Press brake

Bystronic PR 150 x 4100

Condition: excellent (used), mileage: 495,000 km, power: 537 kW (730.12 HP), fuel type: diesel, tire size: 385/65 R 22.5, axle configuration: 8x4, fuel: diesel, fuel tank capacity: 1,000 l, brakes: retarder, color: blue, driver cabin: sleeper cab, emission class: euro6, suspension: steel-air, permissible axle load (axle 1): 8,000 kg, permissible axle load (axle 2): 8,000 kg, permissible axle load (axle 3): 13,000 kg, Equipment: AdBlue, air conditioning, cruise control, retarder, second fuel tank, spoiler, = Additional Options and Accessories = - Leaf spring suspension - Roof spoiler - Refrigerator - Air suspension - Radio/CD player - Sleeper cab - Sun visor - Power take-off (PTO) = Notes = Color: Blue Details Manufacturer: Scania Type: R 730 8x4 Chassis number: YS2R8X40005472379 Year: 2017 Mileage: approx. 495,000 km Engine: 730 HP / EURO 6 / 16-liter diesel / V8 Transmission: Scania Retarder R4100 Front axle: 8,000 kg | 385/65 R 22.5 | leaf suspension Second axle: 8,400 kg | 385/65 R 22.5 | air suspension Rear axles: 13,000 kg | 315/80 R 22.5 | air suspension | hub reduction GVW: 26,000 kg GCW: 160,000 kg Equipment 500L + 500L fuel tanks AdBlue NATO / 24-volt electrical system Warning flashing lights on roof Alcoa rims Tool box PTO with 170L tank JOST JSK38C 3.5" fifth wheel on sliding frame Webasto Cabin Multi-functional steering wheel Cruise control Sun visor 2 x Bed Refrigerator Comfortable seats Storage boxes Radio CD player / AUX / USB Tachograph Roof hatch = Further Information = General Information Year of construction: 2017 Year of manufacture: 2017 Technical Information Number of cylinders: 8 Engine displacement: 16,000 cc Payload: 160,000 kg Permissible total weight: 42,000 kg Transmission Transmission: Scania Retarder R4100 Axle Configuration Front axle: Tire size: 385/65 R 22.5; Alloy rims; Max. axle load: 8,000 kg; Steerable; Suspension: Leaf spring suspension Mid-axle: Tire size: 385/65 R 22.5; Alloy rims; Lift axle; Max. axle load: 8,000 kg; Suspension: Air suspension Rear axle 1: Tire size: 315/80 R 22.5; Twin tires; Alloy rims; Max. axle load: 13,000 kg; Reduction: External planetary axles; Suspension: Air suspension Rjdpjuu Ha Dsfx Akioch Rear axle 2: Tire size: 315/80 R 22.5; Twin tires; Alloy rims; Max. axle load: 13,000 kg; Reduction: External planetary axles; Suspension: Air suspension Functional Body manufacturer: Scania Condition Technical condition: very good Optical condition: very good Damage: none Financial Information Price: On request

Condition: used, Year of construction: 1998, functionality: fully functional, For sale: Coil metal decoiling, slitting, and recoiling line Rcjdjxlcp Nopfx Akieh Condition: used, connected – available for live demonstration. Designed for coil metal decoiling, precise slitting into narrower strips, and recoiling into smaller coils. Technical specifications: Year of manufacture: 1998 Made in: Poland Max. metal width: 1250 mm Knife pairs: 5 Longitudinal slitting, steel: min 0.4 mm / max 1.2 mm Film application function Scrap cutting guillotine Line includes: Decoiler 5 T Recoiler 5 T Multi-knife disc shears Braking and separating segment Turnstile with separator Control panel Purpose: The line is intended for preparation of coil metal for further processing: decoiling, precise longitudinal slitting, recoiling into smaller coils. If you have further questions – we will be happy to assist you.

Condition: used, axle configuration: > 3 axles, first registration: 10/2006, total width: 2,850 mm, suspension: other, tire size: 285/70R19.5, color: black, Equipment: ABS, = Additional Options and Accessories = - Central lubrication system = Notes = Faymonville Jeep dolly D3 Year 2006. 1 x lift axle. 1 x friction steering axle / trailing arm steering. Air suspension. Max. technical weight: 56,000 kg. Faymonville STBZ-5VA Year 2006. Swivel axle. Removable gooseneck. Movable table. Extendable bed: 400 cm. Loading bed: 650 + 400 cm. 50,000 kg gooseneck capacity. Max. technical weight: 119,680 kg. = Further Information = Axle configuration Tire size: 285/70R19.5 Brakes: Drum brakes Front axle 1: Twin tires; tire tread depth left inside: 15%; tire tread depth left outside: 60%; tire tread depth right inside: 60%; tire tread depth right outside: 60%; suspension: air suspension Front axle 2: Twin tires; tire tread depth left inside: 30%; tire tread depth left outside: 30%; tire tread depth right inside: 40%; tire tread depth right outside: 60%; suspension: air suspension Front axle 3: Twin tires; steerable; tire tread depth left inside: 30%; tire tread depth left outside: 70%; tire tread depth right inside: 60%; tire tread depth right outside: 70%; suspension: air suspension Rear axle 1: Twin tires; steerable; tire tread depth left inside: 30%; tire tread depth left outside: 60%; tire tread depth right inside: 40%; tire tread depth right outside: 70%; suspension: hydraulic suspension Rear axle 2: Twin tires; steerable; tire tread depth left inside: 50%; tire tread depth left outside: 50%; tire tread depth right inside: 30%; tire tread depth right outside: 75%; suspension: hydraulic suspension Rear axle 3: Twin tires; steerable; tire tread depth left inside: 60%; tire tread depth left outside: 60%; tire tread depth right inside: 60%; tire tread depth right outside: 60%; suspension: hydraulic suspension Rear axle 4: Twin tires; steerable; tire tread depth left inside: 60%; tire tread depth left outside: 60%; tire tread depth right inside: 40%; tire tread depth right outside: 50%; suspension: hydraulic suspension Rcedpfx Akexbng Ejioh Rear axle 5: Twin tires; steerable; tire tread depth left inside: 70%; tire tread depth left outside: 70%; tire tread depth right inside: 20%; tire tread depth right outside: 70%; suspension: hydraulic suspension Weights Unladen weight: 36,600 kg Payload: 99,400 kg GVW: 136,000 kg Financial information Price: On request Identification Type number: STBZ-5VA + 3 AXLE JEEP DOLLY / E = Company Information = ALL PRICES ARE NET FOR EXPORT (Joris Versteijnen NL-DE-GB; Wouter Greutink NL-DE-GB-ES-IT; Govorim po ryccki). We make every effort to provide accurate information. However, no rights can be derived from the information provided.

Condition: used, Year of construction: 2026, Slitting line 1500 x 6, made by GUIDA Line composition: - Loading coil car - Uncoiler with sliding base and single expanding mandrel - Pressure arm - Feeding telescopic table with cutting edge and deflecting roll - Entry pinch roll - Crop shear - Tilting table - Mechanical centering device - Calming rolls - Slitting shear - Looping pit equipment (entry and exit saddles + connecting tables) - Felt press - Deflecting rolls - Titling table - Recoiler with single expanding mandrel - Separator arm - Electric equipment - Hydraulic equipment - Safety fences protection - Several tooling and accessories - Spare parts Material to be processed: Hot rolled carbon steel Material tensile strength: 400 N/mm² Coil width max.: 1.500 mm Thickness: 1 - 8 mm Coil weight: 20 Tn Coil inside diameter entry: 500/600 601 + steel spacers for bigger diameter Coil external diameter Entry/Exit: 1.700 mm Slitting shear mandrels diam.: 220 mm Blades diameter: 355 mm Line speed: 50/25 m/min with manual speed change gear Rcodjymciaepfx Akish Working Direction: From left to right Power supply tension: 380/50 Hz

Condition: used, Year of construction: 2008, pressure 180 t chamfer lenght 3110 mm distance between columns 2600 mm column arm 410 mm Rsdpfxexa Hivo Akijch ajustment speed 100 mm/sec working feed 10.0 mm/sec return speed 80.0 mm/sec back stop - adjustable max. 750 mm stroke 260 mm dayligth 460 mm table height 880 mm oil volume 210 ltr. operating pressure max. 240 bar control DELEM total power requirement 15.0 kW weight of the machine ca. 11.200 kg. range L-W-H 4250 x 2000 x 2800 mm Current new price approx. 85.000 euros Special price on request Features: - Electro-hydraulic CNC press brake - With DELEM CNC control model “DA 66W” * 2D graphic programming * Automatic bend sequence calculation and collision detection * High-quality LCD screen (TFT) * Swivel control panel, front left - CNC-controlled axes: Y1 + Y2 + X + R + CNC crowning - CNC electric motor-driven backgauge (X axis) * with 2x manually adjustable stop fingers - CNC electric motor height adjustment of the backgauge (R axis) - CNC electric motor table crowning - ROLLERI upper tool adapter (quick-change clamping) * including crowning device in the tool holder - 2x front, sliding support arms (“sliding” system) - Side guard (swivel doors) - Rear guard (sliding door) - 1x freely movable 2-hand/foot control - Operating instructions (PDF)

Condition: excellent (used), Year of construction: 2007, Technical specifications: Max. cutting width: 4050 mm Max. cutting capacity for steel (ST40): 8.0 mm Max. cutting capacity for stainless steel: 6.0 mm Max. cutting capacity for aluminium: 8.0 mm Motorized adjustable backgauge: 1000 mm Rjdeywd Ndjpfx Akioch Cutting gap adjustment Cutting angle adjustment: 2.2° Sheet support device Motor power: 15 kW Dimensions (L x W x H): approx. 4800 x 2200 x 2150 mm Weight: approx. 11.5 tons The seller is not liable for typographical or data transmission errors. The machine is in condition, technically and visually, corresponding to its age; used machines are sold without any warranty.

Condition: refurbished (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 28727, DOUBLE-STROKE HEADER NATIONAL 61MS operational Machinery operational, fully functional. Revised in 2024 (mechanical and electrical parts) Available for any test c/o HBR srl Number of die: 1 Number of punches: 2 Rodpfx Akot Rp A Hoisch Pieces per min.: 400 Cutoff diameter: 6 mm. Cutoff length (min./max.): 10/52 mm. Kickout stroke-die (min./max.): 4.8/30 mm. Kickout stroke-punch (max.): 9.5 mm. Upset diameter: 14 mm. Quill diameter: 19 mm. Cutter insert diameter: 12 mm. Die diameter: 41 mm. Cone punch diameter: 32 mm. Finish punch diameter: 35 mm. Power of main motor: 15 KW Floor space (width): 1.340 mm. Floor space (length): 2.680 mm. Height: 1970 mm. Net weight: 4.700 kg. Gross weight: 5.400 kg.

Condition: excellent (used), Year of construction: 1999, AMADA MODEL GPN 840 HYDRAULIC SHEAR MAXIMUM CUTTING LENGTH 4000 mm MAXIMUM THICKNESS M.S. 45 kg/mm/2 8 mm MAXIMUM THICKNESS S.S. 60/kg/mm2 6 mm STROKES PER. MIN 10 - 35 BACK GAUGE RANGE 10 - 1000 mm MOTOR SIZE 15 KW Rjdpfx Akotrkmneiech MACHINE WEIGHT 10100 kg STANDARD EQUIPMENT PROGRAMMABLE MOTORISED BACK GAUGE 1.5 METRE SIDE GAUGE 1.5 METRE FRONT SUPPORT SHADOW LINE LIGHT AUTOMATIC HYDRAULIC HOLD DOWN CLAMPS CENTRALISED LUBRICATION FOOTSWITCH SHADOW LIGHT BEAM CYCLE COUNTER AUTOMATIC SHEARING CONTACTS IN BACK GAUGE BLADE GAP AND RAKE ANGLE ADJUSTMENT FRONT FLIP STOPS ONE SET OF BLADES 4 CUTTING EDGES ADJUSTABLE STROKE WORK CHUTE HOUR COUNTER AUTO-DIAGNOSTICS

Condition: used, pressure 150 t chamfer lenght 4300 mm distance between columns 3700 mm ram stroke speed 100 mm/sec working feed 8 mm/sec return speed 80 mm/sec stroke 175 mm table height 920 mm Control DELEM DA 52 Rodpfx Ajv S Iryjkiech total power requirement 11 kW weight of the machine ca. 15000 kg dimensions of the machine ca. 4800 x 1700 x 2850 mm Equipment: - Controlled axes Y1 - Y2 - X, as well as CNC crowning - DELEM DA52 CNC control - Electric backgauge (X-axis) - 4x manually adjustable stop fingers - 2x front support arms - AMADA UKB system upper tool holder - Side guard - Foot switch

Condition: used, Year of construction: 2001, HEAVY DUTY ROLLFORMING LINE 11 STATIONS WIDTH: 450 mm Rcsdpfoy Rxzhox Akieh FULL OVERHAUL
