Used Bruderer for sale (52)

Condition: good (used), Year of construction: 1991, operating hours: 49,637 h, functionality: fully functional, machine/vehicle number: 9666, ram adjustment: 64 mm, conveyor belt width: 203 mm, pressing force: 50 t, control cabinet length: 940 mm, control cabinet width: 760 mm, stroke length: 1,651 mm, input voltage: 380 V, overall weight: 9,000 kg, control voltage: 24 V, sheet thickness steel (max.): 4 mm, input frequency: 50 Hz, sheet thickness aluminum (max.): 4 mm, Technical Data Manufacturer: BRUDERER AG Model: BSTA 50 EL CNC Machine Type: CNC High-Performance Punching Machine Year of Construction: 1991 Machine Number: 9666 Press Force: 500 kN (50 t) Connected Load: 40 kW Main Motor Power: 25 kW Supply Voltage: 380 V / 50 Hz Control Voltage: 24 V DC Compressed Air Connection: 6–10 bar Operating Hours: approx. 49,637 h Adjustable Stroke: 16–51 mm Mounting Space/Clamping Plate: 760 x 940 mm Main Drive: 22 kW Power Supply: 400 V / 50 Hz Table Area: 940 x 580 mm Strip Feed Height (adjustable): 50–140 mm Max. Strip Width: 203 mm Max. Material Thickness: 4 mm Hsdpfjzuur Uex Ac Tst Dimensions of machine with BBV 202: 2390 x 1270 x 3090 mm Machine Weight: approx. 9000 kg Configuration 2 x BRUDERER BBV 202/120 DOUBLE strip feeder KOHLER leveling machine 100.180/2.500.2M, year of construction 1992 Unwinding reel / coil reel Soundproof cabin Conveyor belt for part removal Lifting and sorting device for containers Roller conveyors and stacking racks Technical documentation available Description Complete BRUDERER high-performance punching line consisting of a precision punching machine BSTA 50 EL, BRUDERER strip feeder BBV 202/120, KOHLER leveling machine, unwinding reel, soundproof cabin, and discharge and conveying equipment. The system is designed for the efficient processing of strip material in high-speed punching operations. Extensive technical documentation is available.

Condition: used, Year of construction: 1977, Stamping Press Manufacturer: Bruderer AG, Arbon, Switzerland Type: BSTA 110 Serial number: 4343 Hjdpfozil Suox Ac Tot Year of manufacture: 1977 Press force: 110 tonnes Stroke rate: 100–850 strokes/min Stroke (adjustable): 16, 19, 26, 35, 43, 51, 58, 64, 70, 75 mm Ram adjustment: 89 mm Max. tool installation width: 1,170 mm Max. strip feed width: 400 mm Strip feed height above clamping plate: 80–180 mm Bed opening: 1,120 x 400 mm Connected load: 50 kW Supply voltage: 3 x 380 V AC, 50 Hz Control voltage: 24 V AC Compressed air connection: R ½", 6–10 bar Machine dimensions (H x W x D): 3,930 x 3,320 x 2,250 mm Total weight incl. strip feed: approx. 24,600 kg Strip Feed Unit Manufacturer: Bruderer AG, Arbon, Switzerland Type: BBV 320/200 Max. feed: 200 mm Max. strokes/min: up to 1,000 (feed-dependent) Accessories Kohler unwinder Heспо straightener SYS PHS 5000 Sound-insulating enclosure (orange)

Condition: reconditioned (used), Year of construction: 1981, functionality: fully functional, Thrust (tons) 60 Table size (x-y/mm) 890 x 458 Ram dimensions X-Y (mm) 890 x 458 Stroke (mm) 20 - 76 Hedozxt Hlspfx Ac Tot Slide adjustment (mm) 80 Type of strokes: adjustable Strokes per minute 70 - 750

Condition: used, Year of construction: 2004, pressure 80 t stroke 16 - 63 mm no. of strokes 100 - 750 /min distance between columns 970 mm dayligth (stroke and adjustment up) 380 mm column travel -side 380 mm table surface area 940 x 910 mm hole in the table 770 x 190 mm table height over floor 1180 mm ram surface 940 x 510 mm ram adjustment 76 mm material width 203 mm material thickness - 6,0 mm feed length 0 - 120 mm power requirement 37,0 kW Weight 14,50 t dimensions of the machine ca. 2,7 x 1,7 x 3,6 m Hjdpfszrpq Hox Ac Tet with infinitely variable drive, pneumatic clutch/brake combination, semi-automatic stroke adjustment, motoric ram adjustment, fix table, circular oil lubrication mechanical roll feed Bruderer BBV 205/120 with drive via main shaft / pivot shaft of the press consoles Guethle CK 01/0800

Condition: reconditioned (used), Year of construction: 1996, pressing force: 50 t, stroke length: 51 mm, Bruderer BSTA 50USL Hodpfozlqgisx Ac Tjt - Tool loading area 1100mm L-R - Machine under refurbishment, with new controls, - Roll feed BBV or optionally servo feeder available Please contact us for a detailed quotation!

Year of construction: 1993, condition: ready for operation (used), Pressing force: 2000kN, max. installation height: 550mm, total power requirement: 72kW, operating pressure: 210bar. Including feed unit. On-site inspection is possible. Hjdpev Tnytofx Ac Tjt

Condition: excellent (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 9443, total height: 3,160 mm, ram adjustment: 64 mm, total width: 1,300 mm, total length: 2,470 mm, conveyor belt width: 160 mm, pressing force: 50 t, control cabinet height: 1,100 mm, control cabinet length: 1,250 mm, control cabinet width: 400 mm, type of input current: AC, stroke adjustment: 1,651 mm, clearance between the columns: 250 mm, working width: 950 mm, input voltage: 380 V, overall weight: 8,600 kg, control voltage: 24 V, conveyor belt thickness: 4 mm, pressure: 5 bar, compressed air connection: 10 bar, input frequency: 50 Hz, punching force: 50 t, BRUDERER BSTA 50HL (500 kN, year of manufacture 1990, order no. 9443) HIGH-PERFORMANCE STAMPING PRESS 100-1000 SPM Technical data Press manufacturer: BRUDERER AG, Frasnacht, Switzerland Machine model: BSTA 50 HL Serial/order number: Order no. 9443 Year of manufacture: 1990 Total weight approx.: 8,700 kg Soundproof cabin: W 3,460 × L 2,331 × H 3,910 mm (optional extra) Hodpfx Acozq Sdye Tst Stroke range (adjustable): 16 / 19 / 25 / 32 / 38 / 44 / 51 mm Ram adjustment range: 64 mm Tool opening width (max.): 950 mm Support plate – width × depth: 940 × 650 mm Base plate opening W × D: 900 × 200 mm Strip feed height (adjustable): 60 – 140 mm Max. strip feed width: 250 mm Feeder: BBV 195 - 85 Feed angle: 90 degrees Max. strip thickness: 4 mm, strip width: 160 mm Feed length: 0 – 85 mm Supply voltage: 3 × 380 V / 50 Hz Main motor power: 28 kW Control voltage (DC): 24 V DC Pneumatic supply: 6 – 10 bar (R ½" connection) Press width (with feeder): approx. 2,471 mm Press depth: approx. 1,302 mm Press height: approx. 3,165 mm Price including transport in Europe Original technical documentation and circuit diagrams Optional: Sound-insulating safety cabin/enclosure

Year of construction: 1986, condition: ready for operation (used), Max. pressing force: 400kN, stroke rate: 100-1200/min, connected load: 18kW, compressed air connection: R 1/2inch, 6-10bar, adjustable strokes: 13, 15, 19, 25, 32, 38, 44, 51, 57mm, max. fixed stroke (special version): 57mm, ram height adjustment: 60mm, tool installation height: 4 Mm 677, max. width of tool installation opening: 690mm, max. strip passage width: 190mm, strip feed height above clamping plate: 60-140mm, bed opening: 640x220mm, lower clamping plate: 4 Mm 671, upper clamping plate: 4 Mm 672, installation dimensions: 4 Mm 667, length: 1695mm, width: 2185mm, height: 3010mm, weight with feed unit: 6.37t. Equipment: drive control, tool clamping plate, installation dimensions, upper clamping plate, hand protection device, BBV 41.202/150 strip feed unit, strip-end monitoring, transport and lifting device, complete documentation, installation, operating and maintenance instructions and machine tools. An on-site inspection is possible. Hedpfx Acjztra Te Tst

Condition: used, machine/vehicle number: 4131, Item No. Lg 34422 High-performance stamping press BRUDERER BSTA 60 H Hjdpfx Acsinzdls Tet from current production. Stroke adjustment needs to be repaired. without soundproof cabin and without conveyor system. Feeder BBV 202/120

Condition: good (used), Year of construction: 1996, operating hours: 51,573 h, ram adjustment: 51 mm, table length: 510 mm, table width: 400 mm, input voltage: 400 V, Bruderer BSTA200M High-performance automatic punching press. Max. pressure: 200 [kN] (20 [T]). Speed range: 100 - 1800 [spm]. Year of manufacture: 1996. Hjdpfx Aceq A Uaho Tet Feed BBV 101/75 on the right-hand side. Max. strip width: 125 [mm]. Max. feed distance: 75 [mm]. Adjustable stroke: 8; 13; 19; 25; 32; 38; 44; 51 [mm]. Ram height adjustment: 51 [mm]. Dimensions of the clamping plate (clamping plate): 510 x 400 [mm]. Bed opening: 400 x 160 [mm]. Max. distance of the mold width between the columns: 410 [mm]. Max. strip passage width: 260 [mm].= Connected load: 36 [kVA]. Power 400 [V] 50 [Hz]. Control voltage: 24 [V]. Machine dimensions: H 2540 x W 1661 x D 855 [mm]. Machine weight: approx. 3100 [kg]. Control cabinet and control system. CABIN ON PHOTOS IS NOT INCLUDED (optional cost of cabin only 8.000 EUR) Including all original technical documentation. Also high-speed presses in stock: Mabu, Schaal, Bihler and other Bruderer models.

Condition: ready for operation (used), Year of construction: 1995, operating hours: 41,000 h, functionality: fully functional, FOR SALE: BRUDERER BSTA 50USL High-Speed Stamping Press With Automatic Strip Feeder BBV 190 500 kN | 100–1120 spm | Fully automatic | Top-tier Swiss quality Technical Highlights: Nominal force: 500 kN Hsdpowpg Rbjfx Ac Tst Stroke rate: 100–1120 strokes per minute Working hours: 41000 h Main motor: 22 kW Control voltage: 24V DC Power connection: 400V / 50Hz / 62 kVA Adjustable stroke: 16 / 19 / 25 / 32 / 38 /44 / 51  mm Shut height adjustment: 64 mm Working Dimensions: Max tool installation width: 1100 mm Strip pass width: up to 256 mm Ram area: 980 × 420 mm Table area: 1080 × 650 mm Strip entry height adjustable: 60–140 mm Max strip width: 120 mm Max feeding pitch: 85 mm Max material thickness: 4 mm Feeding angle: 180 Deg Machine Dimensions (with BBV 190): Machine footprint (L × W × H): 2407 × 1278 × 3150 mm Weight (approx.): 8,000 kg Equipment Includes: Feeder BBV 190 – fully synchronized mechanical strip feeder system Integrated control cabinet Pneumatic clutch and brake Adjustable stroke and shut height Compressed air connection: 6–10 bar Oil cooling unit included Ready for integration with peripheral systems Condition & Delivery: Machine in excellent technical and visual condition Fully serviced and tested Immediate availability from Europe Worldwide shipping & installation support available Contact us today for pricing and further technical details. Let us help you upgrade your production line with Swiss precision engineering.

Condition: reconditioned (used), functionality: fully functional, ram adjustment: 40 mm, installation height: 2,500 mm, pressing force: 30 t, stroke length: 40 mm, High Speed Automatic Punching Press. Machine with CE certificate and EUR1 certificate of European origin. Hodpevkfmrefx Ac Tst Equipped with twin synchronized double rolls feeds for strips widths from 5 mm – 150 mm. PLC touch screen logical interface control. Numerically controlled stamping process (NC). With stroke and speed counter, programmable length, auto stop. Three working modes: Manual, One stroke and Automatic. Pneumatic clutch and brake. Operator’s instruction manual in English. Stroke power: 300 [KN] (30 [tons]). Adjustable stroke: 8-40 [mm]. Table: 540 x 300 [mm]. Adjustable speed 100 – 600 strokes per minute up to 10 in one second. Maximum strip thickness 2.5 [mm]. Central lubrication. Power consumption 5.5 [kW] Technical Air 5-10 [bar]. Warranty: 1 year. Two feeders are used when you need to stamp very thin, soft strip or very heavy strip, to secure precise feeding. All specifications non-binding , subject to change without notice.

Condition: good (used), Year of construction: 1990, operating hours: 39,687 h, functionality: fully functional, Bruderer BSTA 200 High-performance automatic punching press. max. pressure: 200 kN 20 T Speed range: 100 - 600 spm Year of construction: 1990. Feed BBV on the left side. Adjustable stroke: 8; 13; 19; 25; 32; 38; 44; 51 mm Ram height adjustment: 51 mm Dimensions of the clamping plate (clamping plate): 510 x 400 mm Bed opening: 400 x 160 mm Max. distance of the tool width between the columns: 410 mm. Connected load: 36 kVA Power 400 V 50 Hz Hsdstraadjpfx Ac Tet Control voltage: 24 V Machine dimensions: H 2540 x W 1661 x D 855 mm Machine weight: approx. 3100 kg Switch cabinet and control system. Including all original technical documentation. Also high-speed presses in stock: Mabu, Schaal, Bihler and other Bruderer models.

Condition: used, Year of construction: 1989, Make and model: Bruderer BSTA 25 EL Year of manufacture: 1989 Nominal capacity: 250 kN, 25 tons Hodpfx Aceyrf Aas Tjt Max. number of strokes: 100/1350 Adjustable stroke: 13, 16, 19, 25, 32, 38 mm Table dimensions: 640 x 530 mm Passage between the supports: Longitudinal 640 mm; Lateral 220 mm Fitted with roll feeder BBV 190/85 on right hand side. Max width of strip: 160 mm Feed length: variable up to 85 mm max Optional: Sound insulating cabin Oil pump. Heat exchange oil cooler. Front and rear safety guards. Fitted on 4 spring feet. Slide/Ram adjustment: 51 mm Documentation included. Press weight cca. 5000 kg.

Condition: ready for operation (used), functionality: fully functional, FOR SALE: BRUDERER BSTA 60 High-Speed Stamping Press With Automatic Strip Feeder BBV 300/200 600 kN | 100–800 spm | Fully automatic | Top-tier Swiss quality Technical Highlights: Nominal force: 600 kN Stroke rate: 100–800 strokes per minute Max. feed length: 200 mm. Year: Unknown (No ID Plate) / Tested under power: 2025 Drive power: 30 Hp Control voltage: 24V AC Power connection: 440VAC / 50Hz Adjustable stroke: 20 / 25 / 31 / 38 / 45 /51 / 58 / 64 / 70 / 76 mm Shut/Ram height adjustment: 80 mm Hjdpjxz Ugxefx Ac Tst Working Dimensions: Max tool installation width: 620 mm Strip pass width: up to 320 mm Ram area: 800 × 500 mm Table area: 620 × 680 mm Max strip width: 300 mm Max feeding pitch: 200 mm Max material thickness: 6 mm Feeding angle: 180 Deg Machine Dimensions: Machine footprint (L × W × H): 2210 × 2075 × 2190 mm Weight (approx.): 8,000 kg Equipment Includes: Feeder BBV 300 – fully synchronized mechanical strip feeder system Integrated control cabinet Pneumatic clutch and brake Adjustable stroke and shut height Compressed air connection: 6–10 bar Oil cooling unit included Ready for integration with peripheral systems Machine in excellent technical and visual condition Fully tested Immediate availability from Europe Worldwide shipping available Contact us today for pricing and further technical details. Let us help you upgrade your production line with Swiss precision engineering.

Condition: excellent (used), Year of construction: 1988, Force: 125 tons Hsdpfsdvb Tfsx Ac Tst Windows: yes Daylight: 380mm Table: 1100x700mm Ram: 700x350mm Stroke: 01-120mm Strokes per Minute: Approx. 70 Requested power: 22kW Weight: 8500kg Height: 2900mm

Condition: used, Year of construction: 1985, pressure 25 t no. of strokes 1500 Hub/min total power requirement 20 kW Hsdpfx Aovu E I Dec Tjt

Condition: used, Year of construction: 1980, pressure 25 t Hjdpfx Acevu E Iqe Tot no. of strokes 1500 Hub/min total power requirement 20 kW

Condition: used, Year of construction: 1994, operating hours: 28,000 h, functionality: fully functional, The Bruderer BSTA 80H is an 80-ton high-speed stamping press built for heavy-duty progressive-die production, fitted with a BBV 320/200 strip feeder and Unidor tool monitoring. In stock in Pforzheim, ready for inspection. Nominal force: 800 kN (80 tons) Tool monitoring: Unidor Stroke rate: 100–1,000 spm Strip feeder: Bruderer BBV 320/200 Adjustable stroke: 16–63 mm Clamping plate area: 970 mm Main drive: 43 kW Power supply: 380 V / 50 Hz Ram area: 760 x 510 mm Table area: 950 x 910 mm Strip inlet height (adjustable): 80–180 mm Max. strip width: 360 mm Max. material thickness: 3 mm Machine dimensions: 2834 x 1742 x 3460 mm Weight: approx. 15,550 kg Operating hours (main drive): approx. 28,067 h Hodozibtbepfx Ac Tjt More machines from brands Bruderer, Bihler, Soprem, Noxon, Huras, Schaal and Mabu on stock available on request

Condition: used, Year of construction: 1995, operating hours: 42,000 h, functionality: fully functional, machine/vehicle number: 10317, The BSTA 50UL is a Bruderer high-speed precision stamping press rated at 500 kN (50 tons) nominal force, engineered for continuous progressive-die production at variable stroke rates from 100 to 1,120 strokes per minute. The press is equipped with a Bruderer BBV 202/120 strip feeder, delivering strip widths up to 203 mm and handling material thicknesses up to 2 mm. Adjustable stroke is set between 16 and 51 mm, with strip inlet height adjustable across a 50–140 mm range to accommodate varying tooling and material profiles. Nominal force: 500 kN (50 tons) Tool monitoring: Unidor Stroke rate: 100–1120 strokes per minute (variable) Strip feeder: Bruderer BBV 202/120 Adjustable stroke: 16–51 mm Mounting space / clamping plate: 760–940 mm Main drive: 22 kW Power supply: 400 V / 50 Hz Table area: 940 x 580 mm Strip inlet height (adjustable): 50–140 mm Hjdpfxozibrqj Ac Tjt Max. strip width: 203 mm Max. material thickness: 2 mm Machine dimensions: 3100 x 2700 x 1800 mm Weight: approx. 8,150 kg Operating hours: 42,416 h Sound-insulating cabin available on request More machines from brands Bruderer, Bihler, Soprem, Noxon, Huras, Schaal and Mabu on stock available on reqest

Condition: used, Year of construction: 2008, operating hours: 13,000 h, functionality: fully functional, The Bruderer BSTA 500-110B is a 500 kN Swiss-built high-speed stamping press, fitted with a BSV 75T double servo feeder for precision two-track strip feeding. Capable of up to 750 strokes per minute with B2 touch-screen control. Nominal force: 500 kN (50 tons) Year of manufacture: 2008 Stroke rate: 100–750 spm (variable) Adjustable stroke: 19 / 25 / 34 / 43 / 51 / 57 / 64 mm Ram height adjustment: 64 mm Press table area: 1080 x 650 mm Control: B2, IPC-based touch-screen press control, programmable memory for fast retooling BSV 75T DOUBLE SERVO FEEDER Type: tandem dual-feed servo unit, independently controlled tracks Hedpezh Nnwsfx Ac Tot Max. strip width: 70 mm per track Max. material thickness: 2 mm Feed length: variable, freely programmable Feed angle: variable Pilot release angle: variable No clamping/gripper bars — strip held by driven feed rollers during stamping Designed for parallel advancing of two strips or feeding pre-profiled/pre-stamped strip

Condition: refurbished (used), Year of construction: 2027, pressing force: 60 t, Machine made to order: High speed press BSTA 60 Retrofit and general overhaul Conversion to electronic drive und new Unidor PC-control system. Tool area enlargement possible. Hodezlqlfjpfx Ac Tjt Please contact us for detailed offers.

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, Bruderer roll feed, BBV 202/120, left-hand side, suitable for installation on BSTA 25/250 or BSTA 50/500 presses Feed length 0-120 mm Roller width 120 mm Strip inlet width max. 203 mm Strip thickness max. 6 mm Feed length adjustment motorized. Fully overhauled in 2025. Available for immediate delivery. Also in stock are other feeder models, such as BBV 190/85, BBV 195/85, BBV 205/120, BBV 320/200 etc. Hjdszlqkbopfx Ac Tst Please contact us for more information!

Condition: excellent (used), Year of construction: 2007, operating hours: 19,269 h, functionality: fully functional, BSTA 41, with 2x BBV 202/120+ scrap shear complete refurbished by Bruderer Swiss in 2007, CE conversion possible Hedpfxozlqi Dj Ac Tst Contact us!

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, stroke length: 38 mm, input voltage: 400 V, punching force: 25 t, Bruderer BSTA 25USL with BBV 190/85 roll feed, - year of mfg. 2000 - Tool area 750mm - Adjustable stroke 13 to 38mm - complete documentation - Soundproof cabin Hjdszlqhyepfx Ac Tst - Machine checked, in very good condition! contact us!
