Tailstock

VDF

Condition: refurbished (used), Year of construction: 2022, turning diameter over bed: 540 mm turning diameter over slide rest: 280 mm turning length: 1.500 mm Gtodpfx Ajykaxaefnsu turning diameter in the recess: 580 Working travel of the lower slide max. approx.: 415 mm adjustment of upper support, max. approx.: 140 mm turning speed range: 0 - 1.800 U/min diam. of main spinde: 135 mm spindle bore: 68 mm internal taper diameter: 73 mm bed width: 403 mm Equipped with: Three jaw chucks FORKARDT 250 Digital read out 3 axis fixed steady rest feed safety chip tray several tool holders, 6 chisel holders, 1 holder for clamping sleeve

Condition: used, functionality: fully functional, Year of construction: 2013, Sahinler HPK 200 Hydaulic section and pipe bending machine Mil and Shaft Diameter: 200mm Tool and Roll Diameter: 900mm Working Speed: 2-5 m/min Motor Power: 30 kW Bending capacity x15x4 273x5.6 / 10000 mm Diameter biggest roll 9"x6,3 / 4000 mm Diameter top roll 650 mm Diameter upper roll 650 mm Roll capacity section - 3 200x200x18 / 5000 Shaft diameter 200 mm Top roll x15 with prebending min.120x120 / 3000 mm Voltage 3x400 V Godpfx Aow D Uqxsfnotu Working speed 2-5 m/min Power Power max. 30000 W Height 2300 mm Length 2400 mm Width 3400 mm Weight15000 kg

Condition: good (used), Year of construction: 1957, Ref. -No.: 10573 Manufacturer: VDF Type: W 40 Year of construction: 1957 Gtodpfx Afsxmd Upjnou Type of control: Konventionell Storage location: Halberstadt Country of origin: Germany Machine-No.: 030XXXX Turning Diameter: Ø 960 mm Turning Length: 4500 mm Spindle Speeds: Ø 105 RPM Turning diameter over cross slide: Ø 600 mm Further information: The machine can be viewed under power by arrangement.

Condition: ready for operation (used), Year of construction: 1972, Immediately available from university: Boehringer VDF L & Z Lathe Type E 560 Year of manufacture: 1972 Very few operating hours Centre height: 305 mm Swing over bed: 610 mm Turning length: 4,000 mm Swing in gap: 810 mm Swing over cross-slide: 375 mm Spindle bore: 82 mm Gtsdeyir Scopfx Afneu Spindle speeds: 7 – 1,400 rpm Drive: 12.5 kW Heidenhain digital readout Chuck Faceplate Multifix toolholder with many inserts Steadies Weight: 7 t Price: EUR 12,500 plus VAT ex location

Condition: excellent (used), axle configuration: > 3 axles, loading space length: 17,840 mm, loading space width: 1,750 mm, tire size: 9.50R17,5, wheelbase: 1,350 mm, color: blue, Year of construction: 1992, Color: blue Payload: 43,600 kg Extendable Manufacturer: Goldhofer Type: STZ-VL4-44-80 Extendable Low Loader Chassis number: WG0STZV47N0020238 Year of manufacture: 1992 Weights: - King pin load: 24,000 kg - Axle load: 10,000 kg - Total axle load: 40,000 kg - Gross vehicle weight (GVW): 64,000 kg - Unladen weight: 20,400 kg - Payload: 43,600 kg Axles: - Axle manufacturer: BPW - Air suspension - All axles with hydraulic steering - High/Low valve - ABS braking system - Tyre size: 9.50R17.5, double mounted - Load index: 143/141 J Dimensions: - Length: 17,840 mm - Extensions: 4,000 mm - Maximum extended length: 21,840 mm - Loading platform length: 8,000 – 12,000 mm - Loading platform width: 2,750 mm - Height: 600 mm (+/-100 mm) - King pin height: 1,300 mm Additional Information: - Hydraulic connections for truck hydraulics - Lashing rings - 2x spare wheels - Detachable gooseneck - Hydraulically operated gooseneck - Working lights - Rear bumper with lights - King pin 3.5” - Schübler lubrication system - Outriggers for loading platform widening - Fixed ramps on loading platform - High/Low valve = Further Information = General Information Year of manufacture: 1992 Axle Configuration Tyre size: 9.50R17.5 Axle brand: BPW Rear axle 1: double tyres, max axle load: 10,000 kg, steered Rear axle 2: double tyres, max axle load: 10,000 kg, steered Rear axle 3: double tyres, max axle load: 10,000 kg, steered Rear axle 4: double tyres, max axle load: 10,000 kg, steered Weights Unladen weight: 20,400 kg Payload: 43,600 kg Gross vehicle weight: 64,000 kg Functional Extendable body: Yes Condition Technical condition: very good Visual condition: very good Damages: none Gtjdpfeuu Hbhjx Afnou Financial Information Price: On request Further information Please contact Stefan Schaapveld for more information.

Condition: used, Heidenreich und Harbeck VDF lathe, generally in good condition for its year of manufacture. Comes with 3-jaw and 4-jaw chucks. Feel free to contact us with any questions. Gjdpoyhzxtofx Afnjtu

Condition: good (used), 1 used, very well-maintained L+Z lathe with 3-axis digital readout, HEIDENHAIN make, model VRZ 773 B Manufacturer: VDF Heidenreich & Harbeck, Origin: Germany Model: S 500 Gtodpfxeyf H Uke Afnsu Year of manufacture: 1966 / 1998 geometrically overhauled! Technical Data: Centre height: 250 mm Centre distance: 1000 mm Swing over bed: 530 mm Swing over cross slide: 280 mm Spindle bore: 62 mm Spindle mount DIN 55027: Size 8 Speed range, 24 steps: 9 – 1800 rpm Feed, longitudinal: 0.0071 – 2 mm/rev Feed, cross: 0.0028 – 0.8 mm/rev Threads, metric: 0.2 – 224 mm imperial: 1/8 – 140" module: 0.05 – 56 M diametral pitch: ½ - 400 DP Tailstock taper: MK 5 Main drive power: 15 kW Floor space (L x W x H): 3500 x 1350 x 1350 mm Weight: 2650 kg Accessories / Special Features: • 3-axis digital readout, HEIDENHAIN model VRZ 773 B • 3-jaw chuck, diameter 315 mm, FORKARDT F 315 with safety pin • 1 set of hard top jaws with hard base jaws • 1 set of soft top jaws with hard base jaws • Quick-change tool post system MULTIFIX size B, with 1 insert • High drive power: 15 kW • Coolant system • Chip tray • Bed stop New electromagnetic brake installed in 2021 for €5,800.00 net Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: excellent (used), functionality: fully functional, Year of construction: 2016, control type: NC control, degree of automation: automatic, actuation type: hydraulic, controller model: 4 axis with digital readout, number of rollers: 4, roller (top) diameter: 360 mm, side roll diameter: 320 mm, roller diameter: 400 mm, roller length: 3,050 mm, working width: 3,000 mm, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, sheet thickness stainless steel (max.): 26 mm, overall weight: 17,400 kg, total length: 5,500 mm, total width: 2,010 mm, total height: 1,900 mm, power: 18.5 kW (25.15 HP), input voltage: 400 V, input frequency: 50 Hz, Equipment: cone bending device, documentation/manual, emergency stop, hardened rollers, 4RH17/5NC capacity 3000 x20 mm Gsdpfjxqyxljx Afnstu 4roll plate bending machine NC Imcar year 2016 Capacity plate width 3000 mm Plate thickness 20 mm Prebend 16 mm Central rolls 360 mm Side rolls 320 mm Surface useful on rolls 3050 mm Power supply 380/50 electric 25 Hp on centralized hydraulic unit Weight 17 Ton Dimension 5500x 2010 x H 1900 mm Configuration as shown on photo enclosed Hardened rolls very high surface resistance Conical bending attachment Digital readout NC programmable 4 axis Central support vertical motorized Roller table with hydraulic side arm Safety and emergency installed per norms Hydraulic rolls power driven with planetary gear unit Hydraulic motion of rollers individual with dual initial pre-pinch Open front drop-end hydraulic to unload the closed shells

Condition: excellent (used), Year of construction: 2004, Please read the technical specifications thoroughly. If you are considering this machine as a potential investment, we kindly request your complete credentials with an accurate telephone number and email address in order to submit an offer. We are offering an exceptionally high-quality precision lathe. In its class, this is arguably the best German lathe ever built. BOEHRINGER Precision Lathe Model DUE 500 Year of manufacture: 2004, incl. CE certificate and central lubrication Machine no.: T1022.2027-00 Centre height: 240 mm Swing over bed: 500 mm Swing over cross slide: 285 mm Centre distance: approx. 1,200 mm Turning length (effective): approx. 1,000 mm Bar capacity: 62 mm Spindle nose: DIN 55027 size 6 Spindle diameter: 100 mm Drive power: 11 kW Max. torque: 2,000 Nm 24 spindle speeds: 11.2 – 2,240 rpm 60 cross feeds: 0.03 – 28 mm/rev 60 longitudinal feeds: 0.06 – 56 mm/rev Tailstock quill travel: 190 mm Tailstock taper: MK 5 Space requirement: approx. 4,000 x 1,525 mm (L x W) Weight: approx. 4,300 kg Accessories included: - 3-axis digital readout HEIDENHAIN - Central lubrication - Electrically interlocked chuck guard - Coolant system - Chip protection rear wall - Röhm lathe chuck T 250 mm incl. various clamping jaws - Telescopic cover for leadscrew and support to bed - Machine lamp - Multifix C tool post + 4 holders - Live centre - Operating manual - Circuit diagram - Rapid traverse in longitudinal and cross slide Condition: The machine is in very good technical and visual condition. Backlash in cross slide: approx. 0.3 mm, top slide: approx. 0.15 mm Gedpfew Rdthjx Afnstu Spindle nose runout: approx. 0.006 mm Bed geometry: deviation approx. 0.01 mm over 750 mm of bed length (measured on flat guideway with dial indicator towards the chuck) The following parts have been renewed: - Oil change - New hoses for central lubrication - New wipers - Key for engagement lever replaced - Locking pin for engagement interlock replaced Net price EXW. Delivery with our own truck can be offered for an additional charge.

Condition: excellent (used), Steadies for lathe VDF BOEHRINGER Type: V 800 Gtedpfxoyfny Uj Afnju 1. Fixed steady 1. Travelling steady In very good condition.

Condition: excellent (used), Herringbone Gear Generator MDV 2000 MDV 2000 Characteristics: Gtedefx Ibnepfx Afnsu Max wheel diameter: 2000 mm Min wheel diameter: 50 mm Max module: 12 Min module: 3

Condition: ready for operation (used), Lead and feed screw lathe Manufacturer: VDF Model: MA22 Max. turning length: approx. 1000 mm Centre height: approx. 150 mm Spindle bore diameter: 60 mm With 3-jaw chuck, manufacturer FORKARDT, diameter: 200 mm Gsdpfx Aoyfnabofnstu Coolant system and Multifix quick-change toolpost

Year of construction: 1993, condition: good (used), CNC lathe cycles Fabr.VDF BOEHRINGER type: DUC 560 BJ. 1993 with SIEMENS SINUMERIK 805T control. Turning length: 1000 mm Gjdpfed Ewaaox Afnstu Turning diameter over plan support: 365 mm Turning diameter above bed: 570 mm Spindle speeds: 3-2500U/min spindle motor: 19KW Spindle bore: 62 mm Chuck diameter: 315 mm Forkardt Turret head with 8 POS. VDI 30 With accessories and equipment documentation.

Condition: like new (used), functionality: fully functional, How do you do? We are offering used and compatible clamping devices from Erowa. These are suitable for die sinking and milling. Here are some of the available parts: ER-008617 Plug gauge ER-010723 Control mandrel ITS 50 ER-010561 Replacement probe pin ø 2mm ER-010560 Replacement probe pin ø 5mm ER-093992 Square 25 holder C F-Tool holder with square 25 ER-010592 Square 25 Alignment ruler ER-010495 Square 15 alignment ruler ER-129072 Uniplate Collet holder ø 72 ER16-ER50 Table probe with magnetic base 3D probe ø1-5 Steel pallet ø148mm Gtsdpsvby U Sjfx Afnju All parts have been cleaned and checked by us. A functional test was also carried out. Spare parts are available. Do you have any questions? Then please do not hesitate to contact us.

Condition: good (used), Year of construction: 1962, Centre lathe manufacturer VDF HEIDENREICH&HARBECK type: 24 RO, year of manufacture 1962, overhauled in 1992. Equipped with 3-axis digital readout Heidenhain, 250 mm Forkardt chuck, Multifix B toolholder. Centre height: 255 mm Swing over bed: 510 mm Swing over cross slide: 270 mm Distance between centres: 1000 mm Gsdpfx Afexziuwonetu Spindle bore: 55 mm Spindle speeds: 20 - 900 rpm, Motor power: 6.5 kW The machine is in good condition, electrical diagrams available. Required floor space: Length 3 m, Depth 1.2 m, Height 1.3 m, Weight approx. 1800 kg.
