Edge banding machine EDGETEQ S-300

HOMAG EDGETEQ S-300

Condition: used, machine/vehicle number: 008325, Position 1: Single Edgebanders HOMAG-EDGETEQ S-390 - LOOPTEQ O-300 Bwsdsx Hpklepfx Acvok Position 2: Panel Return Systems HOMAG-EDGETEQ S-390 - LOOPTEQ O-300

Condition: like new (used), Year of construction: 2011, machine/vehicle number: 0-261-04-5736, functionality: fully functional, operating hours: 806 h, workpiece height (max.): 60 mm, edge thickness (max.): 8 mm, feed rate X-axis: 11 m/min, total length: 5,700 mm, Equipment: documentation/manual, Brandt AMBITION 1440 KDF Bedpfsylvpqex Acvjwk Year of manufacture: 2011 Year of commissioning: 2013 In very good condition

Condition: used, machine/vehicle number: 006849, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt Premilling Unit: yes Bwodpswd Itmjfx Acvok Corner Rounding Unit: yes Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: excellent (used), Year of construction: 2009, machine/vehicle number: 241.125, functionality: fully functional, Horizontal Beamsaw of the manufacturer Schelling, designed for cutting wood-based material HPO – cutting optimization program Saw blade projection: max. 95 mm Bodpsx Ebzdsfx Acvjwk Saw carriage feed up to 120 m/min Cutting lengths: Model FH 4 430 - 4.300 mm Can be inspected in working condition until beginning 2026. (dismantling planned) Maximum Saw blade Diameter - 350 mm Projection - 95 mm Clamp opening 90 mm Power Saw motor - 15 kW Scorer Diameter 300 mm Feed rate forward up to 80 m/min reverse 80 m/min Saw feed rate forward up to 120 m/min reverse 120 m/min

Condition: excellent (used), Year of construction: 2003, I sell the 3-axis CNC working centre SCM SCM RECORD 110, year 2003. Configuration: 3-axis main spindle SCM 6,6kW 24.000 rpm Tool magazine 8 positions ISO30 on working head Bwodpfx Acehhruhsvjk Useful working area 2690x940 x Z 150mm (300mm). 2 working fields, 4 clamping areas - Flachtisch Automatic central system of lubrication. Pump BECKER 5,5KW 244/286 m3/h. fast neu. Gewicht 3200kg Xilog Plus new software controller with full instructions ! Very good condition. Available immediately.

Condition: excellent (used), Year of construction: 2014, Drilling line consisting of: 1. MAHROS - BRUSH CF loading system 2. MORBIDELLI - ZENITH F2 CDM through-feed drill 3. MORBIDELLI - ZENITH F2 CDM through-feed drill 4. MAHROS - BRUSH SF unloading system Machine connected - works daily in one shift. The first drill has: Bodpfx Acogb D Afsvjwk upper vertical heads - 3 pcs lower vertical heads - 6 pcs horizontal heads L + P- 2 pcs The second drill has: upper vertical heads - 3 pcs lower vertical heads - 6 pcs horizontal heads L + P- 2 pcs rear horizontal heads - 6 pcs Below are details of the machine and a video The possibility of seeing the machine every day. Line availability August 2021

Condition: used, Year of construction: 2011, machine/vehicle number: 0-261-07-5143, functionality: fully functional, edge thickness (max.): 12 mm, The machine is overall in very good condition. An on-site demonstration is not a problem. This machine is still in full operation. Bsdpfoycxgaex Acvewk

Condition: ready for operation (used), Technical characteristics 5 axes Max workpiece length single 6000 mm, pendulum 2375 mm Max. workpiece width rear 1300 mm Max. workpiece thickness 300 mm, incl. clamping device Consoles with front stop 10 units 100 mm high suction cups for processing the underside of the workpiece Vacuum pump 2 x 100 m3/h Windows control system Windows XP operating system 17" TFT flat screen WOODWOP program Graphic representation of the clamping stations Modern 3D graphic interface software Remote diagnostics Operating voltage 400 V, 50/60 Hz Control cabinet can be positioned on the right or left 5-axis main spindle 15 kW drive5+ HSK F63 Liquid cooling Electronically controlled from 1000 -24000 rpm Tool length 230 mm max Tool Ø: max 180 mm for milling tools 350 mm max for saw blade use Z-axis travel 750 mm Vibration sensor for monitoring the spindle during machining Tool changer by disc 18 stations D=130 milling tool HSK F63 Place pickup for saw blade 350 mm 25 spindles drilling unit (19 vertical, 2+4 horizontal, grooving saw) Bedpst Ttn Esfx Acvjwk Laser projection for positioning of suction cup clamp to show the contour to be milled program in WOODWOP Chip transport belt Power and Motors Voltage: 400 V Pluging: Three-phased Overall dimensions Lenght: 9500 mm Width: 5000 mm Height: 3450 mm

Condition: excellent (used), ELECTRONIC (CNC control) machine, Numerical Control Type NC 500 - Software Tooling System N. 2 Through-feed motorized conveyoring belts - Feeding speed (m/min) 35 - 75 ca. N. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 x HP 1,8 Max. working width (mm) 3200 - Min. working width (mm) 215 Bwodshvi Dujpfx Acvjk N. 7 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 x HP 1,8 N. 3 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 x HP 1,8 N. 5 Vertical top pressure clamps - N. 2 Motorized endless screws to evacuate wastes/chips The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the vertical movement (Hv) of the 2 horizontal units The CNC controls the movement (X axe) of all the vertical units The CNC controls the movement (Y1 and Y2 axes) of the boring heads The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the pressure clamps The CNC controls the movement (X axe) of the conveyor belts The CNC controls programming of the working cycles

Condition: excellent (used), Numerical Control Type NC 400 Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Bodjidqf Rjpfx Acvjwk Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) No. 6 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 3 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 5 Transport belt to evacute chips (wastes) Digital quota (axes) display Total installed power (Kw) 59,1 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts
