Laser cutting machineSongu
Mach 3015
Machine data
- Machine type:
- Laser cutting machine
- Manufacturer:
- Songu
- Model:
- Mach 3015
- Year of construction:
- 2023
- Condition:
- like new (used)
- Functionality:
- fully functional
- Operating hours:
- 2,500 h
Price & Location
- Location:
- Tallinn, Estonia
Technical details
- Control type:
- CNC control
- Controller manufacturer:
- Beckhoff
- Laser type:
- fiber laser
- Laser source model:
- MaxPhotonix
- Laser hours:
- 1,700 h
- Laser power:
- 12,000 W
- Sheet thickness (max.):
- 40 mm
- Table length:
- 3,000 mm
- Table width:
- 1,500 mm
- Working length:
- 3,000 mm
- Working width:
- 1,500 mm
- Feed rate X-axis:
- 100 m/min
- Feed rate Y-axis:
- 100 m/min
- Positioning accuracy:
- 0.05 mm
- Repeat accuracy:
- 0.03 mm
- Workpiece weight (max.):
- 1,500 kg
- Input voltage:
- 400 V
- Type of cooling:
- water
- Overall weight:
- 10,000 kg
- Equipment:
- CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier
Details about the offer
- Listing ID:
- A21265927
- Update:
- 18.02.2026
Description
Machine: Songu Mach 3015 Year 2023 - Put into operation 2024
Power: 12kW MaxPhotonix laser source
Size: 3x1.5m Working area
Working Hours: Total run time - 105days (2520h), Total NC run time 73days (1752h)
Operating system: Beckhoff PLC operated from Windows 10
CAM system: Lantek CAM, postprocessor for the machine. Easy to use and conventient.
Gas system: Hoerbiger with 3 gas inlets (O2, N2 and compressed air 16BAR/Or anything else)
Fully enclosed and with CE marking
Safety systems: Opening the door stops the machine and changing table light barriers stop the table changing process (does not stop the machine while working)
Table changer: Hydraulic table changer with two pallets. Pallets in the machine remain in the same height, tables are chain driven. Hydraulic liftin capacity 1410kg
Alpha direct drive servo drivers for axises with Alpha reducer gears.
Isdpfxsyk Uuis Ah Eetc
Laser head: Precitec ProCutter2.0 - spares and consumables available in EU
Automatic lubrication of axises and guideways
Fume extractor: Donaldson - has big panel filters with automatic cleaning function. Starts when machine starts cutting. Laser frame has sectioned fume extraction system - flaps open up where the laser head is moving.
Positioning speed: 100m/min, acceleration 2.4g
Accuracy: Positioning +-0,05, Repositioning +-0,03
Weight: Main frame ~8800kg, loading table ~2500kg
Camera inside the working area
Side access from two doors, front access
Elecrical cabinet mounted to the machine
Cuts materials like: Mild steel, stainless, aluminium, copper, brass. Example, 20mm mild steel - cutting speed 4m/min (O2), 3mm cutting speed 28m/min (N2)
High pressure air compressor: 16Bar compressor for Air cutting, cheaper function for cutting mild steel
Uses NC code for cutting, part size is determined from NC and cutter compensation parameter that can be changed from the machine
Machine cutting parameters - Fly cut, film burn, small contour, etc. One single parameter consists of 9 different adjustable parameters. Option for nozzle cleaning while cutting and programmable nanojoints (extra small breakaway point for part removal)
Automatic focus control
Automatic sheet location measuring system
Part Stop, Contour Stop, Crash sensor, Low pressure sensors, etc
MDI mode for simple sheet trimming funcion
Machine bed protected from heat
Waste trolleys under the main cutting area and loading table
Graphical visualisation on cutting plan
Alarm log files
Under power, can be tested
Location: Tallinn Estonia
Price: 155 000€
