Akira Seiki RMV 700 APC

Akira Seiki RMV 700 APC

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, total height: 2,600 mm, total length: 3,300 mm, total width: 2,000 mm, overall weight: 5,600 kg, spindle speed (max.): 12,000 rpm, number of spindles: 1, Equipment: chip conveyor, documentation/manual, Here is an offer for a vertical machining center from the manufacturer Akira Seiki with a dual-pallet changer. The machine is in good condition and can be inspected and tested at any time. Manufacturer: Akira Seiki Type: RMV700APC Year of manufacture: 2016 Control: Akira Mi745 - Mitsubishi Technical data: Travel ranges X-Y-Z: 700x400x400 mm Table/pallet: 700x400 mm Number of pallets: 2 (APC) Max. table load: 160 kg Spindle nose to table: 200–600 mm Spindle speed: 12,000 rpm Rapid traverse rate X: 48 m/min Rapid traverse rate Y: 60 m/min Rapid traverse rate Z: 72 m/min Cutting feed rate: 10 m/min Tool magazine: 24 + 1 Spindle taper: HSK63 Max. tool diameter: 75 mm Max. tool length: 200 mm Max. tool weight: 4.5 kg Tool change time (T–T): 1.9 s Chip-to-chip time: 3.4 s Positioning accuracy: 0.012 mm Repeatability: ±0.005 mm Coolant tank: 150 l Power consumption: 25 kVA Nedpezwvqksfx Akiewn Compressed air: 0.5 MPa Machine weight approx.: 5,600 kg Footprint according to manufacturer: 1,900 × 3,144 mm

Year of construction: 1987, condition: ready for operation (used), An old Schumag Aachen drawing machine without control is available. Drawing force: 100kN, drawing speed: 80m/min, material diameter range: 25mm-43mm. On-site inspection is possible. Nsdpjv Tctusfx Akiown

Condition: used, Year of construction: 2001, Technical details: max. wheel diameter: 280 mm Nsdpfx Akewh Dlmsiewn max. module: 5 min. module: 1 min. number of teeth: 7 toolpiece turning speed range: 4.000...10.000 U/min tool length: 210 mm CBN *

Condition: reconditioned (used), Year of construction: 2001, functionality: fully functional, input voltage: 400 V, year of last overhaul: 2023, Description – General: Year of manufacture: 2001/2023 Manufacturer: Emag Machine type: VL3 Technical data: Control system: Fanuc 21i-T Swinging diameter: approx. 210 mm Maximum speed: 6,500 rpm Turret: VDI 40 mm, 12 stations The machine does not have a live tool. Hinged belt chip conveyor Spindle mount: GR. 5 Rotating parts conveyor. Machine weight: approx. 5.5 t The following work was carried out during this overhaul in 2023: - The machine was completely disassembled, cleaned, and repainted. - The main spindle was fitted with new bearings. - The guides and guide shoes in the X-axis and Z-axis were replaced. - The ball screw in the X-axis and Z-axis was replaced. - New unit for central lubrication and new hoses. - The hydraulic unit was inspected and serviced. The drive coupling between the motor and pump was replaced. - The cooling unit was inspected and serviced; the temperature difference controller was replaced. - The clamping cylinder was fitted with new bearings and seals. - The gearbox of the A-axis was fitted with new bearings, and the coupling between the motor and gearbox was replaced. - The electrical cabinet was cleaned. - The control panel was replaced. - New screen. - New internal lighting. - The turret was disassembled, wear parts were inspected, cleaned, and re-sealed. - The turret encoder and encoder wheel were cleaned. Nwsdpfxjtpu Szj Akion - The length measuring systems in the X-axis and Z-axis were disassembled and cleaned. - The springs of the pickup station were replaced. - The motors of the X-axis and Z-axis were checked for bearing damage. - The panes on the work door were replaced. - The chip conveyor was completely disassembled, fitted with new bearings, cleaned, and painted. - Various small parts on the machine were also replaced, of course. The product has been described by us with the utmost care. The description is non-binding and should be verified during an inspection.

Condition: good (used), functionality: fully functional, Equipment: chip conveyor, documentation/manual, For sale used Mori Seiki NHX5000 horizontal machining centre in excellent condition. Njdeuf S Rzspfx Akiewn Model: NHX-5000/40 Year: 2012 The machine is available on site by prior arrangement. Delivery parity: EXW Székesfehérvár. We can assist in disassembling and assembling the machine on request.

Condition: ready for operation (used), Year of construction: 2023, A Mitutoyo CNC bridge coordinate measuring machine is available. Travel X/Y/Z: 1200mm/2000mm/1000mm, measuring volume: 2.4m³, max. workpiece weight: 2500kg, max. workpiece height: 1000mm, probe system: Renishaw, probe positions: 20, measuring accuracy: 2.3+/-0.3/100µm, max. travel speed: 693mm/s. Machine dimensions X/Y/Z: approx. 3400mm/2200mm/3600mm, weight: approx. 6150kg, control: Mcosmos-3 V4.3. Documentation available. An on-site inspection is possible. Nodpfx Aozhnrbskijwn

Condition: used, Year of construction: 2013, x-travel 30000 mm y-travel 3600 mm z-travel 1900 mm Control Heidenhain type TNC 530 i turning speeds 4000 U/min conus taper DIN 69871+AD mm Feed 10000 mm/min spindle drive 46 kW Rapid movement 25000 mm/min chip conveyor 2 St. Plate area 31000x2500 mm total power requirement 85 kW Soraluce Nedpfeyqtnnox Akiown No. 5619 Load hours 9332 On-time hours 27960 Panel array consists of: 1 panel 7000x2500 mm 4 panels 6000x2500 mm Optional: 4x clamping angles Tool package Clamping table The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, functionality: fully functional, machine/vehicle number: E1X359200040, Year of construction: 2009, operating hours: 8,800 h, load capacity: 16,000 kg, lifting height: 5,000 mm, free lift: 2,500 mm, fuel type: diesel, mast type: duplex, construction height: 4,160 mm, power: 142 kW (193.07 HP), fork carriage width: 2,540 mm, fork length: 2,700 mm, empty load weight: 25,920 kg, drive type: Diesel, Heavy-duty forklift – diesel Chassis number: E1X359200040 Load centre: 1200 Fork width: 280 mm Fork thickness: 90 mm Mast type: Duplex Transmission: Hydrostatic Condition: Ready for operation and fully functional Technical condition: Good Front tyres type: Superelastic Front tyres size: 12.00-24 Front tyres condition: 40 – 60% Rear tyres type: Superelastic Rear tyres size: 12.00-24 Rear tyres condition: 20 – 40% Njdpjxybduefx Akiown Description: Camera, central lubrication Sideshift, fork positioner, 4th valve, full cabin,

Condition: ready for operation (used), Year of construction: 1998, Offered is a horizontal machining center (HMC). Travels X/Y/Z: 560mm/510mm/510mm, max. dynamics: 40000mm/min, spindle: 12000rpm, tool holder: MAS BT 40, tool magazine: 60 positions (chain magazine), pallet system: 2-station pallet changer, pallet size X/Y: 400mm/400mm, accessories: approx. 200 tool holders (BT 40), 2 MMI towers with 8 clamping bars, hinged belt chip conveyor, Blum laser/probe, Renishaw 3D probe, machine weight: approx. 9000kg. Inspection possible by appointment. Njdpfoyzh A Nex Akijwn

Condition: used, Year of construction: 2005, Mikron UCP1350 Available immediately! Travel: X-axis: 1,350 mm, Y-axis: 1,150 mm, Z-axis: 895 mm A-axis: degrees NC rotary table: 1.100 x 1.000 mm max. table load: 1.600 kg Spindle mount: HSK-A63 tool magazine: 60 seats Nwjdpfezycl Hox Akien Spindle speed: 15.000 U/min Control: Heidenhain iTNC530 Internal coolant supply (IKZ): 40 bar
