Milling machine

STRIGON ME1000

Condition: used, Year of construction: 1992, Technical details: x-travel: 800 mm y-travel: 550 mm z-travel: 500 mm spindle taper ISO: SK 40 control: Philips 532 quill stroke vertical: 80 mm turning speed range: 0-600 und 600-4000 steples U/min feed:: 1 - 3000 mm/min. rapid traverse: 6 m/min table surface area: 1100 x 600 mm table feed: 1 - 3000 /stufenlos mm/min switched on hours: 82194 h total power requirement: 9,6 (12 kVA) kW weight approx.: 4200 kg dimension machine xH: 2,9 x 2,2 x 2,5 m The machine is located in the technical department. Nwedpfxou Nda Ej Amnjg further technical data: - vertical adjustment table (z-axis) 500mm - Headstock throat depth: min./max.: 200 / 750 mm Equipment: -coolant tank with pump -Manual control unit (hand operated) -linear measuring system Heidenhain *

Condition: excellent (used), Deckel FP1 AKTIV (3-Axis Active) Machine no.: 2102-3240 Year of manufacture: approx. 1988 Travel paths: X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2,000 rpm Motor power: 1.6 and 2 kW Power supply: 380 V, 50 Hz Equipment/Accessories: - Active digital readout, 3 axes, HEIDENHAIN type TNC 113 - Infinitely variable feed in X, Y, and Z axes - Vertical milling head quill travel: 60 mm - Vertical milling head swivels and extends 100 mm horizontally - Coolant system (coolant tank in machine base) - Documentation - Central lubrication system - Machine vice - Various toolholders/collets/tools Space required (L x W x H): 1,350 x 1,100 x 1,700 mm Weight: 850 kg The machine has been visually reconditioned and technically inspected. Geometry inspection videos can be provided upon request. Backlash Y axis: 0.1 mm Backlash X axis: 0.2 mm Backlash Z axis: 0.15 mm Runout horizontal spindle: 0.001 mm Runout vertical spindle: 0.001 mm Parallelism deviation Y axis: 0.002 mm (measurement path: 150 mm) Parallelism deviation X axis: 0.01 mm (measurement path: 300 mm) Geometry inspection videos can be provided upon request. The following parts have been renewed: - Gears in horizontal head replaced and gear shaft newly mounted - New guide cover for Z axis + various attached parts - Machine refurbished - New LEDs installed - Y-axis chain tensioner overhauled Nwedpfx Ameyll A Tsneg - Reference point programming checked - Function test carried out

Condition: good (used), The machine comes from a training workshop, original paint in good condition. Nwodpfx Amsyvqrvjnog

Condition: good (used), Metal milling machine with some cutters included X-axis approx. 800 mm Y-axis max. approx. 300 mm Njdpjxvll Iofx Amnowg Z-axis ? Still a heavy, stable cast iron machine

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 63814, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 4,000 rpm, quill stroke: 80 mm, TECHNICAL DETAILS Travel path X-axis: 600 mm Travel path Y-axis: 400 mm Travel path Z-axis: 400 mm Clamping surface: 254 mm x 354 mm Tool holder: ISO 40 Quill stroke: 80 mm Spindle speeds: 80 - 4,000 rpm Rapid traverse X: 4 m/min Rapid traverse Y: 3 m/min Nwjdoywhbdopfx Amnsg Rapid traverse Z: 5 m/min MACHINE DETAILS Total connected load: 16 kVA
