Machining center

Yilmaz AIM 3410

Year of construction: 2024, condition: new, Twin-head cutting-off machine with automatic mobile head movement driven by an NC-controlled brushless motor. Pneumatic tilting of cutting units from 90° to 22°30’ (outward) in two fixed positions or with optional mechanical adjustment system for intermediate angles. Hydro-pneumatic blade feed. Podpfowp Ugqox Ag Degw

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: 9914346, 3-axis CNC + 1-axis pneumatically controlled floor type vertical machining center 3 axes (X, Y, Z) controlled by CNC + 1 axis controlled pneumatically. Suitable for processing aluminum and PVC profiles. The workpieces are clamped by 4 pneumatic clamps, moved on a tilting beam; this beam has a rotation range of ± 90 ° with pneumatic control. Working cross-section: 200 x 170 mm (YxZ). View specifications X-axis stroke mm 3160 X-axis positioning speed m/min 60 Y-axis stroke mm 360 Pedpfx Ajwgm Sgeg Dsgw Y-axis positioning speed m/min 30 Z-axis stroke mm 345 Z-axis positioning speed m/min 30 A-axis stroke ° 45 - 90 - 45 Electric spindle power kW 3.8 Tool holder taper ISO30 Maximum rotation speed rpm 18000 Cooling system Air Weight kg 1800

Year of construction: 2025, condition: new, The manual length stop with hand wheel and electronic dimension display MD 100 h is ideal for frequently changing section lengths and for stopping long materials. It enables the carriage to be moved quickly and precisely using a hand crank. Existing machines / roller conveyors can be retrofitted at any time. Product Details: • Suitable for hitting steel profiles and solid materials • Hand wheel drive for the carriage • Pneumatic stop clamping with high holding power • digital actual length display in the working area • Direct distance measurement via sensor / magnetic tape • Control with dimensional error compensation Psdpfx Asidmp Tsg Dsgw • Trolley with 3 ball bearings • raise and lower manual arm • Cable chain with steel storage tray • Standard measurement lengths: 1m to 6m, maximum up to 20m • Total length of the system = measuring length + 0.5 m • Left or right hand versions available • Mounting screws • Accesories: – Stop arm with spring damping – Arm retraction with impact damping via pneumatic cylinder – pneumatic arm raise / lower – Piece counter for the number of pieces/cuts made – various material roller conveyors

Condition: new, Year of construction: 2025, XX100405 CNC Machining centre with 4 controlled axes FOM INDUSTRIE FMC 370 Machine in stock Standard configuration: - Liquid-cooled electrospindle 7 kW, 20,000 rpm (HSK-F63) - 9 location tool magazine on head (HSK-F63) - No. 2 pairs of pneumatic vices with positioning through the travelling column - No. 2 pairs of low profile jaws for clamping wide profiles - Left pneumatic reference stop - Minimum quantity lubrication (MQL) with pure oil - Chip and waste collection tank in base - Perimeter guard system with automatically opening, front retractable doors - X FLOW (automatic orientation of lubricant nozzles) - Control: POWER-D - Movable control console - 24” display - FST CAM 4 program Optional equipment installed on the machine: - PR205249 One pairs of additional vices with independent positioning and vises modification: • Transformation of four standard vices to vices with independent positioning • Transformation of standard vices into extra clamping vices - PR205258 Pendular (2 working areas, 2 pieces) and oversides profiles machining: • Second X-FLOW • Right pneumatic fixed stop • Software to manage pendular machining • Safety devices for pendular machining • Tunnel for oversized profile machining • SW to manage oversized machining operations - PR205253 Device to measure profile length - PR205227 Device for integrity and measure of the tool - PR202971 Data import software in accordance to FOM protocol and wireless optical bar code and QR code reader - ZP715059 3D custom milling Module for FST CAM 4 - ZP715010 Module for rigid tapping and chase tapping - PR205268 Rear chip collection tanks for FMC 370 - PR205271 Centralised automatic lubrication system - PR203389 Rear chip collection tank - PR202975 Tool set A3/HSK F63 (8 holders HSKF63, 8 collets and 8 HM milling cutters) Pgjdpfjwhrlnjx Ag Dew - PR204497 Holder HSKF63 with cutter Ø 200 x 6mm - PR203785 Holder HSKF63 with blade Ø 200 mm

Condition: new, Year of construction: 2025, machine/vehicle number: SÇ 1000 DİJİTAL METRE, - 3 Meter length - +/- 0.1 mm measurement accuracy - 220 Volt voltage - Touch screen - One-button push-back feature that allows the cut product to be easily removed from the mold - Design for ease of use - Easy calibration Psdpfxerblalo Ag Dsgw

Year of construction: 1999, condition: excellent (used), Glass tilting and transport table TRIULZI-IG Hydraulic Pgodpfxoiy Dtbs Ag Dow With castor rollers Rollers are moving down for 360 degree glass movement (for sealing) 3600 mm length and 2400 mm working height Good working order Good condition As is Available immediately

Condition: as good as new (ex-display), Year of construction: 2025, Schiavo Top 2000.4 Max. Glas-height: 2.000 mm Thickness: 3-19 mm Prewashingzone / Mainwashingzone / drying zone Podpfx Agewd Raie Degw Stainless steel body 4 brushes (120 mm) maid out of one piece with Incl. water tanks incl. vacuum system for drying zone LED lights on the outled for inspection

Year of construction: 2001, condition: used, Pictures to follow - machine is being overhauled Technical data: - X-axis travel: 7300mm - Y-axis travel: 1000mm - Z-axis travel: 650mm - Swivel angle A-axis: 0-90° freely programmable - Swivel angle C-axis: 0-355° freely programmable - Max. Machining length without end face machining: 7300mm - Max. Machining length with end face machining: 6980mm - Tool changer with 10 places and a saw blade holder - 9 material clamps Psdpfst Ea Tfex Ag Dogw - SK30 tool holder - 2-layer machining

Year of construction: 2021, condition: new, Single-head cutting machine OMC GIOBI 600, new Machine in stock - saw blade D 600 mm - hydro-pneumatic feed - inclination is pneumatic on both sides, with fixed graduations of 22.5° - 45° - 90°. For intermediate gradations, with manual mechanical stop - 2 vertical and 2 horisontal clamps - spray mist blade lubrication system Pgsdpfx Ashrumasg Dsw - integral pneumatic protection

Condition: used, Year of construction: 2016, 8 spindle system. Connected loads: 380/400 V, 19 kW. Podpfx Asv Rbtujg Dogw Glass thickness: 3 - 25 mm. The system produces a beautiful glass finish. Condition: in very good condition.
