Used Index Er 25 for sale (140)

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle power : 24 [kW] - Spindle speeds : 5000 [rpm] - Max. bar diameter : 65 [mm] - C axis indexing precision : 0.001 [°] - Travel : 390 / 600 [mm] TURNING-MILLING SPINDLE - X stroke : 350 [mm] - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 LOWER TURNING-MILLING SPINDLE - Y stroke : ± 80 [mm] - B Axis stroke : 270 [°] - B axis indexing precision : 0.001 [°] - Tool type : HSK-T40 Predpfsv Ig Avex Aa Ejf - Spindle speeds : 18000 [rpm] - Spindle power : 11 [kW] - Fixed tools on milling electrospindle : 6 x VDI25 TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 80 - Tool exchange time : 4.5 [sec] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 68 [kW] WEIGHT & DIMENSIONS - Machine height : 2500 [mm] - Machine weight : 11000 [kg] MACHINE HOURS - Spindle hours : 19781 [h] - Number of turning-milling spindle hours : 9713 [h] EQUIPMENT - CNC : Siemens Sinumerik 840D SL - Coolant tank * with high-pressure pump * with paper filtering unit * Coolant through spindle - Chips conveyor - Spindle cooling unit - Parts catcher

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 720052, turning length: 600 mm, turning diameter: 140 mm, bar passage: 65 mm, controller model: Siemens 840 D PowerLine, distance between spindles: 615 mm, TECHNICAL DETAILS Turning diameter: 140 mm Turning length: 600 mm Maximum bar diameter: 65 mm Distance between spindles: 615 mm Max. spindle speed: 5,000 rpm Main spindle drive power: 20/27 kW Prodpfxjxg Im As Aa Esf Spindle nose: ISO 702/1 140 mm Spindle bearing diameter: 110 mm Max. torque: 105/145 Nm C-axis: 0.001 Chuck diameter: 140 - 160 mm Tool turret: 3 Y-axes: 2 to 3 axes +/- 35 mm B-correction axes: 2 axes +/-1 Driven tool positions: 3 x 12 Tool holder: VDI 25 x 48 DIN 69880 Drive power for driven tools: 8 kW MACHINE DETAILS Control: Siemens 840 D PowerLine Dimensions & Weight Space requirements: approx. 8.0 x 3.5 x 2.5 m Machine weight: approx. 6,500 kg Electrical Data Rated voltage: 400 V AC Rated current: 101 A Rated power: 59 kW Number of phases: 3 Frequency: 50 Hz Control voltage: 24 V DC Total power requirement: 53 kVA EQUIPMENT Index MBL bar loader

Condition: good (used), Year of construction: 2004, spindle passage 60 mm turning length 280 mm control 840 D Siemens turning speed range - drive spindle 6300 U/min drive capacity - spindle motor 3,3 kW turret 1 Scheibenrevolver no. of tools in turret 1 8 worktool system DIN 69 880 / 25mm x-travel 90 mm z-travel 280 mm feed power 5500 N rapid traverse 24 m/min power capacity - milling spindle 5000 kW turret Schwalbenschwanz no. of tools in turret 2 6 x-travel 81 mm z-travel 80 mm feed power 5500 N rapid traverse X-axis 16 m/min rapid traverse Z-axis 24 m/min weight of the machine ca. 2,5 t dimensions of the machine ca. 6,0 x 2,0 x 2,0 m TThe INDEX ABC machine is a compact lathe for short turned parts made from bar stock. It has an inclined bed design with two independent turrets. The top turret is primarily intended for internal machining and machining, while the lower turret is used for external machining. The turret arrangement enables collision-safe working and simple programming programming with high tool availability. The large free space in the working area enables a favourable chip fall The work area consists of two turrets: ‘Turret 1’ - Disc turret with 7 radially arranged tool holders Ø 25 mm DIN 69880 and a holder for the reinforced synchronised spindle on the turret station Podowbvhaspfx Aa Esrf 8. tools with 1’ holders can also be used with an equalising holder can also be used. The turret is prepared for the V-ledge system. - Synchronised spindle for rear end machining, simultaneous parallel machining with main spindle. Ø42 collet chuck or 3-jaw gripper chuck for internal and external clamping and external clamping. Jaw stroke 0.6 mm. Clamping diameter (external) 75 mm. - Back-boring device. Starting from the centre of the working spindle in clockwise direction, 3 stationary back-boring tools are back boring tools are arranged. These are located in the pitch circle of the synchronised spindle. The back machining is carried out simultaneously with the machining on the the working spindle. Two additional tools can also be used, can be equipped with a tool feed drive. ‘Revolver 2’ - Turret with 6 symmetrical dovetail holders and each station with 2 locating holes for cylindrical shank per station. The following tool systems can be used. - stationary tools that can be moved in the Z direction - Driven tools with cylindrical shank Ø25 (can be used in two positions per station) can be used) - including bar loader LM 3200 - + various accessories (various Ø guide half-shells/tool holders) Technical data: - Material bar diameter: (Ø 25 / Ø 36 / Ø 52)- --> round Ø 8 - 25.4 / 8 - 36 / 8 - 52 mm --> square SW Ø 6 - 14 / 6 - 20 / 6 - 20 mm --> hexagon SW Ø 7 - 22 / 7 - 30 / 7 - 41 mm --> octagonal SW Ø 7 - 22 / 7 - 32 / 7 - 40 mm --> bar length max. 3200 mm --> from bars Ø 25 mm, min. 2,500 mm --> up to rods Ø 25 mm, min. 1,500 mm --> bar support = approx. 300 = 6 bars Ø 52 mm Mass (bar loader) = 700 kg

Condition: used, Year of construction: 2006, spindle passage 65 mm spindle diameter in front bearing 110 mm number of spindle speeds 5.000 U/min Power 20/27 KW Control INDEX C 200-4 travel -x axis 850 mm travel -z axis 260 mm number of tapers in turret head 12 driven tools turning speeds 6.000 U/min CNC turning and milling center vertical | INDEX - V160C equipped with turret, milling spindle and pallet conveyor system. The machine only has 17.000 hours of Power-On. The machine is in good condition. For additional equipment information please refer to the original order confirmation which is included in the offer of this machine. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Prodpfxjvzcnzs Aa Eof #Tags: V-160C | V-160 C | V 160 C | V 160C

Condition: used, Year of construction: 2002, turning diameter max. 420 mm turning length 1250 mm control INDEX, C 200-4 D swing diameter 630 mm travel x1 320 mm travel z1 1250 mm travel x2 170 mm travel z2 1250 mm travel x3 320 mm travel z3 1250 mm main spindle speed max. 3000 U/min main spindle drive 53 kW spindle passage 102 mm spindle head DIN 55026 Gr. 11 max. torque on the spindle 675 Nm sub spindle - spindle speed range max. 3000 U/min sub spindle drive 53 kW sub spindle - spindle passage 102 sub spindle - spindle head DIN 55026 Gr. 11 sub spindle - spindle torque 675 Nm travel sub spindle 1250 mm feed power X1 14000/Z1 14000 N rapid traverse X1 20/Z1 40 m/min Prsdst U R Hzjpfx Aa Ejf feed power X2 8600/Z2 14000 N rapid traverse X2 20/Z2 40 m/min feed power X3 14000/Z3 14000 N rapid traverse X3 20/Z3 40 m/min numbers of turret head positions Rev. 1 = 12 numbers of turret head positions Rev. 2 = 10 numbers of turret head positions Rev. 3 = 12 number of driven tool stations 12 / 10 / 12 speed of driven tools max. 6000 U/min max. torque 36 / 21 / 36 Nm tool taper DIN 69880 tool taper ø 40 x 63 mm total power requirement 120 kW weight of the machine ca. 19 t dimensions of machine L x W x H 5,77 x 2,47 x 2,62 m Accessories: segment bushing chuck HAINBUCH on main spindle, collet chuck HAINBUCH, SPANNTOP SP on sub spindle, various tool holders (also for driven tools), chip conveyor, coolant - all 3 turrets are prepared for coolant through spindle, but the highpressure coolant pump and tank are not with the machine -

Year of construction: 1997, condition: ready for operation (used), Turning diameter: 200mm, turning length: 400mm, turning diameter: 420mm, bar diameter: 60mm, max. spindle chuck diameter: 160mm, speed: 5000rpm, turret: 2, positions: 2x14, rapid traverse X/Z: 20m/min/30m/min. Machine dimensions X/Y/Z: approx. 7500mm/2100mm/2100mm, weight: approx. 4500kg. Documentation available. On-site inspection is possible. Prsdpfou T Rgksx Aa Ejf

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - Strokes X/Y/Z : 280/280/145 [mm] - Quick movement : 50 [m/min] - Loading zone strokes X/Z : 110/90 [mm] - Tools number : 8 - Motorized tools number : 2 - Rotary tools speed : 6000 [tr/min] - Rotary tools power : 9,5 [kW] - Tools type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D Pjdpfxouhbfme Aa Eerf - Axis C - Measuring rules on linear axes - Counter spindle - 1 turning tool holder for counter operation - Coolant tank with pump - Chip conveyor

Condition: used, Year of construction: 2000, functionality: fully functional, machine/vehicle number: 500358, turning length: 1,250 mm, turning diameter: 300 mm, spindle motor power: 43 W, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, INDEX G300L with Promot gantry loader. Machine is still in production and under power. The promot loader has 2 rotary indexing belts with approx. 30 pallet spaces each. The machine is equipped with high-pressure cooling lubricant (40 bar), paper belt filter and tool changer. For further information please contact us by mail. Predju Nmq Hopfx Aa Eof

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 510864, turning length: 200 mm, CNC lathe INDEX G200 Overhauled: 2017 Machine number: 510864 max. turning length: 200 mm Bar loading magazine INDEX MBL Main spindle Spindle passage collet clamping: 42mm Spindle diameter in front bearing: 85mm Spindle nose ISO702/1: 5 Chuck diameter: 140/160 Max. Nominal turning diameter: 200mm Max. Rotation diameter: 420mm Power Pmax 100%: 7.5/13/20 Torque Mdmax 100%: 35/61/95 Speed: 6300 Counter spindle Spindle passage collet clamping: 42mm Spindle diameter in front bearing: 85mm Spindle nose ISO702/1: 5 Chuck diameter: 140/160 Power Pmax 100%: 7.5/13 Torque Mdmax 100%: 35/61 Speed: 6300 Min. distance collet: 15mm Longitudinal travel: 445mm Rapid traverse: 22.5mm Cross slide 1 XZ (top) XZ: 120x400mm Feed force: 5000N Cross slide 2 (bottom) XZ: 105x400mm Pjdpfxoulhine Aa Eorf Feed force: 5000N Further information on request!

Condition: used, Year of construction: 2001, workpice diameter max. 90 mm forward bearing diameter 140 mm Turning speeds mainspindle 4.200 U/min Pedjvzcnbepfx Aa Eerf Power 35,5 KW Control INDEX C 200-4 travel -x axis 1.500 mm travel -z axis 340 mm travel -y axis 180 mm b-axis 360 ° CNC turning and milling center vertical | INDEX - V300 equipped with a turret for driven tools as well as y- + B- axis. Further information: - direct measuring system on X + Z The machine is in good condition. For additional equipment information please refer to the original order confirmation which is included in the offer of this machine. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: V-300 | V 300

Condition: reconditioned (used), Year of construction: 1996, functionality: fully functional, turning length: 1,250 mm, spindle diameter: 90 mm, number of slots in tool magazine: 24, Recently renewed (January 2024): Guides Z2 / Z4 / X2; Ball screws Z2 / X2 / Z4; Cable and hoses of the drag chains for Z2 / X2 / Z4 TECHNICAL DETAILS Turning length: 1,250 mm Spindle clearance HSP/GSP: 90 / 90 mm Spindle nose HSP/GSP: taper no. 8 C-axis HSP/GSP: yes (C4) / yes (C3) Turret 1 Axes: XYZB Stations / of which driven: 12 / 6 Additional milling spindle: Capto C4 with automatic tool changer for 6 tools Turret 2 Axes: XZ Stations / of which driven: 12 / 6 Coolant system Type: Knoll system with paper belt filter Predpfx Aevitznsa Esf Low pressure: 8 bar High pressure: max. 80 bar EQUIPMENT - 2x Hainbuch 65 chuck - Numerous turning and drilling attachments with CDI interface - Mechanical steady rest for mounting on turret - Numerous driven tools CDI-Capto C4 radial and axial - Numerous fixed holders CDI-Capto C4 radial and axial

Year of construction: 1997, condition: ready for operation (used), Turning diameter: 200mm, Unrun diameter: 260mm, Turning height: 200mm, Spindle clearance: 30mm, Spindle speed: 7500rpm, Power: 10kW, Torque: 49Nm. Travel X/Z: 520mm/200mm, rapid traverse X/Z: 30m/min, tool positions: 14, tool holder: VDI 30, drive tool speed: 6000rpm. Machine dimensions X/Y/Z: approx. 2100mm/2100mm/2300mm, weight: approx. 3300kg, control: Siemens Sinumerik. The X-axis of the machine makes running noises. Documentation available. On-site inspection is possible. Prjdpfx Aaevpvine Eof

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - Strokes X/Y/Z : 280/280/145 [mm] - Quick movement : 50 [m/min] - Loading zone strokes X/Z : 110/90 [mm] - Tools number : 8 - Motorized tools number : 2 - Rotary tools speed : 6000 [tr/min] - Rotary tools power : 9,5 [kW] - Tools type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C - Measuring rules on linear axes - Counter spindle - 1 turning tool holder for counter operation Prjdpfx Ajuhbftsa Eof - Coolant tank with pump - Chip conveyor

Condition: good (used), Year of construction: 2004, functionality: fully functional, turning length: 600 mm, INDEX C65 Podpfx Aev Dgpzea Esrf CNC turning and milling center Control Index C200-4D (Siemens 840d) 3 turrets each with 12 stations VDI-25 with W-toothing, all stations driven C-axis on main and counter spindle Transmit/Transcyl function Index tool breakage monitoring Parts gantry gripper/parts conveyor belt 600L coolant tank with sieve, 8/18 bar Flow-through cooler for coolant Bar passage up to 65mm on main and counter spindle FMB Turbo 10-65, 3-meter bar loader Chip conveyor Machine is cleaned and loaded freely onto a truck

Year of construction: 2021, condition: ready for operation (used), A bar feeder index is available. Bar diameter (round material): 10mm-65mm, max. bar diameter (hexagonal material): 55mm, max. bar diameter (square material): 46mm, bar length range: 1700mm/4200mm, feed force: 1500N, rapid traverse: 50m/min, feed rate: 30m/min. Machine length: approx. 5300mm, machine weight: approx. 2700kg. Documentation available. On-site inspection is possible. Psdpfxswtg E He Aa Eorf

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 Prjdpfx Aasuhbgwo Ejf - X/Y/Z strokes : 280/280/145 [mm] - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] EQUIPMENT - CN Siemens 840D - Axis C

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - X/Y/Z strokes : 280/280/145 [mm] - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] Pedpfxeuhbgde Aa Eorf EQUIPMENT - CN Siemens 840D - Axis C

Condition: used, TECHNICAL DETAILS - Spindle power : 10,5 [kW] - Spindle speed : 10 000 [Rpm] - Spindle type : A2-4 - X/Y/Z strokes : 280/280/145 [mm] - Rapid traverse : 50 [m/min] - Loading zone X/Z strokes : 110/90 [mm] - Number of tools : 8 - Live tools speed : 6000 [Rpm] - Live tools power : 9,5 [kW] - Tool type : Capto C4 - Dimensions : 1700 x 3000 x 2400 [mm] - Weight : 4000 [kg] - Total installed power : 2,5 [kW] Pedpouhbf Tsfx Aa Eerf EQUIPMENT - CN Siemens 840D - Axis C

Condition: good (used), Year of construction: 2014, Control FANUC 31i-B Main Spindle Bar Capacity 65mm Main Spindle Speed 5000rpm Main Spindle Motor 24/20kW Main Spindle C axis 0.0001 degree Sub Spindle Bar Capacity 65mm Sub Spindle Speed 5000rpm Sub Spindle Motor 24/20kW Sub Spindle C axis 0.0001 degree Sub Spindle Stroke 700mm Sub Spindle Rapid 50m/minute Turret 1 Stations 10 Milling Speed 6000rpm Milling Motor 6.5kW X Axis Stroke 110mm X Axis Rapid 30m/minute Z Axis Stroke 320mm Z Axis Rapid 60m/minute Y Axis Stroke 100mm Y Axis Rapid 15m/minute Turret 2 Stations 10 Prjdsx H R R Hjpfx Aa Eof Milling Speed 6000rpm Milling Motor 6.5kW X Axis Stroke 110mm X Axis Rapid 30m/minute Z Axis Stroke 550mm Z Axis Rapid 60m/minute Y Axis Stroke 100mm Y Axis Rapid 15m/minute Turret 3 Stations 10 Milling Speed 6000rpm Milling Motor 6.5kW X Axis Stroke 180mm X Axis Rapid 30m/minute Installation Footprint 8500 x 1800mm Weight 9000kg Electrics 72 kW, 84 kVA, 122 A, 400 V, 50/60 Hz Accessories Gantry work piece discharge unit, Parts Conveyor, Swarf Conveyor. High Pressure Coolant, Manuals, Tool Monitoring, UNIMAG Interface, Iemca Master 880/33-HF Magazine Barfeed, Hainbuch Collet Chuck fiited to Main Spindle, 3 jaw chuck fitted to Sub Spindle

Condition: used, Technical details: turning diameter: 626 mm turning length: 3000 mm Turning diameter: 600 mm spindle bore: 100 mm spindle turning speed range: 2800 U/min Psdpfovgmimex Aa Eerf weight of the machine ca.: 18 t Machine overhold and retrofit in 2003 with SIEMENS 840 D control - NC steady rest - 12-fold revolving head - splash doors - tailstock - coolant device *

Condition: used, Year of construction: 2015, Technical details: Pjdpfxjxc Idme Aa Eorf number of spindles: 6 spindle passage: 22 mm ?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU. The complete energy supply of all 6 main spindles was replaced in April 25. *

Year of construction: 1982, condition: good (used), Spare parts for CNC lathe INDEX GU 1500 year 1982 Following parts : Tool turret Tailstock Prjdjd Etq Hepfx Aa Eef Complete guide covers.

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, Index ABC (built in 1997) – CNC lathe with MBL Unimag bar feeder Condition: Used, functional Year of manufacture: 1997 Control: Siemens 840C Included: MBL Unimag bar feeder Technical specifications: Max. spindle bore: 61 mm Main spindle speed: up to approx. 6,300 rpm Control: Siemens Sinumerik 840C Spindle mount: A6 or A8 (depending on model) X/Z travel: approx. X = 105 mm / Z = 300 mm Pjdpfx Aaswl Egae Esrf Machine weight: approx. 5,000 kg Space requirement (L x W x H): approx. 3,200 x 1,800 x 2,000 mm Accessories: ✅ MBL Unimag bar feeder – for round material up to Ø 60 mm ✅ Collets and clamping devices ✅ Technical documentation ✅ Chip conveyors

Condition: good (used), Year of construction: 2014, Control FANUC 31i-B Main Spindle Bar Capacity 42mm Main Spindle Speed 7000rpm Main Spindle Motor 29/25kW Main Spindle C axis 0.0001 degree Sub Spindle Bar Capacity 42mm Prsdpfx Aajx H R Rtj Eef Sub Spindle Speed 7000rpm Sub Spindle Motor 19/16.5kW Sub Spindle C axis 0.0001 degree Sub Spindle Stroke 500mm Sub Spindle Rapid 60m/minute Turret 1 Stations 10 Milling Speed 6000rpm Milling Motor 4.2kW X Axis Stroke 70mm X Axis Rapid 30m/minute Z Axis Stroke 250mm Z Axis Rapid 60m/minute Y Axis Stroke 70mm Y Axis Rapid 15m/minute Turret 2 Stations 10 Milling Speed 6000rpm Milling Motor 4.2kW X Axis Stroke 70mm X Axis Rapid 30m/minute Z Axis Stroke 400mm Z Axis Rapid 60m/minute Y Axis Stroke 70mm Y Axis Rapid 15m/minute Turret 3 Stations 10 Milling Speed 6000rpm Milling Motor 4.2kW X Axis Stroke 125mm X Axis Rapid 30m/minute Installation Footprint 7612 x 1530mm Weight 5500kg Electrics 57 kW, 68 kVA, 97 A, 400 V, 50/60 H Accessories Gantry work piece discharge unit, Parts Conveyor, Swarf Conveyor. High Pressure Coolant, Manuals, Tool Monitoring, UNIMAG Interface, Iemca Boss 552-HD Magazine Barfeed, Hainbuch Collet Chuck fiited to Main Spindle, 3 jaw chuck fitted to Sub Spindle

Condition: used, Year of construction: 2009, Technical details: turning diameter: 270 -300 mm turning length: 710 mm total power requirement: 43 kW weight of the machine ca.: 8,5 t Predpfx Aasw Dud Ej Eof dimensions of the machine ca.: 3,16 x 2,15 x 2,15 m The machine does not include a chuck or tools – the machine was originally purchased without these accessories. The G300 has X, Z, Y, C, SP, and driven tools. A bar feeder can be used, but the machine does not have one. *
