Heinz Sanders GmbH

Condition: used, Year of construction: 2000, saw blade diameter 350 mm dimensions of saw-blade 350 x 32 x 2,5 mm cutting diameter 115 mm stroke 100 mm capacity 90 degrees: square 95 mm capacity 90 degrees: flat 180 x 95 mm capacity 45 degrees: round rechts & links 110 mm capacity 45 degrees: square rechts & links 95 mm capacity 45 degrees: flat rechts & links 125 x 95 mm capacity 60 degrees: round 90 mm capacity 60 degrees: square 80 mm capacity 60 degrees: flat 90 x 95 mm cutting speed 15 / 30 / 45 / 90 m/min total power requirement 2,6 kW weight of the machine ca. 375 kg dimensions of the machine ca. 1000 x 950 x 1800 mm -The powerful, 2-stage gear was specially designed for cuts in solid material designed Kwjlhcev Rrrujdwzow -The user has a total of 4 blade speeds for optimal adjustment the material available -The large bearing rotary table with internal table clamping and Precision stops at 0/45/60° ensure quick adjustability miter cuts -The vice with quick clamping (optional is a pneumatic one Vise = MA, available) is with screwed vise jaws Mistake. With their ribbing, these ensure optimal hold of the workpiece -Underframe with lockable door, chip drawer and removable Coolant pan with electric coolant pump -Chip removal brush

Condition: used, Year of construction: 1991, sheet width 3000 mm plate thickness 6 mm rear stop 1000 mm down holder 18 Stk cutting angle 0,5-3 ° oil volume 200 l total power requirement 11 kW weight 4700 kg dimensions of the machine ca. 3850 x 2100 x 1600 mm Kjlov Rgymjhcdwzsww Furnishing: - electric back gauge 750 mm - front support plates with ball rollers - Light barrier behind the machine - Hydraulic cutting adjustment - Cutting gap regulation via handwheel - LED cutting edge lighting - 1x side stop with scale 1500 mm - 1x freely movable foot switch - Operation manual

Condition: used, Year of construction: 2008, sheet width 3050 mm plate thickness 6 mm rear stop 10-1000 mm cutting angle 0,5 - 2,5 ° down holder 20 Stk no. of strokes 14 - 23 Hub/min Kwolhsv Rgygocdwzow work height max. 900 mm oil volume 140 l total power requirement 11 kW dimensions of the machine ca. 4000 x 2150 x 1900 mm weight 7200 kg Furnishing: - electric back gauge 750 mm - front support plates with ball rollers - Light barrier behind the machine - Hydraulic cutting adjustment - Cutting gap regulation via handwheel - LED cutting edge lighting - 1x side stop with scale 1500 mm - 1x freely movable foot switch - Operation manual

Condition: new, Year of construction: 2023, pressure 150 t chamfer lenght 3100 mm distance between columns 2600 mm dayligth 450 mm throat 350 mm stroke 265 mm working feed 9,8 mm/sec Control DELEM DA 66 T total power requirement 22,5 kW weight of the machine ca. 10000 kg dimensions 4000 x 2200 x 2800 mm • Basic version as a C-frame • Compact table model • Ideal for prototypes and small series • Very short setup time • Functionally simple Kwslhcov H Eqcjdwzjw • Wide range of applications • Low noise level • Low energy consumption • Easy handling including special equipment: - CNC control DELEM DA 41T

Condition: new, Year of construction: 2024, table length 2000 mm table width 1000 mm stroke height 400 - 1010 mm weight max. in kg 300 kg weight of the machine ca. 220 kg Kwolhcdev Htkdswzow

Condition: used, Year of construction: 1991, round bar steel 35 mm square edge steel 32 mm L-beam 120 x 12 mm flat steel 400 x 16 / 200 x 20 mm Kwslhcdsv Hti Towzew punching pressure 60 t stroke 10 - 27,5 mm throat 410 mm punch diameter 27 in 17 mm total power requirement 7,5 kW weight of the machine ca. 2000 kg dimensions of the machine ca. 1800 x 800 x 1800 mm Hydraulic machine with 5 stations so punching, notching, shearing flat iron, angle iron, solid material, punching with hand lever, profile steel side with foot switch. Punching discharge: 510 mm! All performance data refer to a material strength of 450 N / mm². Electric 380 volt

Condition: used, cutting range for steel to 50 mm Kelhsv Da Udecdwzsww capacity at 100% 130 A weight of the machine ca. 130 kg dimensions of the machine ca. 650 x 400 x 900 mm

Condition: used, cutting range for steel to 25 mm capacity at 100% 80 A Kwolhcdsv Da T Tswzsw weight of the machine ca. 85 kg dimensions of the machine ca. 650 x 400 x 900 mm

Condition: used, bore capacity in steel (diameter) 35 mm throat 400 mm bore stroke 210 mm 4 speeds 71 - 1344 U/min table-size 515 x 510 mm total power requirement 4,0 kW weight 490 kg dimensions 600 x 1100 x 2250 mm Column drilling machine OPTIdrill DP 33V promotion set / 3020680SET With an electronically controllable drive in a modern design * Industrial engine * Quiet running spindle thanks to new spindle design * Machine operation with safety electronics in 24 V direct current * Guaranteed concentricity = 0.02 mm in the measured drilling spindle * Clockwise/counterclockwise rotation * Precision spindle bore * Control panel with user-friendly, dirt and water resistant * Membrane keyboard * RPM display Kelhcdev Anl Iewzjww * Separate emergency stop button * Tapping function * Precisely crafted, stable drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and rotated by Drilling depth stop * LED machine light integrated in the drill head * V-belt cover with safety switch * Thick-walled steel column for high power absorption and stability * Solid, large base plate with T-slots * Execution of the entire machine Scope of delivery: - Keyless drill chuck mm - T-Nuts -expectors - Operating tool - BMP 0 machine vice

Condition: new, pressure 175 t chamfer lenght 3100 mm distance between columns 2600 mm dayligth 480 mm throat 410 mm stroke 265 mm working feed 10 mm/sec return speed 120 mm/sec work height max. 900 mm quantity of oil 230 l total power requirement 18,5 kW weight of the machine ca. 10500 kg dimensions 4100 x 2000 x 2820 mm - DELEM CNC control model DA-58T graphics / touchscreen * 2D graphic programming * 15 "high definition color TFT screen * Bending sequence calculation * Product programming and display in real size * USB interface - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) Kwslhcdwsv Anlzjzjw - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.85-R08, system "A" with quick-change clamp - Additional crowning device in the tool holder of the upper tool - 4V universal die block M 460 R with die shoe 60 mm holder - BOSCH / HOERBIGER hydr. Components - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protective device v.d. machine Protective device against d. machine - Swiveling control panel, mounted on the left - 2x front support arms "sliding system", with T-slot and tilting cam - 1x double foot control - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes

Condition: used, bore capacity in steel (diameter) 40 mm arm length 1250 mm workpiece height max. 1150 mm turning speeds 25 - 1440 U/min feed range 0,08 - mm/min spindle taper MT 5 total power requirement 5,5 kW Kwolhcdov Anlujwzew dimensions 1900 x 2100 x 2250 mm Weight 2300 kg

Condition: used, saw blade diameter 370 mm cutting diameter 115 mm capacity 90 degrees: flat 300 x 35 mm cutting speed 11 / 15 / 22 m/min total power requirement 1,4 kW Kweljv Acihjhcdwzjw weight of the machine ca. 850 kg dimensions of the machine ca. 1100 x 1100 x 1600 mm -The powerful, 2-stage gear was specially designed for cuts in solid material designed -The user has a total of 4 blade speeds for optimal adjustment the material available -The large bearing rotary table with internal table clamping and Precision stops at ensure quick adjustability miter cuts -The vice with quick clamping (optional is a pneumatic one Vise = MA, available) is with screwed vise jaws Mistake. With their ribbing, these ensure optimal hold of the workpiece -Underframe with lockable door, chip drawer and removable Coolant pan with electric coolant pump -Chip removal brush

Condition: used, Year of construction: 1999, bore capacity in steel (diameter) 36 mm throat 300 mm bore stroke 160 mm 4 speeds 100 - 1600 U/min column diameter 145 mm table-size 500 x 370 mm total power requirement 2,2 kW weight 440 kg dimensions 1200 x 800 x 2300 mm Column drilling machine OPTIdrill DP 33V promotion set / 3020680SET With an electronically controllable drive in a modern design * Industrial engine * Quiet running spindle thanks to new spindle design * Machine operation with safety electronics in 24 V direct current * Guaranteed concentricity = 0.02 mm in the measured drilling spindle * Clockwise/counterclockwise rotation * Precision spindle bore * Control panel with user-friendly, dirt and water resistant * Membrane keyboard Kslhcdwjvzt Dyjzjww * RPM display * Separate emergency stop button * Tapping function * Precisely crafted, stable drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and rotated by 360° * Drilling depth stop * LED machine light integrated in the drill head * V-belt cover with safety switch * Thick-walled steel column for high power absorption and stability * Solid, large base plate with T-slots * Execution of the entire machine Scope of delivery: - Keyless drill chuck 0 - 16 mm - T-Nuts -expectors - Operating tool - BMP 160 machine vice

Condition: new, Year of construction: 2025, bore capacity in steel (diameter) 35 mm throat 300 mm bore stroke 150 mm bore capacity in cast iron (diameter) 40 mm thread capacity M 27 spindle taper MT 4 spindle speeds: Stufenlos 100 - 2000 U/min column diameter 125 mm automatic feeds 3 / 0,1 - 0,2 - 0,3 table: 400 x 420 mm Drive Keilriemen total power requirement 3 kW weight of the machine ca. 360 kg Kjlevzhd Uohcdwzjww dimensions of the machine ca. 760 x 600 x 2000 mm Column drilling machines - V-belt drive with foot switch - Drilling machine of circular column feed automaticmechanical - Drive by electronic wide V-belt - Spindle taper: CM 4 - Stepless speed adjustment with frequency converter - Potentiometer for speed adjustment - digital speed display - Automatic feed reversal when threading - Scale with adjustable drilling depth - automatic tool ejector - Push button for EMERGENCY STOP switch for right/left rotation - Electronic control integrated in the drill head - integrated coolant device - Machine light - height-adjustable chip protection disc with micro switch - fixed table - CE marking

Condition: used, length 1100 mm height 1000 mm total power requirement 16 kW weight of the machine ca. 125 kg dimensions of the machine ca. 1100 x 450 x 1000 mm Year of construction 2020 demonstration machine, as new Easy ARC 01.02 FD-B6 Welbee P500L welding robot station MIG / MAG / water-cooled / torch RTW5000H / welding robot type FD-B6 with welding table 2000x1200mm Hole diameter 28 mm Kwjlhcdjvyupbswzow The mobile welding cell for the craft business Setting range MIG / MAG 20 - 500 A Steplessly adjustable switching levels Duty cycle at rent 40 ° C 50% Current at 100% ED 40 ° C 410 A Wire feed speed 0 - 22 m / min

Condition: used, Year of construction: 2013, length 1100 mm height 1000 mm total power requirement 24 kW weight of the machine ca. 125 kg dimensions of the machine ca. 1100 x 450 x 1000 mm Year of construction 2020 demonstration machine, as new Kwolhcsvyun Rsdwzsw Easy ARC 01.02 FD-B6 Welbee P500L welding robot station MIG / MAG / water-cooled / torch RTW5000H / welding robot type FD-B6 with welding table 2000x1200mm Hole diameter 28 mm The mobile welding cell for the craft business Setting range MIG / MAG 20 - 500 A Steplessly adjustable switching levels Duty cycle at rent 40 ° C 50% Current at 100% ED 40 ° C 410 A Wire feed speed 0 - 22 m / min

Condition: used, length 850 mm height 1050 mm total power requirement 18,4 kW weight of the machine ca. 200 kg dimensions of the machine ca. 850 x 450 x 1050 mm Year of construction 2020 demonstration machine, as new Kwelevx Uz Ushcdwzjw Easy ARC 01.02 FD-B6 Welbee P500L welding robot station MIG / MAG / water-cooled / torch RTW5000H / welding robot type FD-B6 with welding table 2000x1200mm Hole diameter 28 mm The mobile welding cell for the craft business Setting range MIG / MAG 20 - 500 A Steplessly adjustable switching levels Duty cycle at rent 40 ° C 50% Current at 100% ED 40 ° C 410 A Wire feed speed 0 - 22 m / min

Year of construction: 2024, Condition: used, arm length 7000 mm total column height 4290 mm Kwjlevxw Nbehcdwzsw weight max. in kg 250 + 250 kg

Condition: used, Year of construction: 2006, x-travel 620 mm y-travel 420 mm Kwjlhsvxw I Rscdwzsw z-travel 400 mm speeds 50 - 4000 U/min table surface area 800 x 400 mm tool taper SK 40 control Heidenhain total power requirement 17,5 kW weight of the machine ca. 1900 kg dimensions of the machine ca. 2000 x 2250 x 2100 mm - horizontal + vertical milling spindle - Cooling device - swiveling table - Chip tray - Feed X/Y/Z - axis infinitely adjustable 8-1680 mm/min - Rapid traverse X/Y/Z - axis 4000 mm/min - Control HEIDENHAIN TNC 124 - Operating hours: 4764 hours - Machine light - Machine feet - Operation manual

Condition: used, Year of construction: 1995, saw blade diameter 350 mm dimensions of saw-blade 350 x 32 x 2,5 mm cutting diameter 115 mm stroke 100 mm capacity 90 degrees: square 95 mm capacity 90 degrees: flat 180 x 95 mm capacity 45 degrees: round rechts & links 110 mm capacity 45 degrees: square rechts & links 95 mm capacity 45 degrees: flat rechts & links 125 x 95 mm capacity 60 degrees: round 90 mm capacity 60 degrees: square 80 mm capacity 60 degrees: flat 90 x 95 mm cutting speed 15 - 90 m/min total power requirement 2,6 kW weight of the machine ca. 375 kg dimensions of the machine ca. 1000 x 950 x 1800 mm -The powerful, 2-stage gear was specially designed for cuts in solid material designed -The user has a total of 4 blade speeds for optimal adjustment the material available -The large bearing rotary table with internal table clamping and Precision stops at 0/45/60° ensure quick adjustability miter cuts -The vice with quick clamping (optional is a pneumatic one Kwelhcdwsvxlpvezew Vise = MA, available) is with screwed vise jaws Mistake. With their ribbing, these ensure optimal hold of the workpiece -Underframe with lockable door, chip drawer and removable Coolant pan with electric coolant pump -Chip removal brush

Condition: used, Year of construction: 1983, sheet width 3050 mm plate thickness 6,0 mm distance between columns 3000 mm cutting angle 0,5 - 3 ° no. of strokes 9 / 14 Hub/min down holder 18 total power requirement 10 kW weight of the machine ca. 4800 kg dimensions of the machine ca. 3750 x 1600 x 1650 mm Kolhcdsvxlpiswzsww

Condition: used, bore capacity in steel (diameter) 40 mm throat 300 mm bore stroke 170 mm 4 speeds 70 - 1400 U/min table-size 600 x 450 mm total power requirement 3,0 kW weight 350 kg dimensions 1200 x 800 x 2150 mm Column drilling machine OPTIdrill DP 33V promotion set / 3020680SET With an electronically controllable drive in a modern design Kwelhevvnlnecdwzew * Industrial engine * Quiet running spindle thanks to new spindle design * Machine operation with safety electronics in 24 V direct current * Guaranteed concentricity = 0.02 mm in the measured drilling spindle * Clockwise/counterclockwise rotation * Precision spindle bore * Control panel with user-friendly, dirt and water resistant * Membrane keyboard * RPM display * Separate emergency stop button * Tapping function * Precisely crafted, stable drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and rotated by 360° * Drilling depth stop * LED machine light integrated in the drill head * V-belt cover with safety switch * Thick-walled steel column for high power absorption and stability * Solid, large base plate with T-slots * Execution of the entire machine Scope of delivery: - Keyless drill chuck 0 - 16 mm - T-Nuts -expectors - Operating tool - BMP 160 machine vice

Condition: used, Year of construction: 1996, sheet width 3000 mm Kolhcdovuz Uaewzsww plate thickness 8 mm weight of the machine ca. 6500 kg distance between columns 3100 mm down holder 18 Stück cutting angle 0,5 - 3 ° no. of strokes 10 - 23 Hub/min back stop - adjustable 1000 mm work height max. 770 mm total power requirement 15 kW dimensions of the machine ca. 3450 x 2250 x 1500 mm Equipment: - slide-guided / hydraulic guillotine shears - HACO NC control type SC 5 - electric / hydraulic cutting angle adjustment - electric / hydraulic cutting gap adjustment - finger guard at the front - pneumatic sheet metal support - side stop 1000 mm with scale - foot switch

Condition: used, Year of construction: 1992, bore capacity in steel (diameter) 32 mm throat 320 mm bore stroke 170 mm 4 speeds 60 - 1600 U/min table-size 570 x 480 mm total power requirement 1,6 kW weight 650 kg dimensions 1200 x 800 x 2200 mm Column drilling machine OPTIdrill DP 33V promotion set / 3020680SET With an electronically controllable drive in a modern design * Industrial engine * Quiet running spindle thanks to new spindle design * Machine operation with safety electronics in 24 V direct current * Guaranteed concentricity = 0.02 mm in the measured drilling spindle * Clockwise/counterclockwise rotation * Precision spindle bore * Control panel with user-friendly, dirt and water resistant * Membrane keyboard * RPM display * Separate emergency stop button * Tapping function * Precisely crafted, stable drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and Kjlhsvuz T Necdwzsww rotated by 360° * Drilling depth stop * LED machine light integrated in the drill head * V-belt cover with safety switch * Thick-walled steel column for high power absorption and stability * Solid, large base plate with T-slots * Execution of the entire machine Scope of delivery: - Keyless drill chuck 0 - 16 mm - T-Nuts -expectors - Operating tool - BMP 160 machine vice

Condition: used, bore capacity in steel (diameter) 45 mm throat 350 mm bore stroke 180 mm 4 speeds 30 - 765 U/min table-size 720 x 560 mm total power requirement 3,4 kW weight 950 kg dimensions 1200 x 800 x 2300 mm Column drilling machine OPTIdrill DP 33V promotion set / 3020680SET With an electronically controllable drive in a modern design * Industrial engine * Quiet running spindle thanks to new spindle design * Machine operation with safety electronics in 24 V direct current * Guaranteed concentricity = 0.02 mm in the measured drilling spindle * Clockwise/counterclockwise rotation * Precision spindle bore * Control panel with user-friendly, dirt and water resistant * Membrane keyboard * RPM display Kwelhcdsvuz Tvowzow * Separate emergency stop button * Tapping function * Precisely crafted, stable drill table with diagonal T-slots with all-round cooling water channel, can be tilted sideways by ±45° and rotated by 360° * Drilling depth stop * LED machine light integrated in the drill head * V-belt cover with safety switch * Thick-walled steel column for high power absorption and stability * Solid, large base plate with T-slots * Execution of the entire machine Scope of delivery: - Keyless drill chuck 0 - 16 mm - T-Nuts -expectors - Operating tool - BMP 160 machine vice
