Used Radial Boring Machine for sale (64,365)

Condition: used, Radial drilling machine with plate field WEBO type HRH 100 / 3000 Machine. No. 10009555/7 -- 1110185 -- 6046 Year of manufacture 1979 Drilling capacity Ø 100 mm in ST 60 at feed rate 0.5 mm/rev. Nominal throat depth 3000 mm Max. throat depth max. 3100 mm Spindle holder MK 6 Spindle speed 22.4 - 1600 rpm 36 steps Feed rate 0.05 - 2.5 mm/rev 18 steps Spindle - base plate distance 970 - 2335 mm Pinol stroke 325 mm Swivel range of the arm 360 movable on bed, bed length 7500 mm Clamping area panel field 8000 x 2100 mm - Electrical central clamping - Drilling unit can be moved lengthwise on the machine bed by electric motor Gsdpjfbt Hujfx Afnein - Panel field consisting of 2 clamping plates with 7x T-slot, (length 4000 x width 2100 x panel thickness 360 mm) Space requirement L x W x H 8000 x 4550 x 4300 mm Maximum height 4300 mm Transport height (bed with drilling machine) approx. 3150 mm Transport weight (bed with drilling machine) approx. 20 tons Transport dimensions of panel section L x W x H 4000 x 2100 x 900 mm (2 panels stacked on top of each other) Transport weight panel field approx. 14 ton. good condition

Condition: used, Radial drilling machine CSEPEL type RFh 75 / 1500 Machine no. No. 13704 Year of construction 1985 Drilling capacity in steel Ø 75 mm Gedslhwr Ropfx Afnein Drilling capacity in cast iron Ø 90 mm Spindle holder MK 5 Nominal throat depth 1500 mm Largest projection of the spindle 1500 mm (to the column) Smallest projection of the spindle 440 mm (to the column) Distance spindle nose - clamping surface 370 - 1700 mm Cantilever height adjustment 950 mm Table size / clamping surface 1800 x 1100 mm Column diameter 450 mm Pinol stroke 380 mm Spindle speed 19-1900 rpm 21 steps Feed rate 0.047-2mm/rev. 12 steps Motor power 11 kW Mains connection 380 Volt, 50 Hz, 15 kW - Clockwise/anticlockwise rotation of the drilling spindle via hand lever switch - Hydr. gear shift for spindle speed and feed speed - Hydro-mechanical central clamping - Motorized boom height adjustment - Without coolant device - Machine light - Operating instructions Space requirement: Length 2720 mm x width 1170 mm x height max. 3770 mm Transport height with motor on the column: 3500 mm Transport height without motor on the column: 3250 mm Weight: 6.3 tons good condition

Condition: used, Radial drilling machine WEBO Type R4bR Serial No. 15 / E195 Year of manufacture: approx. 1965 Drilling capacity: 50 mm Spindle taper: MT 5 Maximum spindle outreach: approx. 1250 mm (to column) Clamping surface: 1400 x 1000 mm Column diameter: 315 mm Spindle speed: 30 - 1325 rpm, 9 steps Gedpfxou T Ty Ho Afnein Feed: 0.12 - 2 mm/rev, 9 steps Electrical connection: 380 Volt, 50 Hz - Spindle speed in 9 steps - Motorized height adjustment of the boom Required floor space for operation (L x W x H): 220 x 100 x 285 cm Transport dimensions (L x W x H): 220 x 100 x 260 cm (without motor for height adjustment) Weight: approx. 2.8 t.

Condition: excellent (used), feed length X-axis: 700 mm, feed length Y-axis: 350 mm, feed length Z-axis: 475 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 475 mm, spindle speed (max.): 1,500 rpm, spindle speed (min.): 25 rpm, quill stroke: 100 mm, table length: 1,360 mm, table width: 300 mm, Cincinnati 2MK Horizontal Mill with Universal Vertical Head Model: 2MK Table Atea: 1360 x 300mm (53.5” x 11.8”) Longitudinal Travel: 700mm Cross Travel: 350mm Vertical Travel: 475mm Spindle Taper: 50 INT Gsdpeygk Drjfx Afnein Spindle Speeds: 25 – 1500 RPM Machine with: Horizontal Arbor & Arbor Support Angular Double Swivel Head

Condition: ready for operation (used), Year of construction: 1977, Asquith ODI Mk2 14/54 5MT Radial Arm Drilling Machine Spindle centre to column centre max. 54" Spindle travel 14″ Spindle taper 5 MT Spindle speeds (16) 40-2040rpm, Spindle motor 5.5 HP Spindle emergency brake Power elevation of arm Power locking to arm and head Box Table Coolant 415V Electrics 1977 For sale with Jet Machinery Ltd Jet Machinery Stock No: #79026 Giodoyg Skaspfx Afnon Machine Serial Number: P.33677 Cost: £6,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Year of construction: 1979, arm length 1600 mm Giodpfxjyigbco Afnen taper MK 5 weight of the machine ca. 3 t

Condition: good (used), Year of construction: 2006, functionality: fully functional, spindle diameter 125 mm x-travel 3000 mm y-travel 2000 mm z-travel 1500 mm W-axis (spindle longitudinal) 600 mm table-size 1250 x 1600 mm table load capacity - central/maximum 5000 kg Control Heidenhain iTNC 530 tool taper ISO 60 spindle turning speed range 5 - 3000 U/min spindle drive motor 37 kW max. torque on the spindle 1646 Nm transmission ratio 2 Working hours: Gedpfxeyifnuj Afnsin - Machine on: 59.078 h - Autom. cycle: 24.207 h * CNC-control HEIDENHAIN iTNC 530 * Coolant equipment * Table B-axis, 360.000 positions

Condition: used, Year of construction: 2001, Union KCU-130 Table Type Horizontal Boring & Milling Machine with Heidenhain TNC430 Control, X/Y/Z = 4000/3000/1500mm, Table Size 2000 x 2500 x 20,000kgs, B-axis 360 Deg, Spindle Taper BT50, 60 Position ATC, W-axis, U-axis, Swarf Conveyor, Through Spindle Coolant, Guarding Enclosure. S/No. 1370022 (2001) Please Note: Toolholders/Tooling photographed in the toolchanger will not be supplied with this machine. Any available tooling will be a specifically described. Gijdpfex T Ddysx Afnen Please Note: This Lot is located in Irvine. Unfortunately, there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: excellent (used), Year of construction: 2018, bore capacity in steel (diameter) 75 mm spindle taper: MT 5 spindle stroke - max. 380 mm transmission ratio 2 11,2 - 2.000 Gijdpfxoyh Rqfo Afnon quill stroke 16 mm feed for quill 1: 16 spindle throat 2000/ 38 mm spindle drive 15 kW weight 7,1 t Thread in steel, strength 600 N/mm² max. M75x4 Vertical swivel arm adjustment max. 950 mm Drill slide adjustment on the swivel arm 1614 mm Distance between spindle nose and clamping surface max. / min. 2000/670 Accessories: Heidenhain Radial digital display, clamping cube 1000 x 750 x 500 mm Coolant system, work light

Condition: excellent (used), Year of construction: 2012, bore capacity in steel (diameter) 62 mm arm length 350-1600 mm workpiece height max. 1250 mm distance spindle nose and table 350-1250 mm Boring depth max. 315 mm machine table 2400 x 1000 x 200 mm Turning speeds of the bor. spindle 38 - 2000 U / min spindle taper MT5 feed 0,06 - 1,00 mm/U engine output 4 kW stroke drive 1,5 kW Giedpfx Afsyhq T Nsnon oil pump 0,75 kW total power requirement 6 kW weight of the machine ca. 3,8 t dimensions of the machine ca. 2490 x 1050 x 2780 mm Steps of spindle speed: step-less Steps of spindle feed: 8 Speed of the arm up and down: 1.2 m/min Arm moving angle: ±180 degree Spindle moving distance of each dial revolution: 122 mm Max. spindle torque: 400 Nm Max. spindle feed resistance: 16000 N

Condition: good (used), MAS VR8A Arm 2500 mm MC 6 Gisdpfxjxx Dapo Afnsn 10,000 kg

Condition: good (used), Year of construction: 1971, Webo BR 35 V / 1250 Radial Drilling Machine Working Area Distance from spindle to column: smallest 280 mm / largest 1250 mm Distance from spindle or drilling distance to table top: smallest 0 mm / largest 900 mm Distance from spindle to base plate: smallest 200 mm / largest 1400 mm Drill diameter: smallest 860 mm / largest 2800 mm Swivel range: 2,200 mm / clamping diameter approx. 240 mm Clamping area: upper 650 x 500 mm / side 770 x 500 mm Drill spindle diameter 40/85 mm Speed: 30 - 1800 rpm Year of manufacture: 1971 For further technical data, please refer to the machine card. Item condition: used, immaculate, and well maintained. Auction items: Only the Webo BR 35 V / 1250 without the reversible clamp shown. This can be purchased individually or as a bundle in our other auctions. Godpfx Afsihfw Nsnoin Financing through our bank is also possible. komplett-konzept.leasingo.de You can find more metalworking machines – new and used – in our shop! International shipping costs on request!

Condition: excellent (used), Henri Hauser M5 DR jig boring machine spindle diameter 90 mm x-travel 700 mm y-travel 500 mm Drilling capacity in steel 40 mm spindle mounting MK 4 drilling spindle stroke 170 mm number of spindle revolutions 2 infinitely variable 10-2000 rpm Boring diameter max. 230 mm Table dimension - longitudinal 900 mm Table dimension - crosswise 770 mm Vertical travel of cross beam 630 mm Drilling spindle 6 pieces from/to 0.02-0..20 rpm Clearance between uprights 900 mm Passage between spindle and table 815 Spindle motor 4.0 HP Total power requirement 380 V Godpog Ibuxjfx Afnsin Machine weight approx. 3.9 t Complete factory closure, large selection of storage platforms, pallet racks, shelf racks, paternosters. High-quality industrial machines, lathes, grinding machines, hand machines Financing through our bank is also possible. komplett-konzept.leasingo.de Further articles - new and used - you will find in our shop! International shipping costs on request!

Condition: excellent (used), Number of agregats 1 St. Lock depth max. ca. 130 mm connected load 2,5 kW Gedpfx Ajyi Hufefnjin vertical movement 100 mm

Condition: good (used), functionality: fully functional, Radial drilling machine BWF BR40 * 15 speeds * min. speed: 22.4 rpm * max. speed: 2800 rpm T slot table: * Length: 1600mm * Width: 800mm Machine dimensions: Gsdpfx Afoviu Nmsnjin * Length: 2500mm * Height: 2800mm * Width: 1000mm

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Technical details spindle diameter 135 mm x-travel 1000 mm y-travel 700 mm z-travel 300 mm cross rail adjustment - vertical 780 mm distance between table/spindle 1000 mm table surface area 1100 x 842 mm distance between columns 1100 mm table load 1500 kg tool taper SK 45 spindle turning speed range 2400 U/min spindle drive 5,9 kW feed range 1 - 6000 mm/min Giodpfx Aoyf Eziofnjn weight of the machine ca. 10,6 t Additional information Retrofit / overhauling in May 2005 (with geometric measurement): - New Heidenhain iTNC-530 control - New electronics - New Siemens servomotors - Heidenhain glass scales - Revision of drilling spindle unit (total costs 118,436.00 EUR) Equipment: Infrared measuring probe m&h 38.10-MINI Electron. Handwheel Various tool holders Transport dimensions: - Machine (LxWxH) 3500 x 2600 x 2750 mm - Control cabinet (LxWxH) 2300 x 600 x 2300 mm - Hydraulic (LxWxH) 800 x 600 x 1000 mm

Condition: used, Drilling machine Brand: GSP Model: 407C27 Gijdpoyanmwjfx Afnsn Reach: 2250 mm Drilling capacity (steel): - normal feed: diameter 70 mm - slow feed: diameter 90 mm Carriage travel on arm: 1900 mm Drilling radius (min. - max.): 630 - 2500 mm Height (min. - max.): 500 - 1750 mm Vertical arm travel: 850 mm Spindle stroke: 400 mm Spindle speeds: 25 to 1400 rpm Motor power: 6 kW Spindle taper: MT 5

Condition: new, The R 60 VT PRO is a high-quality radial drilling machine that belongs to the Radial Drilling Machines category, representing the latest generation of conventional radial drill presses from KNUTH. This versatile machine simplifies the machining process, supporting precise drilling, countersinking, and thread cutting—ideal for single parts and small batch productions. Built with premium cast materials, its robust design features a large column and torsion-resistant boom, ensuring stability and reliability. Key functionalities include an electronically controlled servo quill feed with a large touchscreen display, automatic thread cutting capabilities, and a powerful coolant system, all designed to streamline operations. The machine offers adjustable height for the boom, central lubrication for maintenance ease, and a variety of user-friendly interfaces for setting operating parameters. With a drilling capacity of 60 mm and throat depth from 350 to 1,600 mm, this robust and advanced radial drilling machine makes daily production tasks smoother. You can request a quote or order online to enhance your machining capabilities with the R 60 VT PRO. Gedpfx Asu E Hzwsfnein

Condition: excellent (used), Dowel Drill DB12 1.1 kW Gisdpfx Afjwmbpmenen 8 mm Stroke 3 Spindles

Condition: used, functionality: fully functional, Scheer DB 22 double-sided line boring machine, 2 drilling motors of 1.8 kW each, 32 mm pitch, 21 spindles per beam, good condition, dimensions 3100 x 1100 x 1800 mm, portal passage 850 mm, weight 345 kg Giodpfx Afew Adrcensn

Condition: used, Year of construction: 1985, Scheer DB5 row drilling machine Year of manufacture: 1985 - 380 Volt - 21 spindles; 32 mm spacing - stop ruler Giodewv Uy Dopfx Afnjn - various dowel drills - portal opening 1056 mm - 2.2 kW

Condition: new, The KNUTH R 80 V radial drilling machine represents a powerful and versatile addition to the Radial Drilling Machines category, designed for drilling, reaming, and countersinking in steel or cast iron. Its robust construction ensures constant high accuracy, while the long projection arm provides exceptional flexibility for handling large and heavy workpieces. Key features include an infinitely variable spindle speed with a digital display and a cube table that offers extended clamping possibilities. Additionally, the machine is equipped with a powerful coolant system, LED work lamp, and user-friendly controls for efficient operation. With a throat depth ranging from 450 to 2,550 mm and a drilling capacity of 80 mm, this model is ideal for various production and construction tasks. Trust KNUTH for your drilling solutions and request a quote for the R 80 V Radial Drilling Machine today. Gjdpfxju Abxfe Afnjin

Condition: new, Drilling capacity cast iron / steel ----- 31.5 / 25 mm Tapping capacity cast iron / steel ----- 20 / 16 mm Speed range ----- (8) 100 ~ 1600 rpm Spindle stroke ----- 135 mm Unload ----- 300 ~ 720 mm Spindle intake ----- MK3 Spindle feed ----- 0.08 / 0.14 / 0.22 mm/omw Cube table----- 250 x 250 x 250 mm Column diameter ----- 150 mm Foot ----- 1200 x 620 mm Maximum distance spindle - base ----- 275 ~ 680 mm Motor ----- 1.1 KW Voltage ----- 400V / 3 Phase Weight ----- 580 KG INCLUDING * Cooling system * CE plug * SCHNEIDER electrics Giedsq E Izmopfx Afnsn OPTION * Floor cabinet

Condition: used, Year of construction: 1972, bore capacity in steel (diameter) 50,0 mm arm length 1.350 mm Giedpfswiikdsx Afnsn workpiece height max. 1630 mm turning speeds 19 - 1320 U/min bore spindles - Morse Taper 5 MK engine output 5,5 kW weight 5 t range L-W-H 2,4 x 1,0 x 3,55 mm feed movement 475 mm floor plate size: 1650x1000 mm feeds 0,07-2,9 mm/U

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, drilling depth: 660 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 1,000 mm, drill diameter: 30 mm, TECHNICAL DETAILS Drilling depth: 660 mm Drill diameter: 30 mm Gsdpfjya U U Ujx Afnjin X-axis travel: 700 mm Y-axis travel: 500 mm Z-axis travel: 1,000 mm W-axis travel: 250 mm Spindle speed: 60 - 60,000 rpm Table length: 900 mm Table width: 500 mm Table load capacity: 2,000 kg MACHINE DETAILS Control system: Heidenhain iTNC530 Dimensions & Weight Dimensions (L x W x H): 3,706 x 3,960 x 2,650 mm Total weight: 8,000 kg EQUIPMENT CNC rotary table (4th axis) Chip conveyor Paper band filter Electronic handwheel Original documentation
