Mi.Mu di Musumeci & C

Condition: refurbished (used), Centerless grinding machine ROSSI MONZA 410 Monzesi Ppjlhcjwf Rqdedw Dsr Grinding wheel width 200mm Grinding wheel diameter 400 pneumatic compensation auto plunge overhaul - retrofit - PLC under power in our warehouse in Gussago BS (Italy) Centerless grinding is a procedure for grinding cylindrical bodies and is used for the mass production of rollers cylinders, tapered rollers, jet needles, pump pistons, hydraulic sliders, crosses, tips, etc. During centerless plunge grinding (plunge grinding), the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, grinding wheels and setting discs have a negative workpiece profile to work which is given to them with the aid of a tool. Centerless through-feed grinding or through-feed grinding and longitudinal grinding: workpieces to be machined proceed continuously with axial feed through the grinding gap. Grinding wheel width: 200 Grinding wheel diameter: 400

Condition: used, CNC Lathe - twin turret - subspindle Y axis NAKAMURA WT 250 CNC Fanuc, Series 16i-T Pslhcdswaa Diew Djpr Spindle - sub spindle 1 turret live tools + Y axis 1 turret live tools (lower) 2x C-Axis Swarf conveyor IEMCA TS560P Bar loader Under power in our in our warehouse in Gussago BS. Mimu machine tools Italy

Condition: used, Favretto 500 Rotary table surface grinding machine, horizontal spindle Ppolhsv Icmkocdw Dsr dia 500mm electric elettrico with DRO

Condition: refurbished (used), Thread rolling machine ORT RP18 B 2-roll overhauled See video The machine is in our warehouse in Gussago BS, under power Test run possible Mimu Machine Tools Italy Power (Ton): 18 Pjlhcdwevxa Dbs Depr Number of rollers: 2

Condition: used, Monzesi Rossi Monza 500 centerless grinding Grinding wheel 250 * 500 Recent Electric retrofit The machine is in our warehouse in Gussago BS, under power M i m u machine tools Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass Ppelsvxagcehcdw Dor thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is given to them with the aid of a tool. The through-feed grinding or also through grinding and longitudinal grinding: pieces to be worked proceed uninterruptedly with axial feed through the rectification axial advancement through the grinding gap.

Condition: refurbished (used), Single pass - progressive honing machine SUNNEN MHS 840 (like VSS 84) overhaul and electronic retrofit (see video and photos) 4 heads, 8-station rotary table This machine can be inspected under power in our warehouse Test run possible M i m u Machine Tools Gussago BS Italy Pelhcovw Ddvsdw Dopr Single-pass honing is a type of honing process used for finishing internal cylindrical surfaces, where a tool with a fixed set of abrasive stones passes through the bore only once to achieve the desired surface finish and dimensional accuracy. In this process, the tool is typically designed with a specific shape and size, allowing for precise material removal in a single stroke

Condition: used, Centerless grinding machine Pjlhcdouyuvfew Djpr ROSSI MONZA 400 Grinding wheel width 200mm Grinding wheel diameter 400 pneumatic compensation under power in our warehouse in Gussago BS (Italy) Centerless grinding is a procedure for grinding cylindrical bodies and is used for the mass production of rollers cylinders, tapered rollers, jet needles, pump pistons, hydraulic sliders, crosses, tips, etc. During centerless plunge grinding (plunge grinding), the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, grinding wheels and setting discs have a negative workpiece profile to work which is given to them with the aid of a tool. Centerless through-feed grinding or through-feed grinding and longitudinal grinding: workpieces to be machined proceed continuously with axial feed through the grinding gap. Grinding wheel width: 200 Grinding wheel diameter: 400

Condition: refurbished (used), Year of construction: 2009, ORT RP30 MS 2-roll 30 tons thread rolling, knurling, small gears 2009 = YOM Electronic overhaul and electronic retrofit with Siemens PLC (2025) The machine is visible working in our warehouse in Gussago BS. Possibility of proof M i m u Machine Tools Ppolsuykz Djhcdw Djr Power (Ton): 30 Number of rollers: 2 PLC: Yes

Condition: used, Chiron FZ15KS 4 axis vertical machining center X: 550mm Y: 400 mm Z: 360 mm Original Peiseler 4th axis Siemens 840D CNC Table surface 1050 x 450 mm Tool change 48 post ISO 40 Spindle speed up to 12000 rpm with the 4th axis Renishaw broken tool detector Coolant through the spindle chip conveyor Pslhcsuyhy Djdw Djpr

Condition: used, ORT RP18B overhauled Ppolhcdjuua H Row Dsr

Condition: used, Sunnen EC3500 honing machine holes: 1,5 to 165mm dia. spindle motor 5.5HP auto stone compensation ASC auto sizing available as option More pics available Under power in our warehouse. Test run possible. Pjlhcourywkjdw Dopr Mimu Machine Tools (Italy) Sunnen EC3500 ml5000 ml3500 ml2000

Condition: used, Ex-Cell-O XG620 Excello XG 620 Siemens CNC overhauled 2011 docs available Polhsurt Tlecdw Depr ball groove milling for constant velocity joints This machine can be inspected in our warehouse in Gussago BS Italy (Milan Area)

Condition: used, Vertical machining center Pslhcdwoumma Ie Djpr CHIRON FZ08KW 2 pallet 15000 RPM HSK40A CNC Fanuc 21iM The machine is visible in our warehouse in Gussago BS. M i m u Machine Tools Gussago BS Italy The machining center is a machine tool equipped with a numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same work piece. It is generally equipped with several motion axles and one automatic tool exchange system and sometimes multiple pallets

Condition: used, Cylindrincal grinding machine KNUTH RSM 750 interna/external DRO This machine can be inspected under power in our warehouse. Mimu Machine Tools Pelhcdwsul Akgj Djpr Gussago BS Italy

Condition: used, Star KJR 25 swiss type lathe Pelhcdeud D Ddsw Depr low price

Condition: used, CNC lathe Daewoo Lynx 200 B CNC Fanuc 21t Ppslhcdwst Ip Uke Dor 10 tool turret tailstock bar feeder The machine can be seen under power in our warehouse (M i m u)

Condition: used, Thread rolling machine ORT RP30U Ppolhst H Ty Uscdw Der 2-roll 30 ton swiveling heads variable speed drive #1331 Under power in our warehouse in Gussago BS. Test run possible M i m u Machine Tools Italy Rolling is a mechanical process without chip removal that can be performed cold or hot, having as a purpose the improvement of the surface finish (therefore the fatigue behavior

Condition: used, Year of construction: 2003, Thread rolling machine ESCOFIER H20Z Psljt Hmv Njhcdw Djpr 2-roll 2 moving heads (in sync) 2 - 20 Ton rolling pressure workpiece diameter: 75mm max. tool diameter: 140-200 mm Max plunge width 160 mm Shafts dia: 69.95 Swivelling: +/-6°, New: 2003 under power in our warehouse, M i M u machine tools

Condition: used, Year of construction: 2004, CNC Thread rolling and gear burnishing machine ESCOFIER P440 CN CNC Siemens Ppjlst Ek Sfohcdw Djr New 2004 - like new 2-roll 2 moving heads 4000 daN rolling pressure workpiece diameter: 100mm max. tool diameter: 180-245mm Swivelling: +/-6°, forward speed: 0.1-20mm/s, reverse speed: 0.1-30mm/s motor power: 8.6kW New: 2004 Condition: like new under power in our warehouse Mimu Machine Tools (Italy)

Condition: used, Horizontal machining center, 6 pallets Priced to sell - dismantled and loaded into truck OKUMA MA40 HA 6P OSP U100M CNC 6 pallets 400mm x 400mm max 400 kgs max workpiece dimensions 600*710 Spindle BT40 / coolant through the spindle 4th axis 1° Tool changer: 100 pos. X = 560mm, Y = 610mm, Z = 560mm 40 m/min under power Mimu Machine Tools (Italy) Ppjlhcdot Ek Slow Dsr X: 560 pallet: 6 Pallet size: 400*400

Condition: used, Thread rolling machine ORT RP18 2-roll Spindles diameter 69.95mm Ppslhjt Apugocdw Dor See video The machine is in our warehouse in Gussago BS, under power Test run possible Mimu Machine Tools Italy

Condition: used, Vertical machining center Daewoo (Doosan) ACE VC500 The machine can be seen working in our warehouse in Gussago BS. Mimu Machine Tools Gussago BS Italy Vertical machining center - 2-pallet Daewoo ACE VC500 CNC Model Fanuc CNC version 18-M Spindle Taper toolholders iso 40 Power spindle 15 Kw RPM 10000 Number of tools 30 X-axis travel 760 mm Y-axis travel 510 mm Z-axis travel 570 mm Changer pallet yes Pallet dimensions 860x560 mm Ppjlhcjtzgaqsdw Der Maximum load allowed 300 Kg Swing type pallet yes High coolant pressure yes Cheap conveyor yes Brand Daewoo Model ACE VC500 Construction year 2000 DIMENSIONS AND WEIGHT Length 3600 mm Width 3700 mm Height 2935 mm Weight 9200 Kg The machining center is a machine tool equipped with numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same work piece. It is generally equipped with multiple axes of motion and a automatic tool exchange system and sometimes multiple pallets

Condition: used, X axis: 610 Pelhcdjtrbb Ejw Depr Y axis: 510 Z axis: 410 CNC type: Fanuc Spindle revolutions: 6000 Vertical machining center LEADWELL MCV 610 CR CNC Fanuc 0M X 610 Y 510 Z 410 6000RPM ISO 40 The machine is in our warehouse in Gussago BS, under power Mimu Machine Tools Gussago BS Italy The machining center is a machine tool equipped with numerical control capable of performing multiple mechanical operations with a single set-up on multiple surfaces of the same work piece. It is generally equipped with multiple axes of motion and a automatic tool exchange system and sometimes multiple pallets

Condition: used, CNC lathe Graziano GT 300 Y Gital Gildemeister CNC Fanuc 16i - T ASA 5 Main spindle power 15 Kw Self-centering diameter 175 mm ASA 5 spindle connection Bar passage 52 mm Turning diameter 230 mm Turning length 500 mm Number of revolutions 5000 Number Tool holder turrets1 Number of tool places first turret 12 Number of motorized first turret 12 First turret tool attachment typeVDI 30 X Axis Travel 160 mm Y Axis travel + - 32 mm Z Axis travel 550 mm Linear axis rapid feeds X Y Z30 m/min Counter spindle yes ASA 5 spindle nose Number of counter spindle revolutions 5000 Power sub spindle 9 Kw Spindle Hole 30 mm Model and brand of bar loader LNS single bar tube Belt chip conveyor Presetting yes 2000 The machine can be seen under power in our warehouse in Gussago BS. Mimu machine tools Pelhcoqn E U Tjdw Dspr

Condition: used, CNC bar lathe Gildemeister CTX 300 with Y axis Fanuc CNC model 16i - T Main spindle nose ASA 6 Main spindle power 12 Kw Main spindle hole 60 mm Turning diameter 230 mm Turning length 500 mm Number of RPM main spindle 5000 Number of tool holder turrets 1 Number of tools 12 Number of live tools 12 tool attachment type VDI 30 X-axis travel 160 mm Y axis travel + - 32 mm Z axis travel 500 mm Rapid feeds X Y Z 24 m/min Sub-spindle yes ASA 5 spindle nose Sub-spindle RPM 5000 / 9 Kw Sub-spindle hole 30 mm Iemca bar loader Swarf conveyor 2002 The machine can be seen working in our warehouse in Gussago BS. Ppjlhcoqh Rpnsdw Dor
