N+F line

HOMAG FL86

Condition: good (used), Year of construction: 2000, High-performance CNC vertical machining centre with SIEMENS 840 D, 2-fold pallet changer, IKZ, linear guides and 30-fold WZW table size 2 x 1000 x 450 mm tool holder DIN 69871 ISO 40 travel X-axis 1100 mm Y-axis 500 mm Z-axis 640 mm speed range 50 - 10.000 rpm table load 600 kg feed range, X/Y/Z, infinitely variable - 10000 mm/min rapid traverse in all axes 30 m/min Drive power 18,5 kW Machine dimensions L x W x H approx. 3605 x 3041 x 3220 mm weight approx. 6700 kg Accessories / special features: - CNC-control SIEMENS 840 D - 2-fold pallet changer - 30-fold tool changer - Full protection cabin with safety doors, electrically protected - High speed up to 10.000 rpm and drive power with 18,5 kW - Linear guides with double recirculating roller shoe, allowing high torques to be absorbed uniformly in all directions - Ball screw spindles in all 3-axes - The entire machine bed is made of Meehanit cast iron and ensures precision, rigidity and vibration damping Bjdpfjd I R E Njx Agzowi - Tool holder DIN 69871, ISO 40 - Hinged chip conveyor with integrated coolant system - 4th axis already prepared - CE-conform Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Year of construction: 2003, condition: good (used), machine/vehicle number: 02070325, Automatic dowel drilling machine 2 horizontal drilling groups 3 vertical drilling groups from top Sidemovement of vertical drilling groups from top Vertical infeed magazine Returnbelt to operator Bwsdpokn Ibusfx Agzei

Condition: used, machine/vehicle number: 004922, Max. panel width: 250 mm Max. panel length: 1500 mm No of Top Units: 2 Bwjdjg E Th Sspfx Agzji Lateral horizontal groups: yes

Condition: excellent (used), Year of construction: 1999, The machine is equipped with a magazine of elements. The parts are returned to the operator. Bjdpfjtt Ddcjx Agzjwi Equipped with 17 spindles

Year of construction: 2000, condition: used, turning diameter 530 mm turning length 1500 mm control Fagor centre height 260 mm swing diameter 475 mm swing diameter over flat guideway 530 mm swing diameter over bed slide 315 mm bed width 350 mm spindle bore 80 mm Bwedsiu A Daopfx Agzoi spindle taper innen MK5 turning speeds 2 turning speed range 0-650/650-2500 U/min feed range 0 - 7000 mm/min rapid traverse 10 m/min diameter of quill 72 mm quill travel 180 mm weight of the machine ca. ca. 3,5 t dimensions of the machine ca. L/B/H 3,50x1,50x180 m

Year of construction: 1989, condition: good (used), • Length of milling 1400 mm • Max. Milling height 120 mm • Max. Width 450 mm • 30 mm spindles • Max spindle diameter 160 mm • Spindle revolutions 8400 / min • Dimensions 4100 x 2000 x 1600 mm • Weight without cabin 1600 kg • 2x 5.5 kw motors Bsdpfx Agsgqr Shezswi • Feed 1-15 m / min

Condition: good (used), Year of construction: 2017, Multi-Sheet Machining For Maximum Output Automatic Loading System CNC Bandsawing, Routing & Drilling CNC Control Of The Bandsaw Movement +/- 90 Degrees The MZ Pluris is recognised as the machine of choice for all sofa and chair frame manufactures. The machine can work with OSB, Plywood, MDF, Chipboard (good quality), solid wood and also some composite materials. It has a number of key advantages over standard CNC nesting machines that include the possibility to stack multiple sheets high eg 5 x 12mm thick sheets, thanks to the use of the bandsaw sheet yield is much better, no vacuum is used so the machine is able to cut small shaped parts without difficulty and lastly cut parts are coming off on to the side discharge conveyor as the machine is still working, thus maximising machine output. Increased working capacity of 2550mm 1550mm Sheet size = 1220 x 2,440mm (8' x 4 ') and 1525 x 1525mm Standard equipment / features: CNC bandsaw specification - Maximum depth of curve 800mm - Minimum radius of cut 50mm - Maximum cutting height 100mm - Automatic angling of blade +/- 90 degrees - Blade size 5900 x 13mm - Automatic sawblade tensioning - Cast aluminium saw pulleys 900mm dia - Self braking motor 11kw CNC router specification: - Maximum working height / cutting depth 60mm - Electro spindle power S6 9KW - Variable rotation speed 7000 - 24000 rpm - HSK 63F tool holder Fence / grippers / supports: - Programmable pusher fence with 6 x pneumatic panel grippers - 8 x panel support arms General: - Automatic centralised lubrication system consisting of 3 x oil pumps - Internal conveyor belt for removal of dust / waste cuts - Free standing electrical control cabinet with PC and keyboard - Hand held remote control CNC vertical drilling unit: - Maximum drilling depth 70mm - 5 x independent drilling spindles in line. (Drills not included). - 1.7kw motor Plus package: - 5 position automatic tool changer - Automatic movement of clamps and support arms - set through the program Lifting table: - 4 screw - Capacity 2550 x 1525mm - Max load capacity 3000kg approx - Max panel pack height 700mm - PIT REQUIRED Year - 2017 CE Serial nr - 22/2017 Bodotqfv Ispfx Agzjwi

Condition: good (used), Year of construction: 2006, A versatile 6 section clamping machine specifically designed for solid wood edge and face laminating. The Clamp Carrier is ideal for producing a variety of components such as panels, table tops, block gluings, joinery sections and stair parts. The patented 'equaliser' clamp arms incorporate a number of important features not found on other types of mechanical clamp that help ensure a quality glue joint is produced. As standard the machine is equipped with a hydraulic clamp tightener / loosener, pneumatic component flattener and hydraulic rotation. Equipped with: 302 type clamp arms with 915mm (36") max opening and 95mm ( 3.5") high jaws - 2 x 80S heavy duty hydraulic drives for rotation - 1 x 80V semi automatic hydraulic clamp tightener. (Hydraulic pack 3 phase electrics). - 1 x 80D pneumatic component flattener Bsdpfx Ageru Evgozewi - Pneumatic movement in / out of front rest - CE safety perimeter guards Year - 2006 CE

Year of construction: 2003, condition: good (used), functionality: fully functional, Horizontal machining center with hydrostatic guides X, Y, Z for highest precision TECHNICAL DETAILS X-travel: 2000 mm Y-way: 1250 mm Z-path: 1400 mm speed: 20 - 5.000 rpm torque: 750 Nm tool holder: HSK 100 Bwsdpspdqrhefx Agzei control: SIEMENS 840D tool changing device: 60 positions Pallet size: 1250 x 1250 mm spindle: 20 kW rapid traverse X-Y-Z: 18 m/min table load: 3 / 5 t MACHINE DETAILS machine weight: approx. 15 t Space requirement: approx. 10.5 x 8.5 x 4.1 m EQUIPMENT NC rotary table 2-fold pallet storage Control panel for loading station IKZ 3D measuring probe Chip conveyor Packing for international transport is exclusive! EXW provision is also possible.

Condition: excellent (used), Year of construction: 2002, Disc diameter 50 mm 7.5 kW motor Bwedeuxnpcspfx Agzei 3 sorters The length of the automatic feeder is 4 m The length of the receiving feeder is 6 m Cutting cross-section 300x100
