CNC turning and milling center

DMG MORI NLX 2500/700

Condition: ready for operation (used), Year of construction: 2013, operating hours: 12,981 h, overall weight: 6,200 kg, This 3-axis DMG MORI NLX 2500Y/700 was manufactured in 2013. It features a main spindle speed of 4000 rpm, a spindle bore of 80 mm, and a 20-station turret BMT40. The machine includes a KNOLL high-pressure system (70 bar) and a chip conveyor. Consider the opportunity to buy this DMG MORI NLX 2500Y/700 horizontal turning machine. Contact us for more information about this machine. Hfjdex Tv Tyopfx Ag Ueb • Rated Power: 30 kVA • Milling Drive Speed: 10000 rpm • Workpiece unloading with tray onto conveyor belt • 20-station turret BMT40 • NC tailstock • Integrated measuring arm for tool measurement • Includes KNOLL high-pressure system (70 bar) & chip conveyor • Various SMW Ø40/Ø60/Ø80 collet chuck • Main Spindle Speed: 4000 rpm • Spindle Bore: 80 mm • Enclosed safety enclosure

Condition: like new (used), Year of construction: 2023, operating hours: 3,751 h, functionality: fully functional, turning length: 700 mm, turning diameter: 356 mm, spindle speed (min.): 6,000 rpm, spindle bore: 81 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 795 mm, DMG MORI NLX2500/700 universal lathe with Y-axis, bar loader and driven tools. Main and counter spindle. Spindle bore diameter: 81 mm. An optional tooling package worth €60,000, which was purchased together with the machine, is available. Hodpfxjx Sp Ize Ag Ujfb

Condition: like new (used), Year of construction: 2011, operating hours: 9,080 h, functionality: fully functional, For sale: Well-maintained CNC turning and milling center DMG Mori Seiki NLX 2500 SY/700, year of manufacture 2011, equipped with Mitsubishi 730 BM control! Only approx. 9,000 operating hours! Travel axes X-axis: 260 mm Y-axis: 100 mm Z-axis: 795 mm Equipment and accessories: - Tool turret: 12 stations, all powered - Driven tool speed: Max. 10,000 rpm - Parts catcher Hsdjxzqhrspfx Ag Usfb - Electrical connection: 400 V - Power consumption: 37.6 KVA - Internal cooling: available - Main spindle chuck: Kitagawa BB210AB - Sub-spindle chuck: Kitagawa B206A521F - Swing diameter: 366 mm - Turning length: 705 mm - Spindle bore: 80 mm - Main spindle max. speed: 4,000 rpm, with 3-jaw chuck - Main spindle power: 18.5 kW - Sub-spindle max. speed: 6,000 rpm, with 3-jaw chuck - Chip conveyor - Tool measurement system in the working area - Manually deployable measuring arm for sub-spindle - Short bar loader, manufacturer: LNS - Includes tools: 8 fixed tools, 3 driven tools - Includes extraction system, brand: Indusa - Includes complete documentation Machine available immediately! Machine has been fully cleaned and inspected! We will undertake loading of the machine! Transport can be organized upon request!

Condition: used, TECHNICAL DETAILS - Number of axes : 6 - Number of spindles : 2 - Number of turrets : 1 MAIN SPINDLE - Spindle nose : A2-8" - Spindle power : 18.5 [kW] - Spindle speeds : 4000 [rpm] - Max. bar diameter : 90 [mm] - Max. turning diameter : 460 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle nose : A2-6" - Spindle power : 11 [kW] - Spindle speeds : 6000 [rpm] - C axis indexing precision : 0.001 [°] TURRET 1 - Number of positions : 12 - Number of motorized positions : 12 - X/Z stroke : 260/795 [mm] - Y stroke : +/-50 [mm] Hfedpjx H Atyofx Ag Usb - Tool type : BMT - Live tools speed : 10000 [rpm] - Live tools power : 5.5 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 41 [kW] MACHINE HOURS - Number of hours under power : 21392.8 [h] - Number of working hours : 13797 [h] EQUIPMENT - CNC : CELOS - Interface : Ethernet / RS232 / USB / PCMCIA - Interactive programming : MAPPS V - 3 colors status lamp - Coolant tank : KNOLL * with high-pressure pump : 70 [bars] * with paper filtering unit - Tailstock option with counterspindle - Chips conveyor - Tool probe - Parts catcher - Parts conveying strip - Bar loader : LNS QUICKLOAD - Electric transformer - Number of turning tool holders : 2 - Number of fixed tool holders : 10 - Collet chuck

Condition: used, Year of construction: 2017, turning diameter max. 356 mm turning length 705 mm control M730 UM Mapps CELOS greates pass round over bed 920 mm Swing dia. over traverse guideway 742 mm turning speed range - main spindle 4.000 min/-1 power capacity - main spindel 18,5 / 15 kW spindle nose JIS A2-8 spindle bore 80 (91) mm C-Axis 0,001 ° Spindle speed range subspindle 6.000 min/-1 power capacity - Sub spindle 11 / 7,5 kW spindle bore 43 mm C-Axis 0,001 ° x-travel 260 mm z-travel 795 mm Hfsdpfxoxzk Ifs Ag Ujb Y - Axis +/-50 mm rapid traverse ( X / Y / Z ) 30 / 10 / 30 m/min number of toolpositions 12 pos. Schank height for square tool 25 mm Drill shank diameter 50 mm turret change time 0,27 sec. Spindle speed - driven tools max. 10.000 min -1 power capacity - driven tools 5,5 / 4,2 kW total power requirement 41 kVA weight of the machine ca. 6,4 t dimensions of the machine ca. 4,0 x 3,0 x 2,3 m CNC - Turning- and MillingCenter DMG MORI - NLX 2500 SY / 700 - Subspindle - Tool-Drive - C, Y-Axis - only 1.237h Spindle hours

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 7024NL256160890J, spindle speed (max.): 10,000 rpm, travel distance Y-axis: 200 mm, rotational speed (max.): 4,000 rpm, bar diameter (max.): 80 mm, distance between centers: 700 mm, Condition: Ball screw drives in X, Y, and Z axes are new + major maintenance package 6 months ago (not in use since) TECHNICAL DETAILS Centre distance: 700 mm Spindle speed: 1 - 4,000 rpm Power: 18.5 / 18.5 / 15 kW (25% duty cycle / 50% duty cycle / continuous) Bar capacity: Ø 80 mm Turret: 12 stations, bolt-on turret Tool spindle: 10,000 rpm Tool spindle power: 5.5 / 5.3 / 7 kW (3 min / 5 min / continuous) Taper: MT5, live center Centers without center tip Overhang length for driven tools: ±100 mm Control: M730UM, CELOS - ERGOline Touch Assembly units: Integrated MK4 bearing for center Chip and cooling system Scraper belt chip conveyor: with magnetic separation, discharge height approx. 1,000 mm Cooling system: increased pressure 5 bar, pump 800 W, flow rate 20 l/min Coolant shower at chuck, incl. high-performance pump Hfodsxamqmjpfx Ag Uob Compressed air discharge system for tool holders Compressed air discharge system for tailstock center In-line filter for cooling system FEATURES - Interface for oil mist separator Ø 150 mm - Tool presetting device not included - Signal light: red, yellow, green, blue - EtherNet/IP interface for automation - Robot interface for DMG Mori Seiki portal robot - Transformer: 45 kVA, three-phase autotransformer - X-axis direction ISO - Machine does not include a chuck

Year of construction: 2012, operating hours: 6,500 h, condition: ready for operation (used), Main Drive Number of axis 3 Media Chip conveyor Yes Additional Equipment KITAGAWA Hollow Clamping Device with KITAGAWA SS1881K21 for the main spindle 15 bar pump with filter Coolant system with increased pressure (5 bar) Hinged belt conveyor, right-hand discharge Integrated parts catcher for the main spindle Interface for bar feed, LNS Double foot switch with protective cover Signal light (red, yellow, green) Tool overhang length 100 mm for driven Y-axis travel + Tool holder package Transformer 45000 VA Hodpfsx D D Uwox Ag Usfb This 3-axis DMG Mori Seiki NLX2500Y 700 was manufactured in 2012. It features a KITAGAWA Hollow Clamping Device, enhanced coolant system at 5 bar, and an integrated parts catcher. Additional attributes include a hinged belt conveyor, I/F for bar feed, and a signal light system. Ideal for turn-mill operations, consider the opportunity to buy this DMG Mori Seiki NLX2500Y 700 horizontal turning machine. Contact us for more information about this machine. Application Types Turning

Condition: like new (used), Year of construction: 2018, operating hours: 23,501 h, functionality: fully functional, turning diameter over cross slide: 740 mm, turning diameter: 920 mm, spindle motor power: 18 W, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 795 mm, milling spindle length: 91 mm, rotational speed (max.): 10,000 rpm, total height: 2,395 mm, total length: 5,330 mm, total width: 4,100 mm, swing diameter over cross slide: 740 mm, spindle nose: JIS A2-8, overall weight: 8,360 kg, CNC controller: Mitsubishi M730UM (CELOS - ERGOline Touch) Capacity X-axis travel mm: 260 Y-axis travel mm: ±50 Z-axis travel mm: 795 Turning length mm: 705 Max. turning diameter mm: ø: 366 Swing over bed mm: ø: 920 Swing over cross-slide mm: 740 Bar work capacity mm: 80 Tool magazine Magazine places: 20 Tool holder: BMT40 Upper turret Number of tool slots St .: 20 Speed driven tools RPM: 10.000 Drive power driven tools kW: 5.5/4.9/4.2 (3 min/5 min/cont) Hfedjwkf H Dopfx Ag Usb Y-axis travel mm: 100 Rapid Feed Rate: 30 Main spindle Speed spindle rpm: 4.000 Drive power spindle kW: 18.5/18.5/15 (25%ED/50%ED/cont) Spindle bore mm: 91 Chuck type: Hollow chuck (Ø254 mm) BB210A821 Manufacturer: KITAGAWA Spindle nose: JIS A2-8 Maximun torque Nm: 49 Counter spindle Speed spindle rpm: 5.000 Drive power spindle kW: 11/7.5 (25%ED/cont) Spindle bore mm: 73 Chuck type: Hollow chuck (Ø210 mm) BB208A621 Manufacturer: KITAGAWA Spindle nose: JIS A2-5 Maximun torque Nm: 22 Counter spindle travel mm: 734 Coolant system Tank capacity liter: 366 Equipment Electronic Handwheel Chip conveyor Signal lamp High pressure pump Mist collector Workarea light Chuck foot switch (double) for main and counter spindle Coolant gun Measuring probe Paper band filter Preparación para trabajar con robot Robot data - Fanuc - R-30iA / Type M-16iB/20 Availability of 10 pallets in the warehouse (10 slots) Clamping by robot: ø40 to 220mm x Hight 20mm Max. Weight by robot piece: 5,6kg Working time hours Under power: 23.501 Potencial nominal kVA: 48 Cutting Time: 7.494 Basic machine dimensions / weight Length mm: 5.330 Width mm: 4.100 Height mm: 2.395 Weight kg: 8.360

Condition: used, Year of construction: 2018, turning diameter max. 356 mm turning length 705 mm control M730 UM Mapps CELOS greates pass round over bed 920 mm Swing dia. over traverse guideway 742 mm turning speed range - main spindle 4.000 min/-1 power capacity - main spindel 18,5 / 15 kW spindle nose JIS A2-8 spindle bore 80 (91) mm C-Axis 0,001 ° Spindle speed range subspindle 6.000 min/-1 power capacity - Sub spindle 11 / 7,5 kW spindle bore 43 mm C-Axis 0,001 ° x-travel 260 mm z-travel 795 mm Y - Axis +/-50 mm rapid traverse ( X / Y / Z ) 30 / 10 / 30 m/min number of toolpositions 12 pos. Schank height for square tool 25 mm Drill shank diameter 50 mm Hodpfx Asvy Ig Hsg Ujfb turret change time 0,27 sec. Spindle speed - driven tools max. 10.000 min -1 power capacity - driven tools 5,5 / 4,2 kW total power requirement 41 kVA weight of the machine ca. 6,4 t dimensions of the machine ca. 5,0 x 3,0 x 2,3 m CNC - Turning- and MillingCenter DMG MORI - NLX 2500 SY / 700 - Subspindle - Tool-Drive - C, Y-Axis

Condition: used, Year of construction: 2014, turning diameter max. 366 mm turning length 705 mm control M 730 BM MAPPS IV greates pass round over bed 920 mm Swing dia. over traverse guideway 742 mm turning speed range - main spindle 4.000 min/-1 power capacity - main spindel 18,5 / 15 kW spindle nose JIS A-8 spindle bearing diameter 140 mm spindle bore 91 mm max. usable bar diameter 80 mm chucking diameter 250 mm Spindle speed range subspindle 6.000 min/-1 power capacity - Sub spindle 11 / 7,5 kW spindle nose JIS A2-5 spindle bearing diameter 85 mm spindle bore 43 mm max. usable bar diameter ( - ) mm chucking diameter 170 mm x-travel 260 mm z-travel 795 mm Y - Axis +/-50 mm rapid traverse ( X / Y / Z ) 30 / 10 / 30 m/min number of toolpositions 12 pos. tool taper BMT 60 Schank height for square tool 25 mm Drill shank diameter 50 mm turret change time 0,27 sec. Spindle speed - driven tools max. 10.000 min -1 power capacity - driven tools 5,5 / 3,7 kW Hfodpfou Hq Rljx Ag Ueb total power requirement 40 kVA weight of the machine ca. 6,4 t dimensions of the machine ca. 5,0 x 3,0 x 2,3 m CNC - Turning- and MillingCenter DMG MORI - NLX 2500 SY / 700 - Main- and Subspindle - C-Axis - Y-Axis - Tool-Drive
