Multispindle

INDEX MS 32 C

Condition: used, Cnc multispindle lathe INDEX MS32C Pedpfx Aasxt U Hpj Eorf

Condition: good (used), Year of construction: 2012, CNC long turning automatic machine Brand: CITIZEN Type: A32 VII CL Year of manufacture: 2012 with: Mitsubishi Meldas control synchronous spindle driven tools rear side machining high pressure pump Prsdpfx Aewntc Usa Eef oil mist extraction fire extinguishing system bar feeder magazine IEMCA BOSS

Condition: used, Cnc multispindle lathe INDEX MS32C Podpsxma Npjfx Aa Esrf

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Max. bar diameter : 32 [mm] - Spindle speed : 6300 [rpm] - slide unity 1.1 : X and Z axes controlled by CNC Pjdpfx Ajuhavdja Eorf - slide unity 1.2 : X and Z axes controlled by CNC - slide unity 2.1 : X and Z axes controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : X and Z axes controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : X and Z axes controlled by CNC - slide unity 5.1 : X and Z axes controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - synchronous unit, spindle position 6.1 EQUIPMENT - CNC Siemens 840D - Counter spindle - Double control panel - 2 NCU - Bar loader : IEMCA SIR MS32 F - Coolant tank : KNOLL * with high pressure pump - Chip conveyor : KNOLL - Cooling unit: Riedel WTS 030.02-NE - Unloading system with 2 CNC axes - Fire extinguisher : KRAFT UND BAUER *NB : working order not guaranteed. To have it checked by a qualified organization of the buyer.

Condition: like new (used), Year of construction: 1990, functionality: fully functional, BOBST AUTOMATIC FOLDER & GLUER MACHINE • TYPE : DOMINO 100-M • SIZE : 100 CM • LOCATION : Our Warehouse in Venlo-Netherlands Details: Full revised in 2022 3 point glueing “NORDSON” Cold Glueing System "ERO" Glueing System 2025 (Optional) “KQ” Glueing System 2025 (Optional) With standart equipments Regularly maintained by Bobst It is completely cleaned and painted It is in perfect condition Available immediately Prodpfxovm Atbs Aa Esf

Condition: used, TECHNICAL DETAILS - number of spindles : 6 independent - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] - machine equipped with 32 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 1.2 : fixed X axis, Z axis controlled by CNC - slide unity 2.1 : fixed X axis, Z axis controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : fixed X axis, Z axis controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : fixed X axis, Z axis controlled by CNC - slide unity 5.1 : fixed X axis, Z axis controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC Prjdpfxeuhaxlj Aa Ejf - counter-spindle position 6.1 EQUIPMENT - INDEX C200-4 control (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR MS32/33/P bar loader - Coolant tank with HP pump - KNOLL chips conveyor - Parts catcher with conveyor in position 6 - Cross drilling device in position 3.1 et 4.1

Condition: used, Cnc multispindle lathe INDEX MS 32 C Pjdpfx Aajuhaqbj Eerf

Condition: used, Year of construction: 2008, clamping force: 160 kN, displacement volume: 251 cm³, injection pressure: 2,500 bar, overall weight: 8,200 kg, load hours: 37,200 h, screw conveyor diameter: 40 mm, terms of delivery: FCA Pegnitz Podpfx Ajwd Udlsa Eorf delivery time: on request terms of payment: 100% prior to delivery

Condition: used, TECHNICAL DETAILS Pjdpfeuhauyjx Aa Eerf - number of spindles : 6 independent - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] - machine equipped with 28 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : X and Z axes controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : X and Z axes controlled by CNC - slide unity 5.1 : X and Z axes controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - synchronous unit, spindle position 6.1 EQUIPMENT - INDEX C200-4 control (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR MS32/33/P bar feeder - Coolant tank: KNOLL AE 1076 * with high-pressure pump - KNOLL VRF 500 chips conveyor - Parts catcher with conveyor in position 6

Condition: used, TECHNICAL DETAILS - number of spindles : 6 independent - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] - machine equipped with 32 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 1.2 : fixed X axis, Z axis controlled by CNC - slide unity 2.1 : fixed X axis, Z axis controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : fixed X axis, Z axis controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : fixed X axis, Z axis controlled by CNC - slide unity 5.1 : fixed X axis,Z axis controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - counter-spindle in position 6.1 Pjdpfx Aeuhangea Ejrf EQUIPMENT - INDEX C200-4 (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR 32/33/P bar loader - Coolant tank with HP pump - KNOLL chips conveyor - RIEDEL cooling unit - Parts catcher with conveyor in position 6.1 - Cross rilling device in position 3.1 et 4.1

Condition: good (used), Year of construction: 2004, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence Podpfxsul Efmj Aa Esrf - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data
