Floor type Boring machine

UNION PCR 150

Condition: ready for operation (used), Year of construction: 2013, This Okuma MCR-A5C30x65 gantry milling machine was manufactured in 2013. It features a robust 100 mm spindle, capable of speeds up to 4000 min⁻¹, and accommodates a maximum workpiece size of 2540 mm by 5540 mm. The machine supports a hefty 30,000 kg on its 2500 × 6300 mm table. Ideal for heavy-duty milling with a rapid feed rate of 20,000 mm/min. Contact us for more information about this machine. Machine Benefits Gsdpfsx D S Ekjx Aciobt Technical Machine Benefits • Dimensions of machine (lxwxh): 2500 mm x 6600 mm x 6350 mm / weight (kg): 59000 kg • Max workpiece width: 2540 mm / max workpiece length: 5540 mm • Table size (width × length): 2500 mm × 6300 mm /max load on table: 30000 kg table height from floor: 850 mm /effective width between columns: 3050 mm/ t-slot (width × number): 24h7 × 13 • Cutting feed rate: 1 to 10000 mm/min/ rapid feed rate: 20000 mm/min/ table movement x-axis: 6500 mm /x-axis travel: 6500 mm /y-axis travel: 3500 mm/ z-axis travel: 650 mm • Tool holder: bt50 + masz type/ tool storage capacity: 50 tools /max tool length: 300 mm • Power supply: 400v, 3 /phases, 50hz rated capacity: 513 kva /full load current: 741 a /peak current: 117/138 a /short circuit current: 18 ka • Spindle diameter: 100 mm /spindle speed: 30 to 4000 min⁻¹ • Large table size suitable for heavy loads. /extensive tool storage capacity. /high rapid feed rate for efficient operations.

Condition: used, Year of construction: 1991, bore capacity in steel (diameter) 50 mm arm length 1100 mm Gedpfx Aceu Sblwoiobt workpiece height max. ca. 1000 mm bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 28 - 2500 U/min feeds 0,05 - 2 mm/U quill stroke 300 mm distance basic plate - spindle nose 630 - 1380 mm crossrail adjustment vertical 750 mm total power requirement 6 kW weight of the machine ca. 4 t dimensions of machine L x W x H 2,74 x 1,14 x 2,59 mm - with thread cutting attachment - Accessories: box table 550 x 550 x 550 mm, vice, coolant

Condition: excellent (used), Year of construction: 2021, operating hours: 3,000 h, travel distance X-axis: 6,100 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 950 mm, CNC Travelling Column Milling Machine – Fully Retrofitted by REM (2021) Powerful and versatile heavy-duty milling machine, completely modernized by REM specialists in 2021 with state-of-the-art Heidenhain TNC 320 control. Ready for immediate production use. Gbsdpon D N H Tofx Acijt KEY SPECIFICATIONS: • X-axis (transversal travel): 6,000 mm • Y-axis (vertical head travel): 2,000 mm • Z-axis (axial slide travel): 950 mm • Dual-spindle head | Head rotation: 360° • Spindle speed: 1,000 – 4,000 rpm • Spindle taper: ISO 50 (automatic locking/unlocking) • Head dimensions: 290 × 290 mm • Spindle motor power: 15 kW (DC) • Machine weight: approx. 32 tonnes • CNC Control: Heidenhain TNC 320 WHY BUY FROM REM? ✔ Machine fully inspected and tested in working conditions ✔ Modern CNC retrofit – new electrics, new drives ✔ Documentation and technical support available ✔ Export worldwide | Competitive shipping Ideal for heavy component machining in aerospace, energy, and heavy industry. Contact us today for full technical specifications, photos, and video demonstration.

Condition: used, swing diameter 2000 mm turning height 1800 mm Control Siemens Sinumerik 840 Dsl turning speeds range 2,8-315 U/min cross rail adjustment - vertical 1200 mm cross rail adjustment - horizontal +/- 1150 mm 1500 mm bit feeder section 240 x 240 mm Minimum immersion diameter 340 mm cutting capacity 50 kN Gbodpfx Asy Dvlqocijt max. torque on the faceplate 50000 Nm speed range step 1 2,8 - 80 U/min speed range step 2 12 - 315 U/min Max. clamping weight 12000 Kg power capacity faceplate 105 kW weight of the machine ca. 33 t dimensions of the machine ca. 10 x 5 x 6,5 m Further technical data: - Feed range of three-phase servo motors: 1–3000 mm/min; 0.01–50 mm/rev - Crossbeam travel speed: 425 mm/min Features/Accessories - Increased turning height (+600 mm) - Z-axis extended to 1500 mm - Magazine capacity: 20 positions - Magazine type: disc magazine - Max. tool length: 525 mm - Chip conveyor - Workpiece measurement - Renishaw probe - Coolant tank capacity: approx. 2000 litres - Coolant pump flow rate: 60 litres/min at 2 bar Overhaul: - Extensively overhauled in 2012 by Siemens Industry Munich - Items overhauled included: control system, cabling, motors, measuring systems, etc. - Further information can be found in the PDF

Condition: used, Year of construction: 1982, Technical details: faceplate diameter: 2600 mm turning diameter over support: 2500 mm Gbedpfx Aswtctyociet turning length: - mm centre distance: 1600 mm turning diameter over bed: 2900 mm spindle bore: 100 mm revolution per minute: gear steps U/min feed range: Überdrehen 0,12-31,5 Plandrehen 0,12-45 mm/min bed guideways length: 2900 mm max. workpiece weight between centres: 400.000 kgs total power requirement: 45 kW weight of the machine ca.: alle Komponenten zusammen: ca. 29,0 t machine dimensions LxWxH: 5.2 x 5,0 x 3,1 m 3-way measuring system with digital display RSF electronics Control panel Cooling unit for Rittal electric cabinet *

Condition: excellent (used), travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 750 mm, table width: 1,500 mm, table length: 850 mm, rotational speed (max.): 2,500 rpm, quill stroke: 120 mm, SHW UF 5 Travels - X-axis (rotary table): 1,500 mm - Y-axis (vertical headstock): 1,000 mm - Z-axis (horizontal headstock): 750 mm Control system - CNC control: Heidenhain TNC 355 Automatic swivel head (change between horizontal and vertical machining) Quill 120mm Milling spindle holder SK 50 Speed 2500 rpm Partial overhaul 2014 - Year of construction 1990 - Inspection/repair 2025 Table assembly - Travel distance: X = 1,500 mm - Clamping surface: 1,500 x 800 mm Chip conveyor Splash guard cabin We have ALL spare parts for this series (SHW UF 5) in stock! About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is in the field of tool milling machines. Our services include spare parts deliveries, on-site customer service, machine overhauls and control system modernizations. Services: - Used machines - Spare parts - Customer service - Machine service - Machine overhauls - Control modernization Gbsdpfx Acevfm I Toiet _____ Used machine - used milling machine - used bed type milling machine - orthogonal milling head - metalworking - tool milling machine - milling head - SHW machine - SHW spare parts - milling machine used - milling machine used - CNC milling machine used - drilling milling machine used - milling machine metal used - metal milling machine used - metal milling machine used metal milling machine used - used cnc milling machine - cnc milling machines - cnc milling machines - milling machine - large part machining - large part machining - large part machining - cnc large part machining - milling - shw - uf5 - uf 5 - Uniforce - SHW UF - SHW Uniforce - SHW Uniforce 5 - UFZ 5 - UFZ5L - UFZ 5 L - MBM Milling Machine - MBM Machine

Condition: used, Year of construction: 1983, Bohrleistung in Stahl (-Ø 50 mm throat 1500 mm workpiece height max. 1380 mm Bohrleistung in Guß (-Ø 60 mm Abstand Spindelmitte bis Säule 320 - 1250 mm swival range +/- 180 ° base plate surface area 2640 x 1000 mm max. torque on the spindle 310 Nm Bohrspindel-Ø/ Aufnahme 75 mm /MK 5 bore spindle stroke 310 mm spindle turning speed range 28 - 2500 U/min Gbodpstv Iklefx Acijt feed: 0,05 - 2 mm/U power capacity 4 kW weight of the machine ca. 4,3 t dimensions of the machine ca. 3,2 x 1 x 2,75 m cube table 500 x 500 x 500 mm

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 3,300 rpm, spindle motor power: 30,000 W, overall weight: 9,100 kg, controller manufacturer: MAZATROL, controller model: Mazatrol Matrix, number of axes: 3, This 3-axis Mazak QT Nexus 350 II M was manufactured in 2008. It features a Mazatrol Matrix control unit, a maximum swing over bed of Ø 830 mm, and a turning length of 1500 mm. The spindle supports speeds up to 3300 rpm with a power of 30 kW. It includes a chip conveyor and tool presetter. If you are looking to get high-quality turning capabilities, consider the Mazak QT Nexus 350 II M machine we have for sale. Contact us for more information. Additional equipment • Chip conveyor • Tool presetter • Autoblock chuck • Toolholders Gbjdpjx D I Rijfx Aciet • User and maintenance manuals Machine Benefits Technical Machine Benefits • Max. Turning diameter: Ø 420 mm • Max. Turning length: 1500 mm • Bar capacity: Ø 102 mm • Spindle nose: asa 11” • Chuck type: autoblock Ø 315 mm • Tool size: 25 × 25 mm / Ø 50 mm • Driven tool motor power: 7. 5 kw • Max. Speed of driven tools: 4000 rpm Extra Information Machine still under power

Condition: used, Year of construction: 2004, Technical details: x-travel: 1500 mm y-travel: 1000 mm z-travel: 1000 mm control for program: TNC 530 spindle hours: noch nicht bekannt h milling head speed: 1: 30 bis 930 und 2: 930 bis 4000 / steples U/min tool taper: horiz./vertical: SK 50 (DIN 69871/Din 69872 Form A) max. torque on the spindle: 1000 Nm spindle head swivable left - right: 90 ° feed: 1 - 6000 mm/min feed power: 30 kN kN rapid traverse: 15 m/min Number of tools: 1 St. table clamping surface LxW: 1600 x 800 mm table load: 40 kN kN voltage: 400 V / 50 HZ V total power requirement: 42 kW Weight approx.: 15,2 t compressed air: 6,3 bar dimension machine xH: 3,1 x 4,7 x 2,6 m dimensions: Kühlfilter: 1,9 x 1,6 x 1,4 mm space requirements approx. LxWxH: ca. 38,5 m² m² Applications: Milling, drilling; tapping, boring. with direct coded length measuring systems the guideways of the 3 axes are on flat guideways CTS and external cooling Milling head position controlled +/-90° milling spindle nominal drive power 22 kW with integrated hydraulic power unit up to 100bar operating pressure with coolant unit with filtration, with high pressure pump 60 bar (internal cooling), nominal delivery 20 l/min. and low pressure pump 4 bar (external cooling) as well as spray gun Hinged belt chip conveyor DGS, type SSF 600 P50 Accessories: Gjdpfxju Nc Rij Acijbt Measuring probe SK40 Reference tool SK40 Milling head SEMPUCO *

Condition: used, Year of construction: 1973, spindle diameter 130 mm x-travel 3000 mm y-travel 2000 mm total power requirement 4,5 kW weight of the machine ca. 30 t Spindle Ø 130 mm Spindle taper SK 50 Working range: X = column, longitudinal 3,000 mm Y = headstock, vertical 2,000 mm Z = spindle stroke 1,000 mm Lower table 3,300 x 2.400 mm Max. weight on table 10 tons/m² Min./ max position of work spindle above table 770 / 2,770 mm Feeds 0.9 - 2,000 mm/min Quick feed for headstock and column 5,000 mm/min Quill feed 0.5 - 1,200 mm/min Speed range, partially infinitely variable 4.5 - 1,250 rpm Weight, approx. 30,000 kg Accessories / Special Features * HEIDENHAIN Digital Display for 3 axes. * Hardened guideways. * Ball screw spindles. * Infinitely variable spindle speeds and feeds. Feeds can be individually driven with motor. * Moving operating platform. * Hanging control panel. * Manual operating control. * Platform. * Hydrostatics in the column displacement. * Mounting plate 3,200 x 2,500 mm, planed, with t-slots. * Top table approx. 1,400 x 2,600 x height 900 mm, one face is handled. * Hydraulic clamping of column and slides. * Motor driven tool clamp. * Lots of accessories, including tool holders with and without tools, separate chip extractor, clamping aids, 1 angle plate, and other plates. Lots of other accessories. This is a strong machine which is very suitable for heavy cuts and therefore ideal for the machine tool industry and for tool manufacturers. Gbedpot Hwt Sofx Aciet Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock as inspected Payment : Net, after conclusion of contract Thank you for your interest. We have other horizontal borers on stock. Please let us know what you need.
