CNC cycle lathe

MONFORTS KNC 6

Condition: ready for operation (used), Year of construction: 1999, number of axes: 2, This Monforts KNC 6 S was manufactured in 1999. A robust horizontal turning machine featuring a maximum turning diameter over bed of 650mm and a maximum turning length of 2,000mm. It includes an R&D control unit, enhancing its operational capabilities. If you are looking to get high-quality turning capabilities, consider the Monforts KNC 6 S machine we have for sale. Contact us for more information. Machine Benefits Technical Machine Benefits • Rotation ⌀ max. Over support: 340 mm • Turn ⌀ max. Over bed: 650 mm Nwedpfsyail Iox Ad Neb • Max. Turning length: 2000 mm Extra Information Machine still under power

Condition: new, Experience unparalleled precision and performance with ROBBI's range of cylindrical grinding machines. Our machines offer grinding lengths starting from 2000mm and are available in semi-automatic and CNC versions. With a grinding diameter range of 300-1000mm, the possibilities are endless. Partly available from stock! Discover our extensive range of optional accessories that make our cylindrical grinding machines even more versatile. Whether it's for complex workpieces or demanding tasks, our machines always deliver the best results. With ROBBI's years of experience, trust us to optimize your machining processes. Invest in quality and precision - contact us today! MAIN TECHNICAL DATA: Model: Omicron CNC 80 Grinding diameter: 795/895/955 mm Grinding length: 3000-6000 mm Center height: 400/450/500 mm Nwodpfx Aotximvsd Nsb Center distance: 3000-6000 mm Swing over bed: 795/895/955 mm Max. workpiece weight between centers: 4 t Additional technical data in the appendix MAIN TECHNICAL DATA: Model: Omicron CNC 60 Grinding diameter: 595/695 mm Grinding length: 1000-3000 mm Center height: 300/350 mm Center distance: 1150-3150 mm Swing over bed: 600/700 mm Max. workpiece weight between centers: 1200 kg Additional technical data available on request or in the appendix MAIN TECHNICAL DATA: Model: Omicron CNC 36 Grinding diameter: 355/455 mm Grinding length: 630-2030 mm Center height: 180/230 mm Swing over bed: 355/455 mm Max. workpiece weight: 250 (300 opt.) kg Additional technical data available on request or in the appendix ACCESSORIES (EXAMPLE FOR OMICRON CNC 80) CNC control: Siemens 840D Glass scales: in the X-axis Coolant system: with coolant collection tray Grinding wheel dresser: mounted on the tailstock (without diamond) Telescopic cover: for the table made of fabric Machine oil: 5l for the spindle Frequency converter: for spindle motor and workpiece drive (stepless) Hydraulic unit: for controlling the tailstock quill Ball screw in the axes: X and Z Optimized cycle with geometric and process parameters - The CNC grinding machines meet the production requirements for medium-sized workpieces. - The machines are equipped with the latest generation SIEMENS 840Di sl system. - The machine can be equipped with automatic measuring systems. - It is possible to design the grinding wheel for geometries specifically created for the required type of production. - High-precision machining can be performed when the grinding machines are equipped with a third interpolated axis and specially designed software. EASY PROGRAMMING Complex programs can be created without the need for ISO programming knowledge. The input of parameters is facilitated by a series of messages and characters that explain the meaning of the various parameters step by step. The programming of work cycles is done by entering the same parameters of the cycle. The sequence of execution of the various cycles can be quickly and intuitively changed. By the way, in addition to affordable new machines and tested used machines, you can expect even more from us: • Consultation and problem-solving at your location • Organization of machine transport to your facility • Installation, commissioning, and turnkey delivery, and more.

Condition: good (used), 2 electronic handwheels from a cycle lathe MONFORTS KNC 8 with rotary encoder no. 6FC9320-5DC00 Nsdpjw Elwrsfx Ad Nowb Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2003, Technical details: turning diameter: 630 mm turning length: 2000 mm swing diameter over bed slide: 350 mm upper slide-adjustment: 195 mm bed width: 550 mm spindle diameter in front bearing: 120 mm spindle drive: 17/25 kW spindle bore: 71 mm spindle turning speed range: 3 - 1800 U/min tailstock-quill taper dia./stroke: 110/210 mm total power requirement: 30 kW dimensions of the machine ca.: 4,9 x 2,1 x 2,0 m weight of the machine ca.: 5 t Machine with Monforts System Euro Turn control - quick tool change device MULTIFIX - 3-jaw chuck - coolant device Nwjdpfx Adsvb Dt Ss Njb - chip conveyor *

Condition: used, Year of construction: 1985, functionality: fully functional, travel distance X-axis: 4,700 mm, travel distance Y-axis: 2,250 mm, travel distance Z-axis: 1,300 mm, total width: 3,000 mm, total length: 8,710 mm, total height: 5,250 mm, spindle diameter: 130 mm, table load: 16,000 kg, table length: 2,200 mm, table width: 2,200 mm, overall weight: 40,000 kg, Accessories: 2 different heads Nodpfew Hr Hpox Ad Nowb 1 faceplate

Condition: used, Year of construction: 1999, turning length 2000 mm greates pass round over bed 630 mm swing diameter over slide rest 350 mm control Monforts Control System K bed width 550 mm turning speed range 2 - 1800 U/min spindle diameter in front bearing 120 mm spindle head DIN 55027 - Size 8 tool taper RD2 PARAT quill stroke 210 mm spindle bore 71 mm total power requirement 30 kW weight of the machine ca. 5 t Nedpow E Nmqjfx Ad Newb dimensions of the machine ca. 4,90 x 2,10 x 2,00 m Three-jaw chuck / key bar / Ø250mm Four-jaw chuck 3-jaw chuck for tailstock 4-station tool post head PARAT Fixed steady rest, Ø small Fixed steady rest, Ø large Various chuck jaws, live centers, live centers, tool holders Chip conveyor with coolant pump

Condition: refurbished (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 193 34-41, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,600 mm, table load: 2,500 kg, spindle diameter: 102 mm, spindle speed (min.): 4 rpm, spindle speed (max.): 1,600 rpm, total height: 3,500 mm, total length: 6,500 mm, total width: 4,700 mm, table length: 1,400 mm, table width: 1,250 mm, year of last overhaul: 2025, Equipment: rotational speed infinitely variable, The machine was overhauled and modernized in 2025 and is immediately ready for operation! Travel paths: - Table cross travel (X-axis): 1600 mm - Spindle head vertical travel (Y-axis): 1250 mm - Table longitudinal travel (Z-axis): 1475 mm (restriction due to large table) - Quill travel (W-axis): 710 mm - Table rotation (B-axis): 360 degrees Clamping table: - Clamping surface: 1250 x 1400 mm - Table load capacity: 2.5 t Spindle: - Diameter: 102 mm - Tool holder: DIN2080, SK 50 - Infinitely variable speed: 4 – 1600 rpm - Drive power: 13 kW Feed: Nwjdpfsw Rn R Rjx Ad Nob - X, Y, Z axes, stepless: 1 – 4000 mm/min Rapid traverse: - X, Y, Z axes: 4 m/min Power consumption: 42 kW Weight: 10 t Space requirements (L x W x H): 6.5 x 4.7 x 3.5 m Equipment: - Heidenhain TNC 320 - Coolant device

Condition: used, Year of construction: 1980, functionality: fully functional, machine/vehicle number: KME 2/750L, Tension carriage for saw frame Nsdpfjv Umb Eex Ad Nswb Viewings are available by appointment.

Condition: good (used), grinding diameter: 1,600 mm, grinding length: 6,000 mm, Manufacturer: CINCINNATI Type: 60 x 216 Year of manufacture: 1970 Covex and Concave grinding 6 steady rest included 2 steady rest hydrostatic Coolant system with magnetic filter Measuring system with 5 arms caliber: Arm 1: Working area 1300 to 1600 mm Arm 2: Working area 1000 to 1300 mm Arm 3: Working area 700 to 1000 mm Arm 4: Working area 400 to 700 mm Specifications Metric US Standard Center height 787 mm Grinding diameter Ø 1574 mm Grinding length 5800 mm Grinding stone dimensions 914 x 101.6 x 304.50 mm Grinding stone speed 1800 rpm Dimensions (estimate) Nwodpfevvvw Eex Ad Njb Length 15100 mm Width 5500 mm Height 3550 mm Weight 120000 kg Please note: The information on this page is correct to the best of our knowledge and belief and, where possible, has been obtained from the manufacturer. The information is given in good faith but accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you check all important details.

Year of construction: 2002, condition: reconditioned (used), Beam cutting, drilling and marking line DISC SAW Brand: KALTENBACH Model: HDM 1431 / T13 / SP-CNC Year 2002 Serial number: 122.400 Weight without accessories: 10,980kh - Disc saw with downward cut. - Geared saw unit, drive system and saw blade on wear-resistant swivel bearing. - Heavy saw gear with pinions in oil bath, with inclined teeth, hardened and sharp. - Hydraulic advancement of the saw blade, adjustable according to the table, very fast recoil. - Hydraulic horizontal clamping device. Rear clamping jaw with long-stroke clamping cylinder and automatic recoil limitation. - Vertical clamping block with self-adjusting push plate. - Oblique cutting device to adjust the angle from 45° to the left to 35° to the right. - Material sensor to automatically switch from rapid advance to work advance. - Hydraulically elevating feed roller for optimum material transport on the saw table. - Economical lubrication by means of a micro-dosing installation, especially suitable for sawing profiles. - Chip collector installed on the machine bench. Nwedpfx Ashzbipod Njb Specs: - Cutting disc housing: 100x4x30x250mm - Cutting disc diameter: 1,430mm - Cutting width: 9.5mm - Cutting speed: 10 to 20m/min. - Saw advance speed: 0-400mm/min. - Fast reverse speed: 2000mm/min. - Total power: 25KW - Working height: 640mm Cutting capacities: 90º cut - Angle steel: 250mm - Steel in U: 400mm - Double T-beam: 600mm - Wide flanged beam: 1008x302mm - Special wing beams: 1000x450mm Cut to degrees: IPBv beam - 75º: 1008x302mm - 60º: 910x302mm - 45º: 716x304mm - 40º: 716x304mm - 35º: 478X307mm IPBs beam - 75º: 1008x402mm - 45º: 524x357mm IPE beam - 45º: 600x220mm DRILLING UNIT Brand: Kaltenbach Model: KDX1215 Serial number: 122.401 Work capabilities: - Angular steel (minimum - maximum): 80x65x10mm - 250x250x28mm - Steel in U (minimum - maximum): 80x45mm - 400x110mm - Double T beam (minimum - maximum): 80x46mm - 600x220mm - Wide flanged beam (minimum - maximum): 100x100mm - 1,008x302mm - Extra wide wings beam: 1,200x500mm Drilling units: 3 - Vertical (Y axis) 1 pc. - Horizontal (Z and W axes) 2ud. Drilling diameters: 8 - 40mm RPM: 150 - 1100 Fast forward - Fast reverse: 3,850mm/min. - 8,000mm/min. Drilling spindle feed rate: 0-500mm/min. Fast spindle positioning tool: 15,000mm/min. Automatic tool changer: 5 u. in each drilling unit. 3x5 u. = 15 total Total power: 45KW MARKING UNIT FEEDING: 26 METERS OF ENTRY WITH BEAM FEEDER + 6 SIDE ARMS FOR BEAM ENTRY IN PARALLEL TO THE ROLLER TRACKS 30 METERS OF ROLLER TRACKS WITH OUTPUT + 6 SIDE ARMS 4 SIDE ARM FOR SMALL PIECES THE GREAT MAJORITY OF ROLLERS ARE MOTORIZED It occupies approximately 60 linear meters between input and output power. *Request machine installation plans.
