Used Scm Fs 520 for sale (649)

Condition: used, Year of construction: 2013, .30 Base machine ACCORD 30 FX N. 1 CONCEPTCNC machining center with a moving gantry and a fixed worktable for processing various sheet-like materials: chipboard, MDF, laminated solid wood, plastic materials, and light alloys. STRUCTUREThe machine is developed using the best three-dimensional CAD systems for solid modeling. The machine bed and moving crossbeam represent the two main elements of the machine structure and are manufactured in the company's own foundry. All mechanical machining operations are carried out on special production equipment in a single setup to ensure optimal precision and to minimize tolerances during machining. The control cabinet is mounted directly on the machine bed, allowing for a very compact design and easy access. CONTROL UNITThe control unit consists of an industrial NC control system with an integrated office PC (desktop computer). The CNC solution with an office PC combines all the features of numerical control with the typical user-friendliness of an office PC, which greatly simplifies the control of the machine by enabling the use of the XILOG MAESTRO user interface, i.e., the software developed by SCM for simple and fast programming, even for non-experts. GENERAL FEATURESPassage height: - 250 mm with H50 accessories- 190 mm with H110 accessoriesPendulum machiningAutomatic lubrication of the axesAir conditioning system to maintain the correct internal temperature in the control cabinet. Software for remote customer serviceOperator interface Xilog MAESTRO with integrated CAD/CAM, which allows for the extremely simple execution of products even with special shapes.A number of advanced functions allow for: - programming via macros- creating and managing subprograms- optimizing machining- managing all machine functions- creating and managing a database of tools93.07.31 Voltage 400 EU 93.12.01 Frequency 50 Hz R0.00.03 LINGUA P.C. GERMAN 02.12.57 ACCORD 30 FX - Worktable X-Y = 3680x1380 56.05.25 No. 6 Support rail MATIC - L1300 The worktable is equipped with: - no. 2 lateral fixed supports- no. 6 aluminum supports, motor-driven and movable along the X-axis- motorized conveyor belt for unloading chipsEach movable support has: - no. 3 motor-driven support rails for clamping cylinders and vacuum suction cups- air blower for cleaning on each movable support- pneumatic locking/release for quick replacement of the clamping cylinders and vacuum suction cups- preparation for lifting devices- preparation for reference stopsThe workpiece vacuum clamping system is divided into 2 independent worktables.23.02.19 DUO Prisma K working unitThe working unit with 5 interpolating axes is located on the moving crossbeam, which provides maximum stability during milling and thus also ensures optimal machining quality of the workpieces, even with high material removal rates. It allows for rotation around the axes arranged at 50° to each other and has many advantages over traditional 5-axis working units, such as: - the full use of the work areas both with 5 axes and with a vertical spindle- spindle external dimensions outside the working area- a particularly light design for horizontal machiningThe unit has a central chip extraction system. Hedpfx Ajzl Ap Nec Tst

Condition: excellent (used), Year of construction: 1993, Manufacturer: SCM Model: T150 Class Year of manufacture: 1993 Motor upgraded: 5.5 kW Tilting range: -10° to +45° Electromagnetic brake Motor with 2 speeds / pole-changeable Speed settings: 3000/4500/6000/7000/10,000 rpm Forward/reverse rotation Table size: 2700 x 700 mm Spindle diameter: 30 mm Table extension: 2 x 650 mm Extendable frame support Aluminum fence jaws Milling fence with fine adjustment - Electric height adjustment - Electric tilt adjustment Feeder: Wegoma VS 44 - 4 rollers Extraction connection: 120 x 120 mm Hsdeyx Nadspfx Ac Tot Space requirement: approx. 2700 x 1300 x 1600 mm Weight: approx. 1000 kg Location: 54634 Bitburg, loaded free on truck, unpacked Delivery as-is, as inspected and function tested without refurbishment, without warranty or guarantee

Condition: excellent (used), CATALOG NUMBER: 7947 Technical specifications: - Track width: 300 mm - Shaft working width: 300 mm - Max. saw blade diameter: 350 mm - Saw blade bore diameter: 70 mm - Max. cutting height: 120 mm - Table width with extension: 750 mm - Table length: 1540 mm – From above: - Kickback barriers (anti-return block for material) - Metal roller guide - Kickback barriers - Metal roller guide - Shaft with saw blades - 2 smooth metal idler rollers – From below: - Guide rail - Kickback barriers - Track (caterpillar) - Central track lubrication - Stepless feed speed adjustment - Feed motor: 1.5 kW - Main motor: 37 kW - Extraction port diameter: 200 mm - Overall dimensions (L/W/H): 1800x1550x1500 mm - Weight: approx. 1700 kg Hedpfezw Dw Ssx Ac Tjt Advantages: – Italian manufacture – Very good condition – DTR technical documentation – Used multirip saw Net price: PLN 33,900 Net price: EUR 8,070 (based on EUR/PLN 4.2) (Prices may change with significant exchange rate fluctuations)

Condition: used, Year of construction: 2023, Special price – Showroom machine Garbsen INDUSTRIAL AUTOMATIC EDGE BANDING MACHINE stefani md (the images of the machine are not binding with regard to the actual features specified below) KEY FEATURES EDGE BANDING OF SOLID WOOD UP TO 15 MM THICKNESS: SIMPLE AND FUNCTIONAL PROCESSING OF EDGES WITH LARGE DIMENSIONS "SGP" GLUE TANK: USE OF EVA AND POLYURETHANE GLUE FOR A PERFECT GLUE JOINT "STARTOUCH" CONTROL: A TOUCH IS ALL IT TAKES TO OPERATE THE MACHINE GENERAL FEATURES Automatic single-sided edge banding machine for applying edge banding with hot melt adhesive to the four sides of straight panels and for subsequent finishing. Machine frame and longitudinal supports made of cold-rolled steel in a box construction, manufactured in a single element, for high rigidity and vibration-free operation to accommodate the working units. Openings with slides for discharging any remaining chips to the floor. Upper pressure beam made of thick-walled steel construction and with columns made of cast iron, for a vibration-free structure where the working units are attached. Pressure rollers on the feed chain in a double row, made of rubber with a high coefficient of friction and with sliding on bearing rollers. Device to protect the pressure rollers from any remaining chips. Electronic adjustment of the upper pressure unit, depending on the panel thickness. Upper working units attached to the pressure beam or mechanically connected to ensure automatic adjustment when changing the panel thickness. Lower working units attached to the machine frame or to the longitudinal support, for a precise reference to the panel. All high-frequency motors are operated via frequency inverters. Protective cover for all units positioned after the gluing unit. Windows made of polycarbonate ensure a good view of the units during processing. Interior lighting of the cabinet. Protective cover with sound-absorbing material for lower noise emissions during processing. The spacer on the infeed guide allows the machine to be fed in the correct spacing. The spacing is automatically adjusted to the selected feed speed. Extraction nozzle arranged on the soundproof hood. Swivel control panel in an ergonomic position at the machine infeed. The electrical system complies with current regulations. Electrical components housed in a metal housing, attached to the machine frame and provided with doors for convenient access during any maintenance work. Panel feed The panel feed is carried out via a feed chain consisting of rubber sliding blocks with a high coefficient of friction, attached to a 1-1/4" industrial chain. The chain slides on 2 guides made of hardened and ground steel, a round guide and a flat guide, to guarantee a straight feed and protect against lateral displacement. Automatic lubrication of the chain. The amount of lubricating oil is optimized by the control system depending on the panels being processed. Support roller track externally and positioned along the entire length of the machine; consisting of an extendable opening system with sliding on linear bearings and plastic sliding rollers with steel pivot pins. "STARTOUCH" CONTROL Main features: 12" touchscreen color display Graphical representation of all processing units and their status (on/off) Hodpszc Ilxofx Ac Tet

Condition: new, Year of construction: 2025, Working width: 25 - 230 mm Working height: 10 - 120 mm Minimum workpiece length: 450 mm Feed rate: 5 - 25 m/min Hodpfxezwvpas Ac Tot Spindles: bottom, right, left, top, universal Surfacing spindle: 4 kW Both vertical spindles: 5.5 kW Spindle (top): 4 kW Universal spindle: 4 kW Spindle diameter: 40 mm Spindle speed: 6000 rpm Machine available ex works, without tools.

Condition: excellent (used), CATALOG NO. 7911 TECHNICAL DATA - Number of spindles: 29 pcs - Distance between outermost spindles: 900 mm - Spindle pitch: 32 mm - Table surface: 700x1220 mm - Table height: 930 mm Hedpfszwpaxex Ac Tst - Pneumatic clamps: 3 pcs - Drilling vertically, horizontally, and at an angle - Vertical/horizontal operation – pneumatic table adjustment - Pneumatic lifting of drilling head - Dimensions (L/W/H): 1400/1050/1400 mm - Weight: 744 kg ADVANTAGES – Manufactured by Italian brand SCM – For 29 drills – Not repainted – Very good condition – Used drilling machine Net price: 5,900 PLN Net price: 1,400 EUR at an exchange rate of 4.2 EUR (Prices may change with significant exchange rate fluctuations)

Condition: excellent (used), CATALOGUE NUMBER 8037 TECHNICAL DATA - Max. width of the workpiece: 1100 mm - Max. height of the workpiece: 160 mm 2 units: 1) Metal, grooved roller for calibrating 2) Rubber, grooved roller + pneumatic sequential apron + metal roller - Motor power: 15 kW - Brake - Top: - Rubber roller, slip, split - Unit - Rubber roller, slip, split - Unit with apron - Rubber, slip, split output roller - Bottom: - 2 metal rollers, slip - Conveyor belt - 2 metal rollers, slip, output - Pneumatic belt oscillation with photocell - Electric table lifting - 2 feed speed types - Feed motor: 0.45 kW / 0.8 kW - Grinding thickness potentiometer - Working pressure: 8-10 bar - Diameter of dust extraction nozzle: 2 x 160 mm - Overall dimensions (L/W/H): 1900 x 1700 x 2000 mm - Weight: 1413 kg ADVANTAGES - Made in Italy, SCM brand - 2 units Hjdozmh U Hjpfx Ac Tst - Grinding thickness potentiometer - Pneumatic sequential apron - Not painted - DTR documentation - Used sander, very good condition Net price: 32,900 PLN Net price: 7,830 EUR Net price calculated based on an exchange rate of 4.2 PLN/EUR (the price may change in the event of significant exchange rate fluctuations)

Condition: excellent (used), CATALOGUE NUMBER 8028 TECHNICAL DATA - track width 300mm - working width of the roller 300mm - max. disc diameter 350mm - disc bore diameter 80mm - max. cutting height 120mm - table width 750mm - table length 1540mm * from above: - pushers (barrier protecting against material kickback) - sliding roller, metal, pressure roller - pushers/pawls - sliding roller, metal, pressure roller - roller with saw blades Hodpszmfr Aefx Ac Tot - 2 smooth, metal sliding rollers * from below: - guide rail (pneumatically adjustable) - pushers/pawls - track - central track lubrication - stepless feed speed adjustment - feed motor 1.1kW - main motor 25kW - dust extraction nozzle diameter 1x200mm, 1x120mm - overall dimensions L/W/H 2430x1530x1450mm - weight 1540kg ADVANTAGES – Made in Italy – Guide rail – pneumatically adjustable – Very good condition – Used multi-blade saw Net price: 38900 PLN Net price: 9262 EUR, depending on the exchange rate of 4.20 EUR (Prices are subject to change due to higher fluctuations)

Condition: used, heavy-duty precision panel saw SCM SI 550 E Class Version: Carpentry - Joinery Cutting length 3200 mm Hedpfx Aozi Sctoc Tot Cutting width approx. 1500 mm Main motor 11 kW 3 speeds: 2500/3000/4200 rpm Mitre fence with length compensation Saw blade up to Ø 550 mm Electric height adjustment and tilting of saw blade with digital displays Machine from retirement / first delivered in 2011 Machine is WORKSHOP TESTED and in EXCELLENT CONDITION Available from stock Lieboch

Condition: good (used), Year of construction: 1985, Used machine Equipment and technical data: - 4-knife planing cutter block - Surfacing: - Working width: 500 mm Hjdpfx Acozpa Uko Tot - Total table length: 2200 mm - Motor: 4 kW - Thicknessing: - Minimum working height: 3 mm - Maximum working height: 230 mm - Maximum chip removal: 8 mm Availability: immediate Location: in stock at warehouse 54634 Bitburg - immediately available -

Condition: used, Technical data: Hsdpszryw Rjfx Ac Tot - Conveyor belt width: 150 mm - Motor: 3 kW - Weight: 490 kg

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, SCM edge banding machine, model K 201, CE mark, complete with control console, edge banding area for workpieces up to 3 mm material thickness and 45 mm material width, reinforced roller separation up to 3 mm, strip magazine, workpiece guidance via chain with roller top pressure, central adjustment of top pressure, frequency inverter, HF cross-cut saw unit, HF radius milling unit, motors with quick-change system, soundproof hood, digital glue temperature control, underfloor gluepot, glue application via roller dosing system, extendable roller rail, central extraction nozzle. Hsdpeyath Hjfx Ac Tot

Condition: new, Year of construction: 2025, heavy-duty construction with cast iron table smooth movements using hand lever and handwheel Hodpfx Asycg U Esc Tst eccentric clamping device dowel drilling unit with 16-22-25-32 mm grid 2 spindle speeds: 1500/3000 rpm WESCOTT drill chuck 1 - 16 mm CE compliant Work table dimensions: 287 x 550 mm Longitudinal travel: 200 mm Vertical travel: 160 mm Cross travel: 125 mm Three-phase motor power: 1.8 kW, 400 V, 50 Hz

Condition: like new (used), Year of construction: 2023, SCM Accord 40 fx CNC machining center with the following equipment: Working area X-Y = 6360 x 1905 mm, Z = 350 mm OF0158 Usable Z clearance height = 350 mm with H50 suction cups OF0165 Axis travel speed of Accord 40 fx Version PRO-SPEED OF0168 Pendulum (dual-zone) operation OF0169 Automatic axis lubrication OF0299 TELESOLVE remote maintenance via Internet 450328 eye-M PRO control console with integrated PC 450291 Additional fixed control panel 870068 TECPAD – remote control of machine functions 560058 No. 10 carrier rails MATIC – L1825 230429 MAXI working unit – Prisma KT 1 870046 Prepared for angle gearbox "Prisma KT-KS" Hedpfsyfgzdox Ac Tet 470014 Air nozzle for tool 870119 Device for tool length measurement 870120 Device for panel thickness measurement 870009 Drilling unit F16 OF0176 Front stop row H50 for worktable with 10 carrier rails 510205 Preparation for clamps for worktable with 10 carrier rails 480178 Front stop row H110 for worktable with 10 carrier rails 480105 Rear stop row H110 for worktable with 10 carrier rails 480137 First lateral stop row H110 for worktable with 10 carrier rails 480005 Suction cups H110, 145x145 mm, 36 pcs 480006 Suction cups H110, 145x55 mm, rotatable, 10 pcs 480007 Suction cups H110, 180x65 mm, rotatable, 10 pcs 480018 Suction cups H110, 145x30 mm, rotatable, 5 pcs 480410 Lifting devices H110, 8 pcs 350016 Vacuum pump 250 (300) m³/h 560538 Additional automatically adjustable base for MATIC 10 carrier rail 190046 PRO-SPEED safety system 524800 "SAV€NERGY" 2.0 energy saving system 210837 TR12 – lateral tool magazine 210056 Rapid 24 – rear tool magazine OF0182 Air conditioning for control cabinet OF0438 Human-machine interface software (HMI) MAESTRO ACTIVE OF0543 Operating system Windows 10 embedded 64 bit OF0422 Machine operating interface software Maestro cnc OF0435 Hardware dongle for Maestro cnc 524309 Maestro 3D-Advanced module 109993 MACHINE LANGUAGE: German SPECIAL FEATURES INCLUDED IN MACHINE CONFIGURATION: - Extension of maximum panel width to 2,120 mm for full processing; traverse length remains unchanged at 1900 mm. - 10 support suction cups for remnants MACHINE ALREADY DISMANTLED AND STORED. LIST PRICE 2023 EUR 399,890.--

Condition: new, Rusticating machine for wooden artefacts such as boards, profiles, beams and strip wood for flooring, with maximum width 40 or 60 cm x 30 cm high. hight adjustment via hand wheel and numerical read out brush DM 200 mm machine in CE working width 600 mm max. working height 300 mm suction DM 2 x 140 mm motor feeder 0,37 kW feeder speed variabel 3 - 20 m/min motor brushing aggregate each 4,0 kW machine weight approx 750 kg inkl. 1 steel brush DM 200 mm 1 TYNEX brush DM 200 mm Advise used machines: • Technical data without obligation, mistake and intermediate sale reserve. • Price is considered ex-location price • All articles or machines are bought as seen without any entitlement on warranty. • It is left to the choice of the buyer to view the machines before at its location. • Special arrangements are possible but only valid in written form. Hedjdd Hi Ejpfx Ac Tot (We answer your inquiries only with stated address + telephone number!)

Condition: as good as new (ex-display), 21-spindle single-head drilling machine, suitable for all carpentry needs, ideal for joining a work center to save time and release it from horizontal drilling operations. PNEUMATIC HEAD ROTATION - with lock and stop reference from 0° to 90°at any angle. SIDE REFERENCE FENCES - Adjustable cast iron fences on a metric scale thanks to a magnify glass and nonius. PATENTED SPIRAL SYSTEM - Device for boring depth adjustment, allowing an easy and quick set-up on a millimetric scale according to the different drill lengths. no of drilling spindles 21 # distance between drilling spindles 32 mm working width 640 mm max drilling depth 65 mm no. of pneumatic work piece clamps 2 # work piece dimensions max 900 x 3000 x 60 mm motor 1,5 kWm 50 Hz, 400 V, 2800 rpm Hsdpfx Ajd Supgec Tet pneumatic pressure requirement 6-8 bar compressed air consumption 10 l/cycle suction DM 80 mm machine dimensions L x W x H = 1030 x 1030 x 1285 mm weight 240 Kg

Condition: new, Clean air extraction / dust extractor Dust-tested to H3, residual dust content less than 0.1 mg/m³ Suitable for extracting and separating dry wood and plastic chips High extraction performance with low space requirement Maximum performance in this class Very quiet Designed for commercial use Robust and compact housing made of galvanized sheet steel Extraction nozzle can be easily converted from left to right for flexible use Large inspection openings Large, mobile chip container with clamping bracket and chip collection bag Dust extractor already fully assembled on delivery, so can be used quickly All models are mobile Polyester fleece filter material, aluminized, therefore with long service life Antistatic filter tested and approved to category M-BIA as standard The fan is connected downstream of the filter Efficiency class extraction motor IE3 Nominal volume flow 1448 m³/h Nominal negative pressure 2242 Pa Power drive motor 2.2 kW, 400 V, 50 Hz Chip collection volume 2 x 165 l Nominal width of external suction connection inlet 160 mm Filter area 9.21 m² Residual dust content < 0.1 mg/m³ Hedor A Eq Ropfx Ac Tjt Sound pressure level max. 73 dB(A) L x W x H approx. = 1618 x 830 x 1653 mm Weight approx. 268 kg VERSION PM Automatic filter cleaning with pneumatic system that moves a scraper frame

Condition: new, Year of construction: 2023, Stable cast iron construction Milling spindle can be swiveled backwards from 0° to -45° Right-left rotation of the milling spindle Hedpfx Ajiknp Roc Tot Generously dimensioned milling unit made of cast iron, attached directly to the table Solid and precise cast iron table Standard curved milling protection hood Aluminum sliding carriage ball contact system Torsion-resistant, highly precise, smooth-running and problem-free in daily use 10-year SCM guarantee on wear of the guideways Milling spindle mounted high up with precision ball bearings, resulting in the lowest possible bearing load and the longest possible service life Exact router fence with quick adjustment and fine adjustment with a scale on the stop jaw Integrated suction connection Large milling table opening allows the use of larger tools Weight approx. 290 kg Extraction connection diameter 2 x 120 mm Working table L x W = 1000 x 435 mm Table height 900 mm Sliding carriage length 1000 mm Sliding carriage width 270 mm Drive motor power 5.0 kW, 400 V, 50 Hz Milling spindle inclination 0 to -45 ° Spindle usable length 100 mm Overhang max. above table 130 mm Spindle speeds 3500/7000/10000 rpm Mandrel diameter 30 mm Tool diameter max. lowerable 180 mm

Condition: excellent (used), Planing width 520 mm Min./Max. working height 3 – 240 mm Motor power 5.5 kW, 400 V, 50 Hz Speed of planing shaft 4500 rpm Diameter of planing shaft 120 mm Planing knives 4 pcs Dimensions of thickness table 520 x 850 mm Feed rate 6.5 / 10 / 13 / 17 m/min Dust extraction diameter 150 mm Hedpfx Asy Egmusc Tet Electric height adjustment Handwheel for fine adjustment of thickness table height Spiral-toothed steel feed roller Segmented pressure bar 2 steel extraction rollers Table roller Low voltage release Emergency stop switch Knife setting gauge Test report for conformity with Section 4 of the AM-VO NEW V-belts NEW BALL BEARINGS NEW PLANING KNIVES Dimensions approx. L x W x H = 1120 x 990 x 1000 mm Weight approx. 600 kg Note on used machines: • Subject to errors in technical specifications and prior sale. • Prices quoted are ex-works, pick-up only – free loading! • The machine has been cleaned and function-tested. • All machines are sold as seen, without any warranty claims. The buyer is free to inspect the machines at our location. • Special agreements are only possible in written form. (We will only answer inquiries if you provide your address and telephone number!)

Condition: new, Working width (finished size) 23 – 180 mm Working height (finished size) 6 -105 mm Min. length of single workpiece 300 mm Feed speed 6 – 12 m/min Motor power horizontal spindles 2 x 7.5 kW Motor power vertical spindles 1 x 7.5 kW Spindle speed 6000 rpm Spindle diameter 35 mm Clamping length vertical spindles 120 mm Clamping length horizontal spindles 190 mm Manual lubricant pump Profile capacity without axial adjustment on vertical spindle 10 mm Los roller integrated in the outfeed table Suction DM 4 x 120 mm Hsdpfx Acsiiv Dcj Tjt Including OPTIONS: - Motor-driven feed roller in front of the planer with lever for quick changeover - Front vertical printing unit in front of the left vertical spindle - Feed table length 2300 mm - Tool package consisting of 4 planing heads and a joint rebate cutter

Condition: reconditioned (used), Year of construction: 2005, through feed moulder with 9 spindles and SCM control 100 PC control system Max. Working width 240 mm Min. Working width 25 mm Max. Working height 120 mm Min. Working height 10 mm Min. Work piece length 640 mm feed speed 6 - 36 m/ min, variabel Spindle DM 40 mm Usable length vertical spindles 140 mm Hedpfx Acog Umrmo Tst Usable length horizontal spindles 250 mm Axial adjustment vertical spindles 0 - 80 mm Axial adjustment horizontal spindles 0 - 45 mm Min and max. Tool DM 100 - 220 mm Min. And Max. Tool DM on planer spindle 120 - 140 mm Profiling capacity of 2. Bottom horizontal spindle with tool DM 200 mm = 15 mm Power feeder motor 5,5 kW DM feeder rollers 140 mm Infekt table length 2500 mm Quick adjustment indeed table and fence 10 mm Required suction capacity 7500 m3/ h Compressed air requirement 6 - 10 bar Weight approx 6000 kg Dimension approx. L x W x H = 6300 x 1620 x 1655 mm Spindle arrangement: Bottom horizontal spindle Motor 11,0 kW Spindle Speed 6000 RPM Right vertical spindle Motor 7,5 kW Spindle Speed 8300 RPM Left vertical Spindle Motor 7,5 kW Spindle Speed 8300 RPM 2. Right vertical spindle Motorleistung 7,5 kW Wellendrehzahl 8300 RPM 2. Left vertical spindle Motor 7,5 kW Spindle Speed 8300 RPM Top horizontal spindle Motor 11,0 kW spindle speed 8300 RPM 2. Bottom horizontal spindle Motor 12,0 kW spindle speed 8300 RPM 2. Top horizontal spindle Motor 11,0 kW spindle speed 8300 U/min 3. Bottom horizontal spindle Motor 7,5 kW spindle speed 8300 U/ min SET - UP quick set up system reduces down times Power Lifting of the feed system and upper spindle units with 100 PC control Pneumatic opening of safety hood full Kardan feed system Feed speed variable Segmented pressure shoe before upper horizontal spindle with parallelogram movement and pneumatic pressure Fine adjustment of outfield table Pneumatic blocking of spindle in working position incl. ZIWO CL 15 automatic feeding unit Advise used machines: • Technical data without obligation, mistake and intermediate sale reserve. • Price is considered ex-location price • All articles or machines are bought as seen without any entitlement on warranty. • It is left to the choice of the buyer to view the machines before at its location. • Special arrangements are possible but only valid in written form. (We answer your inquiries only with stated address + telephone number!)

Condition: new, The model ME 40TR is SCM’s ‘bestseller and in this category offering unrivaled price / performance ratio. We can offer the following new machine SCM me 40tr, CE Hjdpfx Acoc S Di Rj Tst Volt 400 EU, frequency 50 Hz edge thickness coils 0,4 - 3 mm max. edge thickness strips 5 mm min. – max. work piece thickness 8 - 50 mm feed speed 9 m/ min glue pot unit 0,18 kW, capacity 0,8 kg premiling aggregate 2,2 kW, 9000 U/ min end-cutting unit with "Radius" allows you to make a radius on the corners of the edged panel trimming unit 2 x 0,35 kW, 12.000 U/ min OPTIONAL device for panel preheating edge scraping unit flat scraping unit grooving unit 1,1 kW, 12.000 U/ min, notch width 4 mm brushing unit with 2 independent motors magazine for strip edges kid for quick exchange of glue unit ...

Condition: new, Multi-function machine with aluminum sliding table for sawing, milling, planing/thicknessing, and optional long-hole drilling. torsion-resistant, steel-cast iron construction machine table made of cast iron, hardened and ground smooth-running, anodized aluminum sliding table, 10-year SCM warranty on wear of the slide guides large fence system with extendable aluminum telescopic stop and folding stops with combination saw-tenon stop with 45° quick adjustment max. saw blade diameter 315 mm with optional scoring unit, swiveling from 90°-45° helical steel infeed roller for consistent wood feed during thicknessing four milling speeds, manually adjustable standard with right/left rotation of the milling spindle three independent motors for each working unit sliding table with ball contact system equipped with a ball contact system that has proven its worth millions of times permanently smooth running due to hardened and ground guides not susceptible to dust and dirt due to minimal contact point between the ball and trapezoidal rail The dust extraction ports for the planer and thicknesser are on the same – right – side. The dust extraction hose can therefore be used for both types of planers from the same side. helical steel infeed rollers for a constant and even workpiece feed massive anti-recoil guards for the operator's safety 3-knife cutterhead ensures an optimal planing result Fencing length 1600 mm max. saw blade diameter with scoring unit 315 mm max. cutting height at 90° / 45° 100/79 mm max. crosscut width to the left of the saw blade 1660 mm Hedeiiyppjpfx Ac Tet cutting width on the parallel stop 800 mm saw blade speed 3500 rpm saw blade tilt 90° - 45° Working width 300 mm planer table length 1260 mm planer shaft diameter / number of planing knives 72 mm / 3 pcs. Table dimensions 300 x 450 mm min. / max. working height 3 mm / 220 mm max. chip removal 4 mm feed rate 7 m/min Milling spindle diameter 30 mm Useful length of milling spindle 100 mm max. tool diameter 180 mm, can be countersunk Spindle speed 3500/600/800 rpm Motor power 3 x 4 kW, 400 V, 50 Hz Dust extraction port diameter 4 x 120 mm Dust extraction port diameter saw blade guard 60 mm Weight 430 kg OPTIONS: - Professional stops EUR 300.— Saw stop with quick-release lock and micrometric adjustment Planer stop with 90° ÷ 45° with continuous adjustment - Scoring unit incl. saw blade EUR 292.— - Handwheel with numerical display for thickness table positioning EUR 129.— - Feed device EUR 119.— - 2 additional handwheels for unit adjustment EUR 45.— - TERSA cutterhead DM 72 mm EUR 212.— - Xylent spiral cutterhead with 3 rows of knives EUR 717.— - Aluminum long-hole drilling device EUR 390.— - 2 stop flaps on the crosscut fence EUR 150.—

Condition: new, Stable steel-cast iron construction High-precision format sliding carriage made of anodized aluminum with a travel distance of 2250 mm Maximum saw blade diameter of 315 mm, saw blade adjustable by 45° Large fence frame (960 x 600 mm) with an extendable aluminum telescope stop up to 2660 mm Heavily ribbed planer worktables made of cast iron, annealed and stress-relieved for decades of stability and flatness Helical steel infeed roller for uniform material feed Three milling speeds, manually adjustable Milling spindle with clockwise/counterclockwise rotation Three independent industrial motors With lockable main switch, motor protection switch, emergency stop switch Planer table width 410 mm Hedpfx Acoiiynns Tot Planer table length 1810 mm Maximum chip removal 4 mm Thickness table length 605 mm Thickness table width 410 mm Working height min. 3 mm Working height max. 230 mm Feed rate 7 m/min Maximum chip removal 4 mm Dust extraction port diameter 4 x 120 mm Planer cutterhead type TERSA (3 pcs) Planer cutterhead diameter 72 mm Speed 5200 min⁻¹ Circular saw fence length 2250 mm Cutting width with parallel fence 900 mm Max. crosscut width to the left of the saw blade 2310 mm Saw blade tilt 90 – 45 ° Max. cutting height at 90° 90 mm Max. cutting height at 45° 63 mm Saw blade diameter 315 mm Saw blade speed 4000 min⁻¹ Sliding carriage and table Format sliding carriage length 2600 mm Spindle diameter 30 mm Speeds 3500/7000/10000 min⁻¹ Milling tool diameter max. adjustable/non-adjustable 180/210 mm Power of drive motor 3 x 5.0 kW, 400 V, 50 Hz Machine weight approx. 560 kg INCLUDED OPTIONS - Handwheel with gravity-assisted numerical display for thickness table positioning - Sliding carriage length 2600 mm - Professional fences - "TERSA" planer cutterhead - Clockwise/counterclockwise rotation of the milling cutter

Condition: new, Technische Daten: Abmessungen der Heizplatten 3000 x 1300 mm Anzahl der Heizplatten 2 # Anzahl der Presszylinder 6 # Pressdruck 90 t (900 kN) Zylinderdurchmesser 70 mm Anzahl der Etagen 1 # Etagenöffnung ca. 400 mm Anschlussleistung ca. 21,0 kW ELEKTRISCH BEHEIZBARE TISCHE (ELKOM - Deutschland) Der Tisch besteht aus 2 kalibrierten Aluminiumplatten, in denen die elektrischen Widerstände verlegt sind. Die maximale Betriebstemperatur ist 120 Grad C. Im am Tisch wird eine Dämmplatte montiert, die zur Wärmeisolierung gegenüber der Presse dient. Der Bau des Tisches und die präzise Verarbeitung, die von spezialisierten Firmen vorgenommen werden, gewährleisten eine sehr gleichmäßige Verteilung der Temperatur. Die Heizplatten sind mit speziellen Halterungen an der Presse befestigt um die Wärmeausdehnung zu erlauben, außerdem erleichtern sie die Wartung und das Auswechseln. Spezifischer Betriebsdruck des Tisches bis zu 10 kg/cm2 Max. Temperatur der Heizplatte 120 Grad C Arbeitstemperatur 90 Grad C Schuetzsteuerung Waermeschutzschalter Die Zylinder sind aus spezial geschweissten und gross dimensionierten Stahlrohren hergestellt. Hydraulik: Kompakte hydraulische Einheit Fabrikat HAWE aus Deutschland. Pumpe fuer Schliessphase und Druckaufbauphase. Automatische Nachdruckverstellung Leistung der hydraulischen Einheit 3 kW Bewegung des Presstisch von unten nach oben. Pressengestell: Das Pressengestell besteht aus einer schweren verwindungssteifen und spannungsfrei geschweissten Stahlkonstruktion. Beide Presstische sind aus HEA-Profilen geschweisst. Die Bearbeitung der Baugruppen erfolgt auf CNC-Barbeitungsmaschinen. Bewegung des Presstisches mit Zahnstangen und Parallelfuehrung an 2 Ecken des Presstisches aus selbstschmierenden Material. BEDIENTAFEL mit Display und Tastatur: Bedientafel Siemens mit 7-Zoll-Farb-Touchscreen mit Verbindung zum Ethernet- Netzwerk für den Fernwartungsservice. Hodpfefh Tmmox Ac Tet Das System ist mit einer eigenen Software ausgestattet durch die die Bedienung der Presse einfach und intuitiv erfolgen kann. Sie können folgende Parameter programmieren, abrufen und ändern: - Automatische Regelung des hydraulischen Drucks aufgrund des Werkstückgrösse und des gewünschten spezifischen Drucks. Das System reguliert den Druck der Zylinder automatisch und der Bediener muss keine Berechnungen mit Grafiken oder Tabellen anstellen. - Möglichkeit zum Speichern von bis zu 100 Arbeitsrezepten (Temperatur, spezifischer Druck, Pressdauer, Plattengrösse). - Direkteinstellung des hydraulischen Drucks der Zylinder mit digitaler Kontrolle aufgrund der Grafik. Dieses System kann alternativ zur automatischen Regulierung verwendet werden, falls Sie lieber mit der herkömmlichen Methode arbeiten. - Elektronische Regelung der Pressdauer - Elektronische Kontrolle der Temperatur der Tische - Automatische Wiederherstellung des Drucks aufgrund des Nachgebens des Materials. - Komplette Diagnostik und Störungsanzeige mit Meldungen am Display. WEITERE AUSSTATTUNG UND MERKMALE DER PRESSE Haken zum Anheben der Maschine um das Laden/ Entladen der Maschine beim Transport zu erleichtern. Nivelliervorrichtungen die an den Füssen der Presse montiert sind. In die Presse integrierte Schalttafel; dadurch sind weniger Aussenkabel notwendig, die vorhandenen sind jedoch auf jeden Fall angemessen geschützt. inkl. Option: Fehlbelegungsüberwachung (Ebenheitskontrolle)
