Automated Warehouse

SCHELLING VS 12

Condition: used, machine/vehicle number: 008597, Position 1: Automatic Loading Panel Saws SCHELLING-VS 12 - FH6 - FH4 Position 2: Front-Loading Panel Saws SCHELLING-VS 12 - FH6 - FH4 Ijdpfxoy Stvps Aayeaw Position 3: Automated Warehouse SCHELLING-VS 12 - FH6 - FH4

Condition: good (used), Manufacturer: MBT Type: MV-250 S Motor: 5.5 kW Hopper size: 780 x 600 mm Iaedshzr U Ispfx Aayjw Housing size: 3500 x 1000 x 2200 mm

Condition: ready for operation (used), Year of construction: 2014, machine/vehicle number: 208.025, functionality: fully functional, cutting width (max.): 4,200 mm, cutting length (max.): 4,200 mm, stack height: 2,000 mm, Auction of a panel dividing saw with automatic magazine! TECHNICAL DETAILS Capacity: 4,200 mm x 4,200 mm Saw blade overhang at 90°: 72 mm Saw blade overhang at 45°: 50 mm Saw carriage feed rate (forward): 0-100 m/min Saw carriage feed rate (reverse): 0-100 m/min Feed rate of program slider: 0-25 m/min Program slider return speed: 80 m/min Collet maximum opening: 84 mm Collet positions: 65/245/395/985/1,605/2,225/2,845/3,465 mm Cross-pressure range: 50 - 1,250 mm MACHINE DETAILS Main saw motor: 14 kW Scoring saw motor: 1.5 kW Electrical supply: 400 V, 50 Hz, 3-phase Automatic magazine Magazine dimensions: 33.1 x 9.4 m Magazine height: 3,600 mm Stack height: 2,000 mm Iaodpfxozhm E Hj Aayow Input stack height: 1,900 mm Magazine speed X: 0-150 m/min Magazine speed Y: 0-150 m/min Magazine speed Z: 0-60 m/min Maximum panel weight: 300 kg Length adjustment of vacuum lifter: 2,000 - 4,200 mm Width adjustment of vacuum lifter: 1,000 x 2,100 mm Vacuum pump: 40 m³/h Rotating device: 90°

Condition: excellent (used), 13 rolls, Ø 150 mm strip width: 600 - 2.000 mm strip thickness: 6 - 15 mm Iedpfxov S Ad Do Aayeaw design: 4 hi cassette

Year of construction: 2014, condition: ready for operation (used), Max. output: 370kg/h, connected load: 0.25kW, length: 950mm, width: 950mm, height: 1115mm, weight: 75kg, including automatic filling, frame, valve, inspection shaft and documentation. Iaedpjh Akm Tofx Aayow

Condition: repair required (used), functionality: unexamined, Dovetail grooving system for wood packages dimter HK 400 Dovetail grooving system Input lengths: 800–6,000 mm Grooving height: 285 mm, optional 300 mm Color: Blue Consisting of: Iasdpfjvi Hw Njx Aayow Pos. 01 Packaging unit Pos. 02 Package roller conveyor Pos. 03 Central milling cutter Pos. 04 Package roller conveyor Pos. 05 Package singulation unit Pos. 06 Chain transverse conveyor Pos. 07 Infeed roller conveyor Pos. 08 Cycle press Pos. 09 Feed unit Pos. 10 Crosscut saw Including control cabinets and operator panels The system requires repair and is sold in its current condition. It has already been dismantled and is stored in Achern. All technical documentation is available. We are available at any time to answer questions about the system and provide technical information. We will provide consulting support for the repair and reassembly.

Condition: new, maximum load weight: 36,156 kg, overall weight: 45,000 kg, axle configuration: 3 axles, Year of construction: 2026, MAX200-N-3A-13.60-19.5-2.54 Technical Data Speed: 80 km/h Total weight: 45,000 kg Fifth wheel load: 18,000 kg Axle load: 27,000 kg Unladen weight (+/- 3%): 8,844 kg Payload approx.: 36,156 kg Loading area length: 13,600 mm Fifth wheel height, loaded: 950 -> 1050 mm Rear overhang: 2,300 mm Extendable by: 3,400 mm Wheelbase: 1,360/1,405 mm Overall width: 2,540 mm Technical Description Loading area: Extendable loading platform with pneumatically operated locking mechanism. 2 pairs of lashing rings (LC 5,000 daN). 1 pair of lashing rings (LC 10,000 daN). 6 pairs of lashing rings, foldable outwards (LC 5,000 daN). 2 pairs of lashing rings, foldable outwards (LC 10,000 daN). Cutouts in the outer frame of the loading platform for attaching lashing straps (LC 2,000 daN). Fifth wheel: JOST fifth wheel (mechanical) with 2-speed gearbox for 24t Load capacity (50t test load). Axles: SAF axles: SAF CD axles, air-suspended, with disc brakes (377 mm), with lift/lower function (ET 120). The trailing axles with electro-magnetic reversing lock can be activated via reverse gear or manually. Axle tool. (± 80 kg) Braking system: Braking system according to EU regulations with EBS-E (2S2M) without connecting lines to the tractor unit. Steel construction: Steel construction made of high-strength fine-grained steels. Steel grades: S355J2+N/S355MC (yield strength 355 MPa) S690QL/S700MC (yield strength 690 MPa) Painting: First-class and durable corrosion protection of the standard shot-blasted welded frame is guaranteed by a 2-component (2K) zinc dust primer. A high-quality 2-component (2K) topcoat, solid color, in RAL colors of your choice. Rear section metallized and painted in RAL 9010 (pure white). Metallic paint is not possible. Electrical system: Electrical system according to EU regulations, lighting LED 24 Volt ASPÖCK-NORDIK (ASS3) ASPÖCK-UNIBOX on the connection strip at the front with 24N, 24S & 15-pin sockets. Connection according to ISO. 24N ISO-1185 24S ISO-3731 15-pin ISO-12098 Included Accessories Yellow-red air couplings on the galvanized connection strip at the front. 2 chocks with holders. 2" King Pin A galvanized steel front panel approx. 2200 mm high. (± 105 kg) EN12642-XL Yellow reflector tape according to EU regulations on the side, on the extension and at the rear of the trailer. Isdpsg Sk Tvjfx Aaysaw European reflector signs (red-yellow) at the rear of the trailer. Loading area with approximately 38 mm thick hardwood floor. (± 320 kg) 10 pairs of pocket rails for plug-in rails 100 x 50 mm in the outer frame of the loading platform. (± 30 kg) 1 spare wheel holder under the loading platform on the right side, in the direction of travel. Tires 435/50 R 19.5, at the manufacturer's choice. One mudflap at the rear of the trailer. Manual and description on a USB stick. One mounting for a rotating beacon at the rear of the trailer. On the swan neck and at the rear panel, left and right, one mounting each for warning signs including socket. One INOX tool box transversely under the loading platform (1000x400x2500) (± 135 kg) 6 pairs of WADER container pockets in the loading area, for 1x20' container, 2 x 20' containers or 1 x 40' container; an additional locking point is provided in the extension for a 45' container. (± 90 kg) 4 pairs of WADER container locks. (± 60 kg) 10 pairs of galvanized plug-in rails approx. 100 x 50 mm, 1,000 mm high. (± 220 kg) 3 pairs of pocket rail strips, mounted transversely in the loading area, for plug-in rails 100 x 50 mm. (± 95 kg) S

Condition: good (used), Year of construction: 1998, functionality: fully functional, ram adjustment: 40 mm, installation height: 2,400 mm, total width: 17,000 mm, table length: 400 mm, table width: 400 mm, pressing force: 25 t, stroke adjustment: 17 mm, working width: 200 mm, overall weight: 2,500 kg, year of last overhaul: 2023, power: 0.003 kW (0.00 HP), Make: MABU Model: 25 VPR. Made in Germany. Max. Pressure: 250 [kN] (25 [T]). Speed range: 80-400 [spm]. Completely rebuilded Dec. 2023 Year of manufacture: 1998. Operating modes: Manual, One-cycle and Automatic. Equipped with two hand start and foot-clamp start. Fixed stroke: 17 [mm]. Ram adjustment: 40 [mm]. Ijdpfxsq Ikhps Aaysaw Max. Tool dimensions: 400 x 400 [mm]. Power: 3 [kw]. Current: 230 / 400 [V]. Air connection: 5.5 [bar]. Feeder: Silicon SFS 200 on left-hand side. Max. strip width: 200 [mm]. Machine dimensions: H 2350 x W 1700 x D 1400 [mm]. Weight of machine: cca. 2500 [kg]. Electrical cabinet with Mabu Pf 1.3 control. Front and rear safety guards with inspection glass. Technical documentation and operating instructions in English and German included. CE certificate and EUR-1 certificate of origin. On stock, tested and ready for delivery. More used machines from Mabu, Bruderer, Bihler and Schaal available on our stock for sale.

Year of construction: 1980, condition: good (used), strip width: 1.650/1.750 mm Iodpedn I Hrsfx Aayeaw strip thickness: 0,4 - 3 mm coil weight: 10 t interchangeable mandrels, Ø: 304/406/610 mm

Condition: new, Year of construction: 2025, table length: 900 mm, table width: 450 mm, number of spindles: 1, spindle speed (min.): 8,000 rpm, table load: 500 kg, VMC 650 CNC machining center, milling machine with CNC system VMC 650 machining center is a multifunctional equipment that allows you to perform milling, drilling, thread cutting, and turning operations in automatic mode (if these options are available in the machine). The VMC 650 milling machine can have 16- or 24-position tool magazine. Depending on the customer's wishes, the milling machine can be equipped with a GSK, Siemens or Fanuc CNC system. It is possible to optionally add a Y-axis drive. As a very convenient additional option, we recommend installing a chip conveyor that will save you time when working with the equipment. Technical parameters: Worktable size 900x450mm Maximum workpiece weight 500 kg Movement along the axes X/Y/Z 800/450/500 mm Maximum distance from the spindle to the table surface 120-620 mm Motor power 5.5-7.5 kW Maximum spindle speed 8000 rpm Spindle type BT40 Positioning accuracy ±0.008/300 mm Repeatability ±0.005 mm Machine dimensions 300022752550 mm Machine weight 4000 kg It is also possible to supply CNC milling machines, machining centers with other table sizes: VMC 850 table 1000x500 mm VMC 855 table 1000x550 mm VMC 1060 table 1200x600 mm VMC 1160 table 1200x600 mm VMC 1275 table 1300x700 mm VMC 1370 table 1400x700 mm VMC 1580 table 1600x800 mm Isdpfxoxc I Dgo Aaysaw VMC 1680 table 1700x800 mm VMC 1890 table 2000x900 mm
