Milling machine WMW FU 250x1000

Condition: ready for operation (used), Year of construction: 2003, operating hours: 28,000 h, functionality: fully functional, turning diameter: 309 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 89 mm, travel distance Z-axis: 406 mm, controller model: Fanuc Typ 18i-T, TECHNICAL DETAILS Maximum turning diameter: 309 mm Spindle speed range: 25 – 6,000 rpm Travel in X-axis: 89 mm Travel in Z-axis: 406 mm Collet diameter: 42 mm MACHINE DETAILS Control system model: CNC Fanuc Type 18i-T Spindle motor drive power: 11 kW Operating hours: 28,000 h Machine weight: approx. 5,000 kg EQUIPMENT C-axis Y-axis 12-station turret VDI 30 Powered tools at each station Power chuck, diameter 140 mm Hydraulic steady rest Workpiece collection system Chip conveyor Csdpozu Rz Eefx Ac Tohb Coolant system

Condition: good (used), machine/vehicle number: 630, with a swiveling (pivoting) vertical head Table size: 300 x 1,430 mm Table travels: longitudinal (X-axis) 1,000 mm vertical (Z-axis) 520 mm transverse (Y-axis) 360 mm Installation height under the milling spindle approx. 500 mm Overhang of the milling spindle min./max. 350 mm Spindle mount: SK 40 Spindle speeds: 25 - 1,200 rpm Chsdpsbq Rugjfx Ac Tjb Feed rate/rapid traverse: 12-900 mm/min Spindle drive: approx. 3 kW Total drive: 3.4 kW - 380 V - 50 Hz Weight: 2,400 kg

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, turning length: 1,040 mm, turning diameter: 580 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 250 mm, travel distance Z-axis: 1,040 mm, TECHNICAL DETAILS Turning diameter: 580 mm Turning length: 1,040 mm Spindle speed: 3,500 rpm Travel range X-axis: 2,500 mm Travel range Z-axis: 1,040 mm Tailstock diameter: 85 mm MACHINE DETAILS CNC control: Fanuc 18T-C Dimensions & Weight Dimensions (L × W × H): 4,650 × 2,320 × 2,060 mm Machine weight approx.: 7,200 kg EQUIPMENT VDI turret with 12 driven tool stations Chip conveyor Machine without tailstock Foot switch Chuck Turning chuck Csdpfxozu Rzro Ac Tshb

Condition: excellent (used), functionality: fully functional, Year of construction: 2018, operating hours: 1,889 h, laser power: 2,000 W, sheet thickness steel (max.): 15 mm, sheet thickness stainless steel (max.): 8 mm, working length: 3,000 mm, working width: 1,500 mm, The machine has been very well maintained, regularly cleaned, and serviced. It is in near-new condition! TECHNICAL DETAILS Laser power: 2,000 W Laser source manufacturer: IPG Laser type: Fiber laser Max. sheet thickness: 15 mm Max. steel sheet thickness: 15 mm Max. stainless steel thickness: 8 mm Working length: 3,000 mm Working width: 1,500 mm Positioning accuracy: 0.001 mm MACHINE DETAILS Chsdpfxjzt R R Re Ac Tob Control type: CNC control Control manufacturer: Mazak Cooling type: Water Degree of automation: Automatic Drive type: Electric Input voltage: 380 V Input current type: Three-phase Laser on-time: 8,212 h Cutting hours: 1,657 h Year of last overhaul: 2024 EQUIPMENT CE marking Documentation / manual Safety light curtain Shuttle table Extraction system

Year of construction: 1988, condition: used, centre height 140 mm Chodpfx Aceipyx Te Teb chucking diameter 250 mm swivelling range 90 Grad weight of the machine ca. 150 kg Dividing head swivable of a Heckert FU 400

Condition: ready for operation (used), Year of construction: 2007, operating hours: 3,488 h, functionality: fully functional, machine/vehicle number: TM3507008, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 5,000 rpm, controller model: SELCA S 4045 PDH, The table and the dust extraction system are included in the price! TECHNICAL DETAILS Travel range X-axis: 3,500 mm Travel range Y-axis: 1,100 mm Travel range Z-axis: 1,500 mm Codpfx Aozr H H Soc Tjhb Table dimensions: 3,800 x 1,000 mm Spindle taper: ISO 50 Spindle speed: 5,000 rpm Tool positions: 40 Working feed rate: max. 15,000 mm/min Rapid traverse: 40,000 mm/min Maximum axis force (X, Y, Z): 1,500 N MACHINE DETAILS Control system: SELCA S 4045 PDH Operating hours according to image (as of: July 31, 2026) Total: approx. 29,147 h Partial: approx. 3,488 h A manufacturer's offer for dismantling and loading is available for €27,000.

Condition: defective spare-parts repository (used), Year of construction: 2015, functionality: not functional, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item by September 18, 2026! A forklift will be provided on-site for loading. The machine is defective and is intended as a source of spare parts. TECHNICAL DETAILS Printing technology: Inkjet Color system: 7 colors Cjdozx E N Sopfx Ac Tjhb MACHINE DETAILS Electrical connection data Three-phase connection 1: 3/N/PE, 380–415 V, 50/60 Hz, 14 A SCCR three-phase connection 1: 1.5 kA Three-phase connection 2: 3/N/PE, 380–415 V, 50/60 Hz, 4 A SCCR three-phase connection 2: 1.5 kA Single-phase connection: 220–240 V, 50/60 Hz, 16 A SCCR single-phase connection: 35 kA EQUIPMENT Compliance: CE, KCC Safety approval: TÜV Rheinland – Type Approved Safety

Condition: good (used), Year of construction: 1965, Model maker milling machine with swivel head, MK 4, rotary table, d. Accessories Year of construction: 1965 Chodpfsq Ixz Rsx Ac Tjb X (mm): 1000 Y (mm): 600 Mounting (iso/mk): 4 Power (kw): 2

Condition: defective spare-parts repository (used), Year of construction: 2015, functionality: not functional, No minimum price – guaranteed sale to the highest bidder! Submitting a bid obligates you to collect the item by September 18, 2026! A forklift will be provided on-site for loading. The machine is defective and is intended as a source of spare parts. TECHNICAL DETAILS Printing technology: Inkjet Color system: 7 colors MACHINE DETAILS Chedozx E Axjpfx Ac Teb Electrical connection data Three-phase connection 1: 3/N/PE, 380–415 V, 50/60 Hz, 14 A SCCR three-phase connection 1: 1.5 kA Three-phase connection 2: 3/N/PE, 380–415 V, 50/60 Hz, 4 A SCCR three-phase connection 2: 1.5 kA Single-phase connection: 220–240 V, 50/60 Hz, 16 A SCCR single-phase connection: 35 kA EQUIPMENT Compliance: CE, KCC Safety approval: TÜV Rheinland – Type Approved Safety

Condition: ready for operation (used), Year of construction: 2008, operating hours: 14,812 h, functionality: fully functional, product width (max.): 480 mm, product height (max.): 12 mm, product length (max.): 320 mm, TECHNICAL DETAILS Performance (cycles/hour) Speed: max. 14,000/h Wrapping speed: max. 14,000/h Pre-folding: max. 12,000/h Piston opening: max. 12,000/h Offset stitching: max. 12,000/h Dimensions – Width × Spine Length Uncut: max. 320 × 480 mm Uncut: min. 85 × 128 mm Single-up Cut: max. 315 × 475 mm Minimum cut size: 80 × 120 mm Double-up Uncut: min. 85 × 210 mm Trim mark Cut: min. 2 × 64 × 100 mm Product height (compressed) 3-knife cut: max. 12 mm Middle cut as trimming cut: 10 mm Middle cut as punching cut (half punching width): max. 6 mm Triple cut as trimming cut: 5 mm MACHINE DETAILS Operating hours (according to counter): 14,812 h EQUIPMENT 1 CHU feeder 2 DVU vertical feeders 2 DHU horizontal feeders 1 Stitchmaster three-knife cutting machine with middle cut 2 knife sets 4 stitching heads CHA forklift Chsdpfx Aozw Ak Rec Tsb Note: Further technical details can be found in the attached document.

Condition: used, Technical details: table diameter: 315 mm rotatability of the table - manual/mechanic: 360 ° weight of the machine approx.: 100 kg dimensions: 620 x 530 x 135 mm The tables were rarely used other features: -with radial scale -surface is finished -center mounting MK3 -dividing circle 19 / 27 / 31 / 41 / 49 / 59 -operation also possible by machine via coupling on both sides (switchable right-/left-hand rotation with automatic changeover) -foot clamping: support size 360 x 420mm with 1 clamping groove on the front side 16 x 200mm Chjdpfxou N Dz Aj Ac Tsb *

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2024, total length: 1,250 mm, total height: 1,900 mm, total width: 2,000 mm, overall weight: 1,850 kg, No minimum price – guaranteed sale to the highest bidder! Lease return due to factory closure. Machine for the automatic and precise separation or singulation of printed circuit boards from a PCB panel. MACHINE DETAILS New price 2024: €149,000.00 net Processed printed circuit boards: 42,680 pieces Dimensions of pallet (L x W x H): 1,250 x 2,000 x 1,900 mm Machine weight: approx. 1,850 kg EQUIPMENT Cutter diameter control Wear parts package DIVISIO Automatic transport width adjustment SMEMA transport height Separation module, shank cutter 500 W Hardware module, camera Software module, teach function for camera Software module, fiducial mark recognition Extension, 8-position tool changer Extraction hose, manual Monitoring of suction power ASYCAM CAD data conversion A Adrep Offset main switch ESD energy chains and P-hoses, standard Packaging size, group 3 pallet Codpfx Acjzvb I Es Tehb • The height and weight of the asset must be taken into account when selecting the transport vehicle. • A forklift is available for loading. • If the asset is not collected on time, a storage fee of €20.00 per lot and commenced day will be charged. The fee must be paid before collection. • The sale is made without any guarantee or warranty. • No liability is accepted for typing or measurement errors. If in doubt, please compare the information with the provided photos or inspect the goods on site before the auction ends.

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning diameter: 1,800 mm, turning length: 600 mm, spindle bore: 130 mm, spindle speed (max.): 400 rpm, controller model: Siemens 840D Powerline, TECHNICAL DETAILS Chodpfx Aozv Rlgsc Tjb Turning diameter: 1,800 mm Turning length: 600 mm Spindle bore: 130 mm Spindle nose: DIN 55027, size 11 Speed range: 1–400 rpm MACHINE DETAILS Control system: Siemens 840D Powerline Total power requirement: 38 / 52 kW Dimensions & Weight Machine weight: approx. 25 t Transport width: 3,700 mm EQUIPMENT 6-jaw chuck

Condition: used, Technical details: faceplate diameter: 1000 mm Cedju N E E Nepfx Ac Tshb width: 150 mm boring diameter: Ø 130 mm max. passage: Ø 130 mm weight: 475 kg dimensions: Ø 1000 x 255 mm Equipment: -4x external/internal jaws; clamping travel approx. 200mm; clamping range max; approx. Ø 900mm / min. approx. Ø 100mm. -clamping flutes size according to DIN 650: a=22mm; h=43mm; b=40mm; c=16mm x length= 285mm Flange mounting: Ø inside: 195mm, depth 21mm 4x clamping bore pitch circle Ø 235mm *

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 11139737, sheet thickness (max.): 30 mm, working width: 2,000 mm, working length: 6,000 mm, empty load weight: 1,950 kg, The machine will be available starting mid-September! TECHNICAL DETAILS Working area: 6,000 × 2,000 mm Working length: 6,000 mm Working width: 2,000 mm Csdpfx Aozv N Hpoc Tjhb Max. sheet thickness: 30 mm Travel range X-axis: 6,000 mm Travel range Y-axis: 2,000 mm Travel range Z-axis: 150 mm MACHINE DETAILS Plasma source: Kjellberg HiFocus 161 neo Cooling type: Water Voltage: 3 × 400 V Power: 9 kW Frequency: 50 Hz Number of phases: 3 Net weight: 1,950 kg EQUIPMENT Dust extraction system: Donaldson Torit DCE
