3-fold attachment table for Hermle

Hermle C600U, C20U, C30U, C250U, B300U

Condition: excellent (used), Year of construction: 2000, Siemens control unit Bar passage 32 mm 2 x 12-position turrets with driven tools Main / counter spindle Y-axis turret top Parts lifting device Chip conveyor IRCO bar loading magazine Kdedpjwh U Edofx Ah Eeh

Condition: good (used), Year of construction: 1989, operating hours: 64,136 h, Centre height: 350 mm Turning length: 1000 mm Max. swing diameter over bed cover: 600 mm Max. swing diameter over cross slide: 360 mm Kdodjvr Eh Ejpfx Ah Esh Spindle bore: 107 mm Speed range: 16 – 3150 rpm Feed range longitudinal & face: 0.5 – 5000 mm/min Rapid traverse longitudinal & face: 9 m/min Main drive: 30 kW Dimensions of machine with chip conveyor (L x W x H): 5400 x 2200 x 2000 mm Weight: 6400 kg Accessories / Special features: • CNC control GILDEMEISTER EPL 2 with TFT display General description: CNC manual input control system with program entry via function and numeric keypad. All information is entered in dialogue with the screen. Integrated menu technology with plain text display of all functions. Operator keypad, display, and electronic handwheel located within a separate chip guard housing. The EPL control offers the following capabilities: • Direct interactive program entry and editing by the operator through the EPL control without manual technological preparation • NC programs in ISO/EIA format can be entered, output, or manually keyed in via the RS 232 serial interface Machining cycles: • Removal cycles for longitudinal, facing, and contour turning, including with allowance • Thread cutting • Undercuts as per DIN 509-Form E and F and DIN 76; grind stock programmable • Axial and radial grooves as per DIN 471 and 472, including bottom finishing • 90° radii and 45° chamfers • Automatic cutter radius compensation for cycles, undercut, groove, radius, chamfer Programming: • Block-orientated, metric/inch, diameter for absolute entry, radius for incremental entry • Full circle programming, subroutine technology, hide levels for program sections, zero point offset, mode selection via menu Program entry and output: • Interactive via guided menu or direct in dialogue • Hydraulic 3-jaw chuck Ø 315 mm with through spindle bore Ø 80 mm • Hinged chip conveyor • 12-position tool turret VDI 40, 6 standard stations + 6 driven tool stations • Coolant system • RS 232 interface • Electronic handwheel • Electric foot switch for 3-jaw chuck and tailstock quill • Lighting • 12 various standard toolholders (to be finalized on site) Overhauled servo drive for main spindle, 06/2025 Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2013, Technical details: x-travel: 760 mm y-travel: 460 mm z-travel: 460 mm control: Heidenhain TNC 620 switched on hours: 20246 h spindle hours: 7724 h number of spindle speeds: 12.000 U/min. max. torque on the spindle: 75 - 95 Nm spindle taper MT: SK40 tool changer with: 24 Plätze table-size: 900 x 410 mm Kdsdpjvhbpdefx Ah Ejh max. table load: 350 kg feed range: k.A. rapid traverse:: 36 m/min interface: RS232 control voltage: 24 DC V air-pressure connection: 6 / 8 bar total power requirement: 20 kVA Weight approx.: ca. 6,0 t dimension coolant device: 1,7 x 0,7 x 1,35 m dimension machine xH: 1,9 x 2,3 x 2,45 m TNC620 (contouring control with up to 5 controlled axes, particularly suitable for universal milling), can be integrated into the network Safety doors with impact-resistant plastic window panes Chip conveyor Hydraulic unit Coolant preparation system Rittal cooling system on the control cabinet Work area Interior lighting *

Condition: good (used), Year of construction: 2008, In good technical condition and fully operational. Year of manufacture: 2008. Additional Y-axis ±60 mm Maximum spindle speed 3,000 min⁻¹ Spindle motor power 22/18.5 kW Maximum driven tool speed 6,000 min⁻¹ - 300 mm chuck with 90 mm through hole, spindle head A2-8 - Increased power and torque 25/30 kW, 1,000/1,300 Nm - Turning diameter 420-500 mm Kdjdpfx Asxdcigeh Eoh - Turning length 1,250 mm - C-axis, driven tools - NC tailstock, fully programmable, separate motor - Increased Z-axis power - New chip conveyor

Condition: used, Year of construction: 2014, max. turning diameter 160 mm max. turning height 150 mm max. workpiece diameter 100 mm max. workpiece height 150 mm max. turning speeds 6.000 U/min travel -x axis 700 mm Kdedpeqvd Iqjfx Ah Eoh travel -z axis 375 mm c-axis 360 ° control FANUC Vertical Turning Machine | EMAG - VL2 equipped with a workpiece conveyor belt. The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VL-2 | VL 2

Condition: used, Year of construction: 2019, functionality: fully functional, CNC SMOOTH G, travels 730 x 730 x 730 mm, 2 pallets 500 x 500 mm, spindle speed 18,000 rpm, 120-tool magazine, max. workpiece diameter 800 x 1000 mm, rapid traverse 60 m/min, through-spindle coolant 15 bar, RENISHAW preparation, NC rotary table with 360.00 positions, CONCEP conveyor. Kdjdpfsxcvycjx Ah Eoh

Condition: excellent (used), Year of construction: 1991, max. wheel diameter 10 - 330 mm gear width 180 mm max. module 7 min. module 0,5 clamping length 420 mm number of teeth 10 - 600 ical angle +/- 45 ° turning speeds 1100 - 1900 U/min Ksdpow I Hq Dsfx Ah Esdh grinding wheel diameter 280 - 350 mm grinding wheel width 84 - 104 weight of the machine ca. 5,1 t dimensions of the machine ca. 4,5 x 6,0 x 2,3 m

Condition: excellent (used), max. workpiece diameter 600 mm threading length 7000 mm max. module 8 / 12 min. module 1 swival range ° diameter of hob 63 - 140 mm spindle turning speed - stepless 45 - 450 U/min weight of the machine ca. 12,5 t dimensions of the machine ca. 9,0 x 2,0 x 2,2 m Condition: In good condition, checked and partially overhauled by a specialist. The existing milling head was replaced by an overhauled universal milling head. Furnishing: Differential for inclined machining Automatic indexing device (indexing discs changeable!) For multi-wedge, multi-thread parts, then extensive bushings, support rollers and around 70 Change gears. Conversion of the milling head speed to a frequency converter with corresponding Kodpfx Aswgizdeh Ejdh powerful motor is a great thing and saves a lot of set-up time. Equipment: Around 70 change gears, 3 bushing sticks of different sizes, around 20 Bushings, 2 roller mountings, 2 tips for direct mounting on the Clamping spindle, 350 mm chuck, 2 spare part disks.

Condition: ready for operation (used), Swing diameter over bed/face slide: 570mm/420mm, turning diameter: 420mm, turning length: 635mm, traverse path X/Z: 220mm/635mm, speed: 5000rpm, spindle bore: 79mm, max. bar diameter: 65mm. Tool positions: 12, driven tools: 6, tool holder: VDI 30, rapid traverse X/Z: 24m/30m/min. Machine dimensions X/Y/Z: approx. 3500mm/2500mm/2000mm, weight: approx. 4500kg. On-site inspection is possible. Ksdpov Uqcgsfx Ah Eedh

Condition: used, Year of construction: 1969, max. wheel diameter 160,175 mm gear width 355 mm max. module 4,5 spindle bore 75 mm centre distance 410 mm min. number of teeth 2, 3 Kdodpfxevzhf Ss Ah Eoh cutter diameter max. 115 mm cutter length max. 105 mm axis distance between cutter and workpiece - max. 138 mm axis distance between cutter and workpiece - min. 30 mm milling head -swivable 120 ° milling spindle speeds 70 - 400 U/min axial-feeds 0,25 - 4,0 mm/U radial feeds 0,09 - 1,5 mm/U total power requirement ca. 9,5 kW weight of the machine ca. 3,5 t dimensions of the machine ca. 1730x1400x1440 mm Equipment/accessories: - Interchangeable wheels - Milling arbors - Clamping devices - Documentation
