Used Hob for sale (316)

Condition: ready for operation (used), thread length: 3,000 mm, Maximum spindle bore is Ø 80 mm. The possible diameter from the traverse path is max. Ø 250 mm and min. Ø 20 mm. Machining length: 3000 mm. Comes with accessories: change gears, steady rest. For further technical data, please refer to the PDF file. Dkjdpfx Aev Huihoa Het

Condition: used, Year of construction: 2007, control Siemens Sinumerik 840 D weight 57.000 kg voltage 400 V Gleason PFAUTER CNC gear hobbing machine P 2400/2800 for gear cutting of cylindrical and worm gears as well as all other regularly occurring rollable profiles and shapes on the cylindrical workpiece circumference. Large gear hobbing machines from Gleason offer maximum productivity for roughing and finishing cylindrical gears for many industries: wind turbines, industrial gearboxes, mining and shipbuilding, gear machining and many more. The power range of the drive takes future tool developments into account. Of course, the gear hobbing head drive is also backlash-free. These machines are particularly well suited for use with state-of-the-art, cutting materials, regardless of whether dry or wet machining is preferred. The machine can be used for dry or wet machining and is also equipped with the appropriate chip conveyor for both machining methods. The machine is equipped with an internal profile milling head as a motorised milling head. --> Working range and technical data Nominal workpiece diameter: 2.400 mm Dkodowzyp Ijpfx Aa Hst --> Largest millable diameter approx.: 2.800 mm --> Smallest/largest distance between cutter and workpiece axis: 100/1.200 mm --> Largest axial slide travel (special design): 1.300 mm --> Largest clampable cutter (internal milling head): --> Diameter max: 440 mm --> Max. cutter width: 90 mm --> Swivel range of the internal profile milling head/vertical axis: +/- 15° --> Milling mandrel taper: HSK-B160 --> Maximum milling cutter travel: 300 mm --> Table diameter: 2.500 mm --> Part wheel diameter: 2.200 mm --> Table bore --> Diameter: 800 mm --> Depth: 875 mm --> Maximum table load approx.: 40.000 kg --> Max. feed and rapid traverse speeds: --> axial (Z-axis): 4.000 mm/min --> radial (X-axis): 3.000 mm/min --> tangential (Y-axis): 3.000 mm/min --> Milling cutter cooling lubrication device/electric centrifugal pump: approx. 150 l/min --> Increased drop height of magnetic chip conveyor: 1,600 mm --> Increased main stand: 1,300 mm axial slide travel --> Internal profile milling head as motor milling head instead of standard motor milling head --> Max. millable profile depth in steel with approx. 600 N/mm² strength: approx. 65 mm --> Infinitely variable milling speed: 50 - 150 min?¹ --> Max. milling cutter diameter: 440 mm --> Min. milling cutter base circle diameter: 310 mm --> Max. milling cutter width: 90 mm --> Min. internal diameter at 0° bevel angle: 800 mm+) --> Max. workpiece height at 0° bevel angle: 600 mm --> Max. workpiece ring thickness (including clamping device): 500 mm >> Wet and dry, 2 chip conveyors, table diameter 2500 mm

Condition: used, functionality: fully functional, wheel width: 800 mm, module 1-6 diameter max 600mm Dedpfxjxhck Ss Aa Hjkt digital reading Complete machine with documentation, tool holders, change gears,...

Condition: excellent (used), max. wheel diameter 175 mm gear width 350 mm max. module 3 min. module 0,5 weight of the machine ca. 0,9 t Dedpsznnitefx Aa Hjkt dimensions of the machine ca. 1,2 x 0,8 x 1,4 m

Condition: ready for operation (used), Horizontal gear hobbing machine with master hob, Precimo model HR 3-ND-15. Maximum workpiece diameter: 250 mm. Maximum module: 7. Maximum diameter for module 7: 135 mm. Maximum diameter 250 mm for module 5. Maximum hobbing length: 335 mm. Minimum number of teeth to cut: z6. Maximum distance between centers: 735 mm. Maximum hob speed: 435 rpm. Estimated weight: 3500 kg. Dodpsy Swl Usfx Aa Hokt

Condition: excellent (used), max. workpiece diameter 400 mm threading length 1000 mm max. module 4 (8) min. module 1 clamping length max. 850 mm weight of the machine ca. 3,1 t Dodpfezmapiex Aa Hekt dimensions of the machine ca. 3,1 x 1,1 x 1,6 m

Condition: good (used), Year of construction: 1995, functionality: fully functional, The perfect retrofit machine! Mechanically in phenomenal condition! Dkedpfx Aaoy Hfm Ns Hst This machine can be inspected under power until 12.05.2026 and will then be dismantled due to space constraints. Please refer to the attached KLINGELNBERG inspection reports available for download. Gleason P 800 Year of manufacture: 1995 Control: SIEMENS 840 C (discontinued) Condition: Mechanically in excellent condition Functionality: Fully operational Inspection: Available under power Technical Data: Nominal workpiece diameter: 800 mm Max. workpiece diameter: 800 mm Max. workpiece diameter, special version: 1,200 mm Nominal module: 20 / 30 mm Nominal module, special version: 25 / 35 mm Drive power: 35 kW Drive power, special version: 52 kW Cutter head speed range: 20 - 200 rpm Cutter head speed range, special version: 26 - 265 rpm Additional cutter head speed range, special version: 36 - 360 rpm Cutter head swivel range: +30 / -45 degrees Cutter head dimensions (standard cutter head), diameter/length: 350 / 375 mm Min./max. center distance workpiece/tool: 50 / 600 mm Center distance workpiece/tool, special version: 50 / 800 mm Max. axial slide travel: 700 mm Max. axial slide travel, special version: 1,000 mm Max. axial slide travel, special version: 1,300 mm Lowest cutter head position above table: 450 mm Table diameter: 800 mm Table bore diameter: 245 mm Table bore depth: 875 mm Max. table speed: 15 rpm Max. table load: 10,000 kg Machine dimensions: Width A: 5,800 mm Length B: 6,900 mm Height C: 4,700 mm Machine weight: 22,000 kg Regarding the current KLINGELNBERG gear inspection data BEFORE grinding: "Pitch and lead are inconspicuous. One measurement shows a borderline or slightly out-of-tolerance fHα deviation in the profile. Please check whether this value is permissible according to the drawing/customer approval or if correction/rework is required. The gears were always forwarded for grinding to the RZ 1000 REISHAUER and processed accordingly. Nevertheless, overhaul of the C-axis is recommended. A cost estimate from GLEASON PFAUTER LUDWIGSBURG is available. Estimated cost: 10,000 EUR."

Condition: used, Year of construction: 1980, weight 1 t keins Dodpeyg Ratefx Aa Hokt Dimensions (L/W/H) 1200 x 800 x 1450 mm module 1

Condition: good (used), functionality: fully functional, Max. wheel diameter: 710 mm Gear width: 335 mm Table size: 630 mm Table bore: 120 mm Dkjdpszbt Hrsfx Aa Het Max. table load: 700 kg Max. module: 7 Min. module: 1 Hob spindle speed range: 40-315 rpm Feed range: Axial: 0.40 - 5 mm/rev Radial: 0.20 - 2.5 mm/rev Tangential: 0,1-1,25 mm/rev

Condition: used, TOS lathe Type SUA 150 CNC Capacity: 6000 m Year: 1998 CNC Siemens 840 Dksdpfxszxpzxj Aa Het Accessories: Supplied with eye shields.

Condition: used, max. wheel diameter 2000 mm gear width . mm max. module 22 Dedjyqukkopfx Aa Hskt max. hob diameter 250 mm hob turning speeds 16-92 U/min total power requirement 13 kW The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 1983, functionality: fully functional, Max diam 750mm, Z axial travel 900mm, X Radial travel 380mm, table 630mm, CNC Siemens 802D in Z and X. Weight ca 14.000kg Dkjdpjzbt Iijfx Aa Hst

Condition: used, Year of construction: 2008, control Siemens 840D Hobbing Machines for Large Gears Flexible and Versatile Gear Hobbing Gleason’s large hobbing machines offer maximum productivity for roughing and finishing operations on cylindrical gears for many industries: wind turbines, industrial gearboxes, mining, and shipbuilding, gear machining, and many more. The guideways are wide and feature hydraulically preloaded guides, which are used in combination with a separate linear guide and backlash- free Dodpswzypnjfx Aa Hokt rollers. This ensures precise slide movements with every feed. The design of the worktable ensures optimal conditions for absorbing and transferring cutting forces to the machine base. The use hydrostatic table bearings, combined with the proven backlash-free double-worm gear, guarantees precise table movements and the highest flatness and concentricity accuracies of the worktable. This holds true regardless of significant fluctuations in workpiece weight and/or high machining forces. The motorized gear hobbing heads for external and internal gear cutting are designed to meet the requirements of modern cutting tools. All machine sizes can be equipped with both external and internal gear hobbing heads. The power range of the drive takes future tool developments into account. Naturally, the gear hobbing head drive is also backlash-free. These machines are particularly well-suited for use with state-of-the-art cutting materials. >> dry only, 1 chip conveyor, table diameter 1,870 mm

Condition: excellent (used), Year of construction: 2011, machine/vehicle number: 506925, functionality: fully functional, operating hours: 261 h, power: 5.5 kW (7.48 HP), planing width: 630 mm, tool diameter: 125 mm, number of blades: 4, rotational speed (max.): 5,000 rpm, overall weight: 1,260 kg, Offering a used MARTIN thickness planer, model T45. Sale due to restructuring of the company. General Technical Specifications: Planing width: 630 mm Maximum planing depth: 12 mm Planing height: 2.8 - 300 mm Minimum workpiece length: 270 mm Weight: approx. 1,200 kg Table length: 1260 mm Speed: 5000 rpm Thickness table extension 630 x 450 mm, foldable Year of manufacture: 2011 5.5 kW (7.5 hp); maximum planing width 630 mm The machine provides first-class results in planing operations. Operation: 1-axis control for planing dimensions, maximum 99 values can be stored, Button for manual quick and fine adjustment of the planing thickness according to the digital display, Push buttons for starting and stopping the cutterhead, Cutterhead: TERSA full-steel cutterhead Z4 D=125 mm; including locking mechanism for easy cutter replacement Groove for accommodating planing cutters. Thickness table: Electric thickness table adjustment with fine adjustment, feed rate 10 mm/s, mounted on 4 support spindles, preventing tipping, table surface finely planed. Feed: Dedezwpvaepfx Aa Hskt 2 speeds, 6 / 12 m/min, electrically selectable even during planing, large rubber feed rollers D=85 mm to compensate for varying wood thicknesses, rubber rollers are material-friendly and self-cleaning, easy roller replacement; articulated pressure bar at the infeed. Extraction: High-swiveling, split hood with chip extraction connection D=160 mm, Maintenance: Central lubrication strip for oil lubrication points; lubrication of bearings / cutterhead via grease nipples. The machine is still connected and can be tested. Price is quoted plus VAT.

Condition: used, Year of construction: 2006, Technical details: max. wheel diameter: 300 mm max. module: 7 weight of the machine ca.: 15 t table turning speeds: 100 U/min table diameter: 180 mm hob turning speeds: 750 U/min max. hob diameter: 300 cutter length max.: 230 mm Liebherr LC300 with loading automation Machine including counter holder The machine used to work with emulsion Dkjdpfx Aaeyz Sd Rj Het *

Condition: used, Year of construction: 1963, Technical details: Dksdpsvkpu Hsfx Aa Het max. wheel diameter: 900 mm max. module: 10 weight of the machine ca.: 8200 kos. hob dia. - max.: 190 mm cutter length max.: 320 mm milling spindle speeds (infinitely variable): 13-80 U/min workpiece length - max.: 750 mm max. workpiece diameter: 150 mm Counter holder milling mandrel is missing *

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 200 mm gear width: 60 mm max. module: 7 Dkjdpfxjxc E H Se Aa Hst weight of the machine ca.: 15 t table diameter: 180 mm table turning speeds: 100 U/min hob turning speeds: 750 U/min Machine in good condition, without feed, without automation Available 24.08.2024 *

Condition: excellent (used), max. workpiece diameter 600 mm threading length 7000 mm max. module 8 / 12 min. module 1 swival range ° diameter of hob 63 - 140 mm spindle turning speed - stepless 45 - 450 U/min weight of the machine ca. 12,5 t dimensions of the machine ca. 9,0 x 2,0 x 2,2 m Condition: In good condition, checked and partially overhauled by a specialist. The existing milling head was replaced by an overhauled universal milling head. Furnishing: Differential for inclined machining Automatic indexing device (indexing discs changeable!) For multi-wedge, multi-thread parts, then extensive bushings, support rollers and around 70 Change gears. Conversion of the milling head speed to a frequency converter with corresponding powerful motor is a great thing and saves a lot of set-up time. Equipment: Around 70 change gears, 3 bushing sticks of different sizes, around 20 Dedswgizdepfx Aa Hokt Bushings, 2 roller mountings, 2 tips for direct mounting on the Clamping spindle, 350 mm chuck, 2 spare part disks.

Condition: ready for operation (used), Gear hobbing machine type FD320, FD500 and FD 800 Cugir Maximum module 6 to 10 mm Max. working diameter 320 to 800 mm Djdpfx Aocrd Nmsa Hekt

Condition: used, Year of construction: 2007, x-travel 900 mm y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm max. module 20 mm tip circle diameter 350 mm Milling arbour diameter 375 mm Total closing value 80 kVa Dkjdpfjw Rrb Hsx Aa Hot weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation

Condition: good (used), max. wheel diameter 145 mm gear width 110 mm max. module 2 Dedpfx Asy Ivdhoa Hokt min. module 0,3 turning speeds 112 - 1000 U/min min. number of teeth 6 clamping length max. 150 mm total power requirement 3,5 kW weight of the machine ca. 1,3 t dimensions of the machine ca. 1,3 x 0,8 x 1,4 m

Condition: like new (used), Year of construction: 2022, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,300 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, nominal power (apparent): 135 kVA, controller manufacturer: Heidenhain, controller model: TNC640i HSCI, workpiece diameter (max.): 1,500 mm, workpiece weight (max.): 3,000 kg, rotary table diameter: 1,200 mm, overall weight: 37,000 kg, spindle speed (min.): 1,200 rpm, coolant supply: 70 bar, spindle motor power: 7,800 W, spindle nose: BT50/Capto CS, number of spindles: 2, number of slots in tool magazine: 80, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, Ibarmia ZVH60/L6000 is a versatile multi-process machining centre designed for precision milling and turning operations. Equipped with a Heidenhain TNC640i HSCI control system and HR-520 portable hand-wheel, it offers exceptional control and accuracy, further enhanced by Heidenhain Kinematics Opt calibration of rotating axes. This machine features a powerful CAPTO CS main spindle with through-spindle coolant at 70 bar, a generous 80-position tool magazine, and support for BT50/CAPTO tooling. Its horizontal rotary table and turning spindle head deliver up to 78 kW and 1400 Nm, with a 500 mm centre height, while the off-centred Y-axis rotary table allows increased swing for 5-axis operations up to Ø1200 mm. Additional highlights include an automatic self-centring 3-jaw chuck (Ø630 mm), 110 mm bar capacity, hydraulic extension for automated operation, manual tailstock, and sub-plate for tailstock. Precision is assured with RENISHAW RMP600 and TS27R touch probes, while gear hobbing, gear skiving, and grinding with HSKA100 are also supported.For ease of use and maintenance, the machine comes with air and spray guns, mist filtration, a tipping swarf bin, steady rest support, dressing unit, operator platform, and safety door modifications—making it a complete solution for demanding machining tasks. Full Tec spec available upon request Dkedpfx Aaozdix Uo Hst

Condition: used, Year of construction: 1979, max. wheel diameter 350 mm gear width 350 mm max. module 8 min. module total power requirement 7,5 - 22 kW weight of the machine ca. t Djdpfx Aajt Hwxzj Hskt dimensions of the machine ca. m Gear hobber with gear shaping device, 2-cut cycle

Condition: used, Year of construction: 2001, Technical details: max. wheel diameter: 80/120 mm max. module: 2,5 max. top circle diameter: 65 mm : 22 mm : 140 mm : 120 mm slide travel axial ( Z-axis ): 320/400 mm Dimensions (L/W/H): 3270 x 3240 x 2020 mm weight of the machine ca.: 6 t P60 - The compact all-rounder for wheels, shafts and worms The P60 is the smallest machine in the Gleason line of horizontal hobbing machines. The all-rounder not only mills spur gears with all rollable profiles, but is also the optimal solution for machining steering pinions and worms. Dsdoxrwpkopfx Aa Hjkt with automatic loading system, extraction unit, chip conveyor, with balancing device with 2 tailstocks, with Artec process monitoring system, type CTM-BT1.1 *

Condition: like new (used), Year of construction: 2024, operating hours: 7,556 h, functionality: fully functional, 4 x LIEBHERR LC 280 DC Gear Hobbing Machines For sale are 4 identical LIEBHERR LC 280 DC gear hobbing machines, all manufactured in 2024. Manufacturer: Liebherr Verzahntechnik GmbH Model: LC 280 DC Machine Type: CNC gear hobbing machine with integrated ChamferCut unit Quantity Available: 4 units Year of Manufacture: 2024 Example Machine No.: XXX Control: Siemens CNC / HMI user interface Technical Data: Max. Workpiece Diameter: 280 mm Max. Module: 6 mm / 4 mm depending on the version Axial Travel: 400 mm Shift Travel: 200 mm Max. Hob Diameter: 150 mm Hob Speed: 2,250 / 6,000 rpm Table Speed: 250 / 800 rpm Max. Module ChamferCut: 5 mm Max. Tool Speed ChamferCut: 2,000 rpm Max. Tool Diameter ChamferCut: 130 mm Max. Tool Clamping Length Drilling Tool: 236 mm Max. Tool Clamping Length Shank Tool: 360 mm The LC 280 DC is a compact gear hobbing machine for workpieces up to 280 mm in diameter and integrated ChamferCut machining; according to Liebherr, it is designed for gear hobbing and parallel, defined deburring/chamfering. ([Liebherr][1]) Equipment: Dkedpfx Aezdv Upea Hjt Integrated ChamferCut unit Automatic workpiece handling / round magazine Siemens CNC control Liebherr HMI / production interface Workpiece spindle Hobbing head Deburring/chamfering unit Full protection cabin Work area lighting Automation interface CE marking Machine suitable for dry and wet machining, depending on equipment and process Electrical data per machine according to the nameplate: 400 V AC 50 Hz Control voltage: 24 V AC Installed power: 29 kVA Rated current: 42 A cos φ: 0.81 Fuse: 63 A gL Control cabinet weight: 900 kg All 4 machines are identical, manufactured in 2024, and come from modern industrial series production. Technical data according to nameplate, manufacturer's specifications, and photo documentation. Subject to errors and prior sale.
