steady rest), The grinding spindle (single spindle) is directly driven and equipped with an oil cooler. The hollow shaft motor for the A-axis operates at a speed of 0-750 rpm. The C, X, Z, and A axes were overhauled in 2022.

Condition: good (used), Year of construction: 2000, CNC surface and profile grinding machine Fabr.Ziersch & Baltrusch Type:PROFITLINE ZB 62 NC Year of manufacture.2000 grinding range : 600X270mm Electromagnet with continuous transverse pole pitch Hfjdpfjfrbcksx Afnjc 600X200mm. P = 4 mm Wet grinding device, with automatic paper belt filter, machine trough. Complete machine documentation available.

Condition: used, Year of construction: 1977, Surface grinding machine Fabr.Okamoto Type:PSG - 63 UA Bj.1977 Magnet 600 mm X 300 mm. Grinding dimensions : longitudinal 630 mm transverse: 310 mm height : 350 mm Ready for use . Hsdpeiz Tmkofx Afnofc

Condition: good (used), Year of construction: 1991, CNC surface grinding machine, make ELB, type: BRILLANT B8 UNICON with CNC dresser for profile grinding. Hedpovk Elzofx Afnofc Grinding mass: lengthwise 800 mm, width 500 mm, height 400 mm Magnet: 800 mm x 450 mm with paper belt filter and extraction. Complete machine documentation.

Condition: good (used), Year of construction: 1998, Surface sanding machine Fabr.ABA Type: ECOLINE 1006 Bj.1998 with Abamatic 1 N.D. Sanding area max : length 1000 mm width 600 mm height 500 mm Magnetic table size : 1000 mm X 500 mm . Paper belt filter, various accessories Further data see data sheet . Complete machine documentation available. Hjdpfxjvbb Iyj Afnefc Machine in good condition

Condition: good (used), Year of construction: 1975, Coordinate Grinding Machine Manufacturer: HAUSER Type: 5 SM Year: 1975 with 2-axis digital readout Heidenhain. Table: 750 mm x 620 mm Travel: X 700 mm, Y 500 mm, Z 150 mm Grinding head speeds: 9,000 – 80,000 rpm Total power: 6.3 kW Good condition, in stock. Machine dimensions: 2,500 mm x 1,700 mm x 2,700 mm Weight approx. 5,100 kg. Hfodpfjr H Dvdex Afnoc Includes tool cabinet, accessories, and documentation.

Condition: good (used), Year of construction: 1990, CNC Cylindrical Grinding Machine Hedpfx Afoid Aphjnjfc Make: TSCHUDIN Type: HTG 22 - 862 Year 1990 with MARPOSS E14 control and measuring control E5. center width : 650 mm center height : 100 mm grinding length : 620 mm Weight : ca.4 500 Kg. Further data See : TECHNICAL DATA SHEET With many grinding stones and holders Complete machine documentation available. Machine in stock.

Condition: good (used), Year of construction: 1968, Cylindrical grinding machine, manufacturer: STANKOIMPORT, type: XC3, year 1968, with accessories. Model: 3A 161. Centre height: 161 mm, grinding diameter: 322 mm. Centre distance/grinding length: 1000 mm. In good condition. Hfsdpexq Tlrofx Afnoc

Condition: ready for operation (used), Year of construction: 1980, Steel grinding machine Fabr.Eichoff type E2. Hodpfxsiuh Rhe Afnefc Ready for use.

Condition: new, grinding height: 150 mm, height adjustment type: mechanical, total height: 1,450 mm, total length: 1,800 mm, total width: 1,400 mm, overall weight: 850 kg, Equipment: CE marking, Structuring and Sanding Machine / 4-Side Brushing Machine Hfjdpfxoykh Tfj Afnoc Manufacturer: Alpha Brush Model: LS-TSB Versatile brush sanding machine equipped with a total of 6 brush units for 4-sided sanding and structuring of wood materials such as panels, solid wood flooring, scaffolding boards, facade boards, etc. Working width: 300 mm Workpiece height clearance: 150 mm Equipped with: - 1x top brush unit, 2.2 kW - 1x bottom brush unit, 2.2 kW - 1x top brush unit, 2.2 kW - 1x bottom brush unit, 2.2 kW - 1x left-side brush unit, 1.1 kW - 1x right-side brush unit, 1.1 kW Infinitely variable speed control for each brush group (top, bottom, sides) Brush diameter: 260 - 300 mm Quick-change system for brush heads Spring-mounted pressure roller, individually height adjustable Feed rate infinitely variable, approx. 2 - 20 m/min., 0.75 kW Digital display for settings Recommended extraction capacity: 3000-3500 m³/h Voltage: 400 - 480 V, 3 Ph, 50/60 Hz Protection: 32 A Dimensions (LxWxH): approx. 1800 x 1400 x 1450 mm Weight: approx. 850 kg

Condition: good (used), Year of construction: 2004, Ref. -No.: 10629 Manufacturer: MICHAEL DECKEL Type: S20 Turbo Year of construction: 2004 Type of control: CNC Storage location: Halberstadt Country of origin: Germany Workpiece Diameter: 250 mm Max. Grinding length: 340 mm Max. Workpiece Weight: 50 kg Grinding wheel diameter (max.): 150 mm Turning Speeds: 8000 RPM Hodpfoyhvu Ejx Afnofc Workpiece holder: SK 50

Condition: ready for operation (used), Year of construction: 1977, functionality: fully functional, grinding length: 700 mm, grinding width: 550 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 475 mm, TECHNICAL DETAILS X-axis travel: 500 mm Y-axis travel: 300 mm Z-axis travel: 475 mm Manual grinding area Length: 700 mm Width: 550 mm Height: 400 mm Automatic grinding area Length: 700 mm Width: 470 mm Height: 400 mm Table size: 1,100 x 500 mm Hjdpfxjyf Ahmj Afnofc Maximum workpiece height: 400 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,000 x 1,960 x 2,550 mm Machine weight: 3,300 kg EQUIPMENT Operating manual

Condition: like new (used), Year of construction: 2012, operating hours: 344 h, functionality: fully functional, grinding length: 850 mm, grinding width: 400 mm, total height: 505 mm, overall weight: 3,500 kg, Equipment: documentation/manual, Base machine Type Linea Iron 6.3 Hodpeygap Rsfx Afnofc Preparation for magnetic chuck with safety function Magnetic chuck 600 x 300 x 70 mm Paper band filter unit with manual paper unwind Air cooling for hydraulic oil Dressing fixture at the end of the table, incl. space for lateral diamond 2x grinding wheel flanges with manual weights Machine grinding range: Longitudinal 850 mm. Cross 400 mm including max. B (50 mm) grinding wheel. Height distance table to spindle center 505 mm. Weight 3,500 kg.

Condition: good (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 004-040.0004, CNC Cylindrical Grinding Machine Manufacturer: STUDER Model: S22 CNC Year of manufacture: 2009 Machine / Workpiece Data Distance between centers: approx. 650 mm Center height: 175 mm Maximum workpiece weight: 150 kg Maximum grinding length: approx. 800 mm Linear Axes / Guides X-axis (cross slide): Maximum travel approx. 310 mm X-axis feed rate up to approx. 15,000 mm/min (depending on configuration) Z-axis (longitudinal slide): Maximum travel approx. 850 mm Z-axis feed rate up to approx. 30,000 mm/min Grinding Spindle / Grinding Wheel Main spindle power, e.g. 12.5 kW in the standard version Standard grinding wheel diameter e.g. Ø 500 × 80 × 203 mm, circumferential speed up to approx. 50 m/s Optional high-speed grinding (HSG): e.g. grinding wheel Ø 400 x 40 x 127 mm, circumferential speed up to approx. 140 m/s Hsdpjxtpnzefx Afnofc Control / Software / Equipment Control, standard: e.g. FANUC 31i-A (PC integrated) with StuderWIN operator interface Guideways: Machine bed made from Granitan® S103 (mineral cast) for thermal stability and damping Dimensions / Electrical Data Machine weight approx. 8,500 kg Power supply, typically 400 V / 50 Hz (country-specific)

Condition: good (used), Year of construction: 2005, operating hours: 374 h, functionality: fully functional, machine/vehicle number: 112434, total length: 7,310 mm, total width: 1,800 mm, total height: 2,300 mm, overall weight: 4,200 kg, input frequency: 50 Hz, type of input current: three-phase, working height: 80 mm, power: 20 kW (27.19 HP), pressure: 7 bar, Straight line bevelling machine for glass with 7 wheels, serviced in 2025. Minimum glass size: 40 x 40 mm. Speed: 0.5 – 4.1 m/min. Glass thickness: 3 – 20 mm. Bevel angle: 3° – 45°. Maximum bevel width: 50 mm. Power: 20 kW. Excluding water tanks and pump (connected to central system). Hodpfxeyg Dhqo Afnofc

Condition: excellent (used), Year of construction: 1975, The year of manufacture is estimated, but from the 1970s. Partially overhauled, geometry checked (within tolerance). TECHNICAL DATA Centre height: 125 mm Grinding diameter: 250 mm Grinding length: 750 mm Spindle power: 3 kW Grinding spindle head Hfodpfeid Sqwsx Afnoc Speed range: 1500-2420 rpm Grinding wheel dimensions: ø 400x50x127 mm Workpiece spindle head Speed range (stepless): 25 – 450 rpm Rotatable: 90° Spindle taper: MK 5 Tailstock Quill taper: MK 3 Table feed (stepless): 100 – 6000 mm/min Maximum table swivel: 10° EQUIPMENT/ACCESSORIES - Tailstock with fine cross adjustment - Coolant system - Splash guard - 1 flange with diamond grinding wheel - 2 additional flanges - Various setting elements

Condition: used, Year of construction: 1989, Used machine Year of manufacture: 1989 Equipment and technical data: - The conveyor belt integrated into the table is driven by a geared motor. - The built-in dial gauge on the handwheel and at the front of the table allows for precise monitoring of material removal. - The machine is designed on the principle of thickness reduction (thickness planing), which means uniform material removal and grinding accuracy to within 0.1 mm. - Optimal grinding pattern thanks to the oscillating sanding belt. - No belt misalignment due to pneumatically controlled oscillation. - Sanding belt length: 1600 mm - Sanding belt width: 200 mm - Table length: 1000 mm - Working height: 120 mm - Drive motor: 5.5 kW Availability: short-term Hfedpfxjygbpxs Afnjc Storage location: Flörsheim

Condition: used, Year of construction: 1992, Technical details: Hjdpfx Aer R Ek Ssfnefc grinding diameter: 50 mm grinding length: 100 mm centre height: 100 mm centre distance: 200 mm

Condition: used, Year of construction: 2005, Technical details: grinding length: 400 mm workpiece weight: 250 kg weight of the machine ca.: 4,1 t swing diameter: 250 mm grinding spindle speed: 2387, 2938 U/min Hfedpfx Afevap Ryensc

Condition: used, Year of construction: 1989, Technical details: grinding diameter: 300 mm Hfsdper R Elpsfx Afnsc grinding length: 540 mm centre height: 175 mm total power requirement: 20 kVA centre distance: 1000 mm
