CNC lathe

CMZ TA 20 YS-640

Condition: like new (used), Year of construction: 2022, CMZ TA 20 YS-640: YEAR: 2022 CNC: Fanuc 32i FEATURES: Swing over bed: 760 mm Swing over carriage: 600 mm Maximum turning diameter: 460 mm Maximum turning length: 640 mm Distance between chuck faces: 649 mm X-axis travel: 310 mm Z-axis travel: 640 mm Y-axis travel: +70 / –50 mm Rapid traverse X / Z / B: 30 m/min Rapid traverse Y: 15 m/min MAIN SPINDLE: SMW 210 mm chuck Bar capacity: 66 mm Spindle speed: 4,000 rpm Power: 22 / 15 kW at 366 / 286 Nm Spindle nose: ASA 6 A2 Spindle bore: 73 mm Djdpfeyzfbvex Ag Dskk TURRET: 12-station turret, all positions live tooling Max. live tool speed: 12,000 rpm Power: 11.3 / 8.1 kW Max. torque: 75 Nm SUBSPINDLE (Servo): SMW 175 mm chuck Chuck bar capacity: 56 mm Max. usable bar: 52 mm Spindle speed: 4,500 rpm Power: 14 / 18 kW Spindle nose: ASA 6 A2 Machine dimensions: 2,542 x 1,760 x 2,120 mm Weight: 7,500 kg EQUIPMENT: SMW Autoblok BBD 250 chuck SMW Autoblok BBD 175 chuck Tool presetter Servomotor for sub-chuck Set of tool holders including 2 live tool holders Chip conveyor Cycle end lamp High-pressure pump Manual/automatic parts catcher arm (80 x 220 mm – 8 kg) Parts ejector for sub-spindle Interface for bar feeder and mist extractor Set of fixed and live tool holders Set of 3 jaws for each chuck TOP AUTOMAZIONI X-files S-364 SX bar feeder, 3,200 mm/diameter 64 mm MACHINE CONDITION: Machine in excellent, as-new condition! Can be seen in operation.

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, CMZ TA-30-YS-640+GL20II CNC Lathe with Gantry Loader The machine is in very well-maintained condition. Currently, we have two CMZ machines in stock: one equipped with a sub-spindle, the other without a sub-spindle but with a tailstock. Technical data: Year of manufacture: 2018 Control: Fanuc 32iTB iHMI Swing diameter over bed: 760 mm Swing diameter over cross slide: 600 mm Maximum turning diameter: 460 mm Distance between centers: 689 mm Chuck to chuck distance: 625 mm X-axis travel: 310 mm Z-axis travel: 640 mm Y-axis travel: +70/-50 mm B-axis travel: 640 mm Rapid traverse (m/min): 30/30/15/30 Maximum spindle speed: 3,500 rpm ASA 8" A2 Maximum sub-spindle speed: 4,500 rpm ASA 6" A2 Spindle bearing Ø external: 200 mm Spindle bearing Ø internal: 130 mm Spindle bore: 86 mm Bar capacity: 78 mm Number of tool stations: 12 (all live), 12,000 rpm Tool holder: 25x25 (50) Machine weight: 6,500 kg Dkodpfx Agsyhqg No Dek Dimensions (machine only): 2542 mm x 1760 mm x 1880 mm
