CNC Lathe DMG MORI NRX2000 MC
DMG MORI NRX 2000 MC

Name: DMG MORI NRX 2000 MC
Brand: DMG MORI
Availability: InStock

Year of construction

2017

Condition

Used (fully functional)

Location

Saint-Genix-les-Villages France

CNC Lathe DMG MORI NRX2000 MC DMG MORI NRX 2000 MC

Basic data

Machine type:: CNC Lathe DMG MORI NRX2000 MC

Manufacturer:: DMG MORI

Model:: NRX 2000 MC

Year of construction:: 2017

Condition:: reconditioned (used)

Functionality:: fully functional

Operating hours:: 12,270 h

Price & Location

Location:: Le Jasmin, 73240 Saint-Genix-les-Villages, France

Call

Technical details

Dimensions and weight

Overall weight:

5,700 kg

Spindles

Spindle nose:

JIS A2-5

Spindle speed (max.):

6,000 rpm

Tool turrets

Number of driven tool stations in tool turret 1:

Number of tool stations in tool turret 2:

Power details

Input voltage:

400 V

Type of input current:

three-phase

Axis specifications

Travel distance X-axis:

100 mm

Travel distance Z-axis:

220 mm

Rapid traverse Z-axis:

30 m/min

Rapid traverse X-axis:

30 m/min

Further details

Turning diameter:

150 mm

Details about the offer

Listing ID:: A21664863

Reference number:: 90179

Update:: 16.04.2026

Description

CNC Lathe DMG MORI NRX2000 MC

TECHNICAL CHARACTERISTICS:

Year of manufacturing: 2017
CNC control: MITSUBISHI M730UM
Max. turning diameter: 150 [mm]
Stroke X axis: 100 [mm]
Stroke Z axis: 220 [mm]
Rapid traverse rate X1 axis: 30000 [mm/min]
Rapid traverse rate X2 axis: 30000 [mm/min]
Rapid traverse rate Z1 axis: 30000 [mm/min]
Rapid traverse rate Z2 axis: 30000 [mm/min]
Spindle nose: JIS A2-5
Max. machining length spindle 1: 100 [mm]
Max. machining length spindle 2: 100 [mm]
Max. spindle speed - Spindle 1: 6000 [rpm]
Max. spindle speed - Spindle 2: 6000 [rpm]
Live tools power - Turret 1: 1.5 [kW]
Live tools power - Turret 2: 1.2 [kW]
Number of tool stations - Turret 1: 10
Max. speed driven tools - Turret 1: 10000 [rpm]
Number of tool stations - Turret 2: 10
Max. speed driven tools - Turret 2: 10000 [rpm]
Total power required: 38 [kVA]
Supply voltage: 400 [V]
Working hours: 12270 [h]
Weight: 5700 [Kg]

INCLUDED EQUIPMENT:

x1 gantry loader
x2 workstockers (left + right) for raw materials and finished workpieces
x1 RENISHAW workpiece touch probe, type RLP40 (NEW)
x1 drill bit breakage detection sensor (for turret N°1)
x19 static tool holders
x4 axial driven tool holders
x2 KITAGAWA collet chucks, type KLAMP DKF65
x2 three-jaw chucks
x1 status indicator lamp
x1 coolant gun
Knedjyzgc Uspfx Aamsc
x2 remote electronic handwheels (Jogwheels)
x1 oil mist extraction unit
x1 chip conveyor
x1 high-pressure coolant unit, 35 [bar]
x1 SIEBEC cutting fluid filtration unit type MP52D-AP18
x1 set of grippers for the gantry loader
x1 set of axle clamping brackets for machine transport
x1 complete set of manuals (users manual, programming manual, electrical diagrams, gantry loader manual...)

Machine visible under power in our premises by appointment.

Price on request, loading on truck included.

Possibility of shipping Worldwide.

The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed.

Machine tool similar to a mill-turn center, machining center, and milling machine, and to brands such as Schaublin, Index, Mori Seiki, Traub, Tsugami, Star, Tornos, Biglia, Nakamura, Miyano, DMG, Mazak.

CNC lathe, NC lathe, digital lathe, machining center, NC milling machine, CNC milling machine, digital milling machine, Fanuc, iTNC, TNC, Heidenhain, Mori Seiki, Mazak, Hurco, Nakamura, Takamura, Hardinge.
