Panel dividing system

HOLZMA HPP 380/43/43 NEW PROFILINE

Year of construction: 2018, condition: excellent (used), functionality: fully functional, Wemhöner VARIOPRESS Vacuum Membrane Press Basic 1000 S Technical Specifications: Heating platen size (mm): 2850 x 1550 Electric heating platen design: Aluminum, top heating platen Total pressing force (kN): 2400 Max. chamber pressure (bar): 6 Max. operating temperature: 180 degrees Celsius Max. batch or workpiece size (mm): approx. 2460 x 1180 Thermoplastic film in roll form: Film width: approx. 1430 mm Film thickness (mm): approx. 0.25 - 1 Pressure chamber height (mm): max. up to 180 Connected loads: Bwodpfxov Np H Hj Acvok Installed power (kW): approx. 46 Required air pressure (bar): approx. 8

Condition: excellent (used), Year of construction: 2011, Used horizontal panel saw Manufacturer: Holzma Model: PROFI HPL 430/43/22 Year of manufacture: 2011 Cutting length: 4300 mm Cutting width (program pusher travel): 4250 mm Roller rail (double track): 9 pieces Clamps: 7 pieces, first 3 are 2-fingered Air cushion table, width 650 mm: 4 pieces, each 2160 mm long Central blower: 1 unit with increased air output Bwsdpeymx S Dsfx Acvsk - 3 angled lift clamps (2-fingered) - 1 angled lift clamp (1-fingered) - 1st air cushion table: 800 mm wide - Speed package: -> Saw carriage feed: 1 – 150 m/min Technical specifications: Blade projection: 95 mm Saw carriage feed: forwards 25 m/min, reverse constant 90 m/min Automatic cutting height adjustment Angle pressure device, min. pressure width 0 mm; max. pressure width full cutting length Main saw motor: 18 kW, frequency controlled Scorer saw motor: 2.2 kW Operating voltage: 400 V (+10%/-5%) / 50 Hz Electrical connection value with HS motor 18 kW: 28 kW Power Control CADmatic 4.0 control unit with 17" flat display Labeling with part graphics / label software / label printer PICA 104

Year of construction: 2008, condition: ready for operation (used), functionality: fully functional, Wemhöner Basic 1000 Plus - Year of manufacture: 2008 - Very good condition, little used * Type: KT-MB-28/15-240 Bsdpfx Acexbcudjvswk * With automatic pin system and inline turner * 2 tables with automatic Vario-Pin system * Teflon coating for pre-glued foil * Foil laying system for pin table (pre-glued foil) * Heating plate size: 2800 x 1500 mm * Max. workpiece size: 2,540 x 1,250 mm * Membrane: Yes * Cutting station * Foil storage carousel, 3.2 m height with 14 hanging bars * PLC control: Siemens S7 * Control panel for Siemens TP 270 PLC (touchscreen) * Automatic membrane tensioning * Installed power supply: 38.5 kW * Max. chamber pressure: 6 bar * Max. pressing opening: 150 mm * 6 cylinders with Ø 125 mm * Operating voltage: 400V 50/60Hz * Press chamber height: 40/60 mm * Max. pressing force: 2400 kN * Operating pressure of hydraulic system: 320 bar

Condition: used, Year of construction: 2005, Used machine Year of manufacture: 2005 Condition: Guides slightly worn, only suitable for rough cutting Bedpfjwqifkjx Acvswk Equipment and technical data: - Cutting length: 4300 mm - Max. passage height: 2200 mm - Max. trimming height: 2100 mm - Max. scoring height vertical: 2100 mm - Cutting depth: 80 mm - Motor: 5.5 kW - Saw blade speed: 4500 rpm - Saw blade diameter: 300 mm - Extraction: 2 x 100 mm - Compressed air consumption: 60 NL/min Dimensions: 5620 x 1480 x 2990 mm Availability: short-term Storage location: Flörsheim

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, 1 Panel Sizing Saw with Storage System Manufacturer: HOLZMA Model: PROFILINE HPL 530/56/22 – right-hand machine Year: 2008 Including integrated storage system PROFI TLF610/10/05/L Manufacturer: BARGSTEDT Year: 2013 Woodstore inventory management software, offcut management, etc. Storage area approx. 37 x 11.5 m Max. stack height in storage: 2,500 mm Speed Concept: sets completely new standards that revolutionize panel dividing technology. + Significantly higher speed and dynamic acceleration of the saw carriage. + Extreme acceleration of the program pusher. + Central angle alignment device. + Electronic height control of the pressure beam. Bwodpfsyw Ivhsx Acvjk + Optimized motion sequences via integrated gripper measuring system. Cutting length: 5,600 mm Cutting width (program pusher travel): 5,600 mm Panel rotation device for head cuts Laser guide light: marks the cutting line on the workpiece for visible or scribed cuts. Lift table feeding Lift table size: 5,600 x 2,200 mm PROFILINE VAC infeed carriage 5,600 mm Separate infeed carriage for gentle loading of sensitive single panels via vacuum, as well as efficient infeed of panel packs. Saw blade projection: 130 mm Saw carriage feed: Forward 1-150 m/min Reverse constant 150 m/min Program pusher speed: Forward/reverse 90 m/min (in EU countries forward = 25 m/min) Automatic pressure beam height control: yes Automatic cutting height: yes Adjustable pressure beam contact pressure: yes Adjustable gripper contact pressure: yes Gripper release: yes Fully air-cushioned machine table (saw body): yes Angle alignment device: Min. alignment width: 0 mm Max. alignment width: full cutting length Main saw motor (at 50 Hz): 18.0 kW Frequency control: 1,700 – 4,200 rpm Scoring saw motor: 2.2 kW Operating voltage: 400 V / 50 Hz Working height: 1,020 mm SPZ UNIT W. LIFT ELEMENT 2-FINGER 11/510/530 AUTOMATIC EJECTOR FENCE Program-controlled ejection of panel packs to the area of the air cushion tables. FULLY AUTOMATIC SCORING SAW ADJUSTMENT TYPE 530 Camera-controlled GROOVE PROGRAM (AUTOMATIC) Groove program with graphical input and sequence display. Positioning accuracy: Groove depth is steplessly variable via control (hydraulic stop). CUT-OUT/STRESS RELIEF CUTTING PROGRAM LABELLING WITH PART GRAPHICS LABEL PRINTER TYPE PICA 108 Thermal / thermotransfer label printing station OPTIMIZATION PROGRAM 'CAD-PLAN' -JUST-IN-TIME- Additional 'Just-in-time' function (possible operating modes): 1. Optimization at the saw ----- - Possible import of part lists from industry packages, Excel, etc. - Incorporates available offcuts in optimization - In case of production interruption, unproduced parts can be re-optimized - Flexible selection of which parts with which material are optimized and produced at which time 2. Transfer of optimized data to the saw - Modification of optimized cutting plans at the saw: - Delete/add parts - Add available offcuts - Change panel sizes - Combine runs, etc. New optimization is performed directly at the saw. ONLINE DATA TRANSFER + USB PORT CAMERA MONITORING OF THE FEED AREA Material specifications for lift table feed: Max. waviness: 40 mm/m Panel thickness min. 6 mm Thickness tolerance per panel max. +/- 0.2 mm Stacking accuracy +/- 50 mm

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, cutting width (max.): 4,300 mm, section length (max.): 1,600 mm, TECHNICAL DETAILS Max. cutting length: 1,600 mm Min. cutting width: 4,300 mm MACHINE DETAILS Bjdpjyuya Eofx Acvewk Number of transport packages: 8 pcs. Year of manufacture: 2016
