Condition: used, Year of construction: 1995, Order No. 23066 Technical Specifications: - Sanding belt dimensions approx. 2000 x 150 mm - Surface sanding aperture approx. 560 x 150 mm - Sanding belt speed approx. 30 m/sec. - Contact disc W 150 / D 200 mm - Drive disc W 150 / D 200 mm Ijdpfjwf Hppsx Afujih - Drive 400 V / 3 kW - Adjustable working height - Motorized dust extraction - Space requirement approx. W 750 x H 1050 x D 1500 mm - Weight approx. 120 kg

Condition: used, Year of construction: 1995, Constant machine - combination station, dust brush - thickness measuring device - electronic segmented sanding pad MCS System Weber 32 mm - grooved steel calibrating roller - belt blow-off - vacuum conveyor belt. Sanding width: 1100 mm Drive: 15 kW Feed approx. 1.1 kW Height adjustment 0.25 kW Sanding belt dimensions: 1150 x 2500 mm Max. workpiece thickness: 150 mm Machine width: 1700 mm Machine length: 2000 mm Machine height: 2160 + 150 mm Machine weight: 1900 kg Constant working height: 850 mm Extraction connector: belt 180 mm / brush 120 mm Suction air volume: 0.74 m³/s Connected load: 23 kW Compressed air supply: 7 bar Feed speed: 3-15 m/min. Operating hours: 7000 h Location: Nattheim Iiodsx Twcpjpfx Afush

Condition: like new (used), Lot of sandpaper for a Kündig wide-belt sander or similar. 5 pieces: EKA 1000 F 80 8 pieces: ARKFO 120 Technical data: Iiodpfx Asz Iwqwjfush - Dimensions: 650 x 2000 mm

Condition: good (used), Code: 0260 Brand: DMC SCM GROUP Model: UNISAND 2000 - CE Standard Ijdpfjx Dm Tvjx Afueih Automatic wide belt sander with 2 longitudinal units and 1 transverse unit at the inlet for furniture, joinery, custom-made furnishings, panels, wooden doors, window frames, semi-finished products and various - CE Standard Technical data: Max working width 1350 mm Min working width 52 mm Min length 400 mm Min/max working height 4/170 mm Belt feed with variable speed motor Longitudinal abrasive belt length 1370 x 2620 mm Transverse abrasive belt length 150 x 6550 mm Lamellar belt length 140 x 6300 mm Automatic belt centring Automatic table positioning Digital display of working thickness Control panel with dustproof membrane keyboard Electronic system for belt oscillation Rubber-coated pressure rollers Automatic belt centring 1° Group: Transverse Sanding Pad with development 6550 mm and fitted with a lamellar belt, guarantee of stability and excellent abrasive belt tensioning Sectioned electronic pad "EPICS" with electronic control "HYDRA" with 46 sectors, with centre distance 30 mm A LED screen allows verification of the operation of the activated pad sectors The unit is equipped with blowers for cleaning the abrasive belt 2-speed motor power 12/15 Kw Suction hood diameter 160 mm Combined longitudinal calibrating/sanding group with steel roller and sectioned electronic pad 46-sector "EPICS" with centre distance 30 mm Reading barrier 46-sector Abrasive belt dimensions 1370 x 2620 mm Roller diameter 220 mm Motor power 15/18,5 Kw Oscillating blowers with electronic control Sectioned electronic sanding pad "EPICS" with 46 sectors and centre distance 30 mm Reading barrier 46-sector Motor power 15 Kw Oscillating blowers Scotch Brite satin roller Diameter 150 mm Motor power 3 Kw Suction hood diameter 160 mm Vacuum table Electronic control HYDRA 35 Compressed air 8 bar Overall dimensions of assembled machine mm 3200 x 2,900 x 2400 h Overall dimensions for transport mm 3200 x 2300 x 2400 h Weight kg 4400

Condition: excellent (used), Wide Belt Sander for Calibration and Fine Sanding SCM Model RCS 1st Unit: Calibration Roller, Steel 2nd Unit: Combination Unit (Roller 60 Shore, sanding pad with 2 inserts – hard, soft) Working width: 920 mm Abrasive belt dimensions: 930 x 1,525 mm Iijdpfx Afoxqggcsueh Main motor power: 11.0 kW, 400 V, 50 Hz Feed motor power: 0.37 kW, 400 V, 50 Hz 2 feed speeds Electromotive table height adjustment Main switch lockable 2 x emergency stop Table extension with 2 rollers, front and rear Sanding pad inserts fitted with new graphite cloth Including as-new sanding belts All documentation included Note for used machinery: • Specifications, data, and prior sale are subject to change. • Prices stated are ex works – free loaded! • The machine has been cleaned and functionality tested. • All machines are sold as seen without any rights to warranty. Buyers are welcome to inspect the machines on site. • Special agreements are only valid in written form. (We only respond to inquiries that include your address and telephone number!)

Condition: ready for operation (used), Year of construction: 1981, functionality: fully functional, Brand: DMC Model: Europa 90 Year of manufacture: 1981 Tech. info: Roller abrasive belt motor: 15 HP - 2 poles Pad abrasive belt motor: 7,5 HP - 2 poles Conveyor belt motor: 1,5/0,8 - 4/8 poles Two feeding speeds: 7-14 m/min Roller abrasive belt speed: 21 m/sec Pad abrasive belt speed: 10 m/sec Roller abrasive belt length: 2200 mm Pad abrasive belt length: 2200 mm Roller and pad abrasive belt width: 950 mm Max. size of work-piece: 900 x ≠100 x > 200 mm Min. size of work-piece: 40 x ≠ 2 x 200 mm Iiedjrbyrpepfx Afujh Min. operating pressure: 5,5 Atm Compressed air consumption: 300 l/min Diameter of suction hood (roller belt): 200 mm Diameter of suction hood (pad belt): 200 mm Average speed of dust exhaust system: 25-30 m/sec volume of sucked air (roller belt hood): 3150 cu.m/h Volume of sucked air (pad belt hood): 3150 cu.m/h Overall size: 1675x1625xh=2096 mm Weight: 2030 kg Weight of the machine without pad: 1630 kg Stock no: 2001933

Condition: ready for operation (used), Year of construction: 2023, functionality: fully functional, working width: 1,300 mm, workpiece height (max.): 140 mm, controller model: Xinje XD5, empty load weight: 4,500 kg, working length: 200 mm, TECHNICAL DETAILS 1st Station: 15 cup grinding brushes with quick-change mount 2nd Station: 15 cup grinding brushes with quick-change mount 3rd Station: 9 tangentially arranged grinding brushes 4th Station: Crosswise roller with grinding brushes over the entire working width 5th Station: Crosswise roller with grinding brushes over the entire working width 6th Station: Air nozzle across the entire working width Working width: 1,300 mm Working length: 200 mm Workpiece height: 3 - 140 mm MACHINE DETAILS Control system: Xinje XD5 Total power requirement: 13.4 kW Dimensions & Weight Required floor space: approx. 5.1 x 2 x 2.3 m Machine weight: approx. 4,500 kg EQUIPMENT Modular control of the module units Frequency converter for speed control Automatic adjustment of working height range Oscillating blowing air in the final section Easy maintenance and replacement of abrasive paper and brushes Spare brushes Grinding inserts Iodjx Tt Uuopfx Afuoih Rubber conveyor belt with herringbone pattern, solid steel plate underneath across full width

Condition: excellent (used), CATALOGUE NUMBER 6145 TECHNICAL DATA - max width of workpiece 1100mm - max height of workpiece 140mm 3 units: 1) ribbed rubber roller for calibrating, 15kW 2) ribbed rubber roller for calibrating, 11kW 3) ribbed rubber roller for calibrating, 11kW from above: - sliding metal roller - sliding rubber roller - unit - 2 sliding rubber rollers - unit - 2 sliding rubber rollers - unit - sliding rubber roller from below: - infeed table 3600x1000mm - feed speed adjustable via frequency inverter, 0.25kW - pull belt - 3 sliding rubber rollers, output - pneumatic belt oscillation with photocells - belt blowing - electric table lifting - lifting motor 0.75kW - smooth feed speed adjustment - feed motor 2.2kW - with vacuum pump - pump motor 4kW - extraction nozzle diameter 110mm, 80mm - working pressure 6-8bar - extraction nozzle diameter 3×150, 3x200mm - overall machine dimensions L/W/H 3400x2300x2800mm - feeder dimensions L/W/H 3000x1300x900mm - pump dimensions L/W/H 600x950x940mm Iiedpfx Afszw Dtmsueh - weight approximately 5000kg Net price: 32900 PLN Net price: 7650 EUR, depending on the exchange rate of 4.3 EUR (Prices may vary due to higher fluctuations)

Condition: excellent (used), Year of construction: 2008, Working width: 1100 mm Workpiece thickness: 3 – 160 mm Iijdpfx Aeychqzjfuoh Abrasive belt dimensions: 1,120 x 1,900 mm Variable feed speed: 2.6 - 13 m/min Feed motor output: 1.10 kW, 400 V, 50 Hz Extraction port diameter: 2 x 160 mm Compressed air supply: 6 bar Dimensions (L x W x H): 1705 x 1545 x 1905 mm 1st unit: Steel contact roller, diameter 160 mm Motor output: 15 kW, 400 V, 50 Hz 2nd unit: Combination unit with rubber-coated contact roller (Sh 65), rigid sanding shoe Motor output: 11 kW, 400 V, 50 Hz Abrasive belt cleaning via compressed air 3rd unit: Cleaning brush Multi-function display Multi-function lever (conveyor belt, workpiece thickness adjustment) Electronic belt oscillation Pneumatic conveyor carpet oscillation Motorized workpiece thickness adjustment with LED display in 0.1 mm increments Units with emergency braking system Emergency stop button at infeed & outfeed Motor protection switch Roller table extension at infeed with 2 loose rollers Automatic star/delta start Complete documentation Note for used machines: • Specifications and prior sale subject to change. • Stated prices are ex works – loaded free of charge! • The machine has been cleaned and functionally tested. • All machines are sold as seen, without any warranty or guarantee. Buyers are welcome to inspect the machine on site. • Special agreements are only possible in written form. (We only respond to inquiries providing your address and telephone number!)

Condition: excellent (used), CATALOGUE NUMBER: 5799 TECHNICAL DATA - Maximum width of workpiece: 230 mm - Maximum height of workpiece: 140 mm - Minimum length of workpiece: 300 mm - 2 grinding units: - Upper and lower + platens * Upper: - 2 sliding, metallic pressure rollers - Pressure - Grinding unit: 2 metallic rollers + platen - Sliding pressure roller - Traction belt * Lower: - Traction belt - 2 sliding, smooth metallic rollers - Pressure - Grinding unit: 2 metallic rollers + platen - 3 sliding, smooth metallic rollers - Electrically adjustable grinding height Iiodpfxezty Nvo Afuoh - Oscillation of grinding belts - Pneumatic cleaning of belts - Smooth speed adjustment via inverter: 3-15 m/min - Feed motors: 2 x 0.37 kW - Main motors: - Upper: 5.5 kW - Lower: approx. 5.5 kW - Air consumption: 6-8 bar - Diameter of dust extraction nozzles: 4 x 100 mm - Overall dimensions (L/W/H): 2340x1420x1920 mm - Weight: 1480 kg – For short workpieces (belts overlap) – German made – Very good condition – Not painted – Used grinder Net price: 18900 PLN Net price: 4400 EUR Net price calculated at an exchange rate of 4.3 PLN/EUR (Price may change in case of significant exchange rate fluctuations)

Condition: excellent (used), Working width: 110 cm Iijdpfx Aozxzkfjfuoh First unit: steel roller Second unit: combination – rubber roller plus pad Pneumatic belt cleaning Pneumatic oscillation with photocells Electric table height adjustment (up/down) Pneumatic belt tensioning Two feed speeds Abrasive belt size: 2200 x 1130 mm Voltage: 400 V Motor: 12 kW Weight: 1542 kg Year of manufacture: 2004

Condition: used, Belt sanding machine BÜRKLE BSU 2500/800 - used - Sanding belt cover, Extraction fan ----- Technical data ----- Table size: 2,500 x 800 mm, Motor: 5.5 kW, Sanding belt dimensions (LxW): 7,200 mm Iedpfjxlt Ebjx Afuoih

Condition: used, Bütfering ECO 111 Electronic Wide-Belt Calibration and Fine Sanders Contact roller unit 85 SH CPS electronically controlled segmented pad Working width 1100 mm Terminal for various operating programs with selector switch and LED display Motor power approx. 11 kW Brush cleaning unit RTE additional compact roller table at infeed RTA additional compact roller table at outfeed Machine is FULLY REFURBISHED and in TOP CONDITION Available ex-stock Lieboch Iedoy Rzf Aopfx Afueih

Condition: used, Year of construction: 1998, Working width 1350 mm Number of sanding units x st. Used Machine Year of manufacture: 1998 Condition: Overhauled by a Heesemann factory technician, including a new feed belt Features and Technical Specifications: - 1 automatic belt sander with combination unit - with electronic articulated pressure beam - for sanding soft and hard veneers - calibrating and fine sanding solid wood - Calibration of workpiece carrier panels - Removal of defective veneers and coatings - Intermediate sanding of PU, hydro, UV, nitro, and polyester coatings - Sanding of barrier films - With graphical operator terminal - NC-controlled thickness adjustment from 3 to 150 mm - Activation of the calibration roller via the terminal - With patented CSD articulated pressure beam for compensating workpiece tolerances up to 2 mm - Sanding width: 1,350 mm - Sanding belt length: 2,150 mm - Frequency-controlled sanding belt speed: approx. 2–18 m/sec - Sanding shoe width: 100 mm - Sanding unit drive: 15 kW - Feed speed: 5/10 m/min - Compressed air: 6 bar - Compressed air consumption: 15 NL/min - With belt dust extraction: 490 l/min - Exhaust ports: 1 x 180 mm, 2 x 100 mm - Air requirement for grinding unit: 1,800 m³/h Iiedpfszk Nxzex Afuoh - Required air velocity: 20 m/sec - Total power connection: approx. 17 kW - Dimensions: 2090 x 1670 x 2020 mm - Weight: approx. 2500 kg

Condition: excellent (used), functionality: fully functional, Working width: 900mm Steel calibrating roller Combination unit with a rubber roller Iodpfx Afjzxp Npeujih Motor power: 11kW Pneumatic shoe adjustment Pneumatic oscillation with a photocell Element thickness gauge Electric table adjustment Star/Delta start-up Power supply: 380V

Condition: excellent (used), Calibration and fine sanding machine with 1 sanding unit 1 motor, processing from above Working width 1000 mm Sanding belt dimensions 2200 x 1030 mm Workpiece dimensions 3 - 170 mm Table height adjustment motor 0.18 kW, 400 V, 50 Hz Main motor 7.5 kW, 400 V, 50 Hz 2 feed speeds 5.5 & 11 m/min 1st unit: Combination unit, sanding drum, rubberized, 90 Sh / pneumatic sanding pad Sanding pad NEW 2nd unit: Cleaning brush Isdjudxchspfx Afusih Compressed air requirement approx. 6 bar Suction diameter 200 mm Dimensions approx. L x W x H = 1385 x 1980 x 1900 mm Weight approx. 1800 kg Automatic workpiece thickness adjustment with digital display Oscillation of the sanding belt Sanding belt emergency stop with disk brakes Table extension with 3 rollers in the outfeed Emergency stop button Main switch TRANSPORT CARPET LIKE NEW - was replaced by us approx. 3 years ago MORE THAN 30 WIDE BELT SANDERS Note used machines: - Subject to errors in technical specifications and prior sale. - Prices quoted are ex location - free loading! - The machines have been cleaned and functionally tested. - All machines are purchased as seen without any warranty. The buyer is free to inspect the machines on site. - Special agreements are only possible in written form. (Inquiries will only be answered with your address and telephone number).

Condition: excellent (used), functionality: fully functional, Working width 650 mm, combination unit with calibration roller and shoe, two feed speeds, belt oscillation, electric table adjustment, material gauge Ijdpezxqapjfx Afusih

Condition: new, Year of construction: 2024, functionality: fully functional, UNITEK NICE 950 2N RKRT Working width 950 mm Sanding belt size 970 x 2150 mm Maximum working height 160 mm Calibrating roller, steel, Ø 150 Sanding roller, rubber-coated, Ø 150 Finishing pad 50 mm Sanding belt motor power 15 HP Sanding belt speed 18/16 m/s Feed motor with variable speed 0.75 HP Feed speed 4-20 m/min Table lifting motor power 0.33 HP Automatic sanding belt centering "ECO GEAR SYSTEM" Quick stop belt brake Oscillating tensioning rollers Iijdpfjznwp Asx Afush Rubber-coated pressure rollers Safety bar Electronic digital display of workpiece thickness Rollers on infeed and outfeed table, 2 pcs. Dust extraction 2 pcs. - Ø 160 Automatic work thickness positioning Additional equipment (included in the price): Belt motor power 20 HP Automatic conveyor belt centering Oscillating cleaning blower, timer-controlled, 2 pcs. UNITEK NICE 950 1N KRT Working width 950 mm Sanding belt size 970 x 2150 mm Maximum working height 160 mm Calibrating roller, steel, Ø 150 Finishing pad 50 mm Sanding belt motor power 10 HP Sanding belt speed 18 m/s Feed motor with variable speed 0.75 HP Feed speed 4-20 m/min Table lifting motor power 0.33 HP Automatic sanding belt centering "ECO GEAR SYSTEM" Quick stop belt brake Oscillating tensioning roller Rubber-coated pressure rollers Safety bar Electronic digital display of workpiece thickness Rollers on infeed and outfeed table, 2 pcs. Dust extraction 1 pc. - Ø 160 Automatic work thickness positioning Additional equipment (included in the price): Oscillating cleaning blower, timer-controlled UNITEK NICE 650 1N KRT Working width 650 mm Sanding belt size width x length 670 x 2150 mm Maximum working height 160 mm Calibrating roller, steel, Ø 150 Finishing pad 50 mm Sanding belt motor power 10 HP Sanding belt speed 18 m/sec Feed motor with variable speed 0.75 HP Feed speed 4-20 m/min Table lifting motor power 0.33 HP Self-centering of sanding belts using the system “ECO GEAR SYSTEM” Quick stop belt brake Oscillating tensioning roller Rubber-coated pressure rollers Safety bar Electronic digital display of workpiece thickness 2 rollers on infeed and outfeed table 1 dust extraction port Ø 160 Automatic work thickness positioning Additional equipment (included in the price): Mobile cleaning blower for the sanding belt Warranty 12 months on spare parts.

Condition: excellent (used), Catalog number: 7431 TECHNICAL DATA - Maximum width of the workpiece: 950 mm - Maximum height of the workpiece: 150 mm From above: - Metal roller, pressure roller - Unit (grooved rubber roller for calibrating + shoe + metal roller) - Metal roller, smooth, sliding From below: - Traction belt - Pneumatic belt oscillation with photocells - Electric table lifting - 2 feed speed settings Iodjzw Dibjpfx Afueih - Main motor: 7.5 kW - Feed motor: 0.6 kW - Table lifting motor: 0.18 kW - Operating pressure: 8 bar - Diameter of the dust extraction port: 150 mm - Dimensions (L/W/H): 1600x1250x2000 mm - Weight: 1109 kg ADVANTAGES - German made - Additional shoe included - Used machine, very good condition Net price: 19900 PLN Net price: 4628 EUR, depending on the exchange rate of 4.30 EUR (Prices are subject to change due to exchange rate fluctuations)

Condition: new, Industrial belt sander Scantool 150 x 2000 with integrated double dust extraction system Sanding belt: 150 x 2000 mm Working width: 150 mm Motor: 4.8 hp Speed: 34 m/s Table height: 475 to 1240 mm Sanding belt dimensions: 150 x 2000 mm Platen size: 530 mm Weight: 115 kg The Scantool industrial belt sander models with double dust extraction system, 75 x 2000 and 150 x 2000, are powerful, high-quality machines Iodpfsflt Aljx Afueih built according to the strictest environmental and safety regulations. The belt sanders are standardly equipped with a motor brake, adjustable working height, eye protection, angle stop, and motor protection switch with zero-voltage release. This low-noise machine with CE marking is ideally suited for sanding all metals. Motor protection switch with zero-voltage release Separate emergency stop Motor brake Adjustable angle stop Eye protection The infinitely adjustable working height enables an ergonomically correct working position. Perfect design for fast, effective, and safe sanding. Self-adjusting belt tension. Danish top quality.

Condition: used, Year of construction: 1984, Working width 1350 mm Number of sanding units x st. Used Machine Year of manufacture: 1984 Condition: fully inspected and serviced Features and Technical Specifications: - Includes a combination unit with a contact roller and grinding shoe - With height-adjustable contact roller for calibration - With workpiece-controlled air-cushion pressure shoe - 4-way adjustable grit compensation - With pneumatic belt tensioning device - With a rotating texturing brush on the machine’s outlet side - Sanding width: 1350 mm - Sanding belt length: 1900 mm - Clearance height: 150 mm - Main motor: 15 kW - Feed speed continuously adjustable from 2.5 to 12.5 m/min - With roller table at the infeed - With separate additional texturing brush - With roller table at the outlet Iijdpjzlbpnjfx Afujh - With digital display for the electrically driven workpiece thickness adjustment - With automatic workpiece thickness adjustment - Exhaust ports: 2 x 200 mm - Feed belt is in good condition; has one defect (see photo) Dimensions: approx. 2300 x 2000 x 2300 mm Weight: approx. 2500 kg The photos show the machine as it was upon receipt Availability: immediately Location: Röllbach

Condition: new, Industrial belt sander Scantool 75 x 2000 Iijdpfx Afoflt Amjush with integrated dual dust extraction system Sanding belt 75 x 2000 mm Working width: 75 mm Motor: 4.1 HP Speed: 34 m/s Table height: 475 to 1240 mm Sanding belt dimensions: 75 x 2000 mm Platen size: 530 mm Weight: 100 kg The Scantool industrial belt sander models with dual dust extraction system, 75 x 2000 and 150 x 2000, are powerful, high-quality machines built to the strictest environmental and safety standards. The belt sanders are equipped as standard with a motor brake, adjustable work height, eye protection, angle stop, and motor protection switch with zero-voltage release. This low-noise machine with CE marking is ideally suited for sanding all metals. Motor protection switch with zero-voltage release Separate emergency stop Motor brake Adjustable angle stop Eye protection The continuously adjustable work height enables an ergonomically correct working position. Perfect design for fast, efficient, and safe sanding. Self-adjusting belt tension. Danish top quality.

Condition: used, Year of construction: 1983, Working width 1350 mm Number of sanding units x st. Second-hand machine Year of manufacture: 1983 Condition: fully inspected and serviced, Includes new feed belt Features and technical specifications: - Includes combination unit with contact roller and sanding shoe - with height-adjustable contact roller for calibration - with an air-cushion pressure shoe controlled by the workpiece - 4-way adjustable grit compensation - with pneumatic belt tensioning device - fitted with a rotating cleaning brush on the outlet side of the machine - Belt oscillation controlled by a photoelectric sensor for automatic monitoring and control of the lateral belt position to ensure even belt wear - with roller table at the inlet - with digital display for the electrically driven workpiece thickness adjustment - with additional veneer sanding beam - Includes 2 spare grinding shoes - Sanding width: 1350 mm - Sanding belt length: 1900 mm Iodozk Npmepfx Afuoih - Clearance height: 150 mm - Main motor: 15 kW - Feed speed continuously adjustable from 2.5 to 12.5 m/min - Extraction connections: 2 x 200 mm Dimensions: approx. 2300 x 2000 x 2300 mm Weight: approx. 2,300 kg Availability: at short notice Storage location: 63934 Röllbach

Condition: new, Number of sanding units 1 St. Profile width 390 mm Isdpfx Afsytx Ufjuoih Profile height max. 390 mm

Condition: used, usedmake Löserbelt unit 1motor 1 / 1,4 kWspeed 2 speedssuction connection own suction 0,44 kWspace requirement approx. 1400 mm x 800 mm x 1700 mmstorage place 97447 Gerolzhofen, free loaded, unpackeddelivery in as-is condition as viewed,without warranty and guarantee Iisdpfx Afjvwfwksueh
