BIESSE 7-SPINDLE DRILLING HEAD

BIESSE

Condition: not inspected (used), Year of construction: 2016, functionality: unexamined, edge thickness (max.): 22 mm, rotational speed (max.): 12,000 rpm, Equipment: CE marking, The machine has the following configuration: Pre-milling unit Automatic, timer-controlled intervention and positioning via NC Edge preheating lamps Edge band magazine Glue pot for EVA hot-melt adhesive Premelter for EVA hot-melt adhesive QM-705 End trimming unit IN-801 Number of motors: 2 Top and bottom flush trimming unit RS-100 Number of motors: 2 Motor power: 2 kW Speed: 12,000 rpm Fine finishing and contour trimming unit RF-100 Number of motors: 2 Motor power: 2 kW Speed: 12,000 rpm Corner rounding unit AR30 Number of motors: 2 Motor power: 0.8 kW Speed: 12,000 rpm Automatic, timer-controlled intervention Dedpfxsyxndbe Ag Dekk End cutting unit RB02 Positioning by NC Glue scraping unit RCC-701 Polishing unit SP-501 Number of motors: 2 Motor power: 0.25 kW Spraying unit LPT-700 TECHNICAL DETAILS Panel height min: 10 mm Panel height max.: 60 mm Edge thickness min.: 0.4 mm Edge thickness max.: 22 mm MACHINE DETAILS Total connected load: 22 kW EQUIPMENT Feed pressure with rubber belt Panel support guides with NC positioning CE marking The machine is sold and delivered as is (“as seen and approved”) based on photographic documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods prior to collection and assumes responsibility for installation, securing, and use of the machine at the place of destination. External reference: 7673

Condition: not inspected (used), Year of construction: 2000, functionality: unexamined, travel distance X-axis: 5,900 mm, travel distance Y-axis: 1,560 mm, feed rate X-axis: 80 m/min, feed rate Y-axis: 60 m/min, rotational speed (max.): 20,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis working area: 5,900 mm Y-axis working area: 1,560 mm X-axis travel speed: 80 m/min Y-axis travel speed: 60 m/min Z-axis travel speed: 25 m/min Drilling spindles Vertical drilling spindles: 20 Horizontal drilling spindles in X-direction: 6 Horizontal drilling spindles in Y-direction: 2 Total number of vertical and horizontal spindles: 28 Milling spindles Number of controlled axes: 4 Motor power: 10 kW Spindle speed: 20,000 rpm Tool changer Number of positions: 10 Tool: head-mounted MACHINE DETAILS Total installed power: 24 kW Control system: WINDOWS Machine programming software: WRT EQUIPMENT Work table with suction cups Number of suction bar rows: 10 Suction cups for securing the workpiece Vacuum pump The machine is sold and delivered in its actual and legal condition ('as seen and approved') on the basis of photographic documentation and descriptive technical/commercial documents. The buyer is entitled to inspect the item before collection and is responsible for installation, securing and use of the machine at the final destination. External reference: 8173 Dkjdpfx Ajyxm Sweg Dek

Condition: used, machine/vehicle number: 008437, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt, PUR Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 12 m/min Dodsyng Agepfx Ag Djkk Maximum panel thickness: 60 mm Operating Units: 7 nr

Condition: used, machine/vehicle number: 008470, X axis working area: 4300 mm Y axis working area: 2205 mm Working Table: Flat table Main Electrospindle power: 13 KW Dkedpfoyzyrvex Ag Dok Number of controlled axes: 5 axes Total number of drilling spindles: 46 Total number of tool changer positions: 22

Condition: used, machine/vehicle number: 008438, Max. panel width: 4500 mm Max. panel length: 4500 mm Dsdpfx Aeyngy Ssg Dekk Main saw blade projection: 60 mm No of Grippers: 8

Condition: used, machine/vehicle number: 007805, Max. panel width: 3200 mm Max. panel length: 1200 mm No of Bottom Units: 6 No of Top Units: 4 Positioning of Units by NC: yes Lateral horizontal groups: yes Dodpfx Aox A E Sujg Dskk

Condition: good (used), Code: 0318 Brand: BIESSE Model: F 39 E - CE Standard Electronic multiple boring machine with 39 spindles for furniture, carpentry, custom-made furnishings, panels, kitchens, bathroom furniture, doors,window frames, and various - CE Standard Dkedpfx Aeyrgcbeg Dsk Suitable for horizontal and vertical drilling, any intermediate drilling between 0 and 90° can be performed thanks to a gear motor and handwheel. Electronic control Technical data: N° 39 spindles Spindle rotation speed 4000 rpm Center distance between spindles 32 mm Max drilling center distance 1216 mm Drilling depth 65 mm Drilling head motor power 2,3 + 2,3 Hp Air operating pressure 6 bar Installed electrical power 4,1 Kw Overall dimensions mm 1800 x 1140 x 1600 h Weight kg 700

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, power: 67 kW (91.09 HP), input voltage: 400 V, input frequency: 50 Hz, workpiece length (max.): 3,100 mm, workpiece width (max.): 2,205 mm, workpiece height (max.): 170 mm, Equipment: documentation/manual, ROVER A FT 2231 Dodpfoyzxyrsx Ag Dokk

Condition: used, Year of construction: 2014, Empty weight: 4.000 kg Price: On request - Machine available from: 2026-01-26 - Year: 2014 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 89867 - Number of milling spindles [pcs.]: 1 - Type milling table: Flat table - Tool clamping system: HSK-F63 - Drilling unit present: Yes - Saw unit present: Yes - Tool changer positions [pcs.]: 12 - System/software: BiesseWorks Dedpexr Evlsfx Ag Dokk - Safety feature: Safety mat - CNC options: Label machine, Loading system, Unloading system - Table length [mm]: 3600 - Table width [mm]: 1800 - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2012, total height: 2,400 mm, total length: 13,500 mm, total width: 2,450 mm, Empty weight: 2.500 kg Biesse Rover A1536 G FR Year 2012 Central lubrifaction FT work table, X 3765 Y 1560, 9 zones 12 kW electro spindle, ISO 30, air cooled Biesse WORKS Biesse NEST MODULE Dodewnip Dopfx Ag Dekk Air conditioner 16 pos. revolver magazine Work area XYZ 3765*1585*170 2x vacu pump 250 m³ C axis 360° BH 17 L drilling group Including loading and unloading system - Year: 2012 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 81399 - Type milling table: Flat table - Drilling unit present: Yes - └ Horizontal drill spindles [pcs.]: 4 - └ Vertical drilling spindles [pcs.]: 7 - Saw unit present: Yes - Tool changer positions [pcs.]: 16 - Vacuum pump present: Yes - └ Number [pcs.]: 2 - └ Brand: Becker - └ Capacity [m³/h]: 250 - Working range X [mm]: 3765 - Working range Y [mm]: 1585 - Z-axis working range [mm]: 170 - Transport dimensions: 13500mm x 2450mm x 2400mm (l x w x h) - Transport weight [kg]: 2500kg - Transport packages [pcs.]: 4 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets
