Single Edgebanders

HOMAG KDF 860 C

Condition: used, machine/vehicle number: 008323, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, PUR Premilling Unit: yes Corner Rounding Unit: yes Lrsdpfx Aex Hpkxod Eeh Max feed speed: 20 m/min Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, travel distance X-axis: 4,300 mm, travel distance Y-axis: 2,200 mm, Electrospindle with 13.2 kW power, HSK F63 interface 8-position revolver tool magazine at the edge of the Y-axis carriage Drilling head BH25L: - 18 vertical spindles - 3 horizontal spindles (2 in X, 1 in Y) - 1 saw blade Ø120 mm 16-position revolver tool magazine on the X-axis carriage Control panel Lsdpfx Aox Nayijd Eorh Automatic lubrication system Loading and unloading system (sweeping arm + loading suction cups)

Condition: used, machine/vehicle number: 008030, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, PUR, Hot Air Premilling Unit: yes Corner Rounding Unit: yes Lredpfewvq Hgsx Ad Eeh Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 8 nr

Condition: new, engine output 5 kW saw-blade dia. 300-350 mm Working speed 0-40 m/min Ledpfx Aewli Nrjd Esrh weight ca. 1.300 – 1.800 kg kg

Condition: used, machine/vehicle number: 007361, X axis working area: 3050 mm Y axis working area: 850 mm Main Electrospindle power: 9 KW Number of controlled axes: 3 axes Lrodpfxsx A Tibe Ad Eoh Total number of drilling spindles: 19 Total number of tool changer positions: 3

Condition: used, Year of construction: 2001, spindle tilting: Ja -25 bis +45° height adjustment: elektrisch tilting adjustment: elektrisch read out tilting: digital read out spindle height: digital Lodpfx Adowx Nnbo Esrh read out fence: Siko Zähler spindle diameter: 30 mm speeds: 1.500/3.000/4.000/4.500/5.000/6.000/8.000/9.000/10.000 U / min motor power: 7,5 kW motor brake: Ja, automatisch feeder: Wegoma 4 Rollen suction connection: 2 x 120mm machine length: 1900mm machine depth: 1400mm weight: 1000 kg

Condition: new, Year of construction: 2022, Exhibition machine Year of manufacture: 2022 Equipment and technical data: Base machine 7402 with Pin-Jet dowel insertion function Hand control device 2D barcode scanner UPS Lsdpfx Adjwt E Tve Ejrh Quattro-HSK package incl. 4-position tool changer XL drilling head Double drilling spindle in Y-axis Automatic central lubrication Location: Hochheim Availability: approx. week 32/2022

Condition: excellent (used), PANELS RETURN SYSTEM for EDGE BANDER (Right) Lredpfxsff R Tqj Ad Eoh To combine with a single-side Edge Bander allowing the operator (worker) to always stay at the in-feed side of the machine (the processed workpiece will automatically return-back to him). Blowing Air Table, infeed and outfeed (total dimensions mm 3520 x 2560) 180° transfer (mm 3120 x 2140) with motorized roller conveyors and motorized belts Motorized carpet (mm 9080 x 1560) Panel Dimensions (MIN/MAX): Length - 240 mm / 2800 mm Width - 120 mm / 1300 mm Thickness - 8 mm / 60 mm opt. up to 100 mm

Condition: excellent (used), Biesse Stream 5.5 A Edgebander Mileage: 246,000 m Top pressure belt, fluids Pre-milling cutters, Glue application, Pre-melter for PUR adhesive The glue pot is equipped with a glue drain Pneumatic pre-cut guillotine, Pressure rollers fluids Flush trim saws, Top and bottom trimming unit with straight cutters Top and bottom multi-cutter trimming unit Two corner rounding units Fluids Profile scraper (multi R1-R2), Cleaning fluids Flat scraper, Polishing unit, Lrsdpfxsxxlqvo Ad Ejh The machine is equipped with NC control for routers and a pneumatic package, Max workpiece height 60 mm, Max edge banding thickness in roll: 3 mm, Feed rate: 12, 18 and up to 20 m/min The machine is in very good condition.

Condition: excellent (used), C.N.C. WORKING CENTER with 3 axes (X-Y-Z) - Goose-neck type Movable panel (workpiece), static working head, Horizontal position of the panel (workpiece) Numerical Control with Software BiesseWorks (Separate electric and command cabinet) Safety cabin (enclosure) of the working head, Front emergency carpets In-feeding working table (panel support) No. 2 Workpieces fixing clamps (for the panels introduction in the working area) Lrsdewb Allspfx Ad Eoh Out-feeding table (with motorized belts) Minimum workpieces dimensions (X - Y - Z) mm 90 x 70 x 8 (ca.) Maximum workpieces dimensions (X - Y - Z) mm 3000 x 1300 x 60 (ca.) Total installed power (Kw) 24 BOTTOM WORKING UNITS: Independent vertical boring spindles (No.) 29 Independent horizontal boring spindles (No.) 10 (8 X + 2 Y) Circular Grooving Saw (on X axis) dia. (mm) 160 (1 x kw 3,5 ca.) Vertical electro-spindle (No.) ISO 30 (1 x kw 4,5 ca.) TOP WORKING UNITS: Indipendent vertical drilling spindles (No.) 29 Indipendent horizontal drilling spindles (No.) 10 (8 X + 2 Y) Circular Grooving Saw (on X axis) dia. (mm) 160 (1 x kw 3,5 ca.) Vertical electro-spindle (No.) ISO 30 (1 x kw 4,5 ca.)
